This paper presents an enhanced bipolar control strategy for 400 Hz three-phase inverters in aviation ground power supplies, with a focus on maintaining symmetry in power output under unbalanced load conditions. The strategy integrates Linear Active Disturbance Rejection Control (LADRC) for robust positive sequence voltage regulation, Proportional Integral with repetitive control (PI + RC) for harmonic suppression in positive sequence currents, and a Quasi-Proportional Resonance (QPR) controller for negative sequence components in the static coordinate system. By doing so, it simplifies negative sequence control and combines PI + RC to improve the dynamic response and eliminate periodic errors. In the context of symmetry, the proposed strategy effectively reduces the total harmonic distortion (THD) and the three-phase current imbalance degree. Simulation results show significant improvements: under balanced loads, THD is reduced by 41.5% (from 1.95% to 1.14%) compared to traditional PI control; under single-phase and three-phase unbalanced loads, THD decreases by 52.7% (2.56% to 1.21%) and 48.1% (2.39% to 1.24%), respectively. The system’s settling time during load transients is shortened by over 30%, and the three-phase current imbalance degree is reduced by 60–70%, which validates the strategy’s effectiveness in enhancing power quality and system stability, thus restoring and maintaining the symmetry of the power output. Full article

This paper focuses on the development and experimental validation of a single-phase modular multilevel converter (MMC) based on a battery energy storage system (BESS) for residential uninterruptible power supply (UPS) with two-level active SoC balancing control. The configuration and mathematical modeling of the single-phase MMC-BESS are first presented, followed by the details of the control strategies, including dual-loop output voltage and current control in islanded mode, grid-connected control, circulating current control, and two-level active state-of-charge (SoC) balancing control. The design and optimization of the quasi-proportional-resonant (QPR) controllers were investigated by using particle swarm optimization (PSO). Simulation models were built to explore the operating characteristics of the UPS under islanded mode with an RL load and grid-connected mode and assess the control performance. A 500 W experimental prototype was developed and is herein presented, including results under different operating conditions of the MMC-BESS. The experimental results show that for both RL load and grid-connected tests, balancing was achieved. The response time to track the reference value was two grid periods (0.04 s). In the islanded mode test, the THD was 1.37% and 4.59% for the voltage and current, respectively, while in the grid-connected mode test, these values were 1.72% and 4.24% for voltage and current, respectively. Full article

To enhance the speed-control performance of a permanent magnet synchronous motor (PMSM) drive system, an improved sliding-mode anti-interference control strategy is presented. Firstly, to tackle the speed fluctuation issue caused by cogging torque (a periodic disturbance) and time-varying disturbances at low set speeds in PMSM, an improved sliding-mode control (ISMC) is proposed. It consists of a continuous adaptive fast terminal sliding-mode surface (CAFTSMS) and a new reaching law (NRL). The CAFTSMS boosts the system’s immunity to interference, while the NRL, improved via an adaptive function, enhances the fast transient response and notably reduces speed fluctuations. Secondly, a quasi-proportional resonant (QPR) controller is introduced. It suppresses specific-order system harmonics, significantly reducing the harmonic amplitude and strengthening the system’s ability to handle periodic disturbances. Finally, a cascaded extended state observer (CESO) with a special cascade structure is proposed to solve the observation-delay problem in the traditional cascade structure. Experimental results show that the proposed sliding-mode anti-disturbance control strategy performs excellently in overcoming disturbances. Full article

The output voltage of inverters is influenced by nonlinear factors such as dead time and voltage drops, injecting low-order harmonics. This results in fifth and seventh harmonic distortions in the stator current, causing periodic torque ripples and significantly affecting the control precision of Permanent Magnet Synchronous Motors (PMSMs). To address this issue, this paper proposes a control strategy named quasi-proportional-resonant sliding mode control (QPR-SMC). Initially, sliding mode control is employed as the current controller to enhance disturbance rejection capability and provide a rapid dynamic response. Subsequently, a quasi-proportional-resonant controller is introduced to extract the sixth harmonic component from the current, which is then used as a compensation term for the sliding mode control surface. Finally, the current tracking error and the compensation term are combined as inputs to the sliding mode control law, forming a current error-proportional resonant-sliding mode control surface. This approach enhances the harmonic suppression capability of the system. The results demonstrate that the proposed method effectively reduces the fifth and seventh harmonic components in the three-phase current and mitigates motor jitter by suppressing the sixth harmonic in the d–q coordinate system. Full article

In weak grid, feedforward of grid voltage control is widely used to effectively suppress grid-side current distortion of inverters caused by harmonics in point of common coupling (PCC) voltage. However, due to its introduction of a positive feedback loop related to the grid impedance, it results in a significant reduction in the system phase margin. In view of this, in this paper, the output impedance of a three-phase LCL grid-connected inverter under a quasi-proportional resonant (QPR) controller is first modeled. Instead of the traditional grid voltage feedforward control strategy, a band-pass filter is added to the grid voltage feedforward channel. Secondly, a multi-objective constraint method is proposed to make improvements to the feedforward function. Then, a multi-objective constraint function is established with the constraints of base-wave current tracking performance, system stability margin, and low-frequency amplitude, and the feasibility of its function optimization design method is verified. Theoretical analysis shows that the optimized grid voltage feedforward control strategy can effectively reshape the phase characteristics of the system output impedance, which greatly broadens the adaptation range of the system to the grid impedance. Finally, the effectiveness of the proposed control strategy is verified by building a semi-physical simulation experimental platform based on RT-LAB OP4510. Full article

A self-compensating control strategy for harmonic parameters based on the crown porcupine optimization algorithm is proposed for the single-phase rectifier and two-phase inverter operation mode of the bidirectional converter. In order to improve the response speed of the inverter voltage, the instantaneous expressions of the phase angle coefficient and amplitude coefficient of the dc-side voltage doubling fluctuation are derived, and the third harmonic is calculated based on the crown porcupine optimization algorithm according to the Proportional Integral (PI) + Quasi-Proportional Resonance (QPR) double closed-loop control method and injected into the input voltage of the inverter side to offset the influence of the bus-doubling fluctuation on the output voltage of the two-phase inverters of B and C so that the total harmonic content of the two-phase output voltages of the two-phase inverters of B and C can be reduced. The total harmonic content of the B and C inverter output voltages is reduced. The effective control of the control method for single-phase rectifier two-phase inverter mode is verified through simulation. Finally, the effectiveness of the control strategy is verified by experimenting with a 15 kW LCL-type bi-directional converter prototype. Full article

A grid-connected inverter (GCI) with LCL filters is widely used in photovoltaic grid-connected systems. While introducing active damping methods can improve the quality of grid-connected current (GCC), the influence of grid voltage disturbances can still significantly impact the quality of GCC, leading to stability degradation, especially in weak grid conditions. This paper proposes a grid-voltage-weighted feedforward control scheme based on the quasi-proportional resonance (QPR) controller. This scheme introduces compensatory terms with different proportional coefficients in the voltage feedforward, controlled by the QPR controller. Through a series of analyses, reasonable inverter parameters are first designed. Then, the proposed system model is built in Matlab Simulink. Through simulation experiments and comparisons with various types of operating conditions, the effectiveness of the proposed system scheme is validated. It minimizes the impact of grid voltage disturbances, suppresses the influence of grid harmonics on the control system, improves current quality, and enhances the stability of the GCI system. Full article

To reduce the influence of voltage harmonics on the grid current, a control strategy based on adaptive quasi-proportional phase compensated resonance (QPR_PC) is proposed. Firstly, the LCL grid-connected photovoltaic inverter system model is established, and the stability performance of the three-level inverter system under double closed-loop control is analyzed using the output impedance model of the inverter. Then, a QPR regulator for the zero steady-state error tracking of AC signals is studied. To solve the problem that the system has poor robustness against frequency changes when the traditional QPR regulator is used in the static coordinate system, this paper improves the traditional QPR regulator to optimize the response characteristics of the closed-loop system. Based on the QPR regulator, a phase margin compensation structure is introduced to form QPR_PC control. Then adaptive frequency design is added to ensure good control even when the power grid frequency drifts, which is the control strategy proposed in this paper. Verification shows that the proposed method improves the phase margin of output impedance at a specific frequency, restrains the interference of the 3rd, 5th, and 7th harmonics of grid voltage, and improves the dynamic performance of the system and the quality of grid-connected current. Finally, the simulation results show that the total harmonic distortion rate of grid-connected current is reduced by 1.03% after adopting this strategy, which verifies the effectiveness and correctness of the proposed method. Full article

According to the inherent characteristics of the hydraulic power take-off (PTO) system, the output power of a generator tends to be intermittent when the wave is random. Therefore, this paper aims to improve the effective utilization of wave energy and reduce power intermittency by constructing a topology with two branches to transmit electrical energy. Firstly, the wave-to-wire (W2W) model of the system is constructed. Secondly, the W2W model is simulated by using synovial and quasi-proportional resonance (QPR) control with regular and irregular incident waves, and the results of PI control are compared. Then, the control strategy in simulation is verified by experiments. The simulation and experimental results show that the control strategy has better performance, and the stability of the system output power is greatly improved. Full article

In order to effectively improve the power quality and utilize railway regenerative braking energy in high-speed railway traction power supply system, this paper adopts the Modular Multilevel Converter type Railway Power Conditioner (MMC-RPC) with distributed super-capacitor (SC) energy storage (ES) scheme. Firstly, the single-phase MMC mathematical model is established, and the power compensation characteristics of MMC-RPC are derived. Secondly, the Virtual Synchronous Generator (VSG) control strategy is adopted to provide inertial support. Compared with the double closed loop (DCL) control, it has better anti-disturbance and dynamic performance. Then, based on the VSG control, a two-stage circulating current suppression strategy is proposed, in which Quasi-Proportional Complex Integral (QPCI) control is used to suppress the bridge arm circulating current, and integrated Proportional Integral-Quasi Proportional Resonant (PI-QPR) control is an improvement of the VSG control to further suppress the circulating current inside the VSG. Furthermore, the virtual DC motor (VDCM) strategy was proposed to control the charge and discharge of the distributed SC connected to MMC-RPC to recycle railway braking energy. Finally, simulation results of the VSG small signal model and the MMC-RPC simulation model on the Matlab/Simulink platform verify the effectiveness, stability of VDCM and improved VSG controls in the MMC-RPC. Full article
