Triaxial induction logging is particularly outstanding in identifying reservoir parameters including anisotropic strata, inclined boreholes and horizontal wells. However, the coplanar systems follow the traditional induction method of using a shielding coil to offset the direct coupling. This method results in severe horns in the coplanar coil response, which makes it more difficult to evaluate the water (oil) saturation of the reservoir. In this study, we used an analytic method to derive the magnetic field in a finite-thickness anisotropic medium by applying tangential continuity of the electric and magnetic field strengths, introducing the magnetic vector potential and Bessel functions. The response model influenced by different parameters was established. Under the same environmental parameters, the measurement range of the vertical and horizontal conductivities was larger than that of the traditional coplanar system. The apparent conductivity of the target layer was closer to the true value of the vertical conductivity in the layered strata, with an accuracy improvement of 78.9%. Furthermore, the improved coplanar system mechanism was revealed by analyzing the spatial distributions of eddy currents and the magnitudes of the magnetic fields generated. Finally, we designed an experimental device for a coplanar sensing system. Under the same parameters, the received signals of the improved coplanar system were greater than those of the traditional coplanar system in the air, which laid a foundation for the quantitative evaluation of stratigraphic anisotropy response characterization and inversion. Full article

Due to the weak electrical response characteristics of groundwater nitrate contamination, traditional monitoring and remediation assessment methods are limited by low spatiotemporal resolution, high cost, and strong subjectivity. To address this issue, this study proposed an integrated technical framework combining field detection, laboratory-controlled experiments, and remediation process monitoring, aiming to explore the application potential of Electrical Resistivity Tomography (ERT) in nitrate pollution monitoring and remediation evaluation. First, ERT survey lines (L1 and L2) were deployed at a chemical-contaminated site in Luzhou, Sichuan Province, and groundwater samples were collected. Coupled with hydrochemical analysis, the feasibility of ERT for identifying nitrate plumes was verified. Second, a quantitative response model between nitrate concentration and resistivity was established through Miller box experiments, and a multi-line layout was optimized via sand tank experiments to mitigate boundary effects and improve monitoring accuracy. Finally, grouped sand tank experiments involving electroactive bacteria (EAB) and magnetite were conducted. Combined with 16S rRNA sequencing, the coupling mechanism between ERT electrical responses and biogeochemical processes was elucidated. The results showed that the low-resistivity anomaly zones identified by field ERT were accurately consistent with the high-nitrate contamination zones, and Piper diagrams confirmed that nitrate-related ions were the primary cause of the low-resistivity anomalies. The power function quantitative model established by the Miller box experiment (y = 1021.97x^−0.74, R² = 0.9589) enabled the indirect inversion of nitrate concentrations, with a small deviation between theoretical and measured values in the deep layer (16–18 m). The optimized layout of one main and three auxiliary survey lines effectively characterized the spatiotemporal migration of the contamination plume. Under high-water level conditions, the ternary system of nitrate–magnetite–EAB exhibited the strongest low-resistivity response. Microbial analysis indicated that electroactive groups (e.g., Pseudomonas and Flavobacterium) enriched in the EAB group were the core drivers of enhanced electrical conductivity. The integrated ERT monitoring technology system constructed in this study realizes the visual identification of nitrate plumes and dynamic tracking of remediation processes, providing technical support for the precise monitoring and in situ remediation of nitrate contamination in agricultural non-point sources and industrial sites. Full article

Coal mine goaf detection remains confronted with the lack of fast, effective and low-cost exploration means, especially for the accurate prediction of mining threats primarily caused by hydraulic infiltration. The rapid popularization of passive electromagnetic methods has contributed greatly to improving the interpretation effects of different types of goafs. This paper, firstly, summarizes the pros and cons of various exploration methods in goaf detection. Then, the feasibility of goaf detection using novel passive electromagnetic methods (e.g., the super low frequency alternating magnetic component method (SLF) and audio frequency magnetotelluric method (AMT)) is proposed and further discussed. With well-designed geo-electrical goaf models, the theoretical results demonstrate that the semi-quantitative interpretation of SLF responses can be directly used for the delineation of the target layer in the estimated depth range. In contrast, 3D inversion provides more information about conductive targets with the appropriate initial model selection. Then, shallow, low-resistive targets can be more accurately allocated in the inversion maps. Moreover, the real data interpretation results from study areas demonstrate that the SLF method can utilize the magnetic component responses to effectively identify the fault structures, and indirectly contributes to judge the goaf collapse locations in favor of describing the potential distribution of fracture water infiltration. Combined with the three-dimensional (3D) resistivity inversion of AMT data, the low-resistive water-rich areas within the depth of 400 m were revealed. The inverted depth distributions are basically consistent with those of the water-filled goafs and surrounding layers, which were also confirmed by known logging data. The detailed delineations of water-control fracture zones can be inferred to relate to aquifers in some mining areas; this can reveal potential collapses that require successive mining planning. In specific working faces, goaf risks have been handled in advance by strengthening the continuous monitoring of the water level and water inflow. The above verification has laid a theoretical and practical foundation for passive electromagnetic interpretation methods for effectively predicting collapse-type risks or hydraulic threats in coal mine goafs. Full article

Plant communities and their environments are a vital part of synecology research. In this study, we investigated the characteristics of three typical medicinal perennial herbs, Glycyrrhiza uralensis, Rheum altaicum, and Ferula sinkiangensis, and examined their response to local soil properties in Altay Prefecture, China. A total of 29 species belonging to 15 families and 25 genera were recorded. In terms of the target medicinal plants, the importance value was low and community structures were exceedingly simple. Quantitative classification based on WARD cluster analysis suggested that each medicinal plant can be classified into one of three types: annual herbaceous, perennial herbaceous, and subshrub or shrub. Interestingly, the plants gradually transformed from exhibiting nonresistance to xerophytes or halophytes. An investigation of the soil properties beneath the medicinal plants showed that nutrients in black soil were much more abundant than those in sandy and saline soil. Except for leaching phenomenon, the nutrient contents in the soil surface layer (0–10 cm) were higher than those in deep layers (10–20 cm and 20–40 cm), and to some extent, the nutrient contents were inversely proportional to the depth of the soil. The redundancy analysis (RDA) results of the medicinal plants and their relationship with soil properties indicated that the main soil variables impacting the distribution of G. uralensis were available potassium (AK), aspect (ASP), soil moisture (SM), total nitrogen (TN), and total phosphorus (TP); SM, electric conductivity (EC), elevation (ELE), ASP, pH value (pH), available nitrogen (AN), soil organic content (SOC), and the carbon/nitrogen (C/N) ratio had positive effects on the distribution of R. altaicum. F. sinkiangensis grew better in habitats with high contents of SM, EC, TN, AN, available phosphorus (AP), total potassium (TK), and AK. This study aimed at providing effective suggestions for artificial cultivation, conservation, and resilience of Chinese medicinal plants. Full article

This paper presents an assessment of the potential usefulness of the Ground Conductivity Meter (GCM) method to locate seepage pathways in the Maniow levee zone near Kraków, Poland. We have realized this aim through geological recognition of the study area, which requires the implementation of GCM data inversion measured in the sounding version. The GCM measurements were performed along with the net of profiles using combined data from CMD Mini Explorer and CMD Explorer equipment. The methodology of the one-dimensional (1D) inversion of the GCM soundings located along profiles is presented in the article. The legitimacy of the inversion and the relationship of the results obtained in the form of conductivity sections along profiles with geology have been verified in detail. The inversion procedures were tested on the synthetic GCM soundings obtained from modeling processes, by using the electrical conductivity and thicknesses, known from the drilled formations and additionally based on DC-R sounding data. These soundings were performed at some selected reference points in the levee zone. We have used our software and IX1D Interpex software to calculate the forward modeling. Quantitative interpretation processed along the profiles has been proceeded by 1D inversion of GCM data at several referential points located close to boreholes and DC soundings. It was done to verify the correctness of the quantitative interpretation. The geoelectrical models, obtained in a section form, were correlated with the borehole lithology data, providing a reference geological structure in some places. As a result of the work mentioned above, the potential seepage zones were located on the conductivity sections. The thickness of the cohesive silty clay layer, lying near to the surface, in the seepage zones, was thin enough and less than a meter. When the water level in the Vistula river was high enough, water can flow in the noncohesive gravel layer occurring directly below the silty clays and lead to flooding on the landward side of the dams in the Maniow region. Full article

Multi-coil electromagnetic induction (EMI) systems induce magnetic fields below and above the subsurface. The resulting magnetic field is measured at multiple coils increasingly separated from the transmitter in a rigid boom. This field relates to the subsurface apparent electrical conductivity (σ_a), and σ_a represents an average value for the depth range investigated with a specific coil separation and orientation. Multi-coil EMI data can be inverted to obtain layered bulk electrical conductivity models. However, above-ground stationary influences alter the signal and the inversion results can be unreliable. This study proposes an improved data processing chain, including EMI data calibration, conversion, and inversion. For the calibration of σ_a, three direct current resistivity techniques are compared: Electrical resistivity tomography with Dipole-Dipole and Schlumberger electrode arrays and vertical electrical soundings. All three methods obtained robust calibration results. The Dipole-Dipole-based calibration proved stable upon testing on different soil types. To further improve accuracy, we propose a non-linear exact EMI conversion to convert the magnetic field to σ_a. The complete processing workflow provides accurate and quantitative EMI data and the inversions reliable estimates of the intrinsic electrical conductivities. This improves the ability to combine EMI with, e.g., remote sensing, and the use of EMI for monitoring purposes. Full article
