Search Results (20)

Tracking control of a quadrotor–slung load system is extremely challenging due to its under-actuation property, couple effects, and various uncertainties. This work proposes a composite backstepping control framework combining command filter control and a multivariable finite-time disturbance observer to ensure robust position and orientation control for aerial payload transportation with high precision. Firstly, the kinematic and dynamic model under perturbations is derived based on Newton’s second law. The thrust control force consists of two orthogonal parts, each dedicated to regulating the position and orientation of the slung load independently. Then, hierarchical backstepping control generates the two parts in the load-translation and the load-orientation subsystems. Command filters are introduced into nonlinear backstepping to smoothen the control signals and overcome the problem of explosion of complexity. Additionally, to counteract the adverse effect of perturbations emerging in the linear velocity and angular velocity loops, multivariable finite-time observers are developed to ensure the estimation errors converge within a finite time horizon. Finally, comparative numerical simulation results validate the efficacy of the developed quadrotor–slung load tracking controller. Simulation results show that the proposed controller achieves smaller position tracking and orientation errors compared to traditional methods, demonstrating robust disturbance rejection and high-precision control. Full article

Cable suspension transport is a crucial method for quadrotors to transport goods and materials. During transportation, the quadrotor transport system (QTS) faces external disturbances and system uncertainties. Particularly, the underactuated nature of the system poses significant challenges to its stable operation. To solve these problems, this paper proposes a hierarchical control scheme that enhances coupling and leverages advantageous state-coupling to achieve precise positioning and eliminate payload swings for QTS. By leveraging the cascading characteristics of QTS, the design process is greatly simplified through the separate design of the torque input for the inner loop and the force input for the outer loop. Simulation results demonstrate the effective control performance of this method. Full article

During quadrotor load transport, the cable’s elasticity exacerbates load fluctuations, which may result in platform instability or a potential crash. This paper introduced a model of the connecting cable as a spring-damper system and established the dynamic model of the suspension system based on Newton’s law. Nonsingular fast terminal sliding mode control (NFTSMC) was employed for attitude, position, and anti-swing controller design. Adaptive controllers were integrated into altitude control to address uncertainties related to load mass and cable length. The inclusion of an anti-swing controller into the position control loop effectively dampens load oscillations while ensuring accurate position tracking. Numerical simulations demonstrated that the proposed controller outperforms both the energy-based controller and the conventional linear sliding mode controller. Full article

Nonlinear control theory applied to unmanned aeronautical vehicles is an engineering topic that has received higher and higher popularity during the last decade. Model-based control approaches have shown increased performance in flight control accuracy and robustness compared to model-free proposals based on parameter adaptation and estimation. However, model-based structures need more computational efforts in terms of spatial and temporal variables. To avoid these constraints, the latest drone flight controls are based on quaternion models, ensuring more advanced computational performances. To this aim, this paper deals with a flight control algorithm of a quadrotor, in which the mathematics model of the plant is defined in terms of quaternions. Additionally, when aerial vehicles are used in specific applications such as slung load transportation and agriculture fields, among others, the variation of the mass receives high importance since it could make the entire system unstable. In the same line of ideas, this paper presents a ${\mathcal{H}}_{\infty }$ strategy, combined with a Super-Twisting Sliding-Mode Control, ensuring the control objective of the mass variations identification, and trajectory tracking, to be solved. The stability analysis of the proposed control approach is also discussed, and the quality and performances of the presented control strategy are tested by simulations, in an interesting case in which mass variations and external perturbations cannot be negligible. Full article

In response to the non-linear and underactuated characteristics of quadrotor UAV suspension transportation system, this paper proposes a novel control strategy aimed at achieving precise position control, attitude control, and anti-swing capabilities. Firstly, a dynamical model required for controller design is established through the Newton-Euler method. In the controller design process, the paper employs the energy method and barrier Lyapunov function to design a double-closed-loop nonlinear controller. This controller is capable of not only accurately controlling the position and attitude angles of the quadrotor UAV suspension transportation system but also effectively suppressing the swing of the payload. Building on this, considering the elastic deformation of the lifting cable, and by analyzing the forces in the Newton-Euler equations, this paper proposes an adaptive control design for the case where the length of the cable connecting the UAV and the payload is unknown. To validate the effectiveness of the proposed control scheme, comparative experiments were conducted in the MATLAB simulation environment, and the results indicate that the method proposed in this paper exhibits superior control performance compared to traditional controllers. Full article

While using multirotor UAVs for transport of suspended payloads, there is a need for stability along the desired path, in addition to avoidance of any excessive payload oscillations, and a good level of precision in maintaining the desired path of the vehicle. However, due to the nonlinear and underactuated nature of the system, in addition to the presence of mismatched uncertainties, the development of a control system for this application poses an interesting research problem. This paper proposes a control architecture for a multirotor slung load system by integrating a Multi-Surface Sliding Mode Control, aided by a Radial Basis Function Neural Network, with a Deep Q-Network Reinforcement Learning agent. The former will be used to ensure asymptotic tracking stability, while the latter will be used to suppress payload oscillations. First, we will present the dynamics of a multirotor slung load system, represented here as a quadrotor with a single pendulum load suspended from it. We will then propose a control method in which a multi-surface sliding mode controller, based on an adaptive RBF Neural Network for trajectory tracking of the quadrotor, works in tandem with a Deep Q-Network Reinforcement Learning agent whose reward function aims to suppress the oscillations of the single pendulum slung load. Simulation results demonstrate the effectiveness and potential of the proposed approach in achieving precise and reliable control of multirotor slung load systems. Full article

Cargo drones are a cutting-edge solution that is becoming increasingly popular as flight times extend and regulatory frameworks evolve to accommodate new delivery methods. The aim of this paper was to comprehensively understand cargo drone dynamics and guide their effective deployment in Greece. A 5 kg payload quadrotor with versatile loading mechanisms, including a cable-suspended system and an ultra-light box, was manufactured and tested in five Greek cities. A comprehensive performance evaluation and analysis of flight range, energy consumption, altitude-related data accuracy, cost-effectiveness, and environmental were conducted. Based on hands-on experimentation and real-world data collection, the study proposes a novel data-driven methodology for strategically locating charging stations and addressing uncertainties like weather conditions and battery discharge during flights. Results indicate significant operational cost savings (89.44%) and a maximum emissions reduction (77.42%) compared to conventional transportation. The proposed strategic placement of charging stations led to substantial reductions in travel distance (41.03%) and energy consumption (56.73%) across five case studies in Greek cities. Full article

Quadrotors play a crucial role in the national economy. The control technology for quadrotor-slung load transportation systems has become a research hotspot. However, the underactuated load’s swing poses significant challenges to the stability of the system. In this paper, we propose a Lyapunov-based control strategy, to ensure the stability of the quadrotor-slung load transportation system while satisfying the constraints of the load’s swing angles. Firstly, a position controller without swing angle constraints is proposed, to ensure the stability of the system. Then, a barrier Lyapunov function based on the load’s swing angle constraints is constructed, and an anti-swing controller is designed to guarantee the states’ asymptotic stability. Finally, a PD controller is designed, to drive the actual angles to the virtual ones, which are extracted from the position controller. The effectiveness of the control method is verified by comparing it to the results of the LQR algorithm. The proposed control method not only guarantees the payload’s swing angle constraints but also reduces energy consumption. Full article

Quadrotors, commonly known as drones or unmanned aerial vehicles (UAVs), play an important role in load transportation. The complex vehicles used for transporting loads and surveillance purposes can be replaced through the ease of use and mechanical simplicity of the quadrotors. This study aims to introduce a new way of controlling the slung load system of the quadrotor after applying the fractional-order sliding mode control (FOSMC) method for performance enhancement. This method in the presence of external disturbances is likely to help stabilize and track the quadrotor with minimized swinging of the attached load. The results of this study prove the robustness of FOSMC through analysis, outcomes, and graphical representations that show the effect with various angles for a clear and conceptual understanding. The present study contributes to the literature by designing a robust FOSMC for a quadrotor with the help of external disturbances. The results of this study could be applied to the development of the design of upcoming drones which can increase the efficiency as well as the accuracy of load transportation. Further applications in the fields of rescue, agriculture, construction, research, and advancement of the fraction calculus-based control method are recommended using the FOSMC method. Full article

Gradually, it has become easier to use aerial transportation systems in practical applications. However, due to the fixed-length wire, recent studies on load-suspended transportation systems have revealed some practical constraints, especially when using quadrotor unmanned aerial vehicles (UAVs). By actively adjusting the distance between the quadrotor and the payload, it becomes possible to carry out a variety of challenging tasks, including traversing confined spaces, collecting samples from offshore locations, and even landing a payload on a movable platform. Thus, mass variable aerial transportation systems should be equipped with trajectory tracking control mechanisms to accomplish these tasks. Due to the above-mentioned reasons, the present paper addresses the problem of the altitude/yaw tracking control of a mini-quadrotor subject to mass uncertainties. The main objective of this paper is to design a fixed-time stable controller for the perturbed altitude/yaw motions, based on recent results using the fixed-time stability approach. For comparison reasons, other quadrotor motion controllers such as dual proportional integral derivative (PID) loops were considered. To show its effectiveness, the proposed fixed-time controller was validated on a real mini-quadrotor under different scenarios and has shown good performance in terms of stability and trajectory tracking. Full article

This paper presents an architecture for controlling a quadrotor transporting a cable-suspended load of uncertain mass. A family of trajectories is proposed that is composed by three phases—lift-off, transit, and landing—and implemented as a hybrid system. The proposed control system uses an adaptive geometric controller with asymptotic tracking stability. The mass of the transported load was estimated using an adaptive mechanism, which adjusts the action resorting to a geometric control method. The resulting system was validated in simulation with a mid-flight mass reduction of the transported load, and tests were performed using a range of values of load mass and maximum forward velocity. There is work in the literature that approaches the cable-suspended component of the problem, and there are also papers focused on uncertainty in the model, mass included. This work aimed to solve these two problems simultaneously, having the uncertain component being the mass of the suspended load. Full article

When military and civil missions such as transportation increase, fault tolerant control of unmanned aerial vehicles will be an obligation. Although onboard sensors provide information about the status of a quadrotor, the camera is not included in the list. In this study, visual servo control of quadrotors as a popular method for motion control is addressed. we address a visual servo control system for quadrotors as a popular method for motion control. The feature motions in the image plane are analyzed to reveal the relation between the actuator faults and these motions. Four AI fault approximators, a neural network, an extreme learning machine, a linear support vector machine, and a long short-term memory are used to approximate actuator faults of a quadrotor while using feature inputs. The results are convincing and the approximation results are used by a fuzzy logic unit to provide gain-scheduling based fault tolerant control. The proposed system shows sufficient results as a visual servo system for fixed and moving feature targets while providing fault tolerance. Full article

This paper studies the cooperative control of multiple unmanned aerial vehicles (UAVs) with sensors and autonomous flight capabilities. In this paper, an architecture is proposed that takes a small quadrotor as a mission UAV and a large six-rotor as a platform UAV to provide an aerial take-off and landing platform and transport carrier for the mission UAV. The design of a tracking controller for an autonomous docking and landing trajectory system is the focus of this research. To examine the system’s overall design, a dual-machine trajectory-tracking control simulation platform is created via MATLAB/Simulink. Then, an autonomous docking and landing trajectory-tracking controller based on radial basis function proportional–integral–derivative control is designed, which fulfills the trajectory-tracking control requirements of the autonomous docking and landing process by efficiently suppressing the external airflow disturbance according to the simulation results. A YOLOv3-based vision pilot system is designed to calibrate the rate of the aerial docking and landing position to eight frames per second. The feasibility of the multi-rotor aerial autonomous docking and landing technology is verified using prototype flight tests during the day and at night. It lays a technical foundation for UAV transportation, autonomous take-off, landing in the air, and collaborative networking. In addition, compared with the existing technologies, our research completes the closed loop of the technical process through modeling, algorithm design and testing, virtual simulation verification, prototype manufacturing, and flight test, which have better realizability. Full article

This paper deals with the control of a team of unmanned air vehicles (UAVs), specifically quadrotors, for which their mission is the transportation of a deformable linear object (DLO), i.e., a cable, hose or similar object in quasi-stationary state, while cruising towards destination. Such missions have strong industrial applications in the transportation of hoses or power cables to specific locations, such as the emergency power or water supply in hazard situations such as fires or earthquake damaged structures. This control must be robust to withstand strong and sudden wind disturbances and remain stable after aggressive maneuvers, i.e., sharp changes of direction or acceleration. To cope with these, we have previously developed the online adaptation of the proportional derivative (PD) controllers of the quadrotors thrusters, implemented by a fuzzy logic rule system that experienced adaptation by a stochastic gradient rule. However, sagging conditions appearing when the transporting drones are too close or too far away induce singularities in the DLO catenary models, breaking apart the control system. The paper’s main contribution is the formulation of the hybrid selective model of the DLO sections as either catenaries or parabolas, which allows us to overcome these sagging conditions. We provide the specific decision rule to shift between DLO models. Simulation results demonstrate the performance of the proposed approach under stringent conditions. Full article

The paper focuses on the issue of collaborative control of a two quadrotor (Unmanned Aerial Vehicle QDR) system. In particular, two quadrotors perform the task of horizontally transporting a long payload along a predefined trajectory. A leader–follower method is used to synchronize the motion of both QDRs. Conventional PD controllers drive the motion of the leader QDR-L to follow a predefined trajectory. To control a follower QDR-F drive, in the case of indoor applications, a Position Feedback Controller approach (PFC) can be used. To control the QDR-F, the PFC system uses the position information of QDR-L and the required accurate tracking cameras. In our solution, outdoor applications are considered, and usage of the Global Positioning System (GPS) is needed. However, GPS errors can adversely affect the system’s stability. The Force Feedback Controller approach (FFC) is therefore implemented to control the QDR-F motion. The FFC system assumes a rigid gripping of payload by both QDRs. The QDR-F collaborative motion is controlled using the feedback contact forces and torques acting on it due to the motion of the QDR-L. For FFC implementation, the principle of admittance control is used. The admittance controller simulates a virtual “mass-spring-damper” system and drives the motion of the QDR-F according to the contact forces. With the FFC control scheme, the follower QDR-F can be controlled without using the QDR-L positional feedback and the GPS. The contribution to the quality of payload transportation is the novelty of the article. In practice, one of the requirements may be to maintain the horizontal position of the payload. In this paper, an original solution is presented to minimize the horizontal position difference of both QDRs. A new procedure of the transfer admittance controller adaptation according to the mass of the transported payload is designed. The adaptive admittance FFC system is implemented in a Matlab-Simulink environment. The effectiveness of its trajectory tracking and horizontal stabilization functions for variations of the payload mass are demonstrated by numerical calculations. Full article
