In recent years, the increasing frequency of climate change and extreme weather events has significantly elevated the risk of levee breaches, potentially triggering large-scale floods that threaten surrounding environments and public safety. Rapid and accurate measurement of river surface velocities is crucial for developing effective emergency response plans. Video image velocimetry has emerged as a powerful new approach due to its non-invasive nature, ease of operation, and low cost. This paper introduces the Dynamic Feature Point Pyramid Lucas–Kanade (DFP-P-LK) optical flow algorithm, which employs a feature point dynamic update fusion strategy. The algorithm ensures accurate feature point extraction and reliable tracking through feature point fusion detection and dynamic update mechanisms, enhancing the robustness of optical flow estimation. Based on the DFP-P-LK, we propose a river surface velocity measurement model for rapid levee breach emergency response. This model converts acquired optical flow motion to actual flow velocities using an optical flow-velocity conversion model, providing critical data support for levee breach emergency response. Experimental results show that the method achieves an average measurement error below 15% within the velocity range of 0.43 m/s to 2.06 m/s, demonstrating high practical value and reliability. Full article

Aiming at the problem that the range profile of the current array lidar has a low resolution and contains few target details and little edge information, a super-resolution reconstruction method based on projection onto convex sets (POCS) combining the Lucas–Kanade (LK) optical flow method with a Gaussian pyramid was proposed. Firstly, the reference high-resolution range profile was obtained by the nearest neighbor interpolation of the single low-resolution range profile. Secondly, the LK optical flow method was introduced to achieve the motion estimation of low-resolution image sequences, and the Gaussian pyramid was used to perform multi-scale correction on the estimated vector, effectively improving the accuracy of motion estimation. On the basis of data consistency constraints, gradient constraints were introduced based on the distance value difference between the target edge and the background to enhance the reconstruction ability of the target edge. Finally, the residual between the estimated distance and the actual distance was calculated, and the high-resolution reference range profile was iteratively corrected by using the point spread function according to the residual. Bilinear interpolation, bicubic interpolation, POCS, POCS with adaptive correction threshold, and the proposed method were used to reconstruct the range profile of the datasets and the real datasets. The effectiveness of the proposed method was verified by the range profile reconstruction effect and objective evaluation index. The experimental results show that the index of the proposed method is improved compared to the interpolation method and the POCS method. In the redwood-3dscan dataset experiments, compared to the traditional POCS, the average gradient (AG) of the proposed method is increased by at least 8.04%, and the edge strength (ES) is increased by at least 4.84%. In the real data experiments, compared to the traditional POCS, the AG of the proposed method is increased by at least 5.85%, and the ES is increased by at least 7.01%, which proves that the proposed method can effectively improve the resolution of the reconstructed range map and the quality of the detail edges. Full article

Gas–Liquid two-phase flows are a common flow in industrial production processes. Since these flows inherently consist of discrete phases, it is challenging to accurately measure the flow parameters. In this context, a novel approach is proposed that combines the pyramidal Lucas-Kanade (L–K) optical flow method with the Split Comparison (SC) model measurement method. In the proposed approach, videos of gas–liquid two-phase flows are captured using a camera, and optical flow data are acquired from the flow videos using the pyramid L–K optical flow detection method. To address the issue of data clutter in optical flow extraction, a dynamic median value screening method is introduced to optimize the corner point for optical flow calculations. Machine learning algorithms are employed for the prediction model, yielding high flow prediction accuracy in experimental tests. Results demonstrate that the gradient boosted regression (GBR) model is the most effective among the five preset models, and the optimized SC model significantly improves measurement accuracy compared to the GBR model, achieving an R² value of 0.97, RMSE of 0.74 m³/h, MAE of 0.52 m³/h, and MAPE of 8.0%. This method offers a new approach for monitoring flows in industrial production processes such as oil and gas. Full article

Optical flow is the apparent motion of the brightness patterns in an image. The pyramidal form of the Lucas-Kanade ($\mathrm{LK}$) method is frequently used for its computation but experiments have shown that the method has deficiencies. Problems arise because of numerical issues in the least squares ($\mathrm{LS}$) problem $min{∥Ax-b∥}_2^2$, $A\in {\mathbb{R}}^{m\times 2}$ and $m\gg 2$, which must be solved many times. Numerical properties of the solution $x_0=A^{†}b$ = ${\left(A^{T}A\right)}^{-1}{A}^{T}b$ of the $\mathrm{LS}$ problem are considered and it is shown that the property $m\gg 2$ has implications for the error and stability of $x_0$. In particular, it can be assumed that b has components that lie in the column space (range) $\mathcal{R}\left(A\right)$ of A, and the space that is orthogonal to $\mathcal{R}\left(A\right)$, from which it follows that the upper bound of the condition number of $x_0$ is inversely proportional to $cos\theta$, where $\theta$ is the angle between b and its component that lies in $\mathcal{R}\left(A\right)$. It is shown that the maximum values of this condition number, other condition numbers and the errors in the solutions of the $\mathrm{LS}$ problems increase as the pyramid is descended from the top level (coarsest image) to the base (finest image), such that the optical flow computed at the base of the pyramid may be computationally unreliable. The extension of these results to the problem of total least squares is addressed by considering the stability of the optical flow vectors when there are errors in A and b. Examples of the computation of the optical flow demonstrate the theoretical results, and the implications of these results for extended forms of the $\mathrm{LK}$ method are discussed. Full article

As the fields of aviation and aerospace optics continue to evolve, there is an increasing demand for enhanced detection capabilities in equipment. Nonetheless, in applications where both optical and mechanical constraints are stringent, the continuous expansion of optical aperture and focal length is impractical. Given the existing technological landscape, employing super-resolution algorithms to enhance the imaging capability of optical systems is both practical and highly relevant. This study capitalizes on using a 2D scanning galvanometer in optical systems to acquire micro-displacement information. Initially, an imaging model for optical systems equipped with a 2D scanning galvanometer was established, and the displacement vectors for both forward and sweep image motions were defined. On this foundation, we incorporated micro-displacement information that can induce high-frequency aliasing. Subsequently, the motion paths of the galvanometer were planned and modeled. To align image sequences with micro-displacement correlations, the Lucas–Kanade (L-K) optical flow method was employed with multi-layer pyramid iteration. Then, super-resolution reconstruction was performed using kernel regression techniques. Ultimately, we tested the algorithm on an aeronautical optoelectronic pod to evaluate its impact on optical resolution and imaging quality. Compared with the original images, the 16-frame image demonstrated a 39% improvement in optical resolution under laboratory conditions. Moreover, the algorithm exhibited satisfactory performance under both nighttime and daytime conditions, as well as during aerial tests. Full article

Autonomous mobile robots (AMRs) require SLAM technology for positioning and mapping. Their accuracy and real-time performance are the keys to ensuring that the robot can safely and accurately complete the driving task. The visual SLAM systems based on feature points have high accuracy and robustness but poor real-time performance. A lightweight Visual Odometry (VO) based on Lucas–Kanade (LK) optical flow tracking is proposed. Firstly, a robust key point matching relationship between adjacent images is established by using a uniform motion model and a pyramid-based sparse optical flow tracking algorithm. Then, the grid-based motion statistics algorithm and the random sampling consensus algorithm are used to eliminate the mismatched points in turn. Finally, the proposed algorithm and the ORB-SLAM3 front-end are compared in a dataset to verify the effectiveness of the proposed algorithm. The results show that the proposed algorithm effectively improves the real-time performance of the system while ensuring its accuracy and robustness. Full article

The detection of moving objects in images is a crucial research objective; however, several challenges, such as low accuracy, background fixing or moving, ‘ghost’ issues, and warping, exist in its execution. The majority of approaches operate with a fixed camera. This study proposes a robust feature threshold moving object identification and segmentation method with enhanced optical flow estimation to overcome these challenges. Unlike most optical flow Otsu segmentation for fixed cameras, a background feature threshold segmentation technique based on a combination of the Horn–Schunck (HS) and Lucas–Kanade (LK) optical flow methods is presented in this paper. This approach aims to obtain the segmentation of moving objects. First, the HS and LK optical flows with the image pyramid are integrated to establish the high-precision and anti-interference optical flow estimation equation. Next, the Delaunay triangulation is used to solve the motion occlusion problem. Finally, the proposed robust feature threshold segmentation method is applied to the optical flow field to attract the moving object, which is the. extracted from the Harris feature and the image background affine transformation model. The technique uses morphological image processing to create the final moving target foreground area. Experimental results verified that this method successfully detected and segmented objects with high accuracy when the camera was either fixed or moving. Full article

Displacement is critical when it comes to the evaluation of civil structures. Large displacement can be dangerous. There are many methods that can be used to monitor structural displacements, but every method has its benefits and limitations. Lucas–Kanade (LK) optical flow is recognized as a superior computer vision displacement tracking method, but it only applies to small displacement monitoring. An upgraded LK optical flow method is developed in this study and used to detect large displacement motions. One motion controlled by a multiple purpose testing system (MTS) and a free-falling experiment were designed to verify the developed method. The results provided by the upgraded LK optical flow method showed 97 percent accuracy when compared with the movement of the MTS piston. In order to capture the free-falling large displacement, the pyramid and warp optical flow methods are included in the upgraded LK optical flow method and compared with the results of template matching. The warping algorithm with the second derivative Sobel operator provides accurate displacements with 96% average accuracy. Full article

Visual-based object detection and understanding is an important problem in computer vision and signal processing. Due to their advantages of high mobility and easy deployment, unmanned aerial vehicles (UAV) have become a flexible monitoring platform in recent years. However, visible-light-based methods are often greatly influenced by the environment. As a result, a single type of feature derived from aerial monitoring videos is often insufficient to characterize variations among different abnormal crowd behaviors. To address this, we propose combining two types of features to better represent behavior, namely, multitask cascading CNN (MC-CNN) and multiscale infrared optical flow (MIR-OF), capturing both crowd density and average speed and the appearances of the crowd behaviors, respectively. First, an infrared (IR) camera and Nvidia Jetson TX1 were chosen as an infrared vision system. Since there are no published infrared-based aerial abnormal-behavior datasets, we provide a new infrared aerial dataset named the IR-flying dataset, which includes sample pictures and videos in different scenes of public areas. Second, MC-CNN was used to estimate the crowd density. Third, MIR-OF was designed to characterize the average speed of crowd. Finally, considering two typical abnormal crowd behaviors of crowd aggregating and crowd escaping, the experimental results show that the monitoring UAV system can detect abnormal crowd behaviors in public areas effectively. Full article

The strap-down missile-borne image guidance system can be easily affected by the unwanted jitters of the motion of the camera, and the subsequent recognition and tracking functions are also influenced, thus severely affecting the navigation accuracy of the image guidance system. So, a real-time image stabilization technology is needed to help improve the image quality of the image guidance system. To satisfy the real-time and accuracy requirements of image stabilization in the strap-down missile-borne image guidance system, an image stabilization method based on optical flow and image matching with binary feature descriptors is proposed. The global motion of consecutive frames is estimated by the pyramid Lucas-Kanade (LK) optical flow algorithm, and the interval frames image matching based on fast retina keypoint (FREAK) algorithm is used to reduce the cumulative trajectory error. A Kalman filter is designed to smooth the trajectory, which is conducive to fitting to the main motion of the guidance system. Simulations have been carried out, and the results show that the proposed algorithm improves the accuracy and real-time performance simultaneously compared to the state-of-art algorithms. Full article

The development of an efficient and robust method for dense image-matching has been a technical challenge due to high variations in illumination and ground features of aerial images of large areas. In this paper, we propose a method for the dense matching of aerial images using an optical flow field and a fast-guided filter. The proposed method utilizes a coarse-to-fine matching strategy for a pixel-wise correspondence search across stereo image pairs. The pyramid Lucas–Kanade (L–K) method is first used to generate a sparse optical flow field within the stereo image pairs, and an adjusted control lattice is then used to derive the multi-level B-spline interpolating function for estimating the dense optical flow field. The dense correspondence is subsequently refined through a combination of a novel cross-region-based voting process and fast guided filtering. The performance of the proposed method was evaluated on three bases, namely, the matching accuracy, the matching success rate, and the matching efficiency. The evaluative experiments were performed using sets of unmanned aerial vehicle (UAV) images and aerial digital mapping camera (DMC) images. The results showed that the proposed method afforded the root mean square error (RMSE) of the reprojection errors better than ±0.5 pixels in image, and a height accuracy within ±2.5 GSD (ground sampling distance) from the ground. The method was further compared with the state-of-the-art commercial software SURE and confirmed to deliver more complete matches for images with poor-texture areas, the matching success rate of the proposed method is higher than 97% while SURE is 96%, and there is 47% higher matching efficiency. This demonstrates the superior applicability of the proposed method to aerial image-based dense matching with poor texture regions. Full article

Aiming at enhancing the accuracy and reliability of velocity calculation in vision navigation, an improved method is proposed in this paper. The method integrates Mask-R-CNN (Mask Region-based Convolutional Neural Network) and K-Means with the pyramid Lucas Kanade algorithm in order to reduce the harmful effect of moving objects on velocity calculation. Firstly, Mask-R-CNN is used to recognize the objects which have motions relative to the ground and covers them with masks to enhance the similarity between pixels and to reduce the impacts of the noisy moving pixels. Then, the pyramid Lucas Kanade algorithm is used to calculate the optical flow value. Finally, the value is clustered by the K-Means algorithm to abandon the outliers, and vehicle velocity is calculated by the processed optical flow. The prominent advantages of the proposed algorithm are (i) decreasing the bad impacts to velocity calculation, due to the objects which have relative motions; (ii) obtaining the correct optical flow sets and velocity calculation outputs with less fluctuation; and (iii) the applicability enhancement of the optical flow algorithm in complex navigation environment. The proposed algorithm is tested by actual experiments. Results with superior precision and reliability show the feasibility and effectiveness of the proposed method for vehicle velocity calculation in vision navigation system. Full article
