Search Results (79)

Achieving accurate fit in implant-supported prostheses is critical for avoiding mechanical complications; however, the influence of digital manufacturing techniques and abutment designs on misfit and preload remains unclear. This study evaluated the impact of different manufacturing techniques (CAD-cast and 3D printing) and abutment connection types (engaging [E], non-engaging [NE]) on the misfit and preload of implant-supported cantilevered fixed dental prostheses (ICFDPs). Misfit was measured at six points using scanning electron microscopy, and preload was assessed via eight strain gauges placed buccally and lingually on four implants. Frameworks were torqued to 35 Ncm, retorqued after 10 min, and subjected to 200,000 cycles of loading. Mean preload values ranged from 173.4 ± 79.5 Ncm (PF) to 330 ± 253.2 Ncm (3DP). Preload trends varied depending on the abutment type and manufacturing technique, with the 3DP group showing higher preload in engaging (E) abutments, whereas the CAD-cast group showed the opposite pattern. Although preload values varied numerically, these differences were not statistically significant (p = 0.5). In terms of misfit, significant differences were observed between groups (p < 0.05), except between CAD-cast E (86.4 ± 17.8 μm) and 3DP E (84.1 ± 19.2 μm). Additionally, E and NE abutments showed significant differences in misfit within both CAD-cast and 3DP groups. Overall, 3DP frameworks showed superior fit over CAD-cast. These findings suggest that 3DP may offer improved clinical outcomes in terms of implant–abutment fit. Full article

The attenuation of bolt preload is a critical factor leading to bolt fatigue failure, whereas the study of the nonlinear attenuation behavior of preload and its mechanism during installation is an inevitable challenge in engineering practice. The attenuation of the preload of a bolt is mainly related to the stiffness of the bolt body as well as the stiffness of the connected parts. This study aimed to develop an experimental system to analyze the nonlinear attenuation behavior of preload during bolt tightening. First, a simulation system replicating the bolt installation process was constructed in a laboratory setting, incorporating blade and pitch bearing specimens identical to those used in a 10 MW wind turbine, restoring the stiffness coupling characteristics of the “composite-metal bearing” heterogeneous interface at the blade root through a 1:1 full-scale simulation system for the first time. Second, ultrasonic preload measurement equipment was employed to monitor preload variations during the bolt tightening process. Finally, the instantaneous preload decay rate of the wind turbine blade-root bolts and the over-draw coefficient were quantified. Experiments have shown that the preload decay rate of commonly used M36 leaf root bolts is 11–16%. If a more precise value is required, each bolt needs to be calibrated. These findings provide valuable insights for optimizing bolt installation procedures, enabling precise preload control to mitigate fatigue failures caused by abnormal preload attenuation. Full article

Due to the complex operating environment of combine harvesters, uneven terrain, multiple vibration sources, and complex transmission systems, failures easily occur in critical working components, especially the bolted connections of the vibrating screen. To address these issues, this study first established a bolt-tightening mechanical model. Secondly, a finite element simulation of the preload force was performed using Ansys Workbench software (2023R2). The simulation results showed that the bolt head area exhibits a ring-shaped strain distribution. To determine the critical state of bolt loosening, a single-bolt loosening test was conducted. The experimental results indicated that when the bolt pressure decreased to 78.4 N and the torque decreased to 0.5 N·m, bolt loosening intensified, and the pressure value showed a sharp decreasing trend. These pressure and torque values can be defined as the bolt loosening threshold, providing an important reference basis for subsequent monitoring and early warning. Finally, to more realistically simulate actual working conditions, a combine harvester field vibration test was conducted. By arranging triaxial acceleration sensors on the bolted connections of the vibrating screen, acceleration signals were collected under both low-speed and high-speed field operating conditions. Time–frequency analysis was performed on the signals to extract characteristic values for each measurement point. The field vibration test results showed that the characteristic values of the transmission shaft bolt structure of the vibrating screen were at a relatively high level, indicating that this part is subjected to a large vibration load. Furthermore, frequency domain feature analysis revealed that the vibration frequency components in this area are complex, which further increases the risk of bolt loosening. This study provides an in-depth analysis of the loosening characteristics and vibration characteristics of the vibrating screen’s bolted connections in combine harvesters. The results provide an important theoretical basis and technical support for the online monitoring of failures in the vibrating screen’s bolt structure. Full article

The combine harvester, as a multi-component machine comprising a cutting table, a conveyor, a threshing cylinder, and other components, experiences significant stress and bolt failures in cutting table-conveyor structures due to inherent excitation and the cutting table’s cantilevered design. To address bolt loosening monitoring in the critical joint, this paper designed a Wheatstone bridge circuit-based wireless monitoring system and a multi-channel Wheatstone bridge sensor, enabling multi-bolt monitoring on combine harvesters. Utilizing LoRa wireless communication, the system effectively overcomes the wiring complexity and deployment difficulties of traditional agricultural machinery bolt monitoring systems. The Wheatstone bridge sensor can precisely monitor pre-tightening forces up to 150 kN for M12–M24 bolts. A calibration test based on dynamic time warping (DTW) accurately fitted the sensor’s response to pressure and displacement with determination coefficients of 0.9780 and 0.9753. Then, a validation test focusing on connection bolts revealed a 95.12% overlap between the simulated measurement range and the calibration range under pre-tightening conditions. Furthermore, fitting curves for simulated measurements against tightening torque and angle yielded coefficients of determination of 0.9945 and 0.9939, which demonstrated accurate fitting of pre-tightening conditions and defined the monitoring range of 3.02 × 10¹² to 3.49 × 10¹². Finally, combined with simulation results, a field performance test confirmed the sensor’s ability to detect minute 5% pre-load reductions, achieve 200 ms data transmission to a host computer, and maintain lossless data transmission over 1.2 km. This sensor and system design provided a valuable reference for bolt loosening monitoring in combine harvesters and other agricultural machinery. Full article

To investigate the mechanical behavior of precast columns with openings in the beam–column joint core area under axial loads, a systematic study was conducted to examine the effects of the opening parameters on the axial mechanical performance of precast columns. Two sets of six precast concrete column specimens, with opening ratios of 14% and 22%, respectively, were designed and subjected to axial compression tests. The failure patterns, opening ratios in the core area, and other relevant parameters of the specimens were thoroughly analyzed. Additionally, a finite element model incorporating material non-linearities was developed using ABAQUS (2022) software, and parametric numerical simulations were conducted to further explore the structural response. The results indicated that the variations in the opening ratio had no significant effect on the cracking load of the specimens. However, as the opening ratio increased, the peak load of the compressed columns increased by 8.6%, and the ductility factor increased by 12.9%. The study also reveals that opening ratios below 30%, the casing thickness, and the bolt preload have minimal impact on the bearing capacity of precast columns. These findings provide theoretical support for optimizing hole sizes in dry bolted connections for precast concrete structures. Full article

To address the challenge of repairing the damage to concrete box girder bridge piers on mountainous highways caused by falling rocks, this paper proposes an active underpinning technique that integrates a “井”-shaped cap system, graded preloading of the foundation, and synchronized beam body correction. The technique utilizes lateral beam preloading (to eliminate the inelastic deformation of the new pile foundation) and longitudinal beam connections (to form overall stiffness). The method involves building temporary and permanent support systems in stages. Through the two-stage temporary support system transition, the removal and in situ reconstruction of the old piers, a smooth transition from the pier–beam consolidation system to the basin-type bearing system is achieved while simultaneously performing precise correction of beam torsion. The structural safety during the construction process was verified through finite element simulations and dynamic monitoring. Monitoring results show that the beam torsion recovery effect is significant (maximum lift of 5.2 mm/settlement of 7.9 mm), and the pier strain (−54.5~−51.3 με) remains within a controllable range. Before the bridge was opened to traffic, vehicle load and impact load tests were conducted. The actual measured strength and vertical stiffness of the main beam structure meet the design requirements, with relative residual deformation less than 20%, indicating that the structure is in good, elastic working condition. The vehicle running and braking dynamic coefficients (μ = 0.058~0.171 and 0.103~0.163) are both lower than the theoretical value of 0.305. The study shows that this technique enables the rapid and safe repair of bridge piers and provides important references for similar engineering projects. Full article

Background: In dental implants, micro-gaps at the fixation–abutment interface can cause peri-implantitis and/or loosening or loss of the fixation screw; therefore, three-dimensional imaging is widely used to examine different types of connections. In the present study, we focus on the analysis on biconometric connections to detect and (possibly) measure the presence of micro-gaps in the as-positioned state and after repeated loading and unloading. Methods: Seven biconometric dental implants were characterized using micro-computed tomography (micro-CT). In two specimens (group 1), the cap was inserted, and only the apical portion was imaged, to evaluate the cap–abutment connection; in the remaining five specimens (group 2), the fixture–abutment connection was analyzed. Two implants in group 2 were also subjected to load tests to verify whether stresses could induce the formation of micro-gaps as a consequence of preload loss. Results: Micro-CT analysis showed the absence of micro-gaps greater than 10 µm in both cap–abutment and abutment–fixture connections. This was verified, in the fixture–abutment connection, even after mechanical loading and unloading. The results were reproducible in all the investigated samples in the different experimental conditions. Conclusions: In the human force range during chewing, the conical connection showed a high level of resistance to micro-gap formation at the implant–abutment interface. The absence of micro-gaps, as demonstrated here, provides encouraging preliminary data regarding the stability of the biconometric connections, which will be further verified in follow-up studies on a larger sample size. Full article

In wind turbine systems, bolted connections in pitch bearings are subjected to working loads that reduce bolt preload. This reduction can lead to issues such as bolt loosening and eccentric loading, which in turn results in the nonuniform distribution of contact stress across joint surfaces. These issues can compromise structural integrity and reduce fatigue life. However, the study of contact stress mainly focuses on theoretical research, lacking relatively large, complex structures. Also, the stress testing methods for contact surfaces of bolted connections are limited in practical engineering. In this paper, a localized bolt connection model using the finite element method according to pitch bearings in wind turbine systems was established. The contact stress distribution patterns of bolt specimens under varying preloads were investigated. Comparative numerical simulation and experimental analysis using thin-film pressure sensors were conducted. Furthermore, the effect of bolt assembly in different tightening processes on the contours of contact stress was analyzed to identify the optimal tightening sequence. The experimental results demonstrate a positive correlation between preload and maximum contact stress, with stress distribution exhibiting symmetry around the bolt hole and decreasing radially outward. Thin-film pressure sensors can be used for contact stress detection. Furthermore, the diagonal tightening method can achieve a more uniform contact stress distribution compared to other methods, such as sequential and alternate tightening. The findings provide valuable insights for optimizing the contact stress distribution and tightening processes in bolted joint assemblies. Full article

Vibration testing is crucial for understanding structural dynamics, yet conventional modeling of bolt connections often leads to significant inaccuracies. This study systematically compares six bolt connection methods—bonded, adaptive bonded, joint, beam, screw, and fixed bolt—using a finite element analysis of a headlamp vibration test jig. The six bolt connection methods were selected based on approaches adopted in previous studies. The experimental results identified the joint connection method as the most accurate, minimizing deviations in natural frequency to 7.6 Hz compared to experimental tests at 493.2 Hz, while bonded methods overestimated the frequency at 544.1 Hz due to excessive stiffness assumptions. Efficiency analyses highlighted bonded methods as the most computationally streamlined, offering preprocessing times as short as 30 s and shorter overall analysis times. These findings emphasize the importance of selecting appropriate bolt connection methods in the early design phase to ensure accurate natural frequency predictions and mode shape representations. Although this study does not consider bolt preload forces, the work shows the possibility of offering practical guidelines for improving the reliability and efficiency of vibration test jig designs by bridging the gap between analysis and experimental results. Full article

In some occasions, outdoor steel structures like wind towers, bridges, winter sports facilities, and so on are subjected to extreme environmental conditions with the presence of ice and/or with below-zero temperatures. Sometimes in these situations, surface protection of the steel structure is usually designed using hot-dip galvanizing to improve its durability. In these special circumstances, the structure’s connections are also exposed to adverse climatic agents. International standards and codes such as Eurocode 3 or EN1090-2 do not provide indications for these cases. In this experimental research, 24 specimens of non-slip joints with hot-dip galvanized faying surfaces and HV M16 and M20 bolts have been studied. Twelve specimens were subjected to fourteen twelve-hour freeze-thaw cycles, with temperature oscillation and periodic immersion in water. Next, six of the connections were subjected to a slip test under monotonic load at a temperature of −20 ± 0.5 °C and the other six at room temperature. The results were compared with joints kept at room temperature and not subjected to freeze-thaw cycles for the same period of time. The main conclusion of this piece of research is that the short-term slip resistance behavior of joints with hot-dip galvanized surfaces is not reduced for the cases studied. Full article

In hydraulics, threaded plugs are used to close various manufacturing holes and other fluid channels. They are preloaded to ensure sufficient sealing force. Since the range of recommended thread and underhead friction coefficients for preloaded threaded connections in the literature is very wide, they are not suitable for accurate determination of the preload–torque relationships of plug–valve connections. In the study, two non-standard plugs with metric threads were equipped with strain gauges and repeatedly tightened three times in valve housings under lubricated and unlubricated conditions. The preload and tightening torque were measured. (1) Although the plug–valve connections had a similar geometry with the same surface roughness of the contacting surfaces, the average overall friction coefficient (uniform thread and underhead friction coefficient) and torque coefficient differed between the two connections in the unlubricated and lubricated conditions by 16% and 18%, respectively. This indicates that even small geometrical differences can have a considerable influence on these coefficients. The overall friction and torque coefficients were between 8% and 17% higher in the unlubricated condition than in the lubricated condition (not statistically proven). (2) The overall friction and torque coefficients decreased with repeated tightening under lubricated conditions. This influence decreased with the number of tightening repetitions. (3) Consideration of the minimum and maximum thread and underhead friction coefficients given in VDI 2230 would lead to an error in the estimated preload of −15% to +86%. In conclusion, for accurate determination of the preload–torque relationship of the plug–valve connections, measurements considering repeated tightening are crucial. These should be performed for each type and size of plug–valve connection separately. To minimize the repeated tightening influence, it is recommended to re-tighten the connections several times before leaving production. Full article

Bolted connections are a common feature of connection in mechanical structures, employed to secure connected parts by tightening nuts and providing preload. The preload is susceptible to various factors leading to potential bolt loosening. The acoustoelastic theory is the most common measure of a bolt structure’s stress. The present study investigates the relationship between the inherent properties of a structure and its acousticelastic properties. The modal response of the bolted structure under different preload forces is studied by translating the acoustoelastic relationship of the structure into an analysis of its intrinsic properties. The modal analysis reflects the relative change in wave velocity to be determined implicitly based on the eigenfrequencies of the structure. A frequency formulation of classical bolted structures based on acoustoelastic theory is presented in this paper to conduct the intrinsic characteristic analysis of bolted structures. The COMSOL5.4 simulation results are under the acoustic elasticity coefficients for ultrasonic wave propagation in bolt structures, as predicted by the acoustic elasticity theory, and the present solutions are compared with those available in the literature to confirm their validity. A systematic parameter study for bolted structures under the varying preloads with different material parameters, Lame elastic constants, Murnaghan third-order elastic constants, and structural parameters are presented. These results may serve as a benchmark for researchers in this field. Full article

This study investigates the impact of tightening torque (preload) and the friction coefficient on stress generation and fatigue resistance of a Ti-6Al-4V abutment screw with an internal hexagonal connection under dynamic multi-axial masticatory loads in high-cycle fatigue (HCF) conditions. A three-dimensional model of the implant–abutment assembly was simulated using ANSYS Workbench 16.2 computer aided engineering software with chewing forces ranging from 300 N to 1000 N, evaluated over 1.35 × 10⁷ cycles, simulating 15 years of service. Results indicate that the healthy range of normal to maximal mastication forces (300–550 N) preserved the screw’s structural integrity, while higher loads (≥800 N) exceeded the Ti-6Al-4V alloy’s yield strength, indicating a risk of plastic deformation under extreme conditions. Stress peaked near the end of the occluding phase (206.5 ms), marking a critical temporal point for fatigue accumulation. Optimizing the friction coefficient (0.5 µ) and preload management improved stress distribution, minimized fatigue damage, and ensured joint stability. Masticatory forces up to 550 N were well within the abutment screw’s capacity to sustain extended service life and maintain its elastic behavior. Full article

This paper presents the process of the optimization of linear ball bearings with four-point connection using a genetic algorithm and the finite element method. Currently, modern steering systems without an intermediate shaft—steer-by-wire systems—are being developed. The focus of this paper was on the optimization of linear ball bearings with four-point connection, embedded between the outer and inner columns tube in terms of the number of balls in the bearing and the clearance between balls. The aim of the research was to maximize the first two natural frequencies in the steering system, which is crucial for improving the stability and efficiency of the system. Various factors influencing natural vibration such as bearing geometry, raceway and ball materials, and operating conditions (preload) were taken into account in the research. Preload is a major factor affecting not only linear motion but also natural frequency. In order to speed up the calculations, the author’s simplified model of a linear bearing with the use of a system of springs was proposed. The nonlinear properties of the spring were determined on the basis of Hertz’s theory. A genetic optimization process resulted in a linear bearing structure that meets the natural frequency criteria. In addition, the full reference model was numerically compared with the simplified one, which showed convergent results of natural frequencies. Full article

The development of a piezoelectric linear motor is presented in this paper, based on the principle of alternating motion, to meet the acting stroke and accuracy requirements for the probe station’s motion servo system. By partitioning the stator into tangential and normal components, two tangential actuators are affixed to the base, while two normal actuators are fixed on the preloading mechanism, thereby proposing a novel approach for connecting the stator and base. First, the construction and the working principle of the motor were introduced. Subsequently, the motor’s major components were designed through finite element simulation, followed by modeling the motor dynamics and deriving its displacement transfer function. Finally, an experimental prototype was fabricated, and a prototype test system was constructed. The driving method can realize a large stroke operation at a low frequency. The minimum operating frequency of the motor is 1 Hz, the minimum step is 12.55 μm, and the stroke is 105 mm. The study results will promote the development of high-performance probe systems. Full article
