Search Results (119)

Search Parameters:
Keywords = preliminary aerodynamic design

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
22 pages, 1644 KiB
Article
Machine Learning Prediction of Airfoil Aerodynamic Performance Using Neural Network Ensembles
by Diana-Andreea Sterpu, Daniel Măriuța, Grigore Cican, Ciprian-Marius Larco and Lucian-Teodor Grigorie
Appl. Sci. 2025, 15(14), 7720; https://doi.org/10.3390/app15147720 - 9 Jul 2025
Viewed by 368
Abstract
Reliable aerodynamic performance estimation is essential for both preliminary design and optimization in various aeronautical applications. In this study, a hybrid deep learning model is proposed, combining convolutional neural networks (CNNs) and operating directly on raw airfoil geometry, with parallel branches of fully [...] Read more.
Reliable aerodynamic performance estimation is essential for both preliminary design and optimization in various aeronautical applications. In this study, a hybrid deep learning model is proposed, combining convolutional neural networks (CNNs) and operating directly on raw airfoil geometry, with parallel branches of fully connected deep neural networks (DNNs) that process operational parameters and engineered features. The model is trained on an extensive database of NACA four-digit airfoils, covering angles of attack ranging from −5° to 14° and ten Reynolds numbers increasing in steps of 500,000 from 500,000 up to 5,000,000. As a novel contribution, this work investigates the impact of random seed initialization on model accuracy and reproducibility and introduces a seed-based ensemble strategy to enhance generalization. The best-performing single-seed model tested (seed 0) achieves a mean absolute percentage error (MAPE) of 1.1% with an R2 of 0.9998 for the lift coefficient prediction and 0.57% with an R2 of 0.9954 for the drag coefficient prediction. In comparison, the best ensemble model tested (seeds 610, 987, and 75025) achieves a lift coefficient MAPE of 1.43%, corresponding to R2 0.9999, and a drag coefficient MAPE of 1.19%, corresponding to R2 = 0.9968. All the tested seed dependencies in this paper (ten single seeds and five ensembles) demonstrate an overall R2 greater than 0.97, which reflects the model architecture’s strong foundation. The novelty of this study lies in the demonstration that the same machine learning model, trained on identical data and architecture, can exhibit up to 250% variation in prediction error solely due to differences in random seed selection. This finding highlights the often-overlooked impact of seed initialization on model performance and highlights the necessity of treating seed choice as an active design parameter in ML aerodynamic predictions. Full article
Show Figures

Figure 1

25 pages, 1264 KiB
Article
Potential Assessment of Electrified Heavy-Duty Trailers Based on the Methods Developed for EU Legislation (VECTO Trailer)
by Stefan Present and Martin Rexeis
Future Transp. 2025, 5(3), 77; https://doi.org/10.3390/futuretransp5030077 - 1 Jul 2025
Viewed by 296
Abstract
Since 1 January 2024, newly produced heavy-duty trailers are subject to the assessment of their performance regarding CO2 and fuel consumption according to Implementing Regulation (EU) 2022/1362. The method is based on the already established approach for the CO2 and energy [...] Read more.
Since 1 January 2024, newly produced heavy-duty trailers are subject to the assessment of their performance regarding CO2 and fuel consumption according to Implementing Regulation (EU) 2022/1362. The method is based on the already established approach for the CO2 and energy consumption evaluation of trucks and buses, i.e., applying a combination of component testing and vehicle simulation using the software VECTO (Vehicle Energy Consumption calculation TOol). For the evaluation of trailers, generic conventional towing vehicles in combination with the specific CO2 and fuel consumption-relevant properties of the trailer, such as mass, aerodynamics, rolling resistance etc., are simulated in the “VECTO Trailer” software. The corresponding results are used in the European HDV CO2 standards with which manufacturers must comply to avoid penalty payments (2030: −10% for semitrailers and −7.5% for trailers compared with the baseline year 2025). Methodology and legislation are currently being extended to also cover the effects of electrified trailers (trailers with an electrified axle and/or electrically supplied auxiliaries) on CO2, electrical energy consumption, and electric range extension (special use case in combination with a battery-electric towing vehicle). This publication gives an overview of the developed regulatory framework and methods to be implemented in a future extension of VECTO Trailer as well as a comparison of different e-trailer configurations and usage scenarios regarding their impact on CO2, energy consumption, and electric range by applying the developed methods in a preliminary potential analysis. Results from this analysis indicate that e-trailers that use small batteries (5–50 kWh) to power electric refrigeration units achieve a CO2 reduction of 5–10%, depending primarily on battery capacity. In contrast, e-trailers designed for propulsion support with larger batteries (50–500 kWh) and e-axle(s) (50–500 kW) demonstrate a reduction potential of up to 40%, largely determined by battery capacity and e-axle rating. Despite their reduction potential, market acceptance of e-trailers remains uncertain as the higher number of trailers compared with towing vehicles could lead to slow adoption, especially of the more expensive configurations. Full article
Show Figures

Figure 1

15 pages, 2292 KiB
Article
Analytical Shaping of a Rocket Nose as a Stage of Preliminary Aerodynamic Modification
by Adrian Szklarski and Robert Głębocki
Aerospace 2025, 12(7), 594; https://doi.org/10.3390/aerospace12070594 - 30 Jun 2025
Viewed by 168
Abstract
The article discusses the problem of a preliminary analytical method for modifying the shape of a rocket’s nose. The purpose of this method is to determine the shape that minimizes aerodynamic drag, in the context of modifying a ballistic missile to incorporate guidance [...] Read more.
The article discusses the problem of a preliminary analytical method for modifying the shape of a rocket’s nose. The purpose of this method is to determine the shape that minimizes aerodynamic drag, in the context of modifying a ballistic missile to incorporate guidance systems. The traditional design process relies on numerical methods such as CFD (Computational Fluid Dynamics) or machine learning techniques; however, the method presented here can serve as a first iteration to support the design. Advanced simulation tools are often expensive and difficult to access for smaller companies, while open-source software can sometimes be unreliable, difficult to use, and incompatible with professional solutions. This can pose a challenge for businesses planning to collaborate in the future with large corporations that rely on advanced engineering tools. The proposed solution, as previously mentioned, provides a starting point for the entire design process. The approach has been shown to be sufficient from the design work. The entire process was validated during test range trials, during which rockets were launched, and the flight measurement results accurately reflected the aerodynamic properties of the missiles. In the next stages of the project, numerical methods including CFD simulations are planned to verify the analytical results and enable further aerodynamic modification of the design. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

16 pages, 3539 KiB
Article
Aerodynamics Caused by Rolling Rates of a Small-Scale Supersonic Flight Experiment Vehicle with a Cranked-Arrow Main Wing
by Kazuhide Mizobata, Koji Shirakata, Atsuya Honda, Keisuke Shiono, Yukiya Ishigami, Akihiro Nishida and Masaaki Miura
Aerospace 2025, 12(7), 572; https://doi.org/10.3390/aerospace12070572 - 24 Jun 2025
Viewed by 210
Abstract
A small-scale supersonic flight experiment vehicle is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights, which are essential to next-generation aerospace transportation systems. Its baseline configuration M2011 with a cranked-arrow main [...] Read more.
A small-scale supersonic flight experiment vehicle is being developed at Muroran Institute of Technology as a flying testbed for verification of innovative technologies for high-speed atmospheric flights, which are essential to next-generation aerospace transportation systems. Its baseline configuration M2011 with a cranked-arrow main wing with an inboard and outboard leading edge sweepback angle of 66 and 61 degrees and horizontal and vertical tails has been proposed. Its aerodynamics caused by attitude motion are required to be clarified for six-degree-of-freedom flight capability prediction and autonomous guidance and control. This study concentrates on characterization of such aerodynamics caused by rolling rates in the subsonic regime. A mechanism for rolling a wind-tunnel test model at various rolling rates and arbitrary pitch angle is designed and fabricated using a programmable stepping motor and an equatorial mount. A series of subsonic wind-tunnel tests and preliminary CFD analysis are carried out. The resultant static derivatives have sufficiently small scatter and agree quite well with the static wind-tunnel tests in the case of a small pitch angle, whereas the static directional stability deteriorates in the case of large pitch angles and large nose lengths. In addition, the resultant dynamic derivatives agree well with the CFD analysis and the conventional theory in the case of zero pitch angle, whereas the roll damping deteriorates in the case of large pitch angles and proverse yaw takes place in the case of a large nose length. Full article
(This article belongs to the Special Issue Research and Development of Supersonic Aircraft)
Show Figures

Figure 1

21 pages, 2110 KiB
Article
Preliminary Sizing of a Vertical-Takeoff–Horizontal-Landing TSTO Launch Vehicle Using Multidisciplinary Analysis Optimization
by Xiaoyu Xu, Xinrui Fang and Xiongqing Yu
Aerospace 2025, 12(7), 567; https://doi.org/10.3390/aerospace12070567 - 22 Jun 2025
Viewed by 291
Abstract
The vertical-takeoff–horizontal-landing (VTHL) two-stage-to-orbit (TSTO) system is a kind of novel launch vehicle in which a reusable first stage can take off vertically like a rocket and land horizontally like an airplane. The advantage of the VTHL TSTO vehicle is that the launch [...] Read more.
The vertical-takeoff–horizontal-landing (VTHL) two-stage-to-orbit (TSTO) system is a kind of novel launch vehicle in which a reusable first stage can take off vertically like a rocket and land horizontally like an airplane. The advantage of the VTHL TSTO vehicle is that the launch costs can be reduced significantly due to its reusable first stage. This paper presents an application of multidisciplinary analysis optimization on preliminary sizing in conceptual design of the VTHL TSTO vehicle. The VTHL TSTO concept is evaluated by multidisciplinary analysis, including geometry, propulsion, aerodynamics, mass, trajectory, and static stability. The preliminary sizing of the VTHL TSTO vehicle is formulated as a multidisciplinary optimization problem. The focus of this paper is to investigate the impacts of the first-stage reusability and propellant selection on the staging altitude and velocity, size, and mass of the VTHL TSTO vehicles. The observations from the results show that the velocity and altitude of the optimal staging point are determined mainly by the reusability of the first stage, which in turn affects the size and mass of the upper stage and the first stage. The first stage powered by hydrocarbon fuel has a lower dry mass compared with that powered by liquid hydrogen. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

21 pages, 3290 KiB
Article
Analysis of Interactions Among Loss-Generating Mechanisms in Axial Flow Turbines
by Greta Raina, Yannick Bousquet, David Luquet, Eric Lippinois and Nicolas Binder
Int. J. Turbomach. Propuls. Power 2025, 10(2), 11; https://doi.org/10.3390/ijtpp10020011 - 13 Jun 2025
Viewed by 561
Abstract
Accurate loss prediction since the preliminary design steps is crucial to improve the development process and the aerodynamic performance of turbines. Initial design phases typically employ reduced-order models in which the different loss-generating mechanisms are assessed through correlations. These correlations are often based [...] Read more.
Accurate loss prediction since the preliminary design steps is crucial to improve the development process and the aerodynamic performance of turbines. Initial design phases typically employ reduced-order models in which the different loss-generating mechanisms are assessed through correlations. These correlations are often based on the hypothesis of loss linearity, which assumes that losses from different sources can be summed to obtain the total losses. However, this assumption could constitute an oversimplification, as losses occur concurrently and can interact with each other, potentially impacting overall performance, all the more in low aspect ratio turbomachinery. The aim of this paper is to investigate the role of interactions between different phenomena in the generation of loss. 3D RANS simulations are run on two simplified representations of a turbine blade channel, a curved duct and a linear cascade, and on a real turbine vane. Several inlet and wall boundary conditions are employed to examine loss-generating phenomena both separately and simultaneously. This approach enables the analysis of where and how interactions occur and quantifies their influence on the overall losses. Losses caused by boundary layer–vortex interactions are found to be highly sensitive to the relative positions of these two phenomena. It was observed that the loss linearity assumption may be acceptable in certain cases, but it is generally inadequate for off-design conditions and twisted annular configurations. Full article
Show Figures

Figure 1

19 pages, 994 KiB
Article
A Procedure for Developing a Flight Mechanics Model of a Three-Surface Drone Using Semi-Empirical Methods
by Stefano Cacciola, Laura Testa and Matteo Saponi
Aerospace 2025, 12(6), 515; https://doi.org/10.3390/aerospace12060515 - 7 Jun 2025
Viewed by 333
Abstract
Aircraft and fixed-wing drones, designed to perform vertical take-off and landing (VTOL), often incorporate unconventional configurations that offer unique capabilities but simultaneously pose significant challenges in flight mechanics modeling, whose reliability strongly depends on the correct tuning of the inertial and aerodynamic parameters. [...] Read more.
Aircraft and fixed-wing drones, designed to perform vertical take-off and landing (VTOL), often incorporate unconventional configurations that offer unique capabilities but simultaneously pose significant challenges in flight mechanics modeling, whose reliability strongly depends on the correct tuning of the inertial and aerodynamic parameters. Having a good characterization of the aerodynamics represents a critical issue, especially in the design and optimization of unconventional aircraft configurations, when, indeed, one is bound to employ empirical or semi-empirical methods, devised for conventional geometries, that struggle to capture complex aerodynamic interactions. Alternatives such as high-fidelity computational fluid dynamics (CFD) simulations, although more accurate, are typically expensive and impractical for both preliminary design and lofting optimization. This work introduces a procedure that exploits multiple analyses conducted through semi-empirical methodologies implemented in the USAF Digital DATCOM to develop a flight mechanics model for fixed-wing unmanned aerial vehicles (UAVs). The reference UAV chosen to test the proposed procedure is the Dragonfly DS-1, an electric VTOL UAV developed by Overspace Aviation, featuring a three-surface configuration. The accuracy of the polar data, i.e., the lift and drag coefficients, is assessed through comparisons with computational fluid dynamics simulations and flight data. The main discrepancies are found in the drag estimation. The present work represents a preliminary investigation into the possible extension of semi-empirical methods, consolidated for traditional configurations, to unconventional aircraft so as to support early-stage UAV design. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

25 pages, 4392 KiB
Article
Investigation of Stability and Control Shortcomings of the North American X-15
by William P. Lorenzo, Ramana V. Grandhi and Timothy T. Takahashi
Aerospace 2025, 12(6), 513; https://doi.org/10.3390/aerospace12060513 - 6 Jun 2025
Viewed by 322
Abstract
There is growing interest in the design of maneuvering high-speed aircraft to fly within or at the edge of the atmosphere. We identify and develop novel quasi-static vehicle screening methodologies, suitable for use during preliminary design, to better predict an incipient loss of [...] Read more.
There is growing interest in the design of maneuvering high-speed aircraft to fly within or at the edge of the atmosphere. We identify and develop novel quasi-static vehicle screening methodologies, suitable for use during preliminary design, to better predict an incipient loss of control due to the dynamic effects of feedback. We validate these metrics by reverse-engineering Neil Armstrong’s 1962 loss of control and inadvertent atmospheric skip while piloting the X-15. In 1962, then-extant flight dynamics screening methods did not forecast likely troubles. We assemble and refine a collection of predictive metrics which operate upon basic quasi-static aerodynamic data and predict the confluence of lateral/directional stability and controllability issues which plagued the flown mission. These tools, which leverage McRuer’s “equivalent stability derivative” approach, enable future engineers to make proactive design changes which can avoid lateral/directional instabilities developing at high speeds. Full article
Show Figures

Figure 1

12 pages, 2401 KiB
Proceeding Paper
Winglet Design for Class I Mini UAV—Aerodynamic and Performance Optimization
by Eleftherios Nikolaou, Eleftherios Karatzas, Spyridon Kilimtzidis and Vassilis Kostopoulos
Eng. Proc. 2025, 90(1), 111; https://doi.org/10.3390/engproc2025090111 - 7 May 2025
Viewed by 420
Abstract
The aerodynamic performance of an aircraft can be enhanced by incorporating wingtip devices, or winglets, which primarily reduce lift-induced drag created by wingtip vortices. This study outlines an optimization procedure for implementing winglets on a Class I fixed-wing mini-UAV to maximize aerodynamic efficiency [...] Read more.
The aerodynamic performance of an aircraft can be enhanced by incorporating wingtip devices, or winglets, which primarily reduce lift-induced drag created by wingtip vortices. This study outlines an optimization procedure for implementing winglets on a Class I fixed-wing mini-UAV to maximize aerodynamic efficiency and performance. After the Conceptual and Preliminary design phases, a baseline UAV was developed without winglets, adhering to specific layout constraints (e.g., wingspan, length). Various winglet designs—plate and blended types with differing heights, cant angles, and sweep angles—were then created and assessed. A Computational Fluid Dynamics (CFD) analysis was conducted to evaluate the flow around both the winglet-free UAV and configurations with each winglet design. The simulations employed Reynolds-Averaged Navier-Stokes (RANS) equations coupled with the Spalart-Allmaras turbulence model, targeting the optimal winglet configuration for enhanced aerodynamic characteristics during cruise. Charts of lift, drag, pitching moment coefficients, and lift-to-drag ratios are presented, alongside flow contours illustrating vortex characteristics for both baseline and optimized configurations. Additionally, dynamic stability analyses examined how winglets impact the UAV’s stability and control. The results demonstrated a significant improvement in aerodynamic coefficients (CLmax, L/Dmax, CLa, Cma), leading to an increase in both range and endurance. Full article
Show Figures

Figure 1

19 pages, 4234 KiB
Article
Introduction of a System Definition in the Common Parametric Aircraft Configuration Schema (CPACS)
by Tim Burschyk, Marko Alder, Andrea Mancini, Thimo Bielsky, Vivian Kriewall, Frank Thielecke and Björn Nagel
Aerospace 2025, 12(5), 373; https://doi.org/10.3390/aerospace12050373 - 25 Apr 2025
Viewed by 484
Abstract
The aircraft design process is a complex task that requires the collaboration of disciplinary experts from various fields. In practice, this complexity requires a large investment in setting up communication interfaces for the exchange of disciplinary data, and serious misinterpretations are not uncommon. [...] Read more.
The aircraft design process is a complex task that requires the collaboration of disciplinary experts from various fields. In practice, this complexity requires a large investment in setting up communication interfaces for the exchange of disciplinary data, and serious misinterpretations are not uncommon. To increase the efficiency and robustness of data exchange, a common language is essential. As such, the Common Parametric Aircraft Configuration Schema (CPACS) serves as a central data model, which currently includes detailed parametrizations of aircraft geometry and analysis results from traditional disciplines (e.g., aerodynamics, structure, etc.). However, with the recent interest in alternative propulsion and complex on-board system architectures, CPACS is proving to be too limited to meet the needs of the various disciplinary system experts. The particular challenge here is to enable different views on the same systems, i.e., a functional/logical as well as a geometric/physical representation, without violating the principle of unambiguous data. Therefore, this paper proposes an extension of CPACS which introduces an explicit system definition covering both representations. Its potential is demonstrated by two use cases from disciplinary experts in the field of on-board system design at the Hamburg University of Technology (TUHH), based on data provided by aircraft design experts. Through validation against the experts’ needs, the proposed system definition proves to bridge the gap between preliminary aircraft design and on-board system design, enabling a holistic, robust and efficient aircraft design process. Full article
(This article belongs to the Special Issue Aircraft Design and System Optimization)
Show Figures

Figure 1

23 pages, 2649 KiB
Article
Transonic Dynamic Stability Derivative Estimation Using Computational Fluid Dynamics: Insights from a Common Research Model
by Roberta Bottigliero, Viola Rossano and Giuliano De Stefano
Aerospace 2025, 12(4), 304; https://doi.org/10.3390/aerospace12040304 - 3 Apr 2025
Cited by 2 | Viewed by 2037
Abstract
Dynamic stability derivatives are critical parameters in the design of trajectories and attitude control systems for flight vehicles, as they directly affect the divergence behavior of vibrations in an aircraft’s open-loop system when subjected to disturbances. This study focuses on the estimation of [...] Read more.
Dynamic stability derivatives are critical parameters in the design of trajectories and attitude control systems for flight vehicles, as they directly affect the divergence behavior of vibrations in an aircraft’s open-loop system when subjected to disturbances. This study focuses on the estimation of dynamic stability derivatives using a computational fluid dynamics (CFD)-based force oscillation method. A transient Reynolds-averaged Navier–Stokes solver is utilized to compute the time history of aerodynamic moments for an aircraft model oscillating about its center of gravity. The NASA Common Research Model serves as the reference geometry for this investigation, which explores the impact of pitching, rolling, and yawing oscillations on aerodynamic performance. Periodic oscillatory motions are imposed while using a dynamic mesh technique for CFD analysis. Preliminary steady-state simulations are conducted to validate the computational approach, ensuring the reliability and accuracy of the applied CFD model for transonic flow. The primary goal of this research is to confirm the efficacy of CFD in accurately predicting stability derivative values, underscoring its advantages over traditional wind tunnel experiments at high angles of attack. The study highlights the accuracy of CFD predictions and provides detailed insights into how different oscillations affect aerodynamic performance. This approach showcases the potential for significant cost and time savings in the estimation of dynamic stability derivatives. Full article
(This article belongs to the Special Issue Experimental Fluid Dynamics and Fluid-Structure Interactions)
Show Figures

Figure 1

19 pages, 10336 KiB
Article
Trade-Off Conceptual Design of a Camber Morphing Flap for the Next Generation Hybrid Electrical Aircraft Across the HERWINGT Project
by Maria Chiara Noviello, Bernardino Galasso, Ignazio Dimino, Salvatore Ameduri and Antonio Concilio
Appl. Sci. 2025, 15(7), 3660; https://doi.org/10.3390/app15073660 - 26 Mar 2025
Viewed by 464
Abstract
Compliant wing morphing devices deal with controlled and smooth adaptation of the subcomponents’ shape to external conditions. Their structural stiffness distribution, typically resulting from an optimization design process, is tailored to ensure large deformations and sufficient robustness while preserving a given form under [...] Read more.
Compliant wing morphing devices deal with controlled and smooth adaptation of the subcomponents’ shape to external conditions. Their structural stiffness distribution, typically resulting from an optimization design process, is tailored to ensure large deformations and sufficient robustness while preserving a given form under the action of the aerodynamic loads and the internal force system. Within the European project HERWINGT (Hybrid Electric Regional Wing Integration Novel Green Technologies), supported by the Clean Aviation Joint Undertaking (CAJU), a compliant morphing flap (MF) concept has been developed by CIRA to implement adaptive capability for a strut-braced wing of the next generation Hybrid Electric Regional Aircraft. Its aim is to achieve remarkable high-lift performance improvement and related reduction of fuel consumption per flight. Specifically, the work focuses on the evolution of the conceptual architecture of the MF developed across the HERWINGT project, which was investigated in terms of preliminary design and has always accounted for actuation system integration aspects. A step-by-step design approach involving sensitivity finite elements analyses has been then carried out on two MF configurations; the technical outcomes resulting from the development of each of them have been critically analyzed and herein reported. Finally, justifications are provided for all the future adoptable engineering solutions. Full article
(This article belongs to the Section Aerospace Science and Engineering)
Show Figures

Figure 1

27 pages, 4281 KiB
Article
Digital Twin-Driven Design of an Ice Prediction Model
by Andrea Serino, Alberto Dagna, Eugenio Brusa and Cristiana Delprete
Aerospace 2025, 12(2), 107; https://doi.org/10.3390/aerospace12020107 - 31 Jan 2025
Viewed by 949
Abstract
This paper describes the development of an ice creation model to be used within the framework of a model-based systems engineering approach to predict the amount of ice growing on aircraft wings during flight. This model supports the preliminary design of the ice [...] Read more.
This paper describes the development of an ice creation model to be used within the framework of a model-based systems engineering approach to predict the amount of ice growing on aircraft wings during flight. This model supports the preliminary design of the ice protection system, as well as the implementation of a control system, in real-time. When the aircraft meets a high concentration of super-cooled water in the atmosphere and a low temperature, the risk of ice formation on its external surfaces is significant. This causes a decrease in aerodynamic performance, with potential loss of control of the aircraft. To mitigate this effect, ice prevention and protection systems are crucial. The characteristics of the icing phenomena are first defined, then their effects on aircraft behavior during operation are evaluated. This allows us to develop a highly parametric predictive model of the actual icing conditions experienced by the aircraft during a given flight mission. To precisely predict the ice accretion and to design an ice protection system, estimating heat fluxes involving the aircraft’s wing surfaces and the external environment is required. To allow for this, this study also develops a thermal model that is specifically applied to the above-mentioned analysis. This model includes many factors characterizing the atmospheric conditions responsible for ice creation upon the aerodynamic surfaces, and it enables an accurate estimation and quantification of all the parameters necessary to design an appropriate ice protection system. Full article
(This article belongs to the Special Issue On-Board Systems Design for Aerospace Vehicles (2nd Edition))
Show Figures

Figure 1

12 pages, 7826 KiB
Communication
Novel MEMS Multisensor Chip for Aerodynamic Pressure Measurements
by Žarko Lazić, Milče M. Smiljanić, Dragan Tanasković, Milena Rašljić-Rafajilović, Katarina Cvetanović, Evgenija Milinković, Marko V. Bošković, Stevan Andrić, Ivana Jokić, Predrag Poljak and Miloš Frantlović
Sensors 2025, 25(3), 600; https://doi.org/10.3390/s25030600 - 21 Jan 2025
Cited by 1 | Viewed by 2919
Abstract
The key equipment for performing aerodynamic testing of objects, such as road and railway vehicles, aircraft, and wind turbines, as well as stationary objects such as bridges and buildings, are multichannel pressure measurement instruments (pressure scanners). These instruments are typically based on arrays [...] Read more.
The key equipment for performing aerodynamic testing of objects, such as road and railway vehicles, aircraft, and wind turbines, as well as stationary objects such as bridges and buildings, are multichannel pressure measurement instruments (pressure scanners). These instruments are typically based on arrays of separate pressure sensors built in an enclosure that also contains temperature sensors used for temperature compensation. However, there are significant limitations to such a construction, especially when increasing requirements in terms of miniaturization, the number of pressure channels, and high measurement performance must be met at the same time. In this paper, we present the development and realization of an innovative MEMS multisensor chip, which is designed with the intention of overcoming these limitations. The chip has four MEMS piezoresistive pressure-sensing elements and two resistive temperature-sensing elements, which are all monolithically integrated, enabling better sensor matching and thermal coupling while providing a high number of pressure channels per unit area. The main steps of chip development are preliminary chip design, numerical simulations of the chip’s mechanical behavior when exposed to the measured pressure, final chip design, fabrication processes (photolithography, thermal oxidation, diffusion, layer deposition, micromachining, anodic bonding, and wafer dicing), and electrical testing. Full article
Show Figures

Figure 1

33 pages, 6254 KiB
Article
Development of a Reduced Order Model-Based Workflow for Integrating Computer-Aided Design Editors with Aerodynamics in a Virtual Reality Dashboard: Open Parametric Aircraft Model-1 Testcase
by Andrea Lopez and Marco E. Biancolini
Appl. Sci. 2025, 15(2), 846; https://doi.org/10.3390/app15020846 - 16 Jan 2025
Viewed by 997
Abstract
In this paper, a workflow for creating advanced aerodynamics design dashboards is proposed. A CAD modeler is directly linked to the CFD simulation results so that the designer can explore in real time, assisted by virtual reality (VR), how shape parameters affect the [...] Read more.
In this paper, a workflow for creating advanced aerodynamics design dashboards is proposed. A CAD modeler is directly linked to the CFD simulation results so that the designer can explore in real time, assisted by virtual reality (VR), how shape parameters affect the aerodynamics and choose the optimal combination to optimize performance. In this way, the time required for the conception of a new component can be drastically reduced because, even at the preliminary stage, the designer has all the necessary information to make more thoughtful choices. Thus, this work sets a highly ambitious and innovative goal: to create a smart design dashboard where every shape parameter is directly and in real-time linked to the results of the high-fidelity analyses. The OPAM (Open Parametric Aircraft Model), a simplified model of the Boeing 787, was considered as a case study. CAD parameterization and mesh morphing were combined to generate the design points (DPs), while Reduced Order Models (ROMs) were developed to link the results of the CFD analyses to the chosen parameterization. The ROMs were exported as FMUs (Functional Mockup Units) to be easily managed in any environment. Finally, a VR design dashboard was created in the Unity environment, enabling the interaction with the geometric model in order to observe in a fully immersive and intuitive environment how each shape parameter affects the physics involved. The MetaQuest 3 headset has been selected for these tests. Thus, the use of VR for a design platform represents another innovative aspect of this work. Full article
(This article belongs to the Special Issue Application of Fluid Mechanics and Aerodynamics in Aerospace)
Show Figures

Figure 1
