Transparent conductive electrodes (TCEs) are essential components in modern optoelectronic devices, including organic light-emitting diodes and solar cells, sensors, and flexible displays. Indium tin oxide has been the dominant material for TCEs due to its high transparency and conductivity. However, its brittleness, high cost, and increasingly limited availability pose significant challenges for electronics. Crack-template (CT)-assisted fabrication has emerged as a promising technique to develop metal mesh-based TCEs with superior mechanical flexibility, high conductivity, and excellent optical transmittance. This technique leverages the spontaneous formation of random and continuous microcrack networks in sacrificial templates, followed by metal deposition (e.g., Cu, Ag, Al, etc.), to produce highly conductive, scalable, and low-cost electrodes. Various crack formation strategies, including controlled drying of polymer suspensions, mechanical strain engineering, and thermal processing, have been explored to tailor electrode properties. Recent studies have demonstrated that crack-templated TCEs can achieve transmittance values exceeding 85% and sheet resistances below 10 Ω/sq, with mesh line widths as low as ~40 nm. Moreover, these electrodes exhibit enhanced stretchability and robustness under mechanical deformation, outperforming ITO in bend and fatigue tests. This review aims to explore recent advancements in CT engineering, highlighting key fabrication methods, performance metrics across different metals and substrates, and presenting examples of its applications in optoelectronic devices. Additionally, it will examine current challenges and future prospects for the widespread adoption of this emerging technology. Full article

Micro Light Emitting Diode (Micro-LED) technology, characterized by exceptional brightness, low power consumption, fast response, and long lifespan, holds significant potential for next-generation displays, yet its commercialization hinges on resolving challenges in high-density interconnect fabrication, particularly micrometer-scale bump formation. Traditional fabrication approaches such as evaporation enable precise bump control but face scalability and cost limitations, while electroplating offers lower costs and higher throughput but suffers from substrate conductivity requirements and uneven current density distributions that compromise bump-height uniformity. Emerging alternatives include electroless plating, which achieves uniform metal deposition on non-conductive substrates through autocatalytic reactions albeit with slower deposition rates; ball mounting and dip soldering, which streamline processes via automated solder jetting or alloy immersion but struggle with bump miniaturization and low yield; and photosensitive conductive polymers that simplify fabrication via photolithography-patterned composites but lack validated long-term stability. Persistent challenges in achieving micrometer-scale uniformity, thermomechanical stability, and environmental compatibility underscore the need for integrated hybrid processes, eco-friendly manufacturing protocols, and novel material innovations to enable ultra-high-resolution and flexible Micro-LED implementations. This review systematically compares conventional and emerging methodologies, identifies critical technological bottlenecks, and proposes strategic guidelines for industrial-scale production of high-density Micro-LED displays. Full article

The removal of surface residues from single-layer graphene (SLG), including poly(methyl methacrylate) (PMMA) polymers and Cl⁻ ions, during the transfer process remains a significant challenge with regard to preserving the intrinsic properties of SLG, with the process often leading to unintended doping and reduced electronic performance capabilities. This study presents a rapid and efficient surface treatment method that relies on an aqueous sodium nitrite (NaNO₂) solution to remove such contaminants effectively. The NaNO₂ solution rinse leverages reactive nitric oxide (NO) species to neutralize ionic contaminants (e.g., Cl⁻) and partially oxidize polymer residues in less than 10 min, thereby facilitating a more thorough final cleaning while preserving the intrinsic properties of graphene. Characterization techniques, including atomic force microscopy (AFM), Kelvin probe force microscopy (KPFM), and X-ray photoelectron spectroscopy (XPS), demonstrated substantial reductions in the levels of surface residues. The treatment restored the work function of the SLG to approximately 4.79 eV, close to that of pristine graphene (~4.5–4.8 eV), compared to the value of nearly 5.09 eV for conventional SLG samples treated with deionized (DI) water. Raman spectroscopy confirmed the reduced doping effects and improved structural integrity of the rinsed SLG. This effective rinsing process enhances the reproducibility and performance of SLG, enabling its integration into advanced electronic devices such as organic light-emitting diodes (OLEDs), photovoltaic (PV) cells, and transistors. Furthermore, the technique is broadly applicable to other two-dimensional (2D) materials, paving the way for next-generation (opto)electronic technologies. Full article

The rapid developments in conductive polymers with flexible electronics over the past years have generated noteworthy attention among researchers and entrepreneurs. Conductive polymers have the distinctive capacity to conduct electricity while still maintaining the lightweight, flexible, and versatile characteristics of polymers. They are crucial for the creation of flexible electronics or gadgets that can stretch, bend, and adapt to different surfaces have sparked momentous interest in electronics, energy storage, sensors, smart textiles, and biomedical applications. This review article offers a comprehensive overview of recent advancements in conductive polymers over the last 15 years, including a bibliometric analysis. The properties of conductive polymers are summarized. Additionally, the fabrication processes of conductive polymer-based materials are discussed, including vacuum filtering, hydrothermal synthesis, spray coating, electrospinning, in situ polymerization, and electrochemical polymerization. The techniques have been presented along with their advantages and limitations. The multifunctional applications of conductive polymers are also discussed, including their roles in energy storage and conversion (e.g., supercapacitors, lithium-ion batteries (LIBs), and sodium-ion batteries (SIBs)), as well as in organic light-emitting diodes (OLEDs), organic solar cells (OSCs), conductive textiles, healthcare monitoring, and sensors. Future scope and associated challenges have also been mentioned for further development in this field. Full article

In this study, it is shown that an efficient organic optocoupler (OPC) can be fabricated using commercially available and solution-processable organic semiconductors. The transmitter is a single-active-layer organic light-emitting diode (OLED) made from a well-known polyparavinylene derivative, Super Yellow. The receiver is an organic light-emitting diode (OLSD) with a single active layer consisting of a mixture of the polymer donor PTB7-Th and the low-molecular-weight acceptor ITIC; the receiver operates without an applied reverse voltage. OLED and OLSD have the same geometry and simple structure without any interlayers: glass/ITO/PEDOT:PSS/(active layer)/Ca/Al; the OPC is formed by OLED and OLSD which adhere tightly to each other. Despite its simple structure, the OPC showed a current transfer ratio of 0.13%, good linearity, and good dynamic performance: a three-decibel cutoff frequency of 170 kHz and response times to a step change in current at the OPC input of 2 μs. Compared to most organic OPC devices with similar performance parameters, where the transmitter and receiver have complex structures with additional interlayers between the active layers and electrodes and the need to apply a reverse voltage to the receiver, the simple design of our OPC reduces the number of fabrication steps and greatly simplifies the device fabrication process. Full article

Polymers containing π-conjugated segments are a diverse group of large molecules with semiconducting and emissive properties, with strong potential for use as active layers in Organic Light-Emitting Diodes (OLEDs). Stable blue-emitting materials, which are utilized as emissive layers in solution-processed OLED devices, are essential for their commercialization. Achieving balanced charge injection is challenging due to the wide bandgap between the HOMO and LUMO energy levels. This study examines the optical and photophysical characteristics of blue-emitting polymers to contribute to the understanding of the fundamental mechanisms of color purity and its stability during the operation of OLED devices. The investigated materials are a novel synthesized lab scale polymer, namely poly[(2,7-di(p-acetoxystyryl)-9-(2-ethylhexyl)-9H-carbazole-4,4′-diphenylsulfone)-co-poly(2,6-diphenylpyrydine-4,4′-diphenylsulfone] (CzCop), as well as three commercially supplied materials, namely Poly(9,9-di-n-octylfluorenyl-2,7-diyl) (PFO), poly[9,9-bis(2′-ethylhexyl) fluorene-2,7-diyl] (PBEHF), and poly (9,9-n-dihexyl-2,7-fluorene-alt-9-phenyl-3,6-carbazole) (F6PC). The materials were compared to evaluate their properties using Spectroscopic Ellipsometry, Photoluminescence, and Atomic Force Microscopy (AFM). Additionally, the electrical characteristics of the OLED devices were investigated, as well as the stability of the electroluminescence emission spectrum during the device’s operation. Finally, the determined optical properties, combined with their photo- and electro-emission characteristics, provided significant insights into the color stability and selectivity of each material. Full article

A systematic investigation of optical, electrochemical, photophysical, and electrooptical properties of printable green color-emitting polymer (poly(9,9-dioctylfluorene-alt-bithiophene)) (F8T2) and spiro-copolymer (SPG-01T) was conducted to explore their potentiality as an emissive layer for wearable polymer light-emitting diode (PLED) applications. We compared the two photoactive polymers in terms of their spectral characteristics and color purity, as these are the most critical factors for wearable lighting sources and optical sensors. Low-cost, solution-based methods and facile architecture were applied to produce rigid and flexible light-emitting devices with high luminance efficiencies. Emission bandwidths, color coordinates, operational characteristics, and luminance were also derived to evaluate the device’s stability. The tuning of emission’s spectral features by layer thickness variation was realized and was correlated with the interplay between H-aggregates and J-aggregates formations for both conjugated polymers. Finally, we applied the functional green light-emitting PLED devices based on the two studied materials for the detection of Rhodamine 6G. It was determined that the optical detection of the R6G photoluminescence is heavily influenced by the emission spectrum characteristics of the PLED and changes in the thickness of the active layer. Full article

Due to their low cost, good biocompatibility, and ease of structural modification, organic long-persistent luminescence (LPL) materials have garnered significant attention in organic light-emitting diodes, biological imaging, information encryption, and chemical sensing. Efficient charge separation and carrier migration by the host–guest structure or using polymers and crystal to build rigid environments are effective ways of preparing high-performance materials with long-lasting afterglow. In this study, four types of crystalline materials (MODPA: DDF-O, MODPA: DDF-CHO, MODPA: DDF-Br, and MODPA: DDF-TRC) were prepared by a convenient host–guest doping method at room temperature under ambient conditions, i.e., in the presence of oxygen. The first three types exhibited long-lived charge-separated (CS) states and achieved visible LPL emissions with durations over 7, 4, and 2 s, respectively. More surprisingly, for the DDF-O material prepared with PMMA as the polymer substrate, the afterglow time of DDF-O: PMMA was longer than 10 s. The persistent room-temperature phosphorescence effect caused by different CS state generation efficiencies and rigid environment were the main reason for the difference in LPL duration. The fourth crystalline material was without charge separation and exhibited no LPL because it was not a D-A system. The research results indicate that the CS state generation efficiency and a rigid environment are the key factors affecting the LPL properties. This work provides new understandings in designing organic LPL materials. Full article

Poly(3,4-ethylenedioxythiophene)-poly(styrenesulfonate) (PEDOT:PSS) is a commonly used conductive polymer in organic optoelectronic devices. The conductivity and work function of the PEDOT:PSS are two important parameters that significantly determine the performance of the associated optoelectronic device. Traditionally, some solvents were doped in PEDOT:PSS solution or soaked in PEDOT:PSS film to improve its electrical conductivity, but they damaged the integrity of PEDOT:PSS and reduce the film’s work function. Herein, for the first time, we use femtosecond laser irradiation to modify the electrical conductivity and work function of PEDOT:PSS film. We proposed that the femtosecond laser irradiation could selectively remove the superficial insulative PSS, thereby improving the electrical conductivity of the film. The femtosecond laser-irradiated PEDOT:PSS film was further employed as a hole injection layer within cutting-edge perovskite light-emitting diodes (PeLEDs). A maximum luminosity of 950 cd/m² was obtained in PeLEDs irradiated by femtosecond laser light in thin films, which is five times higher than that of the controlled device. Moreover, the external quantum efficiency of the devices was also increased from 4.6% to 6.3%. This work paved a cost-effective way to regulate the electrical properties of the PEDOT:PSS film. Full article

Polyimide (PI) refers to a type of high-performance polymer containing imide rings in the main chain, which has been widely used in fields of aerospace, microelectronic and photonic devices, gas separation technology, and so on. However, traditional aromatic PIs are, in general, the inefficient fluorescence or even no fluorescence, due to the strong inter- and intramolecular charge transfer (CT) interactions causing unavoidable fluorescence quenching, which greatly restricts their applications as light-emitting functional layers in the fabrication of organic light-emitting diode (OLED) devices. As such, the development of fluorescent PIs with high fluorescence quantum efficiency for their application fields in the OLED is an important research direction in the near future. In this review, we provide a comprehensive overview of fluorescent PIs as well as the methods to improve the fluorescence quantum efficiency of PIs. It is anticipated that this review will serve as a valuable reference and offer guidance for the design and development of fluorescent PIs with high fluorescence quantum efficiency, ultimately fostering further progress in OLED research. Full article

Polymer light-emitting diodes (PLEDs) hold immense promise for energy-efficient lighting and full-color display technologies. In particular, blue PLEDs play a pivotal role in achieving color balance and reducing energy consumption. The optimization of layer thickness in these devices is critical for enhancing their efficiency. PLED layer thickness control impacts exciton recombination probability, charge transport efficiency, and optical resonance, influencing light emission properties. However, experimental variations in layer thickness are complex and costly. This study employed simulations to explore the impact of layer thickness variations on the optical and electrical properties of blue light-emitting diodes. Comparing the simulation results with experimental data achieves valuable insights for optimizing the device’s performance. Our findings revealed that controlling the insertion of a layer that works as a hole-transporting and electron-blocking layer (EBL) could greatly enhance the performance of PLEDs. In addition, changing the active layer thickness could optimize device performance. The obtained results in this work contribute to the development of advanced PLED technology and organic light-emitting diodes (OLEDs). Full article

This review comprehensively addresses the developments and applications of polymer materials in optoelectronics. Especially, this review introduces how the materials absorb, emit, and transfer charges, including the exciton–vibrational coupling, nonradiative and radiative processes, Förster Resonance Energy Transfer (FRET), and energy dynamics. Furthermore, it outlines charge trapping and recombination in the materials and draws the corresponding practical implications. The following section focuses on the practical application of organic materials in optoelectronics devices and highlights the detailed structure, operational principle, and performance metrics of organic photovoltaic cells (OPVs), organic light-emitting diodes (OLEDs), organic photodetectors, and organic transistors in detail. Finally, this study underscores the transformative impact of organic materials on the evolution of optoelectronics, providing a comprehensive understanding of their properties, mechanisms, and diverse applications that contribute to advancing innovative technologies in the field. Full article

In this study, fully aromatic polyether sulfones were developed, bearing blue, yellow, and orange–red π-conjugated semiconducting units. Carbazole-, anthracene-, and benzothiadiazole-based fluorophores are copolymerized with a diphenylsulfone moiety. A diphenylpyridine comonomer was additionally utilized, acting as both a solubilizing unit and a weak blue fluorescent group. Using this rationale, fluorescent polyarylethers with high molecular weights, up to 70 kDa, were developed, showing film formation ability and high thermal stability, while preserving excellent solubility in common organic, nonvolatile, and nonchlorinated solvents. Fine-tuning of the emission color was achieved through subtle changes of the comonomers’ type and ratio. Single-chromophore-bearing copolymers emitted in the blue or the yellow region of the visible spectrum, while the dual-chromophore-bearing terpolymers emitted throughout the visible spectrum, resulting in white light emission. Solutions of 20 wt% in polar aprotic solvents at ambient conditions allowed the deposition of fluorescent copolyethers and printing from non-chlorinated solvents. All polyethers were evaluated for their structural and optoelectronic properties, and selected copolymers were successfully used in the emitting layer (EML) of organic light-emitting diode (OLED) devices, using either rigid or flexible substrates. Remarkable color stability was displayed in all cases for up to 15 V of bias voltage. The Commission Internationale de L’Eclairage (CIE) of the fabricated devices is located in the blue (0.16, 0.16), yellow (0.44, 0.50), or white region of the visible spectrum (0.33, 0.38) with minimal changes according to the ratio of the comonomers. The versatile methodology toward semiconducting polyethersulfones for polymer light-emitting diodes (PLEDs) developed herein led to the scaled-up production of luminescent polymers of up to 25 g of high-molecular-weight single batches, demonstrating the effectiveness of this approach as a straightforward tool to facilitate the synthesis of flexible and printable EMLs for large-area PLED coverage. Full article

Poly(9,9-di-n-octylfluorene) (PFO) is a promising material for polymer light-emitting diodes (PLEDs) due to its advantageous properties. To enhance its electron transporting capabilities, diblock polymers were synthesized by attaching polystyrene (PSt) chains of varying lengths to one end of the PFO molecule. In a comparative study with PFO homopolymer, the diblock polymers maintained similar thermal properties, absorption spectra, and photoluminescent stability, while exhibiting slightly deeper lowest unoccupied molecular orbital (LUMO) levels and higher crystallinity. Notably, diblock polymers with shorter polystyrene blocks demonstrated higher electron mobility than the PFO homopolymer and diblock polymers with excessively long polystyrene blocks. These findings suggest that the optimal chain length of the polystyrene block is crucial for maximizing electron mobility, thus offering valuable insights for designing high-performance PLED materials. Full article

Electron and hole transporting layers play a major role in high-performance and stable organic-based optoelectronic devices. This paper demonstrates detailed device engineering of multi-junction organic photovoltaics built on two different metal oxide-based electron and hole transport (buffer) layers prepared by thermal or solution-processed methods. The main focus is on the device processing parameters as well as practical details of preparation of buffer layers to give the research community a clear, step-by-step recipe to successfully replicate and build series and parallel connected multi-junction solution-based organic solar cells for their needs. Here, the recipes and deposition conditions of two metal oxide buffer layers are presented in detail, based on basic commercially available materials and tools, to achieve well-engineered tandem (multi-junction) solution-processed organic solar cells. The buffer layers have appropriate energy levels for electrical selectivity of anode and cathode electrodes, and they are highly stable and chemically compatible with processing of solution-based polymer solar cells. To demonstrate the engineering steps of multi-junction devices, the PCE10:PC70BM blend is used as the active layer for all subcells. Then, to improve the power conversion efficiency of the single-junction photovoltaic device, PCE10:PC70BM blend is used in combination with DPPx:PC70BM with different absorption spectra for bottom and top subcell active layers. An optimized series tandem device with 10.6% power conversion efficiency is demonstrated. Generally, the device structures reported here can also be used for other types of optoelectronic devices, such as light emitting diodes and photodetectors. Full article
