Search Results (31)

This study presents the design, development, and experimental assessment of soft pneumatic actuators for achieving bending motion utilizing vacuum pressure, with their final application to soft robotic grippers. A novel soft actuator design is introduced, satisfying the following design requirements: safe operation without the risk of explosion, the ability to achieve large angular bending while overcoming significant forces, and the use of soft materials that are resistant to material fatigue. A vacuum-driven soft bending actuator (VSBA) was designed, incorporating a cylindrical ribbed bellow geometry and an integrated limiting element within its structure. Two variations of the VSBA were fabricated, each differing in the materials and manufacturing processes employed. The first version employs a cylindrical ribbed bellow made of thermoplastic rubber (TPR), while the other versions utilize heat-shrinkable polymer materials, resulting in an innovative manufacturing process capable of producing actuators in various sizes and shapes. This contributes to the analysis of how actuator geometry affects performance and enables its miniaturization. The performance of the novel VSBAs were experimentally assessed through measuring the bending angle, blocking force, and angular velocity–angle characteristics. The results confirmed a maximum bending angle of 140° corresponding to a bending ratio of 78%, a maximum blocking force of 110 N, and maximum angular velocity of 520°/s at a vacuum pressure of −0.8 bar. Finally, a soft robotic gripper was developed, consisting of three newly designed VSBAs. Experimental assessments demonstrated the gripper’s capability to grasp objects of various shapes, with a maximum holding force of 28 N. Full article

Soft robots with compliant bodies offer safe human–robot interaction as well as adaptability to unstructured dynamic environments. However, the nonlinear dynamics of a soft robot with infinite motion freedom pose various challenges to operation and control engineering. This research explores the motion of a pneumatic soft robot under diverse loading conditions by conducting finite element analysis (FEA) and using machine learning. The pneumatic soft robot consists of two parallel hyper-elastic tubular chambers that convert pneumatic pressure inputs into soft robot motion to mimic an elephant trunk and its motion. The body of each pneumatic chamber consists of a series of bellows to effectively facilitate the expansion, contraction, and bending of the body. The first chamber spans the entire length of the soft robot’s body, and the second chamber spans half of it. This unique asymmetric design enables the soft robot to bend and curl in various ways. Machine learning is used to establish a forward kinematic relationship between the pressure inputs and the motion responses of the soft robot using data from FEA. Accordingly, this research employs an artificial neural network that is trained on FEA data to estimate the reachable workspace of the soft robot for given pressure inputs. The trained neural network demonstrates promising estimation accuracy with an R-squared value of 0.99 and a root mean square error of 0.783. The workspaces of asymmetric double-chamber and single-chamber soft robots were compared, revealing that the double-chamber robot offers approximately 185 times more reachable workspace than the single-chamber soft robot. Full article

This study describes the design, simulation, and development process of a rehabilitation glove driven by soft pneumatic actuators. A new, innovative finger soft actuator design has been developed through detailed kinematic and workspace analysis of anatomical fingers and their actuators. The actuator design combines cylindrical and ribbed geometries with a reinforcing element—a thicker, less extensible structure—resulting in an asymmetric cylindrical bellow actuator driven by positive pressure. The performance of the newly designed actuator for the rehabilitation glove was validated through numerical simulation in open-source software. The simulation results indicate actuators’ compatibility with human finger trajectories. Additionally, a rehabilitation glove was 3D-printed from soft materials, and the actuator’s flexibility and airtightness were analyzed across different wall thicknesses. The 0.8 mm wall thickness and thermoplastic polyurethane (TPU) material were chosen for the final design. Experiments confirmed a strong linear relationship between bending angle and pressure variations, as well as joint elongation and pressure changes. Next, pseudo-rigid kinematic models were developed for the index and little finger soft actuators, based solely on pressure and link lengths. The workspace of the soft actuator, derived through forward kinematics, was visually compared to that of the anatomical finger and experimentally recorded data. Finally, an ergonomic assessment of the complete rehabilitation glove in interaction with the human hand was conducted. Full article

This paper will develop the restoring model of a commercial pneumatic artificial muscle (PAM) based on a McKibben structure, which comprises an elastic element connected with a viscoelastic element in parallel. The elastic element is generated by compressed air inside the rubber bellow; meanwhile, the viscoelasticity is affected by the rubber material. In particular, the viscoelastic property of the rubber material is proposed based on the Maxwell model. Instead of derivative of integer orders, an equation of motion of the fractional model is introduced to better capture the amplitude- and frequency-dependent property of the viscoelasticity of the PAM. The equation expressing the hysteresis loop due to the viscoelasticity of the PAM material will then be analyzed and built. A water cycle algorithm is employed to determine the optimal set of the proposed model. To evaluate the effectiveness of the proposed model, a comparison between the simulation calculated from the proposed model and experimental data is considered under harmonic force excitation. This study’s results give potential insight into the field of system dynamic analysis with the elastic element being PAM. Full article

The present work demonstrates the manufacturing process of a pneumatic bellow actuator with an embedded sensor, utilizing a novel manufacturing approach through the complete use of additive manufacturing techniques, such as direct ink writing (DIW) and traditional fused deposition modeling (FDM) methods. This study is innovative in its integration of a dielectric electroactive polymer (DEAP) structure with sensing electrodes made of conductive carbon grease (CCG), showcasing a unique application of a 3D-printed DEAP with CCG electrodes for combined DEAP sensing and pneumatic actuation. Initial experiments, supported by computational simulations, evaluated the distinct functionality of the DEAP sensor by itself under various pressure conditions. The findings revealed a significant change in capacitance with applied pressure, validating the sensor’s performance. After sensor validation, an additive manufacturing process for embedding the DEAP structure into a soft pneumatic actuator was created, exhibiting the system’s capability for dual sensing and actuation, as the embedded sensor effectively responded to applied actuation pressure. This dual functionality represents an advancement in soft actuators, especially in applications that require integrated and responsive actuation and sensing capabilities. This work also represents a preliminary step in the development of a 3D-printed dual-modality actuator (pneumatic and electrically activated DEAP) with embedded sensing. Full article

This paper presents a study of the vibration isolation properties of pneumatic suspension systems for work machinery seats, with a particular focus on adjustable stiffness. It highlights the contribution that semi-active seat suspension systems make to vibration reduction, ultimately leading to improved passenger comfort levels and increased safety for vehicle users. The primary objectives of the research were twofold: firstly, to identify the key parameters of the apneumatic vibration isolation system; and secondly, to evaluate its performance in improving vibration damping. This entailed the development of a mathematical model that would foreground the movement through simulations based on different initial pressures, thus enabling the accurate prediction of real-life scenarios concerning the vibration-damping characteristics of the seating system, taking into account the different design options available for working machine technology applied at the test bed level, of which the pneumatic isolator is an integral component. In the cognitive process, the verification and validation of the formulated theoretical model play an important role. This approach enables the behaviour of the actual system to be inferred from the results of simulation studies, thus allowing the design of an appropriate vibration control system. By simulating different air bellow pressures, the characteristics of the seat suspension system can be assessed. This study provides valuable insights into optimising the vibration-damping capability of the air suspension system. Full article

A miniature pneumatic bellows device was designed for in-situ testing inside the scanning electron microscope. The device uses a pneumatic actuator to load the specimen and displacement is directly monitored with a linear variable differential transformer sensor. Its application allowed the direct monitoring of microstructural and defect evolution in materials at the micro scale. The data produced by this testing device, in combination with measurements from micro digital image correlation, were successfully used to model the crystal plasticity of a martensitic/bainitic steel at the microstructural length scale. Full article

Presently, mechanical system vibroisolation is becoming increasingly important. One of the new approaches is semi-active vibroisolation using elements capable of changing a selected mechanical property. These include, among others, pneumatic flexible shaft couplings capable of changing torsional stiffness during operation. The main goal of the article is to examine the potential advantages of a newly patented pneumatic coupling over a current type with the same pneumatic element arrangement. For comparison, parameters determinable from static load characteristics were selected. These parameters are maximum twist angle and torque, average torsional stiffness, and the percentage of torque transmitted by the bellows rubber shell. In all cases, the new coupling had better properties. Since the prototype of the new coupling has not yet been produced, its parameters were determined from its mathematical-physical model. The article contains a full procedure to obtain the static load characteristic of a new coupling type, beginning with the determination of air bellows force/height and volume/height characteristics, then optimum sizes of coupling with regards to the operating range of elements, the dependency of element height on the coupling’s twist angle, and finally the computation of the static load characteristic considering isothermal gas compression. The presented procedure can be applied to any pneumatic bellows where the force/height characteristics of different pressures are given. Full article

The development of soft robotics owes much to the field of biomimetics, where soft actuators predominantly mimic the movement found in nature. In contrast to their rigid counterparts, soft robots offer superior safety and human–machine interaction comfort, particularly in medical applications. However, when it comes to the hand rehabilitation exoskeletons, the soft devices have been limited by size and material constraints, unable to provide sufficient tensile strength for patients with high muscle tension. In this paper, we drew inspiration from the muscle structure found in the tail of dragonflies and designed a novel central tendon-based bellows actuator. The experimental results demonstrated that the central tendon-based bellows actuator significantly outperforms conventional pneumatic bellows actuators in terms of mechanical output. The tensile strength of the central tendon-based bellows actuator exceeded that of pneumatic actuators more than tenfold, while adding only 2 g to the wearable weight. This finding suggests that the central tendon-based bellows actuator is exceptionally well-suited for applications demanding substantial pulling force, such as in the field of exoskeleton robotics. With tensile strength exceeding that of pneumatic bellows actuators, this biomimetic design opens new avenues for safer and more effective human–machine interaction, revolutionizing various sectors from healthcare to industrial automation. Full article

Redundant cascade manipulators actuated by pneumatic bellows actuators are passively compliant, rugged and dexterous, making them exceptionally well suited for application in agriculture. Unfortunately, the bellows are notoriously difficult to precisely position. This paper presents a novel control algorithm for the control of a parallel platform actuated by pneumatic bellows, which serves as a module of a cascade manipulator. The algorithm combines a feed-forward controller and a variable-gain I-controller. The mathematical model of the module, which serves as the feed-forward controller, was created by applying two simple regression steps on experimentally acquired data. The gain of the I-controller is linearly dependent on the total reference error, thereby addressing the prevalent problem of “a slow response or excessive overshoot”, which, in the described case, the simple combination of a feed-forward and constant-gain I-controller tends to suffer from. The proposed algorithm was experimentally verified and its performance was compared with two controllers: an ANFIS controller and a constant gain PID controller. The proposed controller has outperformed the PID controller in the three calculated criteria: IAE, ISE and ITAE by more than 40%. The controller was also tested under dynamic loading conditions, showing promising results. Full article

Despite an emerging interest in soft and rigid pneumatic lightweight robots, the pneumatic rotary actuators available to date either are unsuitable for servo pneumatic applications or provide a limited angular range. This study describes the functional principle, design, and manufacturing of a servo pneumatic rotary actuator that is suitable for continuous rotary motion and positioning. It contains nine radially arranged linear bellows actuators with rollers that push forward a cam profile. Proportional valves and a rotary encoder are used to control the bellows pressures in relation to the rotation angle. Introducing freely programmable servo pneumatic commutation increases versatility and allows the number of mechanical components to be reduced in comparison to state-of-the-art designs. The actuator presented is designed to be manufacturable using a combination of standard components, selective laser sintering, elastomer molding with novel multi-part cores and basic tools. Having a diameter of 110 mm and a width of 41 mm, our prototype weighs less than 500 g, produces a torque of 0.53 Nm at 1 bar pressure and a static positioning accuracy of 0.31° with no limit of angular motion. By providing a description of design, basic kinematic equations, manufacturing techniques, and a proof of concept, we enable the reader to envision and explore future applications. Full article

This paper proposes a method for accurate 3D posture sensing of the soft actuators, which could be applied to the closed-loop control of soft robots. To achieve this, the method employs an array of miniaturized sponge resistive materials along the soft actuator, which uses long short-term memory (LSTM) neural networks to solve the end-to-end 3D posture for the soft actuators. The method takes into account the hysteresis of the soft robot and non-linear sensing signals from the flexible bending sensors. The proposed approach uses a flexible bending sensor made from a thin layer of conductive sponge material designed for posture sensing. The LSTM network is used to model the posture of the soft actuator. The effectiveness of the method has been demonstrated on a finger-size 3 degree of freedom (DOF) pneumatic bellow-shaped actuator, with nine flexible sponge resistive sensors placed on the soft actuator’s outer surface. The sensor-characterizing results show that the maximum bending torque of the sensor installed on the actuator is 4.7 Nm, which has an insignificant impact on the actuator motion based on the working space test of the actuator. Moreover, the sensors exhibit a relatively low error rate in predicting the actuator tip position, with error percentages of 0.37%, 2.38%, and 1.58% along the x-, y-, and z-axes, respectively. This work is expected to contribute to the advancement of soft robot dynamic posture perception by using thin sponge sensors and LSTM or other machine learning methods for control. Full article

Soft robotics research has rapidly incorporated Additive Manufacturing (AM) into its standard prototyping repertoire. While numerous publications have highlighted the suitability of AM for producing soft pneumatic actuators, fluidic components, and lightweight structures, their integration into an industry-like robotic arm has not yet been shown. Against this background, a pneumatically actuated robot was developed that incorporates additively manufactured soft structures into rigid articulated hinges that generally allow for integration into today’s industrial production lines. The development of the robot, including pneumatic soft rotary bellows and rotary vane actuators (RVAs), is summarized, and its functionality is proven. It was found that using AM can increase the structural stiffness of robot links to a significant degree as manufacturing-related constraints in topology optimization are largely eliminated. Moreover, it was found that multi-material polyjet printing of soft rotary bellows actuators allows for highly integrated designs that provide low leakage and friction. However, these soft rotary actuators are still inferior in terms of endurance and performance if compared to AM replicas of RVAs. Our work narrows the gap between soft robotics research and today’s industrial applications, may realign research directions, and may provide impulses for the industry towards soft robotics and AM. Full article

Today, we are witnessing an increasing trend in the number of soft pneumatic actuator solutions in industrial environments, especially due to their human-safe interaction capabilities. An interesting solution in this frame is a vacuum pneumatic muscle actuator (PMA) with a bellow structure, which is characterized by a high contraction ratio and the ability to generate high forces considering its relatively small dimensions. Moreover, such a solution is generally very cost-effective since can be developed by using easily accessible, off-the-shelf components combined with additive manufacturing procedures. The presented research analyzes the precision positioning performances of a newly developed cost-effective bellow PMA in a closed-loop setting, by utilizing a Proportional-Integral-Derivative (PID) controller and a Linear Quadratic Regulator (LQR). In a first instance, the system identification was performed and a numerical model of the PMA was developed. It was experimentally shown that the actuator is characterized by nonlinear dynamical behavior. Based on the numerical model, a PID controller was developed as a benchmark. In the next phase, an LQR that involves a nonlinear pregain term was built. The point-to-point positioning experimental results showed that both controllers allow fast responses without overshoot within the whole working range. On the other hand, it was discovered that the LQR with the corresponding nonlinear pregain term allows an error of a few tens of micrometers to be achieved across the entire working range of the muscle. Additionally, two different experimental pneumatic solutions for indirect and direct vacuum control were analyzed with the aim of investigating the PMA response time and comparing their energy consumption. This research contributes to the future development of the pneumatically driven mechatronics systems used for precise position control. Full article

This study developed a soft pneumatic glove actuated by elliptical cross-sectional guided bending bellows to augment finger-knuckle rehabilitation for patients with hand dysfunction. The guided bending bellows actuators (GBBAs) are made of thermoplastic elastomer (TPE) materials, demonstrating the necessary air tightness as a pneumatic actuator. The GBBAs could produce different moments of inertia when increasing internal air pressure drives the GBBAs bending along distinct symmetry planes and exhibits anisotropic kinematic bending performance. Actuated by GBBAs, wearable soft rehabilitation gloves can be used for daily rehabilitation training of hand dysfunction to enhance the range of motion of the finger joint. To control each finger of the gloves independently to achieve the function of manipulating gestures, a multi-channel pneumatic control system is designed, and each air circuit is equipped with an air-pressure sensor to make adjustments based on feedback. Compared with general soft robotic exoskeleton gloves currently used for hand dysfunction, the GBBAs actuated soft gloves have the advantage of enhancing the rehabilitation strength, finger movement range, and multi-action coordination applied with guided bending bellows actuators. Full article
