Tokamak technology, as the cornerstone of nuclear fusion energy, holds immense potential in achieving efficient plasma confinement and high energy densities. To comprehensively map the rapidly evolving landscape of this field, this study employs bibliometric analysis to systematically examine the research and development trends of tokamak technology from 2014 to 2024. The data are drawn from 7702 academic publications in the Scopus database, representing a global research effort. Additionally, the study incorporates 2299 tokamak-related patents from Google Patents over the same period, analyzing their technological trends to highlight the growing significance of tokamak devices. Using the R language and the Bibliometric package, the analysis explores research hotspots, institutional influences, and keyword evolution. The results reveal a multifaceted global landscape: China leads in publication output, and the United States maintains a leading role in citation impacts and technological innovation, with other notable contributions from Germany, Japan, South Korea, and various European countries. Patent trend analysis further reveals the rapid expansion of tokamak applications, particularly with significant innovations in high-temperature superconducting magnets and plasma control technologies. Nevertheless, the study identifies major challenges in the commercialization process, including plasma stability control, material durability, and the sustainability of long-term operations. To address these, the study proposes concrete future directions, emphasizing international collaboration and interdisciplinary integration. These efforts are crucial in accelerating tokamak commercialization, thereby providing a strategic roadmap for researchers, policymakers, and industry stakeholders to advance the global deployment of clean energy solutions. Full article

Negative Ion Source Neutral beam Injection (NNBI), as a critical auxiliary heating system for magnetic confinement fusion devices, directly affects the plasma heating efficiency of tokamak devices through the reliability of its beam source system. The single-shot experiment constitutes a significant experimental program for NNBI. This study addresses the frequent equipment failures encountered by the NNBI beam source system during a cycle of experiments, employing fault tree analysis (FTA) to conduct a systematic reliability assessment. Utilizing the AutoFTA 3.9 software platform, a fault tree model of the beam source system was established. Minimal cut set analysis was performed to identify the system’s weak points. The research employed AutoFTA 3.9 for both qualitative analysis and quantitative calculations, obtaining the failure probabilities of critical components. Furthermore, the F-V importance measure and mean time between failures (MTBF) were applied to analyze the system. This provides a theoretical basis and practical engineering guidance for enhancing the operational reliability of the NNBI system. The evaluation methodology developed in this study can be extended and applied to the reliability analysis of other high-power particle acceleration systems. Full article

The mechanisms by which rotation influences zonal flows (ZFs) in plasma are incompletely understood, presenting a significant challenge in the study of plasma dynamics. This research addresses this gap by investigating the role of non-inertial effects—specifically centrifugal and Coriolis forces—on Geodesic Acoustic Modes (GAMs) and ZFs in rotating tokamak plasmas. While previous studies have linked centrifugal convection to plasma toroidal rotation, they often overlook the Coriolis effects or inconsistently incorporate non-inertial terms into magneto-hydrodynamic (MHD) equations. In this work, we derive self-consistent drift-ordered two-fluid equations from the collisional Vlasov equation in a non-inertial frame, and we modify the Hermes cold ion code to simulate the impact of rotation on GAMs and ZFs. Our simulations reveal that toroidal rotation enhances ZF amplitude and GAM frequency, with Coriolis convection playing a critical role in GAM propagation and the global structure of ZFs. Analysis of simulation outcomes indicates that centrifugal drift drives parallel velocity growth, while Coriolis drift facilitates radial propagation of GAMs. This work may provide valuable insights into momentum transport and flow shear dynamics in tokamaks, with implications for turbulence suppression and confinement optimization. Full article

In axisymmetric fusion devices like tokamaks, the winding of the magnetic field is characterized by its safety profile $q=q_{\mathbf{B}}$. Similarly, the winding of the current density field is characterized by $q_{\mathbf{J}}$. Currently, the relationship between $q_{\mathbf{B}}$ and $q_{\mathbf{J}}$ profiles and their effect on tokamak plasma confinement properties remains unexplored, as the $q_{\mathbf{J}}$ profile is neither computed nor considered. This study presents a reconstruction of the current density winding profile from experimental data in the quiescent H-mode. The topology analysis derived from $(q_{\mathbf{B}},q_{\mathbf{J}})$ was carried out using Hamada coordinates. It shows a large central plasma region unaffected by current filamentation-driven resonant magnetic perturbations, while the outer region harbors a spectrum of magnetic resonant modes, induced by current filaments located within the core plasma, which degrade peripheral confinement. These results suggest a QH-mode signature pattern needing further validation with additional data. Implementing $(q_{\mathbf{B}},q_{\mathbf{J}})$ real-time monitoring could provide insights into tokamak confinement regimes with significant implications. Full article

The paper presents a conceptual study of a neutron source based on a spherical tokamak (ST). The plasma scenario chosen for the ST is non-thermal fusion (hot ion mode), which is extensively used on machines like JET and TFTR deuterium–tritium (DT) experiments, which seems suited for low fusion gain reactors. As demonstrated in experiments, this scenario is a robust tool for neutron production. Starting from a new scaling law of energy confinement tested, approximately, on ST40 spherical tokamak, the parameters of a 15 MW ST DT fusion reactor (ST180) are derived, and a preliminary radial build of the machine is established. Full article

The objective of the proposed research is to develop plasma soft X-ray (SXR) radiation imaging that includes spectral information in addition to standard SXR tomography for the purpose of studying, for example, tungsten transport and its interplay with magnetohydrodynamics (MHD) in tokamak plasmas in an ITER-relevant approach. The SXR radiation provides valuable information about both aspects, particularly when measured with high spatial and temporal resolution and when tomographic reconstructions are performed. The spectral data will facilitate the tracking of both light and high-Z impurities. This approach is pertinent to both the advancement of a detailed understanding of physics and the real-time control of plasma, thereby preventing radiative collapses. The significance of this development lies in its ability to provide three-dimensional plasma tomography, a capability that extends beyond the scope of conventional tomography. The utilization of two-dimensional imaging capabilities inherent to Gas Electron Multiplier (GEM) detectors in a toroidal view, in conjunction with the conventional poloidal tomography, allows for the acquisition of three-dimensional information, which should facilitate the study of, for instance, the interplay between impurities and MHD activities. Furthermore, this provides a valuable opportunity to investigate the azimuthal asymmetry of tokamak plasmas, a topic that has rarely been researched. The insights gained from this research could prove invaluable in understanding other toroidal magnetically confined plasmas, such as stellarators, where comprehensive three-dimensional measurements are essential. To illustrate, by attempting to gain access to anisotropic radiation triggered by magnetic reconnection or massive gas injections, such diagnostics will provide the community with enhanced experimental tools to understand runaway electrons (energy distribution and spatial localization) and magnetic reconnection (spatial localization, speed…). This work forms part of the optimization studies of a detecting unit proposed for use in such a diagnostic system, based on GEM technology. The detector is currently under development with the objective of achieving the best spatial resolution feasible with this technology (down to approximately 100 µm). The diagnostic design focuses on the monitoring of photons within the 2–15 keV range. The findings of the optimization studies conducted on the amplification stage of the detector, particularly with regard to the geometrical configuration of the GEM foils, are presented herein. The impact of hole shape and spacing in the amplifying foils on the detector parameters, including the spatial size of the avalanches and the electron gain/multiplication, has been subjected to comprehensive numerical analysis through the utilization of Degrad (v. 3.13) and Garfield++ (v. bd8abc76) software. The results obtained led to the identification of two configurations as the most optimal geometrical configurations of the amplifying foil for the three-foil GEM system for the designed detector. The first configuration comprises cylindrical holes with a diameter of 70 μm, while the second configuration comprises biconical holes with diameters of 70/50/70 μm. Both configurations had a hole spacing of 120 μm. Full article

Turbulence and transport phenomena play a crucial role in the confinement and stability of tokamak plasmas. Turbulent fluctuations in certain physical quantities, such as density or temperature fluctuations, can have a wide range of spatial scales, and understanding their correlation length is important for predicting and controlling the behavior of the plasma. The correlation length in the radial direction is identified as the critical length in real space. The dynamics in real space are of significant interest because transport in configuration space is primarily focused on them. When investigating transport caused by the $\mathbf{E}\times \mathbf{B}$ drift, the correlation length in real space represents the size of $\mathbf{E}\times \mathbf{B}$ whirls. It was numerically discovered that in drift wave turbulence, this length is inversely proportional to the normalized mode number of the fastest growing mode relative to the drift frequency. Considerable time was required before a proper analytical derivation of this condition was accomplished. Therefore, a connection has been established between phenomena occurring in real space and those occurring in k-space. Although accompanied by a turbulent spectrum in k-space with a substantial width, transport in real space is uniquely determined by the correlation length, allowing for accurate transport calculations through the dynamics of a single mode. Naturally, the dynamics are subject to nonlinear effects, with resonance broadening in frequency being the most significant nonlinear effect. Thus, mode number space is once again involved. Resonance broadening leads to the detuning of waves from particles, permitting a fluid treatment. It should be emphasized that the consideration here involves the total electric field, including the induction part, which becomes particularly important at higher beta plasmas. Full article

Processes associated with plasma self-organization in tokamaks are presented in the possible logical sequence. The resulting picture of physical processes in self-organized plasmas is predicted based on the nonrequiibrium thermodynamic approach, which uses the Smoluchowski-type equation for the energy balance. The self-organization of magnetized plasma leads to the formation of the universal MHD structure, where the normalized pressure profiles are similar. Finally, experimental confirmation of the proposed physical picture in magnetic fusion facilities is given. Full article

After a vacuum failure in a tokamak, plasma runaway or plasma disruptions frequently occur during plasma recovery, causing difficulties in rebuilding a well-confined collisional plasma. In this work, the impurity behavior during plasma recovery after a vacuum failure in the 2019 spring campaign of the Experimental Advanced Superconducting Tokamak (EAST) was studied by analyzing the spectra recorded by fast-time-response extreme ultraviolet (EUV) spectrometers with 5 ms/frame. During the plasma current ramp-up in recovery discharges, a high content of the low-Z impurities of oxygen and carbon was found, i.e., dozens of times higher than that of normal discharges, which may have caused the subsequent runaway discharges. The electron temperature in the recovery discharge may have dropped to less than 75 eV when the collisional plasma quenched to the runaway status, based on the observable impurity ions in the two cases. Therefore, the lifetime of collisional plasma in the recovery discharge, τ_c, was deduced from the lifetime of H- and He-like oxygen and carbon ions identified from EUV spectra. It was found that, after several discharges with real-time lithium granule injection, the runaway electron flux and O⁺ influx reduced to 45% and 20%, respectively. Meanwhile, the lifetime of confined plasma was extended from 113 ms to 588 ms, indicating the effective suppression of impurities and runaway electrons and improvement in plasma performance by real-time lithium granule injection. The results in this work provide valuable references for the achievement of first plasma in future superconducting fusion devices such as ITER and CFETR. Full article

The China Fusion Engineering Test Reactor (CFETR), a superconducting magnetic confinement tokamak fusion reactor, will develop a high-performance torus cryopump to pump torus plasma exhaust gas. The inlet valve is one of the key components of the cryopump, and it is used to isolate the cryopump from the plasma for regeneration, to control the pumping speed of the cryopump, and to operate as a pressure relief valve in case of a failure, such as the cryopipe breaking inside the cryopump chamber. This paper presents a novel inlet valve. Ensuring that the design of the inlet valve meets the above requirements will be a challenge. In order to verify the reliability of the inlet valve, its critical components are analyzed and optimized by the Finite Element Method. The effect of the stroke of the inlet valve on pumping performance is then estimated by the Monte Carlo Method, and the pressure profile in the whole flow field is studied to predict the cryopump’s behavior. Finally, the seismic capacity of the optimized inlet valve is analyzed, and the mechanical performance of the inlet valve is shown to meet CFETR design criteria. These design and analysis results will provide technical support and references for the development of the CFETR torus cryopump. Full article

In this study, we observed magnetohydrodynamic (MHD) activity of the spherical tokamak Globus-M2 which led to a deterioration in plasma confinement, such as a transition from the H-mode to L-mode, or even disruption. This instability was found to be tearing modes, which are a result of the formation of magnetic islands in plasma and which impose limits on plasma pressure. The width and velocity of the islands are key parameters that determine their impact on plasma confinement. The Doppler backscattering (DBS) method has been shown to be effective for the study of MHD activity. This method was employed on the spherical tokamak Globus-M2, together with an array of magnetic probes, to study the tearing modes. The available DBS systems allowed for simultaneous measurements from half of the minor radius to the separatrix. The results are presented of our investigation of tearing modes that lead to a transition from the H-mode or a disruption. Comparative analysis was conducted of the observed tearing modes and the influence of different plasma parameters on their development. Full article

Mathematical modelling of heating and current drive as well as yields and distributions of fusion products in a magnetically confined plasma subject to neutral beam injection requires, in turn, modelling of distributions of fast ions, which is a complex task including calculations of the source of suprathermal particles, i.e., the number of fast ions occurring in unit volume during unit time owing to the injection of fast atoms. The knowledge of the magnetohydrodynamic equilibrium, beam injection geometry and spatial distribution of the magnetic field are the necessary prerequisites. Explicit general analytical formulae for the source of fast ions have been obtained by two different methods. In addition, a method of statistical modelling is presented. Calculations of spatial and angular distributions of the fast ion source for a tokamak and verifications of the obtained results have been performed by a number of methods. Full article

A simple model is presented to describe how the radio frequency electromagnetic field modifies the plasma density the antenna faces in tokamaks. Aside from “off-the-shelf” equations standardly used to describe wave-plasma interaction relying on the quasilinear approach, it invokes the ponderomotive force in presence of the confining static magnetic field. The focus is on dynamics perpendicular to the $B_o$ magnetic field. Stronger fields result in density being pushed further away from the launcher and in stronger density asymmetry along the antenna. Full article

The EU-DEMO must demonstrate the possibility of generating electricity through nuclear fusion reactions. Moreover, it must denote the necessary technologies to control a powerful plasma with adequate availability and to meet the safety requirements for plant licensing. However, the extensive radioactive materials inventory, the complexity of the plant, and the presence of massive energy sources require a rigorous safety approach to fully realize fusion power’s environmental advantages. The Tokamak building barrier design must address two main issues: radioactive mass transport hazards and energy-related or pressure/vacuum hazards. Safety studies are performed in the frame of the EUROfusion Safety And Environment (SAE) work package to support design improvement and evaluate the thermal-hydraulic behavior of confinement building environments during accident conditions in addition to source term mobilization. This paper focuses on developing a thermal-hydraulic model of the EU-DEMO Tokamak building. A preliminary model of the heat ventilation and air conditioning system and vent detritiation system is developed. A loss-of-coolant accident is studied by investigating the Tokamak building pressurization, source term mobilization, and release. Different nodalizations were compared, highlighting their effects on source term estimation. Results suggest that the building design should be improved to maintain the pressure below safety limits; some mitigative systems are preliminarily investigated for this purpose. Full article

ITER is an international collaborative effort towards the realization of fusion energy via the magnetic confinement concept. Two of the equatorial ports in the facility are dedicated to the testing of tritium breeding concepts, which is essential for the tritium self-sufficiency of future fusion reactors. The concerned Test Blanket System (TBS) consists of a Test Blanket Module (TBM) residing inside the TBM–Port Plug (TBM-PP) and its associated ancillary systems in the Tokamak facility. In this paper, the results of a full suite of nuclear analyses concerning the shielding performance of the Pipe Forest (PF) and Bioshield Plug (BP), to reflect on the evolution of their designs, are discussed. On the BP side, the design of the peripheral part has been reviewed considering the ventilation openings and butterfly doors, to assure the design compliance with the Radiation Map (RadMap) requirements for the neutron flux in the Port Cell (PC), behind the BP. On the PF side, the pipes routing and maintenance corridor door have been redesigned, by taking into account results from previously concluded nuclear analyses. The neutronics model was developed from CAD and was used to perform transport simulations in two plasma modes: on and off. For plasma-on mode, the plasma neutron field in the Port Interspace (PI) as well as behind the BP was assessed and few shielding options were explored. The responses due to decay neutrons from ¹⁷N in activated cooling water were also considered. For the plasma-off mode, the focus was shifted to further refine the ShutDown Dose Rate (SDDR) maps, which is of importance for maintenance operations that are foreseen to take place at various stages of ITER operation, in particular following the FPO-1, FPO-2, and Short operation scenarios. In addition, detailed activation analyses were carried out to provide a provisional waste classification. Full article
