Search Results (19)

This study presents an experimental and numerical investigation into the stress field in cylinders manufactured from photosensitive resin using the Masked Stereolithography (MSLA) technique. For material characterization, tensile and bending test data from resin specimens were utilized. The stress field in resin disks was experimentally analyzed using photoelasticity and Digital Image Correlation (DIC) methods, subjected to compressive loads, according to the cylinder–plane contact model. Images were captured during the experiments using polarizing film and a low-cost CPL lens, coupled to a smartphone. The experimental results were compared with numerical and analytical simulations, where the formation of fringes and regions indicating the direction and magnitude of normal and shear stresses were observed, with variations ranging from 0.6% to 8.2%. The convergence of the results demonstrates the feasibility of using parts produced with commercially available photosensitive resin on non-professional printers for studying contact theory and stress fields. In the future, this methodology is intended to be applied to studies on stress in gears. Full article

In this study, the fabrication of microfluidic chips through the bonding of poly (methyl methacrylate) (PMMA) boards featuring designed patterns to create a three-dimensional sandwich structure with embedded microchannels was explored. A key focus was optimization of the interface quality of bonded PMMA pairs by adjusting the solvent, such as such as acetone, alcohol, and their mixture. Annealing was conducted below 50 °C to leverage the advantages of low-temperature bonding. Because of the differences in the chemical reactivity of PMMA toward acetone, alcohol, and their combinations, the resulting defect densities at the bonding interfaces differed significantly under low-temperature annealing conditions. To achieve the optimal sealing integrity, bonding pressures of 30 N, 40 N, and 50 N were evaluated. The interface was analyzed through microstructural examination via optical microscopy and stress measurements were determined using digital photoelasticity, while the bonding strength was assessed through tensile testing. Full article

This study investigates the impact of various experimental parameters on the reflective photoelastic coating technique used to measure the stress and strain in model soil particles. The focus is directed towards three pivotal parameters: the choice of adhesive for the photoelastic coating, the inherent properties of the light source, and the configuration of the camera for color image analysis. Through a series of uniaxial compression tests on consistently crafted model soil particles, a notable relationship emerges between the adhesive’s shear strength, its viscosity, and the uniformity of the photoelastic response. While the light source’s characteristics and camera adjustments hold significance, their influence on the consistency of the response is comparatively subtle. Consequently, the adhesive’s role is underscored as instrumental in influencing the photoelastic response, offering valuable insights for subsequent research endeavors utilizing the reflective photoelastic technique. Full article

The degree of quality of thermoplastic injection-molded parts can be established based on their weight, appearance, and defects. However, the conditions of the injection process may induce effects on the mechanical performance of the injected parts, and the residual stresses can cause cracks or early failures when an external load or force is applied. To evaluate these mechanical behaviors, different experimental techniques have been reported in the literature, where digital photoelasticity has stood out both for being a non-contact technique and for achieving quantitative results through sophisticated computational algorithms. Against this background, our proposal consists of analyzing the overall residual stress distribution of parts injected under different molding conditions by using digital photoelasticity. In this case, the specimens are subjected to bending strength tests to identify possible effects of the injection process conditions. The findings show that, at mold temperatures of 80 °C, flow-induced residual stresses increase with packing pressure. However, these internal stress levels do not affect the external load applied by the mechanical bending test, while the mass injected at higher levels of packing pressure helps to increase the bending strength of the injected part. At lower mold temperatures (50 °C), the mechanical strength of the injected part is slightly reduced, possibly due to a lower effect of the packing pressure. Full article

Particle locations determine the whole structure of a granular system, which is crucial to understanding various anomalous behaviors in glasses and amorphous solids. How to accurately determine the coordinates of each particle in such materials within a short time has always been a challenge. In this paper, we use an improved graph convolutional neural network to estimate the particle locations in two-dimensional photoelastic granular materials purely from the knowledge of the distances for each particle, which can be estimated in advance via a distance estimation algorithm. The robustness and effectiveness of our model are verified by testing other granular systems with different disorder degrees, as well as systems with different configurations. In this study, we attempt to provide a new route to the structural information of granular systems irrelevant to dimensionality, compositions, or other material properties. Full article

The bonding structure is affected by environmental loads during use, causing internal stress in the adhesive layer, which leads to the debonding and expansion of the bonding layer. Therefore, it is important to accurately measure the stress distribution of the bonding layer to assess the life of the bonding structure. In this study, based on the transmission and reflection terahertz time-domain spectroscopy (THz-TDS) technique, the stress optical coefficients of a silicone adhesive were measured, and the calculation models of the transmission and reflection stress optical coefficients were derived. In the reflection calculation model, the caliper THz thickness measurement method was proposed to compensate for the thickness change of the silicone adhesive, under tensile stress. Under the transmission THz-TDS stress optical coefficient calculation model, the stress optical coefficient C of the silicone adhesive is 0.1142 ± 0.0057 MPa⁻¹, and the stress optical coefficient C of the reflective system is 0.1135 ± 0.0051 MPa⁻¹. The test results show that the reflective THz-TDS can also be used to measure the optical stress coefficient of the material, which compensates for the shortcomings of the traditional transmission measurement method, and lays a foundation for the characterization of the internal stress of the adhesive layer of the adhesive structure. Full article

The sense of touch is fundamental for a one-to-one mapping between the environment and a robot that physically interacts with the environment. Herein, we describe a tactile fingertip design that can robustly detect interaction forces given data collected from a camera. This design is based on the photoelastic effect observed in silicone matter. Under the force applied to the silicone rubber, owing to the stress-induced birefringence, the light propagating within the silicone rubber is subjected to the angular phase shift, where the latter is proportional to the increase in the image brightness in the camera frames. We present the calibration and test results of the photoelastic sensor design on a bench using a robot arm and with a certified industrial force torque sensor. We also discuss the applications of this sensor design and its potential relationship with human mechano-transduction receptors. We achieved a force sensing range of up to 8 N with a force resolution of around 0.5 N. The photoelastic tactile fingertip is suitable for robot grasping and might lead to further progress in robust tactile sensing. Full article

Our study investigated the partially degenerate intermodal four-wave mixing (IM-FWM) process in nonlinear multimode optical fibers with strain-induced birefringence. The difference in the refractive index along the two orthogonal directions was due to the photoelastic effect that occurred when the fiber under test (FUT) was subjected to uniformly applied diameter stress caused by winding on a cylinder of a given diameter. Our work analyzed how the nonlinear frequency conversion and the output modal field profiles depended on the degree of birefringence in FUT. The experimental results significantly affected the order of the excited moduli in fiber sections characterized by different amounts of birefringence. We also checked the efficiency of the FWM process for different polarizations of the pump beam to determine those for which the FWM process was most effective for the 532 nm sub-nanosecond pulses. More than 30% conversion efficiency was obtained for the FUTs with a length of tens of centimeters. Full article

The light polarization properties provide relevant information about linear–optical media quality and condition. The Stokes–Mueller formalism is commonly used to represent the polarization properties of the incident light over sample tests. Currently, different Stokes Polarimeters are mainly defined by resolution, acquisition rate, and light to carry out accurate and fast measurements. This work presents the implementation of an automatic Stokes dynamic polarimeter to characterize non-biological and biological material samples. The proposed system is configured to work in the He-Ne laser beam’s reflection or transmission mode to calculate the Mueller matrix. The instrumentation stage includes two asynchronous photoelastic modulators, two nano-stepper motors, and an acquisition data card at 2% of accuracy. The Mueller matrix is numerically calculated by software using the 36 measures method without requiring image processing. Experiments show the efficiency of the proposed optical array to calculate the Mueller matrix in reflection and transmission mode for different samples. The mean squared error is calculated for each element of the obtained matrix using referenced values of the air and a mirror. A comparison with similar works in the literature validates the proposed optical array. Full article

The aim of this article was to compare the biomechanical properties of commercial composites containing different photoinitiators: Filtek Ultimate (3M ESPE) containing camphorquinone (CQ); Estelite Σ Quick (Tokuyama Dental) with CQ in RAP Technology^®; Tetric EvoCeram Bleach BLXL (Ivoclar Vivadent AG) with CQ and Lucirin TPO; and Tetric Evoceram Powerfill IVB (Ivoclar Vivadent AG) with CQ and Ivocerin TPO. All samples were cured with a polywave Valo Lamp (Ultradent Products Inc.) with 1450 mW/cm². The microhardness, hardness by Vicker’s method, diametral tensile strength, flexural strength and contraction stress with photoelastic analysis were tested. The highest hardness and microhardness were observed for Filtek Ultimate (93.82 ± 17.44 HV), but other composites also displayed sufficient values (from 52 ± 3.92 to 58,82 ± 7.33 HV). Filtek Ultimate not only demonstrated the highest DTS (48.03 ± 5.97 MPa) and FS (87.32 ± 19.03 MPa) but also the highest contraction stress (13.7 ± 0.4 MPa) during polymerization. The TetricEvoCeram Powerfill has optimal microhardness (54.27 ± 4.1 HV), DTS (32.5 ± 5.29 MPa) and FS (79.3 ± 14.37 MPa) and the lowest contraction stress (7.4 ± 1 MPa) during photopolymerization. To summarize, Filtek Ultimate demonstrated the highest microhardness, FS and DTS values; however, composites with additional photoinitiators such as Lucirin TPO and Ivocerin have the lowest polymerization shrinkage. These composites also have higher FS and DTS and microhardness than material containing CQ in Rap Technology. Full article

This work aims to explore the interaction between water and ion-exchanged aluminosilicate glass. The surface mechanical properties of ion-exchanged glasses after different hydration durations are investigated. The compressive stress and depth of stress layer are determined with a surface stress meter on the basis of photo-elasticity theory. The hardness and Young’s modulus are tested through nanoindentation. Infrared spectroscopy is used to determine the variation in surface structures of the glass samples. The results show that hydration has obvious effects on the hardness and Young’s modulus of the raw and ion-exchanged glasses. The hardness and Young’s modulus decrease to different extents after different hydration times, and the Young’s modulus shows some recovery with the prolonging of hydration time. The ion-exchanged glasses are more resistant to hydration. The tin side is more resistant to hydration than the air side. The results are expected to serve as reference for better understanding the hydration process of ion-exchanged glass. Full article

The successful restoration of teeth requires a good connection between the inlay and natural tissue. A strong bond may improve retention and reinforce tooth structure. The purpose of this study was to evaluate the influence of cement layer thickness on contraction stress generated during photopolymerization, and to determine the changes in stress state of the cement occurring during aging in water (over 84 days). Two cements were used: resin composite cement (NX3) and self-adhesive resin cement (Maxcem Elite Chroma). A cylindrical sample made of CuZn alloy was used to imitate the inlay. The stress state was measured by photoelastic analysis. The contraction stress of the inlay restoration was calculated for cement layer thicknesses of 25 µm, 100 µm, 200 µm, and 400 µm. For both tested materials, the lowest contraction stress was observed for the thinnest layer (25 µm), and this increased with thickness. Following water immersion, a significant reduction in contraction stress was observed due to hygroscopic expansion. Applying a thin layer (approximately 25 µm) of composite and self-adhesive resin cements resulted in high levels of expansion stresses (over −6 MPa) after water aging. Full article

This study is a contribution to our understanding of the mechanical behaviour of dental implants through the use of the finite element and the photoelastic methods. Two internal connection and bone level dental implants with different design have been analysed (M-12 by Oxtein S.L., Zaragoza, Spain, and ASTRA, from Dentsply Sirona, Charlotte, NC, USA), evaluating the stress distribution produced by axial stresses and a comparison has been established between them, as well as between the two methods used, in order to validate the adopted hypotheses and correlate the numerical modelling performed with experimental tests. To load the implant in laboratory testing, a column was placed, such that the loading point was about 9.3 mm from the upper free surface of the resin plate. This column connects the implant with the weights used to define the test load. In turn, support for both plates was achieved by two 6 mm bolts 130 mm apart and located on a parallel line with the resin (flush with the maximum level of the implant), at a depth of 90 mm. The results obtained with both methods used were similar enough. The comparison of results is fundamentally visual, but ensures that, at least in the range of forces used, both methods are similar. Therefore, the photoelastic method can be used to confirm in a real way the virtual conditions of the finite element models, with the implications in the investigation of dental implants that this entails. Full article

This paper aimed to perform systematical study on the distribution of landslide thrust in pile-anchor support system, which has been a widely applicable treatment method in landslide control with safety, highly efficiency and adaptation. The advantage of photoelastic technique is visualization of strain and stress fields, therefore photoelastic model tests are conducted to show the distribution of landslide thrust in pile-anchor structure before failure in landslide. The effects of different materials and pile lengths are investigated by 6 photoelastic test cases under different loading conditions. It can be found from quantitative analysis of experimental results that load proportion of anchor would increase gradually with the decrease of pile embedded depth or the increase of landslide thrust force. Meanwhile, landslide thrust distribution in pile-anchor structure is directly affected by the stiffness of piles. The pile-anchor structure is significantly better at reducing bending moment value and optimizing bending moment distribution of pile. Finally, some theoretical analysis and design suggestions are proposed based on the experimental study. Full article

The effect of initial granular structural conditions on load transmission patterns was experimentally investigated. Two types of granular structures were prepared by laminating cylindrical model particles of different diameters, to which photoelastic sheets were attached. Two-dimensional, reflective photoelasticity tests were performed under two granular conditions: (1) a uniform structure without initial defects and (2) with initial local imperfections at the bottom of the granular assembly. Two granular assemblies were tested for uniaxial compressive loading and shallow foundation loading conditions. For macroscopic analyses of the load–displacement relationship, the photoelastic response of individual particles was measured to microscopically observe the distribution of the main contact force chains within each granular assembly. Furthermore, the effect of initial local defects on the bearing capacity of granular assemblies was examined by confirming particle movement and the expansion of initial local defects in the granular assembly via particle image velocimetry (PIV). As a result, a completely different form of internal contact force chain was developed from the beginning of loading to the final failure stage, depending upon whether or not initial local instability existed in the granular assembly. In particular, a significant effect on the bearing capacity was found under shallow foundation loading conditions. Full article
