Search Results (22)

The development of holography has facilitated significant advancements across a wide range of disciplines. A phase-only spatial light modulator (SLM) plays a crucial role in realizing digital holography, typically requiring a phase mask as its input. Non-iterative (NI) algorithms are widely used for phase mask generation, yet they often fall short in delivering precise solutions and lack adaptability in complex scenarios. In contrast, the Simulated Annealing (SA) algorithm provides a global optimization approach capable of addressing these limitations. This study investigates the integration of NI algorithms with the SA algorithm to enhance the optimization of phase mask generation in digital holography. Furthermore, we examine how adjusting annealing parameters, especially the cooling strategy, can significantly improve system optimization performance and symmetry. Notably, we observe a considerable improvement in the efficiency of the SA algorithm when non-iterative methods are employed to generate the initial phase mask. Our method achieves a perfect representation of the symmetry in desired light fields. The efficacy of the optimized phase masks is evaluated through optical tomographic measurements using two-dimensional mutually unbiased bases (MUBs), with the resulting average similarity reaching 0.99. These findings validate the effectiveness of our methodin optimizing phase mask generation and underscore its potential for high-precision optical mode recognition and analysis. Full article

A spatial light modulator (SLM) is a key element in several applications, but it is subject to surface deformation due to manufacturing imperfections or environmental factors. Therefore, the current study aims to analyze and compensate for such deformations in a phase-only SLM using a Michelson interferometer. The recorded interferogram represents the interference between the wavefront reflected from the SLM surface (object wave) and a reference wave. Noise in the recorded interferogram can degrade the accuracy of phase measurements. Various digital filtering techniques were applied to improve the signal-to-noise ratio (SNR) of the interferogram. The filtered interferogram enabled accurate phase extraction through Fourier transform processing and side peak selection using a spatial carrier frequency method. Additionally, phase errors caused by the tilt of the reference beam were corrected. Thereafter, the conjugate of the corrected phase distribution was used to calculate a phase-only computer-generated hologram (CGH), which was displayed on the SLM to compensate for surface deformations. The effectiveness of the proposed compensation procedure was confirmed by a second phase measurement, which demonstrated improved SLM performance. This study highlights the impact of combining the interferometric techniques with digital processing for precise surface deformation analysis. Full article

A portable incoherent digital holography system without a polarization filter or a refractive lens was developed. Phase-shifted self-interference incoherent holograms of light diffracted from an object were generated without attenuation due to a polarization filter using two polarization-sensitive phase-only spatial light modulators (TPP-SLMs). The number of optical elements in filter-free lens-free incoherent digital holography was reduced to make the system compact and portable. Experiments were conducted using the developed digital holography system set on a tripod stand and objects illuminated by a light-emitting diode. Full article

Airy beams showing curved paths have found extensive applications in fields such as optical trapping, biomedical analysis, and material processing. Despite their utility, dynamic control of Airy beams poses a significant challenge. This work investigates the experimental realization of dynamic steering of Airy beams by utilizing computer-generated holograms with phase-amplitude encoding on a phase-only spatial light modulator (SLM). We successfully generated and controlled Airy beams by imposing dynamic phase masks that manipulated both the phase and amplitude of the field, which sets our approach apart from conventional methods with only phase manipulation. By directly encoding in situ such a hologram and transferring it to an SLM, we are able to control the initial position and rotational orientation of Airy beams without relying on mechanical movement or traditional optical setups involving lenses and apertures. Generating Airy beams in any initial position and rotational direction is anticipated to significantly impact applications such as optical trapping, optical communication, and biomedical imaging by providing a flexible platform for dynamic Airy beam manipulation. Full article

Traditional synthetic-aperture radar (SAR) imaging, while adept at capturing stationary scenes with clarity, often results in the blurring of moving targets due to Doppler spectrum disparities. To overcome this, this study introduces an innovative optical approach for imaging moving targets. By employing a spatial light modulator (SLM), the phase information of SAR data can be modulated onto a light beam. Then, the light propagation path is meticulously designed to take advantage of the free propagation of light to compensate for the phase differences in SAR data, thereby achieving focal clarity. Simulations and experimental validations have demonstrated that this method surpasses traditional digital imaging techniques in terms of focusing precision. Additionally, the processing delay is only as long as the time taken for light propagation. The optical path is simple, avoiding complex assembly and alignment. This novel approach opens up new possibilities for the SAR imaging of moving targets, offering potential applications in moving target extraction, separation, and velocity estimation. Full article

An oblique-incidence interferometric measurement method is proposed to measure and adjust optical surfaces with a liquid-crystal-on-silicon spatial light modulator (LCoS-SLM). The optical system only consists of an interferometer and an LCoS-SLM with precision mounts. It could reduce the measuring cost and time consumption due to the programmable function of the LCoS-SLM and offer the ability to align the optical system. The oblique-incidence measurement theory and optical system adjustment method are established based on an off-axis paraboloid model. The ray-tracing program to calculate the compensation phase map in the measurement is proposed with math models. In the optical alignment step, the off-axis paraboloid model is used to apply the LCoS-SLM as a phase compensator to generate a focusing spot or light spot array to adjust the measured optical surface. And in the interferometric measurement step, the calculated compensation phase map from the ray-tracing calculation is loaded on the LCoS-SLM using the same optical setup as the optical alignment step without any mechanical adjustment. Two interference measurement experiments of typical optical surfaces were carried out to verify the accuracy of the measuring system. Full article

The increasing enhancement in the modulation accuracy of spatial light modulators has garnered significant attention towards real-time control technology for light fields based on these modulators. It has been demonstrated that this technology possesses a remarkable capability to generate vector beams with arbitrary complex amplitude distributions. Nevertheless, past studies indicate that the generation of only one vector beam at a time has been observed. The simultaneous generation of numerous vector light fields can give rise to several challenges, including compromised picture quality, limited single-mode operation, and intricate optical path configurations. In pursuit of this objective, we present a novel methodology that integrates the coding methodology of modified off-axis interferometric holography with the idea of optical superposition. This technique facilitates the concurrent generation of several vector beams. In this study, we present a demonstration of the simultaneous creation of twelve vector beams using a single spatial light modulator (SLM) as a proof of concept. Significantly, this technology has the ability to generate an unlimited quantity of vector light fields concurrently under the assumption that the resolution of the SLM does not impose any limitations. The findings indicate that the imaging quality achieved by this technology is of a high standard. Furthermore, it is possible to separately control the beam waist radius, topological charge, polarization order, and extra phase of each beam. Full article

Micro-fabrication based on structured-beam-assisted Two-Photon Polymerization (2 PP) provides a rapid and flexible method for the manufacture of microstructures with complex morphologies. The tunable Abruptly Autofocusing Vortex (AAFV) beams were designed theoretically and generated experimentally based on a single-phase-only Spatial Light Modulator (SLM). Their specific spatial intensity distributions were further utilized to assist the fabrication of a bowl-shaped Three-Dimensional (3D) micro-trap array via 2 PP with a one-step exposure technique. Finally, the fabricated microstructures act as a novel tool for the trapping and spatial positioning of micro-particles with different diameters, which shows potential applications in fiber optics and cell study. Full article

Multi-focal laser direct writing (LDW) based on phase-only spatial light modulation (SLM) can realize flexible and parallel nanofabrication with high-throughput potential. In this investigation, a novel approach of combining two-photon absorption, SLM, and vector path-guided by scalable vector graphics (SVGs), termed SVG-guided SLM LDW, was developed and preliminarily tested for fast, flexible, and parallel nanofabrication. Three laser focuses were independently controlled with different paths, which were optimized according to the SVG to improve fabrication and promote time efficiency. The minimum structure width could be as low as 81 nm. Accompanied by a translation stage, a carp structure of 18.10 μm × 24.56 μm was fabricated. This method shows the possibility of developing LDW techniques toward fully electrical systems, and provides a potential way to efficiently engrave complex structures on nanoscales. Full article

Limited by the low space-bandwidth product of the spatial light modulator (SLM), it is difficult to realize multiview holographic three-dimensional (3D) display. To conquer the problem, a method based on the holographic optical element (HOE), which is regarded as a controlled light element, is proposed in the study. The SLM is employed to upload the synthetic phase-only hologram generated by the angular spectrum diffraction theory. Digital grating is introduced in the generation process of the hologram to achieve the splicing of the reconstructions and adjust the position of the reconstructions. The HOE fabricated by the computer-generated hologram printing can redirect the reconstructed images of multiview into multiple viewing zones. Thus, the modulation function of the HOE should be well-designed to avoid crosstalk between perspectives. The experimental results show that the proposed system can achieve multiview holographic augmented reality (AR) 3D display without crosstalk. The resolution of each perspective is 4K, which is higher than that of the existing multiview 3D display system. Full article

A pulse burst optical system has been developed, able to alter an energetic, ultrafast 10 ps, 5 kHz output pulse train to 323 MHz intra-burst frequency at the fundamental 5 kHz repetition rate. An optical delay line consisting of a beam-splitting polariser cube, mirrors, and waveplates transforms a high-energy pulse into a pulse burst, circulating around the delay line. Interestingly, the reflected first pulse and subsequent pulses from the delay line have orthogonal linear polarisations. This fact allows independent modulation of these pulses using two-phase-only Spatial Light Modulators (SLM) when their directors are also aligned orthogonally. With hybrid Computer Generated Holograms (CGH) addressed to the SLMs, we demonstrate simultaneous multi-spot periodic surface micro-structuring on stainless steel with orthogonal linear polarisations and cylindrical vector (CV) beams with Radial and Azimuthal polarisations. Burst processing produces a major change in resulting surface texture due to plasma absorption on the nanosecond time scale; hence the ablation rates on stainless steel with pulse bursts are always lower than 5 kHz processing. By synchronising the scan motion and CGH application, we show simultaneous independent multi-beam real-time processing with pulse bursts having orthogonal linear polarisations. This novel technique extends the flexibility of parallel beam surface micro-structuring with adaptive optics. Full article

In this paper, we propose and experimentally demonstrate a parallel coding and two-beam combining approach for the simultaneous implementation of dynamically generating holographic patterns at their arbitrary linear polarization states. Two orthogonal input beams are parallelly and independently encoded with the same target image information but there is different amplitude information by using two-phase computer-generated holograms (CGH) on two Liquid-Crystal-on-Silicon-Spatial-Light Modulators (LCOS SLMs). Two modulated beams are then considered as two polarization components and are spatially superposed to form the target polarization state. The final linear vector beam is created by the spatial superposition of the two base beams, capable of controlling the vector angle through the phase depth of the phase-only CGHs. Meanwhile, the combined holographic patterns can be freely encoded by the holograms of two vector components. Thus, this allows us to tailor the optical fields endowed with arbitrary holographic patterns and the linear polarization states at the same time. This method provides a more promising approach for laser data writing generation systems in the next-generation optical data storage technology in transparent materials. Full article

The binary computer-generated hologram (BCGH) has attracted much attention recently because it can address the high-speed binary spatial light modulator (SLM), such as a digital micromirror device (DMD) SLM. In this paper, our concern is the development of an algorithm to produce high-quality BCGHs. In particular, simulated annealing (SA) is an efficient algorithm used to produce a phase-only computer-generated hologram. In the study of SA for the production of a BCGH, we found some inherent shortcomings of SA, and the quality of the produced BCGHs is limited. Accordingly, we have modified SA and propose the simulated-annealing binary search (SABS) algorithm. We have also proposed a method to quickly determine the parameters for SABS. In the comparison with SA, the mean square error of the SABS BCGHs decreases by 32% on average. Therefore, the SABS is a promising technique for a high-quality holographic display by DMD. Full article

The rarely considered case of laser beam propagation and focusaing through the moderately scattering medium was researched. A phase-only spatial light modulator (SLM) with 1920×1080 pixel resolution was used to increase the efficiency of focusing of laser radiation propagated through the 5 mm layer of the scattering suspension of 1 µm polystyrene microbeads in distilled water with the concentration values ranging from 10⁵ to 10⁶ mm⁻³. A CCD camera with micro-objective was used to estimate the intensity distribution of the far-field focal spot. A Shack-Hartmann sensor was used to measure wavefront distortions. The conducted experimental research demonstrated the 8% increase in integral intensity and 16% decrease in diameter of the far-field focal spot due to the use of the SLM for laser beam focusing. Full article

Photocurable three-dimensional (3D) printing is a stepwise layer-by-layer fabrication process widely used in the manufacture of highly specialized objects. Current 3D printing techniques are easily implemented; however, the build rate is slow and the surface quality is less than ideal. Holographic 3D display (3DHD) technology makes it possible to reform planar wavefronts into a 3D intensity distribution, which appears as a 3D image in space. This paper examined the application of holographic imaging technology to 3D printing based on photocurable polymers. The proposed system uses a 3DHD diffractive optics system based on a liquid-crystal-on-silicon spatial light modulator (LCoS-SLM), wherein a 3D layered image is created in the optical near field, based on a computer-generated hologram (CGH) optimized using the iterative angular spectrum algorithm (IASA) and a circular IASA. From a single CGH, multiple 2D sliced images are created in space to form a 3D optical image used to initiate the photopolymerization of photocurable resin to form 3D objects. In experiments, the proposed 3D printing system was used to create five polymer objects with a maximum axial length of 25 mm and minimum feature width of 149 μm. The phase-only CGH reformed the incident light into a distribution of optical intensity with high diffraction efficiency suitable for photocuring. Despite limitations pertaining to fabrication area and axial complexity in this initial study, the proposed method demonstrated high light efficiency, high resolution in the lateral direction, rapid fabrication, and good object continuity. Full article
