With the increasing complexity of the electromagnetic environment, radar waveform design needs to break through the limitation of traditional single-function architectures, prompting the emergence of integrated radar waveforms. Currently, the mainstream integrated signals are achieved through conventional waveform synthesis or time/frequency division multiplexing. However, the former suffers from limited design flexibility and is confined to single scenario applications, while the latter has interference between different sub-channels, which will limit the performance of multi-function radar. Aiming at the above problems, this paper proposes a waveform optimization method for a detection and cover integrated signal with high Doppler tolerance. By constructing a joint optimization model, the sidelobe characteristics of the signal’s autoambiguity function and the output response of the non-cooperative matched filter were incorporated into the unified objective function framework. The gradient descent algorithm is used to solve the model, and the optimized waveform with low sidelobe characteristics and multiple false target interference abilities is obtained. When the optimized waveform generates multiple false targets to cover our radar position, its peak sidelobe level (PSL) drops below −23 dB, and most of the sidelobe levels in the range-Doppler interval of interest drop below −40 dB. Finally, the proposed integrated waveform undergoes hardware-in-the-loop experiments, experimentally validating its performance and the effectiveness of the proposed method. Full article

This paper introduces a robust waveform design method aimed at reducing the impact of electromagnetic interference in radar systems, thereby enhancing target detection accuracy. We propose utilizing a high-order p-norm to characterize the peak sidelobe level (PSL) of the waveform. Additionally, the method incorporates spectral zero-trapping within known interfering frequency bands to mitigate interference effects. A unified optimization objective function is developed to ensure optimal correlation properties of waveforms for dual-use in radar and communication systems. By employing the AdamW algorithm for dynamic adjustment of the iteration factor, combined with a gradient descent search, this method refines both the autocorrelation of the waveform and its resilience to known disturbances. Experimental results demonstrate that our approach significantly improves autocorrelation performance over randomly generated initial waveforms. Moreover, the introduction of spectral zero-trapping notably enhances interference suppression in targeted frequency bands, thereby boosting overall signal performance. Our method effectively balances interference rejection with the minimization of sidelobe levels, offering a pragmatic waveform solution for complex radar environments. Full article

We demonstrate a low latency delay of a radio frequency (RF)–linear frequency-modulated (LFM) pulse by modulating it onto optical carriers from a Kerr comb and sending the signal through a concatenation of off-the-shelf linearly chirped fiber Bragg gratings (LC-FBGs) and chirped-and-sampled FBG (CS-FBG). We characterize the frequency response and latency of the LC-FBG and CS-FBG. Then, experimentally, the LFM pulse performance is characterized by measuring the peak sidelobe level (PSL) at the output of the tunable delay system. The experiment, performed with an LFM pulse of 1 GHz bandwidth at a 10 GHz center frequency, shows a PSL better than 34.4 dB, attesting to the high quality of the buffer RF transfer function. Thus, the proposed optical memory buffer architecture, utilizing compact devices based on a Kerr comb and FBGs, offers several benefits for delaying LFM pulses, including (i) a larger tunable delay range, (ii) low latency, (iii) wide bandwidth, and (iv) high PSL. Full article

The orthogonal frequency-division multiplexing (OFDM) mode with a linear frequency modulation (LFM) signal as the baseband waveform has been widely studied and applied in multiple-input multiple-output (MIMO) radar systems. However, its high sidelobe levels after pulse compression affect the target detection of radar systems. For this paper, theoretical analysis was performed, to investigate the causes of high sidelobe levels in OFDM-LFM waveforms, and a novel waveform optimization design method based on deep neural networks is proposed. This method utilizes the classic ResNeXt network to construct dual-channel neural networks, and a new loss function is employed to design the phase and bandwidth of the OFDM-LFM waveforms. Meanwhile, the optimization factor is exploited, to address the optimization problem of the peak sidelobe levels (PSLs) and integral sidelobe levels (ISLs). Our numerical results verified the correctness of the theoretical analysis and the effectiveness of the proposed method. The designed OFDM-LFM waveforms exhibited outstanding performance in pulse compression and improved the detection performance of the radar. Full article

This article aims to improve the synthesis efficiency and radiation performance of large ultra-wideband (UWB) rotationally symmetric sparse circular planar arrays by using a modified differential evolution algorithm (MDEA). In the proposed MDEA, we adopt a new encoding mechanism in which an individual represents an element position expressed in polar coordinates. Importantly, such an encoding mechanism can facilitate the multiplication calculation for the array factor in the individual being updated while making it easier to meet the given minimum element spacing constraint. Moreover, to cater to the new encoding mechanism, some low-dimensional evolution operators are introduced to avoid the prematurity. In particular, the UWB rotationally symmetric sparse planar array synthesis problem is transformed into the sidelobe suppression problem of the array pattern at the highest frequency under the given array aperture, and the minimum spacing constraints is used to guarantee enough space to place physical UWB antenna elements. Two synthesis examples of UWB sparse planar arrays based on rotationally symmetric structures are presented. The results show that the peak sidelobe level (PSL) obtained by the proposed MDEA is significantly lower than the results obtained by some existing algorithms in an acceptable CPU time, which proves the effectiveness and superiority of the proposed MDEA. Full article

External interference in ionospheric sounding seriously degrades the quality of echo signals and data; thus, it should be eliminated. This paper presents a method for suppressing interference using chaotic coding with a set of Bernoulli map sequences; compared with other commonly used coding methods such as Barker code, complementary code, and Barker-like codes, through simulation, the ambiguity function (AF) of Bernoulli map codes has better performance in terms of peak sidelobe level (PSL), integral sidelobe ratio (ISL), noise suppression (NS), and signal-to-noise ratio (SNR). Experimental tests were performed using a vertical ionosonde in Yinchuan, Ningxia Hui Autonomous Region, China, and the ionosonde was operated by alternating 40-bit Barker-like coding and 40-bit Bernoulli map coding each day to compare the effectiveness of interference suppression. The results showed that using Bernoulli map coding could remove interference and improve SNR significantly, thereby improving the data quality of the resulting ionograms. Full article

In radar detection, in order to make the beam have variable directivity, a Capon beamformer is usually used. Although this traditional beamformer enjoys both high resolution and good interference suppression, it usually leads to high sidelobe and is sensitive to array steering vector (ASV) mismatch. To overcome such problems, this study devises a novel, robust adaptive beamformer that is robust to ASV mismatch under the constraint where the sidelobe is oriented to the ground. Moreover, to make full use of the transmit power, the constraint of a low peak-to-average power ratio (PAPR) is also taken into consideration. Accordingly, this robust adaptive beamformer is developed by optimizing a transmitting beamformer constrained by ASV mismatch and low PAPR. This optimization problem is transformed into a second-order cone programming (SOCP) problem which can be efficiently and exactly solved. The proposed transmit beamformer possesses not only adaptive interference rejection ability and robustness against ASV mismatch, but also direct sidelobe control and a low PAPR. Simulation results are presented to demonstrate the superiority of the proposed approach. The proposed method can make the peak sidelobe level (PSL) level on the ground side below −30 dB. Full article

Circular ground-based SAR (GBSAR) is a new 3D imaging GBSAR with the potential of acquiring high-quality 3D SAR images and 3D deformation. However, its donut-shaped spectrum and short radius of antenna rotation cause high sidelobes on 3D curved surfaces, resulting in 3D SAR images with poor quality. The multi-phase-center circular GBSAR with full array can effectively suppress sidelobes by filling the donut-shaped spectrum to be the equivalent solid spectrum, but it requires a larger number of phase centers, increasing system cost and engineering difficulties. In this paper, a sidelobe suppression method for circular GBSAR 3D imaging based on sparse optimization of radial phase-center distribution is proposed to suppress high sidelobes at low cost. By deriving the point spread function (PSF) of multi-phase-center circular GBSAR and taking the peak sidelobe level (PSL) and integrated sidelobe level (ISL) of the derived PSF as multi-objective functions, we solve the multi-objective optimization problem to optimize the sparse distribution of radial phase centers. The advantage of the proposed method is that the solved optimal radial phase-center distribution can effectively suppress the 3D sidelobes of circular GBSAR with a limited number of phase centers. Finally, the sidelobe suppression effect of the proposed method is verified via 3D imaging simulations. Full article

The multivariate range function of the high-speed maneuvering target induces modulations on both the envelop and phase, i.e., the range cell migration (RCM) and Doppler frequency migration (DFM) which degrade the long-time coherent integration used for detection and localization. To solve this problem, many long-time coherent integration methods have been proposed. Based on mechanisms of typical methods, this paper names two signal processing modes, i.e., processing unification (PU) mode and processing separation (PS) mode, and presents their general forms. Thereafter, based on the principle of the PS mode, a novel long-time coherent integration method, known as the generalized dechirp-keystone transform (GDKT), is proposed for radar high-speed maneuvering target detection and localization. The computational cost, energy integration, peak-to-sidelobe level (PSL), resolution, and anti-noise performance of the GDKT are analyzed and compared with those of the maximum likelihood estimation (MLE) method and keystone transform-dechirp (KTD) method. With mathematical analyses and numerical simulations, we validate two main superiorities of the GDKT, including (1) the statistically optimal anti-noise performance, and (2) the low computational cost. The real radar data is also used to validate the GDKT. It is worthwhile noting that, based on closed analytical formulae of the MLE method, KTD method, and GDKT, several doubts in radar high-speed maneuvering target detection and localization are mathematically interpreted, such as the blind speed sidelobe (BSSL) and the relationship between the PU and PS modes. Full article

Aperiodic sparse 2D ultrasonic array configurations, including random array, log spiral array, and sunflower array, have been considered for their potential as conformable transducers able to image within a focal range of 30–80 mm, at an operating frequency of 2 MHz. Optimisation of the imaging performance of potential array patterns has been undertaken based on their simulated far field directivity functions. Two evaluation criteria, peak sidelobe level (PSL) and integrated sidelobe ratio (ISLR), are used to access the performance of each array configuration. Subsequently, a log spiral array pattern with −19.33 dB PSL and 2.71 dB ISLR has been selected as the overall optimal design. Two prototype transducers with the selected log spiral array pattern have been fabricated and characterised, one using a fibre composite element composite array transducer (CECAT) structure, the other using a conventional 1–3 composite (C1–3) structure. The CECAT device demonstrates improved coupling coefficient (0.64 to 0.59), reduced mechanical cross-talk between neighbouring array elements (by 10 dB) and improved operational bandwidth (by 16.5%), while the C1–3 device performs better in terms of sensitivity (~50%). Image processing algorithms, such as Hough transform and morphological opening, have been implemented to automatically detect and dimension particles located within a fluid-filled tube structure, in a variety of experimental scenarios, including bespoke phantoms using tissue mimicking material. Experiments using the fabricated CECAT log spiral 2D array transducer demonstrated that this algorithmic approach was able to detect the walls of the tube structure and stationary anomalies within the tube with a precision of ~0.1 mm. Full article

Ultrasonic Testing (UT) is one of the most important technologies in Non-Detective Testing (NDT) methods. Recently, Barker code and Golay code pairs as coded excitation signals have been applied in ultrasound imaging system with improved quality. However, the signal-to-noise ratio (SNR) of existing UT system based on Barker code or Golay code can be influenced under high high attenuation materials or noisy conditions. In this paper, we apply the convolution of Barker and Golay codes as coded excitation signals for low voltage UT devices that combines the advantages of Barker code and Golay code together. There is no need to change the hardware of UT system in this method. The proposed method has been analyzed theoretically and then in extensive simulations. The experimental results demonstrated that the main lobe level of the code produced by convolution of Barker code and Golay code pairs is much higher than the simple pulse and the main lobe of the combined code is higher than the traditional Barker code, sidelobe is the same as the baker code that constitutes this combined code. So the peak sidelobe level (PSL) of the combined code is lower than the traditional Barker code. Equipped with this, UT devices can be applied in low voltage situations. Full article

In the field of sensor signal processing, windows are time-/frequency-domain weighting functions that are widely applied to reduce the well-known Gibbs oscillations. Conventional methods generally control the spectral characteristics of windows by adjusting several of the parameters of closed-form expressions. Designers must make trade-offs among the mainlobe width (MW), the peak sidelobe level (PSL), and sometimes the sidelobe fall-off rate (SLFOR) of windows by carefully adjusting these parameters. Generally, not all sidelobes need to be suppressed in specified applications. In this paper, a novel method, i.e., the inverse of the shaped output using the cyclic algorithm (ISO-CA), for designing window functions with flexible spectral characteristics is proposed. Simulations are conducted to test the effectiveness, flexibility and versatility of the method. Some experiments based on real measured data are also presented to demonstrate the practicability. The results show that the window functions generated using the cyclic algorithm (CA) yield better performance overall than the windows of conventional methods, achieving a narrower MW, a lower PSL, and a controllable SLFOR. In addition, steerable sidelobes over specified regions can be acquired both easily and flexibly while maintaining the original properties of the initial window as much as possible. Full article

Contrast degradation is a critical problem in ultrasound plane wave imaging (PWI) resulting from signals leakage from the sidelobes. An ideal sidelobe reduction method may enhance the contrast without remarkably increasing computational load. To this end, we introduce a new singular value decomposition (SVD) sidelobe reduction beamformer for coherent plane wave compounding (CPWC) based on a previous work. The SVD takes advantage of the benefits of the different features of the mainlobe and sibelobe in terms of spatio-angular coherence and removes the sidelobes before the final coherent summation. This SVD-based method provides a three-dimensional approach (2D in the space and 1D in the angle) while the computation load is kept satisfactory by a dimension-reduced operation before the SVD. To directly observe the sidelobe level, we demonstrate the performance of our SVD method with a point spread function (PSF) simulation. Compared to CPWC, our method shows a 6.2 dB reduction in the peak sidelobe level (PSL). We also applied our method to the anechoic cyst inside the speckle for the imaging contrast. Both in the simulation and phantom studies, our method enhances the contrast-to-noise ratio (CNR) by more than 10%. Therefore, this new beamformer can be an efficient way to suppress sidelobes in PWI. Full article

The use of a generalized sidelobe canceler (GSC) can significantly improve the lateral resolution of medical ultrasound systems, but the contrast improvement isn’t satisfactory. Thus a new Eigenspace-based generalized sidelobe canceler (EBGSC) approach is proposed for medical ultrasound imaging, which can improve both the lateral resolution and contrast of the system. The weight vector of the EBGSC is obtained by projecting the GSC weight vector onto a vector subspace constructed from the eigenstructure of the covariance matrix, and using the new weight vector instead of the GSC ones leads to reduced sidelobe level and improved contrast. Simulated and experimental data are used to evaluate the performance of the proposed method. The Field II software is applied to obtain the simulated echo data of scattering points and circular cysts. Imaging of scattering points show that EBGSC has the same full width at half maximum (FWHM) as GSC, while the lateral resolution improves by 35.3% and 52.7% compared with synthetic aperture (SA) and delay-and-sum (DS), respectively. Compared with GSC, SA and DS, EBGSC improves the peak sidelobe level (PSL) by 23.55, 33.11 and 50.38 dB, respectively. Also the cyst contrast increase by EBGSC was calculated as 16.77, 12.43 and 26.73 dB, when compared with GSC, SA and DS, respectively. Finally, an experiment is conducted on the basis of the complete echo data collected by a medical ultrasonic imaging system. Results show that the proposed method can produce better lateral resolution and contrast than non-adaptive beamformers. Full article
