To address distributed mass payload (DMP) anti-swing control problems typified by offshore wind turbine blades, this paper adopts multi-body dynamics and rigid-flexible coupling modelling approaches. It derives the geometric constraints and static equilibrium equations for marine crane multipoint lifting of DMP, and establishes a dynamic coupling model considering ship roll and pitch environmental excitations. Then, under the maximum environmental excitation set in the experiment, the flexible cable parallel anti-swing system achieves swing suppression rates of 41.0% and 58.0% for the in-plane and out-of-plane angles of the DMP with regular geometric shape and mass distribution, respectively. For the DMP with irregular geometry and mass distribution, the suppression rates are 48.4% and 39.3% for the in-plane and out-of-plane angles, respectively. It is found that, after adjusting the lifting method and increasing the distance between the lifting points, the maximum in-plane angle of the payload decreases by 2.3%, while the out-of-plane angle maximum decreases by 52.0%. These results demonstrate the effectiveness of adjusting lifting methods in suppressing swing for irregular DMPs, thereby verifying the reliability and applicability of the flexible cable parallel anti-swing system and providing a reference for improving anti-swing performance and lifting efficiency in offshore DMP operations. Full article

This study proposes a new approach to improving laser sensor data collection through optimised sensor settings. Specifically, it examines the influence of laser sensor configurations on laser scanning measurements obtained by using a laser line triangulation sensor for transparent and non-transparent plastics, as well as aluminium alloys. Distance data were acquired with a three-degree-of-freedom positioning device and the laser sensor under both manual and automatic settings. Measurements were performed at the sensor’s reference distance and across a wide range of positional configurations. The results of extensive experimental tests highlight optimal sensor configurations for various materials and sensor orientations relative to the scanned surface, including both in-plane and out-of-plane angles, to enhance the reliability and accuracy of distance data collection. Full article

Steel I-beams may be subject to deviation from their normal path towards the lateral direction due to obstacles along their axis line. This deviation in the lateral direction, i.e., the out-of-plane distance, affects the behavior of the steel beams and may reduce their ultimate capacity. To obtain this effect, finite element modeling (FEM) was used to model these beams with and without an out-of-plane distance at the mid-span beam length with several different variables. These variables were the out-of-plane distance, cross-section dimensions, beam length, and steel yield stress. The reliability of using FEM simulation was confirmed by comparing the experimental test results of 25 available steel beams in previous studies. The results indicate the high accuracy of the simulation of this beam in terms of ultimate capacity, structural behavior, and deformation patterns. After verifying the results, 116 broad-flange I-beam (BFIB) steel beams with different out-of-plane distances were modeled. The results showed that using an out-of-plane distance equal to the flange width of the BFIB-300 cross-section caused a 60% decrease in the ultimate capacity. The reduction ratios in the ultimate moment capacity in out-of-plane steel beams were directly proportional to the out-of-plane distance, cross-sectional dimensions, and steel yield stress, while the beam length had no effect. Failure in beams containing an out-of-plane distance occurs as a result of a global buckling in the upper flange, which contains tensile stresses at the outer edge and compressive stresses at the inner edge, with stress concentration occurring at the point of contact of the out-of-plane part with the main beam. The prediction results of the design codes were compared with the results of experimental tests and the FEM analysis of the beams with and without out-of-plane distances. For all the beams with out-of-plane distances, all the design codes were unable to predict this ultimate capacity. Full article

The finite point method (FPM) is a numerical, mesh-free technique for solving differential equations, particularly in fluid dynamics. While the FPM has been previously applied in solid mechanics to analyze plates under in-plane loading, there remains a notable scarcity of research exploring the out-of-plane analysis of elastic plates using this method. This study thoroughly investigates the elastic FPM analysis of thin plates subjected to transverse loadings, focusing specifically on various boundary conditions (BCs). Boundary conditions represent a significant challenge in the out-of-plane analysis of thin plates within the FPM framework. To address this challenge, the approach incorporates additional nodal points positioned close to each boundary node, supplementing the points distributed throughout the plate’s interior and along its edges. The strong form of the governing equation is employed for the interior points, while the analysis also includes the scenario of a plate resting on boundary columns. Both distributed and concentrated external loads are examined to provide a comprehensive understanding of the behavior under different loading conditions. Furthermore, the optimal placement of the extra boundary nodes is briefly discussed, alongside a focus on the number of nodes within the finite point clouds. An appropriate range for this number is proposed, although the determination of the optimal distance for the extra boundary nodes and the ideal number of cloud points is earmarked for future research. The contribution of this work is to enhance the understanding of the FPM in the context of thin plates, particularly concerning the critical influence of boundary conditions. Full article

A significant percentage of bridges in the United States are serving beyond their 50-year design life, and many of them are in poor condition, making them vulnerable to fatigue cracks that can result in catastrophic failure. However, current fatigue crack inspection practice based on human vision is time-consuming, labor intensive, and prone to error. We present a novel human-centered bridge inspection methodology to enhance the efficiency and accuracy of fatigue crack detection by employing advanced technologies including computer vision and augmented reality (AR). In particular, a computer vision-based algorithm is developed to enable near-real-time fatigue crack detection by analyzing structural surface motion in a short video recorded by a moving camera of the AR headset. The approach monitors structural surfaces by tracking feature points and measuring variations in distances between feature point pairs to recognize the motion pattern associated with the crack opening and closing. Measuring distance changes between feature points, as opposed to their displacement changes before this improvement, eliminates the need of camera motion compensation and enables reliable and computationally efficient fatigue crack detection using the nonstationary AR headset. In addition, an AR environment is created and integrated with the computer vision algorithm. The crack detection results are transmitted to the AR headset worn by the bridge inspector, where they are converted into holograms and anchored on the bridge surface in the 3D real-world environment. The AR environment also provides virtual menus to support human-in-the-loop decision-making to determine optimal crack detection parameters. This human-centered approach with improved visualization and human–machine collaboration aids the inspector in making well-informed decisions in the field in a near-real-time fashion. The proposed crack detection method is comprehensively assessed using two laboratory test setups for both in-plane and out-of-plane fatigue cracks. Finally, using the integrated AR environment, a human-centered bridge inspection is conducted to demonstrate the efficacy and potential of the proposed methodology. Full article

A methodology to predict key aspects of the structural response of masonry walls under blast loading using artificial neural networks (ANN) is presented in this paper. The failure patterns of masonry walls due to in and out-of-plane loading are complex due to the potential opening and sliding of the mortar joint interfaces between the masonry stones. To capture this response, advanced computational models can be developed requiring a significant amount of resources and computational effort. The article uses an advanced non-linear finite element model to capture the failure response of masonry walls under blast loads, introducing unilateral contact-friction laws between stones and damage mechanics laws for the stones. Parametric finite simulations are automatically conducted using commercial finite element software linked with MATLAB R2019a and Python. A dataset is then created and used to train an artificial neural network. The trained neural network is able to predict the out-of-plane response of the masonry wall for random properties of the blast load (standoff distance and weight). The results indicate that the accuracy of the proposed framework is satisfactory. A comparison of the computational time needed for a single finite element simulation and for a prediction of the out-of-plane response of the wall by the trained neural network highlights the benefits of the proposed machine learning approach in terms of computational time and resources. Therefore, the proposed approach can be used to substitute time consuming explicit dynamic finite element simulations and used as a reliable tool in the fast prediction of the masonry response under blast actions. Full article

Ultrathin Co${}_x$Fe${}_{3-x}$O${}_4$ films of high structural quality and with different Co content (x = 0.6–1.2) were prepared by reactive molecular beam epitaxy on MgO(001) substrates. Epitaxy of these ferrite films is extensively monitored by means of time-resolved (operando) X-ray diffraction recorded in out-of-plane geometry to characterize the temporal evolution of the film structure. The Co ferrite films show high crystalline ordering and smooth film interfaces independent of their Co content. All Co${}_x$Fe${}_{3-x}$O${}_4$ films exhibit enhanced compressive out-of-plane strain during the early stages of growth, which partly releases with increasing film thickness. When the Co content of the ferrite films increases, the vertical-layer distances increase, accompanied by slightly increasing film roughnesses. The latter result is supported by surface-sensitive low-energy electron diffraction as well as X-ray reflectivity measurements on the final films. In contrast, the substrate–film interface roughness decreases with increasing Co content, which is confirmed with X-ray reflectivity measurements. In addition, the composition and electronic structure of the ferrite films is characterized by means of hard X-ray photoelectron spectroscopy performed after film growth. The experiments reveal the expected increasing ${\mathrm{Fe}}^{3+}$/${\mathrm{Fe}}^{2+}$ cation ratios for a higher Co content. Full article

This paper presents a study on the dynamic behavior of thin aluminum plates subjected to consecutive fragment impact and blast loading. To this end, two separate experimental setups are used. In the first setup, 2 mm thick aluminum plates $EN$-$AW$-$1050A$-$H24$ were subjected to the ballistic impact of fragment-simulating projectiles (FSPs). Experiments were carried out for FSP calibers of 7.62 mm and 12.7 mm considering both single impact and triple impacts with variations in the spacing of the impact locations. The out-of-plane displacement and in-plane strain fields were measured using digital image correlation (DIC) coupled to a pair of high-speed cameras in a stereoscopic setup. In the second setup, a subsequent blast loading was applied to the perforated plates using an explosive-driven shock tube (EDST). After the plates are perforated, the strain field around the holes depended on the caliber, the impact orientation of the FSP, and the distance between the impact locations. When the blast loading was applied, cracks tended to appear in areas of strain concentration between the perforated holes. It was found that the relative distance between the holes significantly influences the target’s response mode. Full article

Charge-coupled devices (CCD) allow imaging by photodetection, charge integration, and serial transfer of the stored charge packets from multiple pixels to the readout node. The functionality of CCD can be extended to the non-destructive and in-situ readout of the integrated charges by replacing metallic electrodes with graphene in the metal-oxide-semiconductors (MOS) structure of a CCD pixel. The electrostatic capacitive coupling of graphene with the substrate allows the Fermi level tuning that reflects the integrated charge density in the depletion well. This work demonstrates the in-situ monitoring of the serial charge transfer and interpixel transfer losses in a reciprocating manner between two adjacent Gr-Si CCD pixels by benefitting the electrostatic and gate-to-gate couplings. We achieved the maximum charge transfer efficiency (CTE) of $92.4\%$, which is mainly decided by the inter-pixel distance, phase clock amplitudes, switching slopes, and density of surface defects. The discussion on overcoming transfer losses and improving CTE by realizing a graphene-electron multiplication CCD is also presented. The proof of the concept of the in-situ readout of the out-of-plane avalanche in a single Gr-Si CCD pixel is also demonstrated, which can amplify the photo packet in a pre-transfer manner. Full article

This work proposes that laser pulses can generate finite amplitude Rayleigh waves for process monitoring during additive manufacturing. The noncontact process monitoring uses a pulsed laser to generate Rayleigh waves, and an adaptive laser interferometer to receive them. Experiments and models in the literature show that finite amplitude waveforms evolve with propagation distance and that shocks can even form in the in-plane particle velocity waveform. The nonlinear waveform evolution is indicative of the material nonlinearity, which is sensitive to the material microstructure, which in turn affects strength and fracture properties. The measurements are made inside a directed energy deposition additive manufacturing chamber on planar Ti-6Al-4V and IN-718 depositions. By detecting the out-of-plane particle displacement waveform, the in-plane displacement and velocity waveforms are also available. The waveform evolution can be characterized (i) for one source amplitude by reception at different points or (ii) by reception at one point by applying different source amplitudes. Sample results are provided for intentionally adjusted key process parameters: laser power, scan speed, and hatch spacing. Full article

The interest in magnetic nanostructures exhibiting perpendicular magnetic anisotropy and exchange bias (EB) effect has increased in recent years owing to their applications in a new generation of spintronic devices that combine several functionalities. We present a nanofabrication process used to induce a significant out-of-plane component of the magnetic easy axis and EB. In this study, 30 nm thick CoO/Co multilayers were deposited on nanostructured alumina templates with a broad range of pore diameters, 34 nm ≤ D_p ≤ 96 nm, maintaining the hexagonal lattice parameter at 107 nm. Increase of the exchange bias field (H_EB) and the coercivity (H_C) (12 times and 27 times, respectively) was observed in the nanostructured films compared to the non-patterned film. The marked dependence of H_EB and H_C with antidot hole diameters pinpoints an in-plane to out-of-plane changeover of the magnetic anisotropy at a nanohole diameter of ∼75 nm. Micromagnetic simulation shows the existence of antiferromagnetic layers that generate an exceptional magnetic configuration around the holes, named as antivortex-state. This configuration induces extra high-energy superdomain walls for edge-to-edge distance >27 nm and high-energy stripe magnetic domains below 27 nm, which could play an important role in the change of the magnetic easy axis towards the perpendicular direction. Full article

Acetylenedicarboxylic acid dihydrate (ADAD) represents a complex with strong hydrogen bonding between the carboxylic OH and the water molecule. An X-ray re-examination of the ADAD crystal structure confirms the O^…O distance of the short hydrogen bonds, and clearly shows different bond lengths between the two oxygen atoms with respect to the carbon atom in the carboxyl group, indicating a neutral structure for the complex. The neutral structure was also confirmed by vibrational spectroscopy, as no proton transfer was observed. The diffraction studies also revealed two polymorph modifications: room temperature (α) and low temperature (β), with a phase transition at approximately 4.9 °C. The calculated vibrational spectra are in satisfactory agreement with the experimental spectra. A comparison of the structure and the vibrational spectra between the ADAD and the oxalic acid dihydrate reveals some interesting details. The crystal structures of both crystal hydrates are almost identical; only the O^…O distances of the strongest hydrogen bonds differ by 0.08 Å. Although it was expected that a larger O^…O spacing in the ADAD crystal may significantly change the infrared and Raman spectra, especially for the frequency and the shape of the acidic OH stretching vibration, both the shape and frequency are almost identical, with all subpeaks topped on the broad OH stretching vibration. The O^…O distance dependent are only in- and out-of-plane OH deformations modes. The presence of polarons due to the ionized defects was not observed in the vibrational spectra of ADAD. Therefore, the origin of the broad OH band shape was explained in a similar way to the acid dimers. The anharmonicity of a potential enhances the coupling of the OH stretching with the low-frequency hydrogen bond stretching, which, in addition to the Fermi resonance, structures the band shape of the OH stretching. The fine structure found as a superposition of a broad OH stretching is attributed to Davydov coupling. Full article

This paper proposes a new optical configuration for a two-axis surface encoder that can measure the in-plane (X-axis) and out-of-plane (Z-axis) displacements of a positioning stage. The two-axis surface encoder is composed of a scale grating and a sensor head. A transparent grating is employed in the sensor head for measurement of the Z-directional displacement of the scale grating based on the Fizeau-type measurement method; a reference beam reflected from the transparent grating and the zeroth-order diffracted beam from the scale grating are superimposed to generate an interference signal. A pair of prisms and a beam splitter are also employed in the sensor head, so that the positive and negative first-order diffracted beams can be superimposed over a long working distance to generate an interference signal for measurement of the X-directional displacement of the scale grating. Focusing on the new, extended Z-directional measurement mechanism, proof-of-principle experiments were carried out to verify the feasibility of the proposed optical configuration for the surface encoder that can measure the uni-directional displacements of a scale grating along the X- and Z-axis. Experimental results from the developed optical configuration demonstrated the achievement of a Z-directional measuring range of ±1.5 mm. Full article

This paper presents modeling and analysis of light diffraction and light-intensity modulation performed by an optical phased array (OPA) system based on metal-coated silicon micromirrors. The models can be used in the design process of a microelectromechanical system (MEMS)-based OPA device to predict its optical performance in terms of its field of view, response, angular resolution, and long-range transmission. Numerical results are derived using an extended model for the 1st-order diffracted light intensity modulation due to phase shift. The estimations of the optical characteristics are utilized in the designs of an OPA system capable of active phase modulation and an OPA system capable of array pitch tuning. Both designs are realized using the Multi-User MEMS Processes (PolyMUMPs) in which polysilicon is used as structural material for the MEMS-actuated mirrors. The experiments are performed to evaluate the optical performance of the prototypes. The tests show that the individually actuated micromirrors, which act as phase shifters, can transmit the most optical power along the 1st-order diffracted beam by actively changing their out-of-plane positions. In addition, the 1st-order diffracted beam with high optical intensity can be steered for distance measurement. Full article

Using the density functional theory with the hybrid functional B3LYP and the basis of localized orbitals of the CRYSTAL17 program code, the dependences of the wavenumbers of normal long-wave ν vibrations on the P(GPa) pressure ν(cm⁻¹) = ν₀ + (dv/dP)·P + (d²v/dP²)·P and structural parameters R(Å) (R: a, b, c, R_M-O, R_C-O): ν(cm⁻¹) = ν₀ + (dv/dR) − (R − R₀) were calculated. Calculations were made for crystals with the structure of calcite (MgCO₃, ZnCO₃, CdCO₃), dolomite (CaMg(CO₃)₂, CdMg(CO₃)₂, CaZn(CO₃)₂) and aragonite (SrCO₃, BaCO₃, PbCO₃). A comparison with the experimental data showed that the derivatives can be used to determine the P pressures, a, b, c lattice constants and the R_M-O metal-oxygen, and the R_C-O carbon-oxygen interatomic distances from the known Δν shifts. It was found that, with the increasing pressure, the lattice constants and distances R decrease, and the wavenumbers increase with velocities the more, the higher the ν₀ is. The exceptions were individual low-frequency lattice modes and out-of-plane vibrations of the v₂-type carbonate ion, for which the dependences are either nonlinear or have negative dv/dP (positive dv/dR) derivatives. The reason for this lies in the properties of chemical bonding and the nature of atomic displacements during these vibrations, which cause a decrease in R_M-O and an increase in R_C-O. Full article
