To address the coupled fault diagnosis challenge between temperature sensors and equipment in traction converter cooling systems, this paper proposes a dual-level intelligent diagnostic architecture. This method achieves online sensor fault isolation and early equipment anomaly warning by leveraging spatiotemporal correlation modeling of multimodal sensor data and ensemble learning-based prediction. At the first level, it integrates multi-source parameters such as outlet temperature and pressure to establish dynamic prediction models, which are combined with adaptive threshold mechanisms for detecting various sensor faults including offset, open-circuit, and noise interference. At the second level, it monitors the status of temperature sensors through time-series analysis of inlet temperature data. Verified on an edge computing platform, the proposed method effectively resolves the coupling misdiagnosis between sensor distortion and equipment faults while maintaining physical interpretability, thereby significantly enhancing diagnostic robustness under complex operating conditions. Full article

Inter-turn short-circuit fault is a common electrical issue in high-speed train traction motors, which can severely degrade motor performance and significantly shorten operational lifespan. Early detection is crucial for ensuring the safety of traction systems. This paper presents a digital twin-based method for diagnosing stator winding inter-turn short-circuit faults in induction motors. First, an advanced rapid-solving algorithm is employed to establish a real-time digital twin model of the motor under healthy conditions. Second, a mathematical model characterizing stator winding faults is developed. Subsequently, fault detection and localization are achieved through analyzing three-phase current residuals between the digital twin model and the actual system. Extensive simulations and experiments demonstrate that the proposed method generates a fault index amplitude approximately 20 times larger than traditional sampling-value-based prediction methods, indicating exceptional sensitivity. The approach is minimally invasive, requiring no additional measurement equipment. Moreover, it maintains diagnostic capability even under motor parameter mismatch conditions, outperforming traditional methods. The proposed method demonstrates distinct advantages for high-speed train traction systems. It enables real-time monitoring and predictive maintenance, effectively reducing operational costs while preventing catastrophic failures. Full article

This paper presents a novel fault diagnosis technique for remote-controlled robotic arm systems, utilizing deep fuzzy echo state networks (DFESNs) and applies the covariance matrix adaptation evolution strategy (CMA-ES) to optimize the hyperparameters of the DFESN model. The developed DFESN model, optimized via CMA-ES, efficiently performs online fault classification through small datasets and training. The method is evaluated through experiments on a leader–follower robotic arm system, demonstrating high accuracy and efficiency. The faults under consideration include leader sensor fault, communication fault, actuator fault, and follower sensor fault. Only follower sensor data are utilized for fault diagnosis. The DFESN model achieves a mean accuracy of 99.5% with the shortest training and online diagnosis times compared to other methods, making it suitable for real-time fault diagnosis applications. Full article

Proton exchange membrane fuel cell (PEMFC) fault diagnosis faces two critical limitations: conventional offline methods lack real-time predictive capability, while existing prediction approaches are confined to single fault types. To address these gaps, this study proposes an online multi-fault prediction framework integrating three novel contributions: (1) a sensor fusion strategy leveraging existing thermal/electrochemical measurements (voltage, current, temperature, humidity, and pressure) without requiring embedded stack sensors; (2) a real-time sliding window mechanism enabling dynamic prediction updates every 1 s under variable load conditions; and (3) a modified CNN-based Bi-LSTM parallel model with attention mechanism (ConvBLSTM-PMwA) architecture featuring multi-input multi-output (MIMO) capability for simultaneous flooding/air-starvation detection. Through comparative analysis of different neural architectures using experimental datasets, the optimized ConvBLSTM-PMwA achieved 96.49% accuracy in predicting dual faults 64.63 s pre-occurrence, outperforming conventional LSTM models in both temporal resolution and long-term forecast reliability. Full article

Fault diagnosis based on the partial discharge (PD) recognition has been widely applied on a gas-insulated line breaker (GILB) and gas-insulated switchgear (GIS) as a reliable online condition monitoring method. This paper dealt with insulation defect diagnosis based on a Random Forest (RF) algorithm with an optimized feature selection method. Four different types of insulation defect models, such as the free-moving particle (FMP) defect, the protrusion-on-conductor (POC) defect, the protrusion-on-enclosure (POE) defect, and the delamination defect, were prepared to simulate representative PD single pulses and PRPD patterns generated from the GILB. The PD signals generated from defect models were detected using the PRPD sensor which can detect phase-synchronized PD signals with the applied high-voltage (HV) signals without the need for additional equipment. Various statistical PD features were extracted from PD single pulses and PRPD patterns according to four kinds of PD defect models, and optimized features were selected with respect to variance importance analysis. Two kinds of PD datasets were established using all statistical features and top-ranked features. From the experimental results, the RF algorithm achieved accuracy rates exceeding 92%, and the PD datasets using only half of the statistical PD features could reduce the computational times while maintaining the accuracy rates. Full article

DFIG rotor windings face high stress and transients from back-to-back converters, causing inter-turn short circuit (ITSC) faults. Rapid rotor-side dynamics, combined with the unique capability of DFIG to operate in multiple modes, make the fault detection in rotor windings more challenging. This paper presents a comprehensive methodology for online ITSC fault diagnosis in DFIG rotor windings based on zero-sequence current (ZSC) component analysis under variable operating conditions. Fault features are identified and defined through the analytical evaluation of the DFIG mathematical model. Further, a simple yet effective algorithm is presented for online implementation of the proposed methodology. Finally, the simulation of the DFIG model is carried out in MATLAB/Simulink under both sub-synchronous and super-synchronous modes, covering a range of variable loads and low-frequency conditions, along with different fault severity levels of ITSC in rotor windings. Simulation results confirm the effectiveness of the proposed methodology for online ITSC fault detection at a low-severity stage and precise location identification of the faulty phase within the DFIG rotor windings under both sub-synchronous and super-synchronous modes. Full article

To address the issue of control inaccuracy caused by the zero-offset fault in current sensors within the multiphase brushless DC motor (BLDCM) drive system, this paper proposes a fault diagnosis and fault-tolerant control method based on current signals. Different from traditional solutions that rely on hardware redundancy or precise modeling, this method constructs a dual-channel fault diagnosis framework by integrating the steady-state amplitude offset of the phase current after the fault and the abnormal characteristics of dynamic sector switching. Firstly, sliding time window monitoring is used to identify steady-state amplitude anomalies and locate faulty sectors. Subsequently, an algorithm for detecting the difference in current changes during sector switching is designed, and a logic interlocking verification mechanism is combined to eliminate false triggering and accurately locate single or multiple fault phases. Furthermore, based on the diagnostic information, a repeated iterative online correction method is adopted to restore the accuracy of the current measurement. This method only relies on phase current signals and rotor position information, does not require additional hardware support or accurate system models, and is not affected by the nonlinear characteristics of the motor. Finally, the experimental verification was carried out on a nine-phase BLDCM drive system. Experimental results indicate that the torque fluctuation of the system can be controlled within 5% through the fault-tolerant control strategy. Full article

The maintenance of gas turbines relies a lot on gas path diagnostics (GPD), which includes two approaches. The first approach employs a physics-based model (thermodynamic model) to convert measurement shifts (deviations) induced by deterioration into fault parameters, which drastically simplify diagnostics. The second approach relies on data-driven models, makes diagnosis in the space of measurement deviations, and involves pattern recognition techniques. Although a thermodynamic model is an essential element of GPD, it has limitations. This model is a complex software critical to computer resources, and the computation sometimes does not converge. Therefore, it is difficult to use the model in online applications. Since the 1990s, we have developed many thermodynamic models for different engines. Since the 2000s, simplified data-driven models were investigated. This paper proposes to substitute a thermodynamic model for novel simplified data-driven models that have the same functionality, i.e., take into consideration the influence of both operating conditions and engine faults. The proposed models are formed and compared with the underlying thermodynamic model. To obtain a solid conclusion about these models, they are verified in twelve test cases formed by three test-case engines, two model types, and two approximation functions. Although the accuracy of the simplified models varies from 1.15% to 0.0082%, it was found acceptable even for the worst case. Thus, these simple-but-accurate models with the functionality of a physics-based model represent a good replacement for the latter. It is expected that the models will stimulate the further development of advanced diagnostic systems. Full article

Rotating machinery, as a vital and inevitable component in industrial production and processing, plays a crucial role in ensuring the normal operation of production processes. However, most of the existing fault diagnosis methods for rotating machinery are either offline or cloud-based online approaches, which suffer from long latency and large data volumes, making them unable to meet real-time requirements. To reduce latency and data transmission volume, this research proposes a fault diagnosis method for rotating machinery based on edge computing. This research constructs an edge node that integrates signal acquisition, data preprocessing, feature extraction, and fault diagnosis classification to accurately and in real-time identify the fault status of equipment. To address the issues of low fault diagnosis recognition rate and data redundancy associated with single sensors under complex working conditions, this research proposes a fault diagnosis method based on dual-channel CNN decision-level fusion. To alleviate the computational pressure on edge nodes, the equipment fault status diagnosis model is trained on the upper computer, and the data preprocessing and diagnosis model are embedded into the edge nodes. The correctness and real-time performance of the proposed method were validated through comparisons with other methods and online fault diagnosis experiments. Full article

With the development of UAV technology, the composition of UAVs has become increasingly complex, interconnected, and tightly coupled. Fault features are characterized by weakness, nonlinearity, coupling, and uncertainty. A promising approach is the use of deep learning methods, which can effectively extract useful diagnostic information from weak, coupled, nonlinear data from inputs with background noise. However, due to the diversity of flight environments and missions, the distribution of the obtained sample data varies. The types of fault data and corresponding labels under different conditions are unknown, and it is time-consuming and expensive to label sample data. These challenges reduce the performance of traditional deep learning models in anomaly detection. To overcome these challenges, a novel weighted-transfer domain-adaptation network (WTDAN) method is introduced to realize the online anomaly detection and fault diagnosis of UAV electromagnetic-sensitive flight data. The method is based on unsupervised transfer learning, which can transfer the knowledge learnt from existing datasets to solve problems in the target domain. The method contains three novel multiscale modules: a feature extractor, used to extract multidimensional features from the input; a domain discriminator, used to improve the imbalance of the data distribution between the source domain and the target domain; and a label classifier, used to classify data categories for the target domain. Multilayer domain adaptation is used to reduce the distance between the source domain datasets and the target domain datasets distributions. The WTDAN assigns different weights to the source domain samples in order to weight the different contributions of source samples to solve the problem during the training process. The dataset adopts not only open datasets from the website but also test datasets from experiments to evaluate the transferability of the proposed WTDAN model. The experimental results show that, under the condition of fewer anomalous target data samples, the proposed method had a classification accuracy of up to 90%, which is higher than that of the other compared methods, and performed with superior transferability on the cross-domain datasets. The capability of fault diagnosis can provide a novel method for online anomaly detection and the prognostics and health management (PHM) of UAVs, which, in turn, would improve the reliability, repairability, and safety of UAV systems. Full article

This study introduces an innovative two-stage framework for monitoring and diagnosing high-dimensional data streams with sparse changes. The first stage utilizes an exponentially weighted moving average (EWMA) statistic for online monitoring, identifying change points through extreme value theory and multiple hypothesis testing. The second stage involves a fault diagnosis mechanism that accurately pinpoints abnormal components upon detecting anomalies. Through extensive numerical simulations and electron probe X-ray microanalysis applications, the method demonstrates exceptional performance. It rapidly detects anomalies, often within one or two sampling intervals post-change, achieves near 100% detection power, and maintains type-I error rates around the nominal 5%. The fault diagnosis mechanism shows a 99.1% accuracy in identifying components in 200-dimensional anomaly streams, surpassing principal component analysis (PCA)-based methods by 28.0% in precision and controlling the false discovery rate within 3%. Case analyses confirm the method’s effectiveness in monitoring and identifying abnormal data, aligning with previous studies. These findings represent significant progress in managing high-dimensional sparse-change data streams over existing methods. Full article

This paper presents a state-based method to address the verification of $\mathcal{K}$-diagnosability and fault diagnosis of a finite-state vector discrete-event system (Vector DES) with partially observable state outputs due to limited sensors. Vector DES models consist of an arithmetic additive structure in both the state space and state transition function. This work offers a necessary and sufficient condition for verifying the $\mathcal{K}$-diagnosability of a finite-state Vector DES based on state sensor outputs, employing integer linear programming and the mathematical representation of a Vector DES. Predicates are employed to diagnose faults in a Vector DES online. Specifically, we use three different kinds of predicates to divide system state outputs into different subsets, and the fault occurrence in a system is detected by checking a subset of outputs. Online diagnosis is achieved via solving integer linear programming problems. The conclusions obtained in this work are explained by means of several examples. Full article

Dry-type air-core reactors (DARs) often have inter-turn short circuit (ITSC) faults. However, traditional fault detection methods for DARs generally demonstrate poor timeliness and low sensitivity, and few methods combine intelligent algorithms for objective and accurate diagnosis. Therefore, a novel online diagnosis method for ITSC faults was proposed. First, the “field-circuit” coupling 2D model of reactors was established to simulate the impact of ITSC faults on the characteristics of various state parameters; accordingly, the Lissajous graph was introduced to characterize the short circuit fault. Then, the variation law of the Lissajous graph under different inter-turn fault layers, turns, and degrees was explored to verify the feasibilities of the proposed method. Finally, to achieve rapid diagnosis and fulfill the requirements of edge computing, a lightweight network model named MobileNetV3-Small was used and combined as a classifier to achieve accurate diagnosis of ITSC faults. The results robustly validate that the Lissajous graphical method can significantly reflect ITSC faults through observing the variation in the graph and feature parameters. Furthermore, the MobileNetV3-Small model achieves a diagnostic accuracy of up to 95.91%, which can further enhance the diagnostic accuracy of the ITSC fault degree. Full article

In complex electromagnetic environments, such as substations, converter stations in power systems, and the compartments of aircraft, trains, and automobiles, electromagnetic immunity testing is crucial. It requires that the electric field sensor has features such as a large dynamic measurement range (amplitude from hundreds of V/m to tens of kV/m), a fast response speed (response time in the order of nanoseconds or sub-nanoseconds), a wide test bandwidth (DC to 1 GHz even above), miniaturization, and robustness to strong electromagnetic interference. This paper introduces a multi-channel, ultra-wideband transient electric field measurement system. The system’s analog bandwidth covers the spectrum from DC and a power frequency of 50 Hz to partial discharge signals, from DC to 1.65 GHz, with a storage depth of 2 GB (expandable). It overcomes issues related to the instability, insufficient bandwidth, and lack of accuracy of optical fibers in analog signal transmission by using front-end digital sampling based on field-programmable gate array (FPGA) technology and transmitting digital signals via optical fibers. This approach is effectively applicable to measurements in strong electromagnetic environments. Additionally, the system can simultaneously access four channels of signals, with synchronization timing reaching 300 picoseconds, can be connected to voltage and current sensors simultaneously, and the front-end sensor can be flexibly replaced. The performance of the system is verified by means of a disconnect switch operation and steady state test in an HVDC converter station. It is effectively applicable in scenarios such as the online monitoring of transient electromagnetic environments in high-voltage power equipment, fault diagnosis, and the precise localization of radiation sources such as partial discharge or intentional electromagnetic interference (IEMI). Full article

Maintenance strategies such as condition-based maintenance and predictive maintenance of machines have gained importance in industrial automation firms as key concepts in Industry 4.0. As a result, online condition monitoring of electromechanical systems has become a crucial task in many industrial applications. Motor current signature analysis (MCSA) is an interesting noninvasive alternative to vibration analysis for the condition monitoring and fault diagnosis of mechanical systems driven by electric motors. The MCSA approach is based on the premise that faults in the mechanical load driven by the motor manifest as changes in the motor’s current behavior. This paper presents a novel data-driven, MCSA-based CM approach that exploits autoregressive (AR) spectral estimation. A multiresolution analysis of the raw motor currents is first performed using the discrete wavelet transform with Daubechies filters, enabling the separation of noise, disturbances, and variable torque effects from the current signals. AR spectral estimation is then applied to selected wavelet details to extract relevant features for fault diagnosis. In particular, a reference AR power spectral density (PSD) is estimated using data collected under healthy conditions. The AR PSD is then continuously or periodically updated with new data frames and compared to the reference PSD through the Symmetric Itakura–Saito spectral distance (SISSD). The SISSD, which serves as the health indicator, has proven capable of detecting fault occurrences through changes in the AR spectrum. The proposed procedure is tested on real data from two different scenarios: (i) an experimental in-house setup where data are collected during the execution of electric cam motion tasks (imbalance faults are emulated); (ii) the Korea Advanced Institute of Science and Technology testbed, whose data set is publicly available (bearing faults are considered). The results demonstrate the effectiveness of the method in both fault detection and isolation. In particular, the proposed health indicator exhibits strong detection capabilities, as its values under fault conditions exceed those under healthy conditions by one order of magnitude. Full article
