Search Results (32)

Wastewater generation is a growing concern in the preliminary treatment of heavy crude oil and tar sand. The separation of fine oil droplets from water by flotation is a critical process in the production of bitumen from tar sand. The flow structure from a high-resolution simulation of a single air macrobubble (>3 mm diameter) rising through water in the presence of a very dilute dispersion of mono-sized oil microdroplets (30 μm) under quiescent conditions is presented. A combined model of computational fluid dynamics (CFD), a volume of fluid (VOF) multiphase approach, and the discrete phase method (DPM) was developed to simulate bubble dynamics, the trajectories of the dispersed oil droplet, and the interaction between the air bubble and the oil droplet in quiescent water. The CFD–VOF–DPM combined model reproduced the interacting dynamics of the bubble and oil droplets in water at the bubble–droplet scale. With an extremely large diameter ratio between the bubble and the dispersed oil droplet, this model clearly demonstrated that the dominant mechanism for the interaction was the hydrodynamic capture of oil droplets in the wake of a rising air macrobubble. The entrainment of the oil droplets into the wake of the rising bubbles was strongly influenced by the bubble’s shape. Full article

Due to their high surface area and low weight, silica aerogels are ideally suited for several uses, including drug delivery, catalysis, and insulation. Oil–water–oil (OWO) double emulsion is a simple and regulated technique for encasing a volatile oil phase in a silica shell to produce hollow silica (SiO₂) aerogel particles by using hydrophilic and hydrophobic emulsifiers. In this study, the oil–water–oil (OWO) double emulsion method was implemented to synthesize surface-modified hollow silica (SiO₂) aerogel particles in a facile and effective way. This investigation mainly focused on the influence of the N-hexane-to-water glass (OW) ratio (r) in the first emulsion, silica (water glass) content concentration (x), and surfactant concentration (s) variations. Furthermore, surface modification techniques were utilized to customize the aerogel’s characteristics. The X-ray diffraction (XRD) patterns showed no imprints of impurities except SiO₂. Scanning electron microscopy (SEM) and transmission electron microscopy (TEM) images highlight the hollow microstructure of silica particles. Zeta potential was used to determine particle size analysis of hollow silica aerogel particles. The oil–water–oil (OWO) double emulsion approach was successfully employed to synthesize surface-modified hollow silica (SiO₂) aerogel particles, providing precise control over the particle characteristics. By the influence of the optimization condition, this approach improves the aerogel’s potential applications in drug delivery, catalysis, and insulation by enabling surface modifications. Full article

Microdroplet-based fluidic systems have the advantages of small size, short diffusion time, and no cross-contamination; consequently, droplets often provide a fast and precise reaction environment as well as an analytical environment for individual molecules. In order to handle diverse reactions, we developed a method to create organic single-micron droplets (S-MDs) smaller than 5 μm in diameter dispersed in silicone oil without surfactant. The S-MD generation microflow device consists of a mother droplet (MoD) generator and a tapered separation channel featuring multiple side channels. The tapered channel enhanced the shear forces to form tails from the MoDs, causing them to break up. Surface treatment with the fluoropolymer CYTOP protected PDMS fluid devices from organic fluids. The tailing separation of methanol droplets was accomplished without the use of surfactants. The generation of tiny organic droplets may offer new insights into chemical separation and help study the scaling effects of various chemical reactions. Full article

Microfluidics offers a highly controlled and reproducible route to synthesize lipid vesicles. In recent years, several microfluidic approaches have been introduced for this purpose, but double emulsions, such as Water-in-Oil-in-Water (W/O/W) droplets, are preferable to produce giant vesicles that are able to maximize material encapsulation. Flow focusing (FF) is a technique used to generate double emulsion droplets with high monodispersity, a controllable size, and good robustness. Many researchers use polydimethylsiloxane as a substrate material to fabricate microdroplet generators, but it has some limitations due to its hydrophobicity, incompatibility with organic solvents, and the molecular adsorption on the microchannel walls. Thus, specific surface modification and functionalization steps, which are uncomfortable to perform in closed microchannels, are required to overcome these shortcomings. Here, we propose glass as a material to produce a chip with a six-inlet junction geometry. The peculiar geometry and the glass physicochemical properties allow for W/O/W droplet formation without introducing microchannel wall functionalization and using a variety of reagents and organic solvents. The robust glass chip can be easily cleaned and used repeatedly, bringing advantages in terms of cost and reproducibility in emulsion preparation. Full article

Uniform and stable droplet generation is critical for accurate and efficient digital nucleic acid analysis (dNAA). In this study, an integrated microfluidic step emulsification device with wide-range droplet generation capability, small device dimensions, convenient fabrication strategy, low contamination and high robustness was developed. A tree-shaped droplet generation nozzle distribution design was proposed to increase the uniformity of droplet generation by equating flow rates, and the flow field in the design was numerically simulated. Theoretical analysis and comparative experiments on droplet size were performed regarding the influences of nozzle dimensions and surface properties. With incubation and hydrophobic reagent treatment, droplets as small as 73.1 μm were generated with multiplex nozzles of 18 μm (h) × 80 μm (w). The droplets were then collected into a standard PCR tube and an on-chip monolayer droplet collection chamber, without manual transfer and sample contamination. The oil-to-sample volume ratio in the PCR tube was recorded during collection. In the end, the droplets generated and collected using the microfluidic device proved to be stable and uniform for nucleic acid amplification and detection. This study provides reliable characteristic information for the design and fabrication of a micro-droplet generation device, and represents a promising approach for the realization of a three-in-one dNAA device under a step emulsification method. Full article

In vitro compartmentalization (IVC) is a technique for generating water-in-oil microdroplets to establish the genotype (DNA information)–phenotype (biomolecule function) linkage required by many biological applications. Recently, fluorinated oils have become more widely used for making microdroplets due to their better biocompatibility. However, it is difficult to perform multi-step reactions requiring the addition of reagents in water-in-fluorinated-oil microdroplets. On-chip droplet manipulation is usually used for such purposes, but it may encounter some technical issues such as low throughput or time delay of reagent delivery into different microdroplets. Hence, to overcome the above issues, we demonstrated a nanodroplet-based approach for the delivery of copper ions and middle-sized peptide molecules (human p53 peptide, 2 kDa). We confirmed the ion delivery by microscopic inspection of crystal formation inside the microdroplet, and confirmed the peptide delivery using a fluorescent immunosensor. We believe that this nanodroplet-based delivery method is a promising approach to achieving precise control for a broad range of fluorocarbon IVC-based biological applications, including molecular evolution, cell factory engineering, digital nucleic acid detection, or drug screening. Full article

A device and method for the constant pressure regulation of microdroplet PCR in microfluidic chips are developed to optimize for the microdroplet movement, fragmentation, and bubble generation in microfluidic chips. In the developed device, an air source device is adopted to regulate the pressure in the chip, such that microdroplet generation and PCR amplification without bubbles can be achieved. In 3 min, the sample in 20 μL will be distributed into nearly 50,000 water-in-oil droplets exhibiting a diameter of about 87 μm, and the microdroplet will be subjected to a close arrangement in the chip without air bubbles. The device and chip are adopted to quantitatively detect human genes. As indicated by the experimental results, a good linear relationship exists between the detection signal and DNA concentration ranging from 10¹ to 10⁵ copies/μL (R² = 0.999). The microdroplet PCR devices based on constant pressure regulation chips exhibit a wide variety of advantages (e.g., achieving high pollution resistance, microdroplet fragmentation and integration avoidance, reducing human interference, and standardizing results). Thus, microdroplet PCR devices based on constant pressure regulation chips have promising applications for nucleic acid quantification. Full article

The conventional pneumatic Minimum Quantity Lubrication (MQL), when not properly designed, may have poor atomization and insufficient wetting performance, resulting in higher oil mist concentration and poor film formation ability in the cutting zone. The intervention of an external electric field can change the atomization mechanism of microdroplets and enhance the lubrication and cooling capability of MQL. However, the mechanism of the effect of jet parameters on the atomization performance of Electrostatic Minimum Quantity Lubrication (EMQL) under the synergistic effect of multiple fields has not been fully analyzed. In this paper, based on the designed needle electrode charging nozzle, the atomization medium charging and atomization mechanisms are investigated, and a mathematical model of the volume average diameter of droplets (VAD) is established. Based on multi-parameter atomization experiments, the electrode conical jet atomization model is validated and the mechanism of the influence of jet parameters on the atomization characteristics is analyzed. The results show that the VAD is negatively correlated with air pressure and electrical. The atomization performance of the droplets was improved under the applied voltage condition, which was manifested by the obvious refinement of the VAD, with a maximum reduction of 34.67%, a maximum reduction of 20% in the droplet group size distribution span (R.S.), and a different degree of reduction in the percentage concentration of fine particulate matter. In addition, the model fitted well with the experimental values, with an overall error of about 10%. Full article

We developed a microfluidic chip integrated with nucleic acid purification and droplet-based digital polymerase chain reaction (ddPCR) modules to realize a ‘sample-in, result-out’ infectious virus diagnosis. The whole process involved pulling magnetic beads through drops in an oil-enclosed environment. The purified nucleic acids were dispensed into microdroplets by a concentric-ring, oil–water-mixing, flow-focusing droplets generator driven under negative pressure conditions. Microdroplets were generated with good uniformity (CV = 5.8%), adjustable diameters (50–200 μm), and controllable flow rates (0–0.3 μL/s). Further verification was provided by quantitative detection of plasmids. We observed a linear correlation of R² = 0.9998 in the concentration range from 10 to 10⁵ copies/μL. Finally, this chip was applied to quantify the nucleic acid concentrations of the severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2). The measured nucleic acid recovery rate of 75 ± 8.8% and detection limit of 10 copies/μL proved its on-chip purification and accurate detection abilities. This chip can potentially be a valuable tool in point-of-care testing. Full article

Currently, coaxial electrohydrodynamic jet (CE-Jet) printing is used as a promising technique for the alternative fabrication of drop-on-demand micro- and nanoscale structures without using a template. Therefore, this paper presents numerical simulation of the DoD CE-Jet process based on a phase field model. Titanium lead zirconate (PZT) and silicone oil were used to verify the numerical simulation and the experiments. The optimized working parameters (i.e., inner liquid flow velocity 150 m/s, pulse voltage 8.0 kV, external fluid velocity 250 m/s, print height 16 cm) were used to control the stability of the CE-Jet, avoiding the bulging effect during experimental study. Consequently, different sized microdroplets with a minimum diameter of ~5.5 µm were directly printed after the removal of the outer solution. The model is considered the easiest to implement and is powerful for the application of flexible printed electronics in advanced manufacturing technology. Full article

With the advent of many optofluidic and droplet microfluidic applications using laser-induced fluorescence (LIF), the need for a better understanding of the heating effect induced by pump laser excitation sources and good monitoring of temperature inside such confined microsystems started to emerge. We developed a broadband highly sensitive optofluidic detection system, which enabled us to show for the first time that Rhodamine-B dye molecules can exhibit standard photoluminescence as well as blue-shifted photoluminescence. We demonstrate that this phenomenon originates from the interaction between the pump laser beam and dye molecules when surrounded by the low thermal conductive fluorocarbon oil, generally used as a carrier medium in droplet microfluidics. We also show that when the temperature is increased, both Stokes and anti-Stokes fluorescence intensities remain practically constant until a temperature transition is reached, above which the fluorescence intensity starts to decrease linearly with a thermal sensitivity of about $-0.4\%/°$C for Stokes emission or $-0.2\%/°$C for anti-Stokes emission. For an excitation power of 3.5 mW, the temperature transition was found to be about 25 $°$C, whereas for a smaller excitation power (0.5 mW), the transition temperature was found to be about 36 $°$C. Full article

Catastrophic oil spill accidents, oily industrial wastewater, and other types of uncontrolled release of oils into the environment are major global issues since they threaten marine ecosystems and lead to a big economic impact. It can also affect the public health of communities near the polluted area. This review addresses the different types of oil collecting methods. The focus of this work will be on the different approaches to materials and technologies for oil/water separation, with a special focus on water/oil emulsion separation. Emulsified oil/water mixtures are extremely stable dispersions being, therefore, more difficult to separate as the size of the droplets in the emulsion decreases. Oil-absorbent materials, such as sponges, foams, nanoparticles, and aerogels, can be adjusted to have both hydrophobic and oleophilic wettability while displaying a porous structure. This can be advantageous for targeting oil spills in large-scale environmental and catastrophic sets since these materials can easily absorb oil. Oil adsorbent materials, for example, meshes, textiles, membranes, and clays, involve the capture of the oily material to the surface of the adsorbent material, additionally attracting more attention than other technologies by being low-cost and easy to manufacture. Full article

Micro-droplets are widely used in the fields of chemical and biological research, such as drug delivery, material synthesis, point-of-care diagnostics, and digital PCR. Droplet-based microfluidics has many advantages, such as small reagent consumption, fast reaction time, and independent control of each droplet. Therefore, various micro-droplet generation methods have been proposed, including T-junction breakup, capillary flow-focusing, planar flow-focusing, step emulsification, and high aspect (height-to-width) ratio confinement. In this study, we propose a microfluidic device for generating monodisperse micro-droplets, the microfluidic channel of which has an asymmetric cross-sectional shape and high hypotenuse-to-width ratio (HTWR). It was fabricated using basic MEMS processes, such as photolithography, anisotropic wet etching of Si, and polydimethylsiloxane (PDMS) molding. Due to the geometric similarity of a Si channel and a PDMS mold, both of which were created through the anisotropic etching process of a single crystal Si, the microfluidic channel with the asymmetric cross-sectional shape and high HTWR was easily realized. The effects of HTWR of channels on the size and uniformity of generated micro-droplets were investigated. The monodisperse micro-droplets were generated as the HTWR of the asymmetric channel was over 3.5. In addition, it was found that the flow direction of the oil solution (continuous phase) affected the size of micro-droplets due to the asymmetric channel structures. Two kinds of monodisperse droplets with different sizes were successfully generated for a wider range of flow rates using the asymmetric channel structure in the developed microfluidic device. Full article

Chronic wound healing represents an impactful financial burden on healthcare systems. In this context, the use of natural products as an alternative therapy reduces costs and maintains effectiveness. Phytotherapeutic gels applied in photodynamic therapy (PDT) have been developed to act as topical healing medicines and antibiotics. The bioactive system is composed of Spirulina sp. (source of chlorophylls) and Copaifera reticulata oil microdroplets, both incorporated into a polymeric blend constituted by kappa-carrageenan (k-car) and F127 copolymer, constituting a system in which all components are bioactive agents. The flow behavior and viscoelasticity of the formulations were investigated. The photodynamic activity was accessed from studies of the inactivation of Staphylococcus aureus bacteria, the main pathogen of hospital relevance. Furthermore, in vivo studies were conducted using eighteen rabbits with dermatitis (grade III and IV) in both paws. The gels showed significant antibiotic potential in vitro, eliminating up to 100% of S. aureus colonies in the presence or absence of light. The k-car reduced 41% of the viable cells; however, its benefits were enhanced by adding chlorophyll and copaiba oil. The animals treated with the phytotherapeutic medicine showed a reduction in lesion size, with healing and re-epithelialization verified in the histological analyses. The animals submitted to PDT displayed noticeable improvement, indicating this therapy’s viability for ulcerative and infected wounds. This behavior was not observed in the iodine control treatment, which worsened the animals’ condition. Therefore, gel formulations were a viable alternative for future pharmaceutical applications, aiming at topical healing. Full article

Membrane filtration is a promising technology for oil/water emulsion filtration due to its excellent removal efficiency of microdroplets of oil in water. However, its performance is highly limited due to the fouling-prone nature of oil droplets on hydrophobic membranes. Membrane filtration typically suffers from a low flux and high pumping energy. This study reports a combined approach to tackling the membrane fouling challenge in oil/water emulsion filtration via a membrane and a flow channel development. Two polysulfone (PSF)-based lab-made membranes, namely PSF- PSF-Nonsolvent induced phase separation (NIPS) and PSF-Vapor-induced phase separation (VIPS), were selected, and the flow channel was modified into a wavy path. They were assessed for the filtration of a synthetic oil/water emulsion. The results showed that the combined membrane and flow channel developments enhanced the clean water permeability with a combined increment of 105%, of which 34% was attributed to the increased effective filtration area due to the wavy flow channel. When evaluated for the filtration of an oil/water emulsion, a 355% permeability increment was achieved from 43 for the PSF-NIPS in the straight flow channel to 198 L m⁻² h⁻¹ bar⁻¹ for the PSF-VIPS in the wavy flow channel. This remarkable performance increment was achieved thanks to the antifouling attribute of the developed membrane and enhanced local mixing by the wavy flow channel to limit the membrane fouling. The increase in the filtration performance was translated into up to 78.4% (0.00133 vs. 0.00615 kWh m⁻³) lower in pumping energy. The overall findings demonstrate a significant improvement by adopting multi-pronged approaches in tackling the challenge of membrane fouling for oil/water emulsion filtration, suggesting the potential of this approach to be applied for other feeds. Full article
