In the process of the intelligent inspection of belt conveyor systems, due to problems such as its long duration, the large number of rollers, and the complex working environment, fault diagnosis by acoustic signals is easily affected by signal coupling interference, which poses a great challenge to selecting denoising methods of signal preprocessing. This paper proposes a novel wavelet threshold denoising algorithm by integrating a new biparameter and trisegment threshold function. Firstly, we elaborate on the mutual influence and optimization process of two adjustment parameters and three wavelet coefficient processing intervals in the BT-WTD (the biparameter and trisegment of wavelet threshold denoising, BT-WTD) denoising model. Subsequently, the advantages of the proposed threshold function are theoretically demonstrated. Finally, the BT-WTD algorithm is applied to denoise the simulation signals and the vibration and acoustic signals collected from the belt conveyor experimental platform. The experimental results indicate that this method’s denoising effectiveness surpasses that of traditional threshold function denoising algorithms, effectively addressing the denoising preprocessing of idler roller fault signals under strong noise backgrounds while preserving useful signal features and avoiding signal distortion problems. This research lays the theoretical foundation for the non-contact intelligent fault diagnosis of future inspection robots based on acoustic signals. Full article

Offshore support structures and mooring systems are predominantly subject to corrosion and fatigue. These structures are typically covered with marine growth of various types. Conventional inspection methods for assessment of the structural integrity require access to the cleaned surface of these structures; however, the cleaning process is highly undesirable from the technical, economical, and environmental points of view. This paper highlights research on feasibility assessment of detection and localization of corrosion damage under marine growth using acoustic emission (AE). Experiments were conducted on two carbon steel plates, one baseline sample and one covered with artificially fabricated marine growth. The results of accelerated corrosion experiments suggest that corrosion-induced ultrasound signals can be detected with satisfactory signal-to-noise ratio using non-contact AE sensors. Ultrasound waves passing through marine growth showed around 12 dB drop in amplitude when compared to the base plate. A localization algorithm for corrosion induced-ultrasound signals was successfully implemented. Full article

Non-destructive testing, with non-contact from a remote location, to detect and visualize internal defects in composite materials such as a concrete is desired. Therefore, a noncontact acoustic inspection method has been studied. In this method, the measurement surface is forced to vibrate by powerful aerial sound waves from a remote sound source, and the vibration state is measured by a laser Doppler vibrometer. The distribution of acoustic feature quantities (spectral entropy and vibrational energy ratio) is analyzed to statistically identify and evaluate healthy parts of concrete. If healthy parts in the measuring plane can be identified, the other part is considered to be internal defects or an abnormal measurement point. As a result, internal defects are detected. Spectral entropy (SE) was used to distinguish between defective parts and healthy parts. Furthermore, in order to distinguish between the resonance of a laser head and the resonance of the defective part of the concrete, spatial spectral entropy (SSE) was also used. SSE is an extension of the concept of SE to a two-dimensional measuring space. That is, based on the concept of SE, SSE is calculated, at each frequency, for spatial distribution of vibration velocity spectrum in the measuring plane. However, these two entropy values were used in unnormalized expressions. Therefore, although relative evaluation within the same measurement surface was possible, there was the issue that changes in the entropy value could not be evaluated in a unified manner in measurements under different conditions and environments. Therefore, this study verified whether it is possible to perform a unified evaluation for different defective parts of concrete specimen by using normalized SE and normalized SSE. From the experimental results using cavity defects and peeling defects, the detection and visualization of internal defects in concrete can be effectively carried out by the following two analysis methods. The first is using both the normalized SE and the evaluation of a healthy part of concrete. The second is the normalized SSE analysis that detects resonance frequency band of internal defects. Full article

The article describes a complex of non-contact methods for remote diagnosis of high-voltage insulators as well as the two-channel method for remote diagnostics of the operating state of high-voltage insulators, based on the registration of partial discharges by electromagnetic and acoustic sensors. The presented device allows visual inspection and searches for faulty high-voltage equipment and a remote non-contact method of recording high-intensity electric fields of industrial frequency and their spatial distribution based on the electro-optical effect. The scheme of using the system for monitoring and diagnosing the technical condition of high-voltage support insulators of open switchgear is described. The results of experimental studies confirm the possibility of industrial applicability of the proposed method for non-contact remote diagnostics of the state of high-voltage insulators under operating voltage. Full article

The absolute acoustic nonlinearity parameter β is defined by the displacement amplitudes of the fundamental and second-order harmonic frequency components of the ultrasonic wave propagating through the material. As β is a sensitive index for the micro-damage interior of industrial components at early stages, its measurement methods have been actively investigated. This study proposes a laser-ultrasonic detection method to measure β. This method provides (1) the β measurement in a noncontact and nondestructive manner, (2) inspection ability of different materials without complex calibration owing to direct ultrasonic displacement detection, and (3) applicability for the general milling machined surfaces of components owing to the use of a laser interferometer based on two-wave mixing in the photorefractive crystal. The performance of the proposed method is validated using copper and 6061 aluminum alloy specimens with sub-micrometer surface roughness. The experimental results demonstrated that the β values measured by the proposed method for the two specimens were consistent with those obtained by the conventional piezoelectric detection method and the range of previously published values. Full article

Ultrasound non-destructive testing (NDT) is a common technique used for defect detection in different materials, from aluminium to carbon-fiber-reinforced polymers (CFRPs). In most cases, a liquid coupling medium/immersion of the inspected component is required to maximize impedance matching, limiting the size of the structure and materials. Air-coupled inspection methods have recently been developed for noncontact inspections to reduce contact issues in standard ultrasonic inspections. However, transmission of ultrasound in air is very inefficient because of the enormous impedance mismatch between solids and air, thus requiring a signal amplification system of high-sensitivity transducers. Hence, the captured signal amplitude may not be high enough to reveal any wave distortion due to defects or damage. This work presents a design of a holey-structured metamaterial lens with a feature size of λ/14 aiming at improvement of acousto-ultrasonic imaging using air-coupled transducers. The required effect is obtained by matching geometrical parameters of the proposed holey-structured metamaterials and the Fabry–Perot resonance modes of the structure. Transmission tests have been conducted on different fabricated metamaterial-based structures, to assess the frequency component filtering of the proposed method in both acoustic (f = 5 kHz, 20 kHz) and ultrasonic range (f = 30 kHz, 40 kHz). Results showed an improved sensitivity of damage imaging, with an increase in amplitude of the design frequencies of the lens by 11 dB. Air-coupled inspections were conducted on a stress-corrosion cracked aluminum plate and impacted CFRP plate using the holey-structured lens. Results showed an improvement in the damage-imaging resolution due to a wave-amplitude increase across the defective features, thus demonstrating its potential as an efficient and sensitive inspection tool for damage-detection improvement in geometrically complex components of different materials. Full article

Steel wires are widely used as raw materials for spring valves in engines. Considering the quality and safety issues of their structure, there is a demand to develop nondestructive inspection approaches to detect initial damages in steel. In this study, nonlinear ultrasonic-guided waves generated by an electromagnetic acoustic transducer (EMAT) were used to inspect the defects in steel wires. As one of the noncontact testing methods, the use of EMAT has significant advantages to decrease the nonlinearity induced by instruments and transducer contact condition. The principles of design and manufacturing of EMAT are first introduced. The fundamental theory of nonlinear guided waves is also briefly discussed in this investigation. Phase-matched guided wave modes were generated and measured by using EMAT. Variations of acoustic nonlinearity corresponding to existing defects in specimens were obtained. A scanning electron microscope (SEM) was used to check the existence of microdefects in specimen. The results indicate that the use of EMAT can be an effective means to generate and measure nonlinear ultrasonic-guided waves for inspection of microdefects. Full article

Ultrasonic testing is an important means to detect defacing defects, such as scratches and cracks, but when the size of these defects is smaller than the wavelength of ultrasonic waves, it is difficult to detect them using traditional methods like the pulse-echo method and broadband ultrasound attenuation method for the diffraction of ultrasonic waves at the defects. Based on the non-contact characteristic of electromagnetic acoustic transducers (EMATs), a transducer for scanning inspection was developed in this paper. The transducer was utilized to detect and measure the depth of the defacing defects on an aluminium plate based on the near-field enhancement of ultrasonic Lamb waves. The results show that the amplitude of the S0 Lamb wave experiences a large enhancement when the transducer is passed over the scratch defects and the enhancement has a clearly positive correlation with the depth of the scratch defects. When the depth increases from 0.1 mm to 0.9 mm, the amplitude of S0 Lamb waves increases from 1.13 times to 2.27 times the S0 Lamb waves received on the aluminium plate without defects. The new method can be utilized to detect the defacing defects on the aluminium plate and get better detection effects than the traditional methods without analyzing the relatively small reflection waves. Full article

Additive manufacturing (AM) is a production technology where material is accumulated to create a structure, often through added shaped layers. The major advantage of additive manufacturing is in creating unique and complex parts for use in areas where conventional manufacturing reaches its limitations. However, the current class of AM systems produce parts that contain structural defects (e.g., cracks and pores) which is not compatible with certification in high value industries. The probable complexity of an AM design increases the difficulty of using many non-destructive evaluation (NDE) techniques to inspect AM parts—however, a unique opportunity exists to interrogate a part during production using a rapid surface based technique. Spatially resolved acoustic spectroscopy (SRAS) is a laser ultrasound inspection technique used to image material microstructure of metals and alloys. SRAS generates and detects `controlled’ surface acoustic waves (SAWs) using lasers, which makes it a non-contact and non-destructive technique. The technique is also sensitive to surface and subsurface voids. Work until now has been on imaging the texture information of selective laser melted (SLM) parts once prepared (i.e., polished with $R_a<0.1$ $\mathsf{\mu }$ m)—the challenge for performing laser ultrasonics in-process is measuring waves on the rough surfaces present on as-deposited parts. This paper presents the results of a prototype SRAS system, developed using the rough surface ultrasound detector known as speckle knife edge detector (SKED)—texture images using this setup of an as-deposited Ti64 SLM sample, with a surface roughness of $S_a\approx 6$ $\mathsf{\mu }$ m, were obtained. Full article

Elevated temperature, gamma radiation, and geometric constraints inside dry storage casks for spent nuclear fuel represent a harsh environment for nondestructive inspection of the cask and require that the inspection be conducted with a robotic system. Electromagnetic acoustic transducers (EMATs) using non-contact ultrasonic transduction based on the Lorentz force to excite/receive ultrasonic waves are suited for use in the robotic inspection. Periodic permanent magnet EMATs that actuate/receive shear horizontal guided waves are developed for application to robotic nondestructive inspection of stress corrosion cracks in the heat affected zone of welds in stainless steel dry storage canisters. The EMAT’s components are carefully selected in consideration of the inspection environment, and tested under elevated temperature and gamma radiation doses up to 177 °C and 5920 krad, respectively, to evaluate the performance of the EMATs under realistic environmental conditions. The effect of gamma radiation is minimal, but the EMAT’s performance is affected by temperatures above 121 °C due to the low Curie temperature of the magnets. Different magnets are needed to operate at 177 °C. The EMAT’s capability to detect notches is also evaluated from B-scan measurements on 304 stainless steel welded plate containing surface-breaking notches. Full article

Harsh environments and confined spaces require that nondestructive inspections be conducted with robotic systems. Ultrasonic guided waves are well suited for robotic systems because they can provide efficient volumetric coverage when inspecting for various types of damage, including cracks and corrosion. Shear horizontal guided waves are especially well suited for robotic inspection because they are sensitive to cracks oriented perpendicular or parallel to the wave propagation direction and can be generated with electromagnetic acoustic transducers (EMATs) and magnetostrictive transducers (MSTs). Both types of transducers are investigated for crack detection in a stainless steel plate. The MSTs require the robot to apply a compressive normal force that creates frictional force coupling. However, the coupling is observed to be very dependent upon surface roughness and surface debris. The EMATs are coupled through the Lorentz force and are thus noncontact, although they depend on the lift off between transducer and substrate. After comparing advantages and disadvantages of each transducer for robotic inspection the EMATs are selected for application to canisters that store used nuclear fuel. Full article

Concentrated Solar Plants (CSPs) are used in solar thermal industry for collecting and converting sunlight into electricity. Parabolic trough CSPs are the most widely used type of CSP and an absorber tube is an essential part of them. The hostile operating environment of the absorber tubes, such as high temperatures (400–550 °C), contraction/expansion, and vibrations, may lead them to suffer from creep, thermo-mechanical fatigue, and hot corrosion. Hence, their condition monitoring is of crucial importance and a very challenging task as well. Electromagnetic Acoustic Transducers (EMATs) are a promising, non-contact technology of transducers that has the potential to be used for the inspection of large structures at high temperatures by exciting Guided Waves. In this paper, a study regarding the potential use of EMATs in this application and their performance at high temperature is presented. A Periodic Permanent Magnet (PPM) EMAT with a racetrack coil, designed to excite Shear Horizontal waves (SH₀), has been theoretically and experimentally evaluated at both room and high temperatures. Full article

Surface waves are commonly used for vibration-based nondestructive testing for infrastructure. Spectral Analysis of Surface Waves (SASW) has been used to detect subsurface properties for geologic inspections. Recently, efforts were made to scale down these subsurface detection approaches to see how they perform on small-scale structures such as concrete slabs and pavements. Additional efforts have been made to replace the traditional surface-mounted transducers with non-contact acoustic transducers. Though some success has been achieved, most of these new approaches are inefficient because they require point-to-point measurements or off-line signal analysis. This article introduces a Mobile Acoustic Subsurface Sensing system as MASS, which is an improved surface wave based implementation for measuring the subsurface profile of roadways. The compact MASS system is a 3-wheeled cart outfitted with an electromagnetic impact source, distance register, non-contact acoustic sensors and data acquisition/ processing equipment. The key advantage of the MASS system is the capability to collect measurements continuously at walking speed in an automatic way. The fast scan and real-time analysis advantages are based upon the non-contact acoustic sensing and fast air-coupled surface wave analysis program. This integration of hardware and software makes the MASS system an efficient mobile prototype for the field test. Full article

This work presents a convenient and non-contact acoustic sensing approach for measuring ground vibration. This approach, which uses an instantaneous dynamic tire pressure sensor (DTPS), possesses the capability to replace the accelerometer or directional microphone currently being used for inspecting pavement conditions. By measuring dynamic pressure changes inside the tire, ground vibration can be amplified and isolated from environmental noise. In this work, verifications of the DTPS concept of sensing inside the tire have been carried out. In addition, comparisons between a DTPS, ground-mounted accelerometer, and directional microphone are made. A data analysis algorithm has been developed and optimized to reconstruct ground acceleration from DTPS data. Numerical and experimental studies of this DTPS reveal a strong potential for measuring ground vibration caused by a moving vehicle. A calibration of transfer function between dynamic tire pressure change and ground acceleration may be needed for different tire system or for more accurate application. Full article
