Search Results (14)

This study proposes an iterative method based on thermal equilibrium equations to calculate the radial temperature distribution of long-span overhead transmission lines under forced convection. This paper takes the ACSR 500/280 conductor as the research object, establishes the three-dimensional finite element model considering the helix angle of the conductor, and carries out the experimental validation for the LGJ 300/40 conductor under the same conditions. The model captures internal temperature distribution through contour analysis and examines the effects of current, wind speed, and ambient temperature. Unlike traditional models assuming uniform conductor temperature, this method reveals internal thermal gradients and introduces a novel three-stage radial attenuation characterization. The iterative method converges and accurately reflects temperature variations. The results show a non-uniform radial distribution, with a maximum temperature difference of 8 °C and steeper gradients in aluminum than in steel. Increasing current raises temperature nonlinearly, enlarging the radial difference. Higher wind speeds reduce both temperature and radial difference, while rising ambient temperatures increase conductor temperature with a stable radial profile. This work provides valuable insights for the safe operation and optimal design of long-span transmission lines and supports future research on dynamic and environmental coupling effects. Full article

This paper presents an improved compact model for TeraFETs employing a nonlinear transmission line approach to describe the non-uniform carrier density oscillations and electron inertia effects in the TeraFET channels. By calculating the equivalent components for each segment of the channel—conductance, capacitance, and inductance—based on the voltages at the segment’s nodes, our model accommodates non-uniform variations along the channel. We validate the efficacy of this approach by comparing terahertz (THz) response simulations with experimental data and MOSA1 and EKV TeraFET SPICE models, analytical theories, and Multiphysics simulations. Full article

An equivalent nonuniform transmission line model for electromagnetic radiation in free space is developed. By properly defining a voltage and a current associated with the transverse component of the mode fields, a kind of telegrapher’s equation is derived for each spherical harmonic mode in frequency domain. Based on the equivalent distribution inductance and capacitance, the local characteristic impedance and phase velocity are derived. For each spherical mode, a cutoff spherical surface and an associated cutoff radius are introduced to separate the space into an evanescent region and a propagating region. A spherical mode field decays approximately exponentially in the evanescent region and experience local reflection in the propagating region. The proposed model may provide an intuitive illustration for the radiation process in free space. Full article

In this paper, planar and the cylindrical broadband non-uniform acoustic absorbers were constructed, both of which use broadband absorption units (BAUs) as their building blocks. The impedance boundary Navier–Stokes equation (IBNSE) method was developed to predict the absorption characteristics of the lined duct with non-uniform acoustic absorbers, in which each small piece of perforated plate is acoustically equivalent to a semi-empirical impedance model through the boundary condition. A total of four semi-empirical impedance models were compared under different control parameters. The full Navier–Stokes equation (FNSE) method was used to verify the accuracy of these impedance models. It was found that the IBNSE method with the Goodrich model had the highest prediction accuracy. Finally, the planar and the cylindrical non-uniform acoustic absorbers were constructed through spatial extensions of the BAU. The transmission losses and the absorption coefficients of the rectangular duct–planar acoustic absorber (RDPAA) and annular duct–cylindrical acoustic absorber (ADCAA) systems under grazing flow were predicted, respectively. The results demonstrated that the broadband absorption of the designed non-uniform acoustic absorbers was achieved. The developed IBNSE method with Goodrich model was accurate and computationally efficient, and can be used to predict the absorption characteristics of an acoustically treated duct in the presence of grazing flow. Full article

The present paper gives an overview of modelling methods of standard grounding systems under surge conditions, using the non-uniform transmission line approach. The model presented considers the soil ionization and the frequency dependence of the soil parameters during the current transients. Furthermore, the representation of the non-linear response of the soil is made using a shunt time-variable resistance to simulate the behavior of the grounding resistance when a surge current flows through the system. The model development and analysis are made using ATP-EMTP/ATPDraw transient software. Full article

In many fields, such as space astrophysics, plasma and vacuum electronics, there are many nonlinear strong coupling physical problems. In order to solve the problem of electron beam–wave interaction in cylindrical Traveling wave tube (TWT) with symmetrical structure, a multi particle simulation algorithm for beam circuit is designed. The algorithm allows aperiodic time input, nonuniform linearity and large space diagnosis for different particles. In this algorithm, the field of coupled slow-wave transmission line is simulated by finite difference method. Assuming that there is strong coupling between the beam and the circuit, the space center equation of transmission along the line is obtained, and the space charge field is modeled considering the space charge effect, which can easily be ignored. The Particle In Cell (PIC) method of frog leaping step scheme is adopted to evaluate the electric field of each particle center, determine the circuit and space charge field, and design the termination part to compensate for the loss in order to avoid self-excited agitation. Finally, a simple numerical simulation is carried out for the electromagnetic problem and the accuracy of the code is checked against the electromagnetic simulator CHPIC. Therefore, the algorithm can be used to solve the problem of beam–wave interactions in a fixed structure (cylindrical) in multiple fields and can accurately record the data in the process. Full article

In this article, the average power handling capability (APHC) of corrugated slow-wave transmission lines (SWTLs) is investigated. Firstly, the attenuation constants of conductor and dielectric are extracted by the multiline method. Secondly, the thermal resistance of corrugated SWTLs is analyzed based on the constant-angle model. To deal with the non-uniform corrugated structure of SWTLs, the concept of average heat-spreading width (AHSW) is introduced. Finally, the APHC of the corrugated SWTL is calculated using the attenuation constant and the thermal resistance. In addition, the APHC considering the temperature-dependent resistivity of metal conductor is also presented. For validation, the APHCs of SWTLs with different geometric parameters are evaluated. The results agree well with those obtained by the commercial software. Full article

Research on corona discharge, shared by physics, chemistry and electrical engineering, has not arrested yet. As a dissipative process, the development of corona increases the resistive losses of transmission lines and enhances the line capacitance locally. Introducing additional losses and propagation delay, along the line, non-linearity and non-uniformity of the line parameters; therefore, corona should not be neglected. The present work is meant to provide the reader with comprehensive information on the corona macroscopic phenomenology and development, referring to the most relevant contributions in the literature on this subject. The models proposed in the literature for the simulation of the corona development are reviewed in detail, and sensitivity curves are provided to highlight their dependence on the input parameters. Full article

An advanced method of modeling radio-frequency (RF) devices based on a deep learning technique is proposed for accurate prediction of S parameters. The S parameters of RF devices calculated by full-wave electromagnetic solvers along with the metallic geometry of the structure, permittivity and thickness of the dielectric layers of the RF devices are used partly as the training and partly as testing data for the deep learning structure. To implement the training procedure efficiently, a novel selection method of training data considering critical points is introduced. In order to rapidly and accurately map the geometrical parameters of the RF devices to the S parameters, deep neural networks are used to establish the multiple non-linear transforms. The hidden-layers of the neural networks are adaptively chosen based on the frequency response of the RF devices to guarantee the accuracy of generated model. The Adam optimization algorithm is utilized for the acceleration of training. With the established deep learning model of a parameterized device, the S parameters can efficiently be obtained when the device geometrical parameters change. Comparing with the traditional modeling method that uses shallow neural networks, the proposed method can achieve better accuracy, especially when the training data are non-uniform. Three RF devices, including a rectangular inductor, an interdigital capacitor, and two coupled transmission lines, are used for building and verifying the deep neural network. It is shown that the deep neural network has good robustness and excellent generalization ability. Even for very wide frequency band (0–100 GHz), the maximum relative error of the coupled transmission lines using the proposed method is below 3%. Full article

Improved Spectral Efficiency (SE) is a prominent feature of Massive Multiple-Input and Multiple-Output systems. These systems are prepared with antenna clusters at receiver $\left(R_x\right)$ and transmitter $\left(T_x\right)$. In this paper, we examined a massive MIMO system to increase SE in each cell that ultimately improves the area throughput of the system. We are aiming to find appropriate values of average cell-density (D), available bandwidth (B), and SE to maximize area throughput because it is the function of these parameters. Likewise, a SE augmentation model was developed to attain an increased transmit power and antenna array gain. The proposed model also considers the inter-user interference from neighboring cells along with incident angles of desired and interfering users. Moreover, simulation results validate the proposed model that is implementable in real-time scenarios by realizing maximum SE of 12.79 bits/s/Hz in Line of Sight (LoS) and 12.69 bits/s/Hz in Non-Line of Sight (NLoS) scenarios, respectively. The proposed results also substantiate the SE augmentation because it is a linear function of transmit power and array gain while using the Uniform Linear Array (ULA) configuration. The findings of this work ensure the efficient transmission of information in future networks. Full article

Since the atmosphere has a strong scattering effect on ultraviolet light, the transmission of non-line-of-sight (NLOS) signals can be realized in the atmosphere. In previous articles, ultraviolet (UV) light atmospheric scattering has been characterized by many scattering models based on spot light sources with uniformly distributed light intensity. In order to explore the role of light sources in atmospheric transmission, this work proposed a UV light atmospheric transport model under different types of light source, including light-emitting diode (LED), laser, and ordinary light sources, based on the Monte Carlo point probability method. The simulation of the light source in the proposed model is a departure from the use of a light source with uniform intensity distribution in previous articles. The atmospheric transmission efficiency of different light sources was calculated and compared with the data of existing models. The simulation results showed that the type of light source can significantly change the shape of the received signal and the received energy density. The Monte Carlo (MC) point probability method dramatically reduced the calculation time and the number of photons. The transmission characteristics of different ultraviolet light sources in the atmosphere provide a theoretical foundation for the design of ultraviolet detection and near-ultraviolet signal communication in the future. Full article

Electromagnetic transients are responsible for overvoltages and overcurrents that can have a negative impact on the insulating elements of the electrical transmission system. In order to reduce the damage caused by these phenomena, it is essential to accurately simulate the effect of transients along transmission lines. Nonuniformities of transmission line parameters can affect the magnitude of voltage transients, thus it is important to include such nonuniformities correctly. In this paper, a frequency domain method to compute transient voltage and current profiles along nonuniform multiconductor transmission lines is described, including the effect of time-varying and nonlinear elements. The model described here utilizes the cascade connection of chain matrices in order to take into consideration the nonuniformities along the line. This technique incorporates the change of parameters along the line by subdividing the transmission line into several line segments, where each one can have different electrical parameters. The proposed method can include the effect of time-dependent elements by means of the principle of superposition. The numerical Laplace transform is applied to the frequency-domain solution in order to transform it to the corresponding time-domain response. The results obtained with the proposed method were validated by means of comparisons with results computed with ATP (Alternative Transients Program) simulations, presenting a high level of agreement. Full article

The modeling of the Ultra-High Voltage (UHV) tower plays an important role in lightning protection analysis of transmission lines because the model used will directly affect the reliability of the results. Moreover, the higher the voltage level is, the more prominent the impact becomes. This paper first analyzes the inapplicability of the Hara multi-segment multi-surge impedance model for the ±1100 kV UHV towers, and then builds a non-uniform transmission line model of the tower. Secondly, the multi-segment multi-surge impedance model is used to study the influence of the tower’s spatial structure changes on its electromagnetic transient characteristics. It is concluded that the more accurately the nominal height of the tower is modeled, the more accurately its electromagnetic transient response is reflected. Finally, the lightning electromagnetic transient responses of the tower with the non-uniform transmission line model and with the multi-segment multi-surge impedance model are compared and analyzed, which shows that the non-uniform transmission line model is more in line with the actual situation under the lightning strikes. Full article

In recent years, the air particulate pollutants formed by the combustion of fossil fuels and the emission of industrial waste gases have constantly been produced, and the polluted particles deposit also seriously affects social production and people’s lives. For instance, pollution-induced flashover is seriously threatening the safe operation of the power system, while insulator pollution non-uniformity has great influence on the flashover voltage of insulators. Therefore, in this paper both field contamination experiments of HVDC (High Voltage Direct Current) transmission lines and wind tunnel contamination simulation tests were conducted, and pollution non-uniformity coefficient K_T/B, K_W/L and K_H/M were proposed and obtained. The results showed that the degree of contamination on top surface and leeward side is heavier than that on bottom surface and windward side. Thus, in the DC energized condition, contamination along the string is also non-uniform, and serious pollution occurs mainly in the high voltage terminal. In order to explain the uneven distribution phenomenon along the string, the coupling-physics model of composite insulator string was established and using the finite element method, the electric field around the insulator was simulated. Furthermore, basing on the field charging theory, the value of electric field force on particles around the insulator surface was calculated and the mechanism of non-uniformity along the insulator sting was then explained. The results are very important for guiding insulation design and field anti-pollution works. Full article
