This study investigates the vibrational and acoustic properties of Sitka spruce (Picea sitchensis (Bong.) Carr.) and Indian rosewood (Dalbergia latifolia Roxb.), two common musical instrument woods, at moisture contents of 2%, 7%, and 12%. The specimens with dimensions of 400mm (longitudinal) × 25 mm (radial) × 10 mm (tangential) were tested under cantilever beam conditions using non-contact magnetic field excitation to generate sinusoidal and pulse signals. Vibration data were collected via acceleration sensors and FFT analyzers. The test method was based on ASTM D6874-12 standard. Results indicate that increasing moisture content reduces acoustic vibration characteristics, with hardwoods exhibiting higher declines than softwoods. From 2% to 12% moisture content, the first-order sound radiation quality factor of Sitka spruce and Indian rosewood decreased by 15.41% and 15.57%, respectively, while the sound conversion rate declined by 41.91% and 43.21%. Increased moisture content lowers first-order and second-order resonance frequencies, amplitude ratios, dynamic elastic modulus, vibration propagation velocity, acoustic radiation quality factor, and acoustic conversion efficiency, while increasing acoustic impedance and the loss factor. With excitation frequency increases from 100 Hz to 1500 Hz, vibration propagation velocity rises slightly, while the loss factor declines. Full article

Magnetic pose tracking is a non-contact, accurate, and occlusion-free method that has been increasingly employed to track intra-corporeal medical devices such as endoscopes in computer-assisted medical interventions. In magnetic pose-tracking systems, a nonlinear estimation algorithm is needed to recover the pose information from magnetic measurements. In existing pose estimation algorithms such as the extended Kalman filter (EKF), the 3-DoF orientation in the $S^3$ manifold is normally parametrized as unit quaternions and simply treated as a vector in the Euclidean space, which causes a violation of the unity constraint of quaternions and reduces pose tracking accuracy. In this paper, a pose estimation algorithm based on the error-state Kalman filter (ESKF) is proposed to improve the accuracy and robustness of electromagnetic tracking systems. The proposed system consists of three electromagnetic coils for magnetic field generation and a tri-axial magnetic sensor attached to the target object for field measurement. A strategy of sequential coil excitation is developed to separate the magnetic fields from different coils and reject magnetic disturbances. Simulation and experiments are conducted to evaluate the pose tracking performance of the proposed ESKF algorithm, which is also compared with standard EKF and constrained EKF. It is shown that the ESKF can effectively maintain the quaternion unity and thus achieve a better tracking accuracy, i.e., a Euclidean position error of 2.23 mm and an average orientation angle error of 0.45°. The disturbance rejection performance of the electromagnetic tracking system is also experimentally validated. Full article

The present work is aimed at studying the effects of the magnetorheological finishing process, using a low-frequency alternating magnetic field, on the finishing performance of 6063 aluminum alloy. The study investigates the influence of key excitation parameters such as current, frequency, excitation gap, and iron powder diameter on the material removal and surface roughness (Ra) of the finished workpiece by experiments. This study employs a single-factor experimental method, and the finish surface is analyzed by a Zigo non-contact white light interferometer. The magnetic field strength in the processing area increases with the increase in the excitation current and decreases with the increase in the excitation gap. When the current frequency is set to 1 Hz, the circulation and renewal of abrasives in the magnetic cluster is most sufficient, resulting in the optimal surface roughness value for the workpiece. According to the experimental results of the excitation parameters, more suitable process parameters were selected for a two-stage finishing experiment. The surface roughness of 6063 aluminum alloy was improved from 285 nm to 3.54 nm. Experimental results highlighted that the magnetorheological finishing using a low-frequency alternating magnetic field is a potential technique for obtaining nano-scale finishing of the 6063 aluminum alloy. Full article

Abnormal formation of girth weld is a major threat to the safe operation of pipelines, which may lead to serious accidents. Therefore, regular inspection and maintenance of girth weld are essential for accident prevention and energy security. This paper presents a novel method for inspecting abnormal girth weld formation in oil and gas pipelines using alternating excitation detection technology. The method is based on the analysis of the microscopic magnetic variations in the welded area under alternating magnetic fields. An internal inspection probe and electronic system for detecting abnormal girth weld formation were designed and developed. The system’s capability to identify misalignment, undercutting, root concavity, and abnormal formation height of girth weld was tested by numerical simulation and experimental study. The results show that the detection system can effectively identify a minimum misalignment of 0.5 mm at a lift-off height of 15 mm. The proposed method offers several advantages, such as rapid response, low cost, non-contact operation, and high sensitivity to surface flaws in ferromagnetic pipelines. Full article

A dual-coil inductive displacement transducer is a non-contact type measuring element for measuring displacement and is widely used in large power equipment systems such as construction machinery and agricultural equipment. However, the effect of the coil excitation method on the performance of dual-coil inductive displacement sensors has not been studied. This paper investigates the impact of different coil excitation methods on the operating performance of displacement transducers. The working principle, electromagnetic characteristics, and electrical characteristics were analyzed by building a mathematical model. A transducer measurement device was used to determine the relationship between core displacement and coil inductance. Three coil excitation methods were proposed, and the effects of the three coil excitation methods on the amplitude variation, phase shift, linearity, and sensitivity of the output signal were studied by simulation based on the AD630 chip as the core of the conditioning circuit. Finally, the study’s feasibility was demonstrated by comparing the experiment to the simulation. The results show that, under the uniform magnetic field strength distribution in the coil, the coil voltage variation is proportional to the inductive core displacement. The amplitude variation is the largest for the dual-coil series three-wire (DCSTW) and is the same for the dual-coil series four-wire (DCSFW) and dual-coil parallel differential (DCPD). DCSFW has an enormous phase shift. DCSTW has the best linearity. The research in this paper provides a theoretical basis for selecting a suitable coil excitation, which is conducive to further improving the operating performance of dual-coil inductive displacement transducers. Full article

L. Brillouin predicted inelastic light scattering by thermally excited sound waves in 1922. Brillouin scattering is a non-contact and non-destructive method to measure sound velocity and attenuation. It is possible to investigate the elastic properties of gases, liquids, glasses, and crystals. Various kinds of phase transitions, i.e., liquid–glass transitions, crystallization, polymorphism, and denaturation have been studied by changing the temperature, pressure, time, and external fields such as the electric, magnetic, and stress fields. Nowadays, Brillouin scattering is extensively used to measure various elementary excitations and quasi-elastic scattering in the gigahertz range between 0.1 and 1000 GHz. A brief history, spectroscopic methods, and Brillouin scattering studies in materials science on ferroelectric materials, glasses, and proteins are reviewed. Full article

Alternating current field measurement (ACFM) testing is one of the promising techniques in the field of non-destructive testing with advantages of the non-contact capability and the reduction of lift-off effects. In this paper, a novel crack detection approach was proposed to reduce the effect of the angled crack (cack orientation) by using rotated ACFM techniques. The sensor probe is composed of an excitation coil and two receiving coils. Two receiving coils are orthogonally placed in the center of the excitation coil where the magnetic field is measured. It was found that the change of the x component and the peak value of the z component of the magnetic field when the sensor probe rotates around a crack followed a sine wave shape. A customized accelerated finite element method solver programmed in MATLAB was adopted to simulate the performance of the designed sensor probe which could significantly improve the computation efficiency due to the small crack perturbation. The experiments were also carried out to validate the simulations. It was found that the ratio between the z and x components of the magnetic field remained stable under various rotation angles. It showed the potential to estimate the depth of the crack from the ratio detected by combining the magnetic fields from both receiving coils (i.e., the x and z components of the magnetic field) using the rotated ACFM technique. Full article

Tracking of biological and physiological processes on the nanoscale is a central part of the growing field of nanomedicine. Although atomic force microscopy (AFM) is one of the most appropriate techniques in this area, investigations in non-transparent fluids such as human blood are not possible with conventional AFMs due to limitations caused by the optical readout. Here, we show a promising approach based on self-sensing cantilevers (SSC) as a replacement for optical readout in biological AFM imaging. Piezo-resistors, in the form of a Wheatstone bridge, are embedded into the cantilever, whereas two of them are placed at the bending edge. This enables the deflection of the cantilever to be precisely recorded by measuring the changes in resistance. Furthermore, the conventional acoustic or magnetic vibration excitation in intermittent contact mode can be replaced by a thermal excitation using a heating loop. We show further developments of existing approaches enabling stable measurements in turbid liquids. Different readout and excitation methods are compared under various environmental conditions, ranging from dry state to human blood. To demonstrate the applicability of our laser-free bio-AFM for nanomedical research, we have selected the hemostatic process of blood coagulation as well as ultra-flat red blood cells in different turbid fluids. Furthermore, the effects on noise and scanning speed of different media are compared. The technical realization is shown (1) on a conventional optical beam deflection (OBD)-based AFM, where we replaced the optical part by a new SSC nose cone, and (2) on an all-electric AFM, which we adapted for measurements in turbid liquids. Full article

The non-contact detection of buried ferromagnetic pipeline is a long-standing problem in the field of inspection of outside pipelines, and the extraction of magnetic anomaly signal is a prerequisite for accurate detection. Pipeline defects can cause the fluctuation of magnetic signals, which are easily submerged in wide-band background noise without external excitation sources. Previously, Variational Mode Decomposition (VMD) was used to separate modal components; however, VMD is based on narrow-band signal processing algorithm and the calculation is complex. In this article, a method of pipeline defect signal based on Variational Specific Mode Extraction (VSME) is employed to extract the signal of a specific central frequency by signal modal decomposition, i.e., the specific mode is weak magnetic anomaly signal of pipeline defects. VSME is based on the fact that a wide-band signal can be converted into a narrow-band signal by demodulation method. Furthermore, the problem of wide-band signal decomposition is expressed as an optimal demodulation problem, which can be solved by alternating direction method of multipliers. The proposed algorithm is verified by artificially synthesized signals, and its performance is better than that of VMD. The results showed that the VSME method can extract the magnetic anomaly signal of pipeline damage using experimental data, while obtaining a better accuracy. Full article

The non-contact magnetostrictive sensor (MsS) has been widely used in the guided wave testing of pipes, cables, and so on. However, it has a disadvantage of low excitation efficiency. A new method for enhancing the excitation efficiency of the non-contact MsS for pipe inspection using guided waves, by adjusting the axial length of the excitation magnetic field, is proposed. A special transmitter structure, in which two copper rings are added beside the transmitter coil, is used to adjust the axial length at the expense of weakening the excitation magnetic field. An equivalent vibration model is presented to analyze the influence of the axial length variation. The final result is investigated by experiments. Results show that the excitation efficiency of the non-contact MsS is enhanced in the whole inspection frequency range of the L(0,2) mode if the axial length is adjusted to a certain value. Moreover that certain axial length is the same for pipes of different sizes but made of the same material. Full article
