Silicon carbide (SiC)-coated carbon nanowalls (CNWs) have been proposed for use as implantable scaffold electrodes. Therefore, we investigated the effects of the SiC coating on CNWs and assessed the effects of the application of electrical stimulation (ES) on human mesenchymal stem cells cultured on SiC-coated CNWs. Measurements were conducted using immunofluorescence staining, proliferation assays, and quantitative reverse transcription polymerase chain reaction. Our results showed that the SiC coating increased the cell adhesion area, and the combination of the SiC coating and ES promoted cell proliferation. Furthermore, ES enhanced osteogenic differentiation on CNWs, both with and without the SiC coating. In SiC-coated samples, the increase in wall thickness of CNWs by the SiC coating promoted neural differentiation. These findings indicate that scaffold electrodes composed of SiC-coated CNWs enhance cell adhesion and proliferation; the application of ES to such electrodes promotes osteogenic differentiation, while the SiC coating itself promotes neural differentiation. Full article

Current collectors are key components of lithium-ion batteries, providing conductive pathways and maintaining interfacial stability with the electrode materials. Conventional metal-based current collectors, such as aluminum and copper, exhibit excellent conductivity and mechanical strength. However, they have considerable limitations, including electrochemical corrosion, interfacial resistance caused by the formation of passive layers, and mechanical degradation due to repeated cycling. To overcome these challenges, various carbon-based coatings, including amorphous carbon, graphene, and carbon nanotubes, have been developed. These coatings enhance the current collector performance by improving the collector conductivity, chemical stability, and interfacial adhesion. Vertically aligned graphene-like structures known as carbon nanowalls (CNWs) have garnered attention owing to their unique architecture, resulting in high surface area, exceptional conductivity, and excellent thermal and mechanical properties. In this mini-review, the recent advancements in carbon-based coating technologies and their role in enhancing the performance of current collectors were summarized, focusing on the innovative applications of CNWs in next-generation energy storage systems. Full article

Plasma-enhanced chemical vapor deposition (PECVD) was used to obtain several graphite nanowall (GNW)-type films at different deposition times on silicon and copper to achieve various thicknesses of carbonic films for the development of electrochemical sensors for the detection of anthracene. The PECVD growth time varied from 15 min to 30 min to 45 min, while scanning electron microscopy (SEM) confirmed the changes in the thickness of the GNW films, revealing a continuous increase in the series. X-ray diffraction (XRD) analysis revealed that the crystallinity of the GNW film samples increased with increasing crystallite size and decreasing dislocation density as the deposition time increased. Electrochemical characterization of the GNW-based electrodes indicated that the electroactive area and heterogeneous electron transfer rate constant were greater for the GNW 45 min film in the carbonic material series. We present the transfer of GNW films on flexible polyethylene substrates for achieving flexible electrochemical sensors for further use in anthracene determination. The flexible GNW-based electrodes were investigated using differential pulse voltammetry (DPV) in the presence of anthracene. The results showed that the highest sensitivity in anthracene detection was provided by the sensor with the GNW film obtained after 45 min of PECVD growth. The optimization of the GNW film thickness for the development of flexible electrochemical sensors on polyethylene substrates represents a successful approach for enhancing the electrochemical performance of carbonic materials. Full article

Multiform NiO nanowalls with a high specific surface area were constructed in situ on carbon foam (CF) to construct NiO@CF/OD composite phase change materials (CPCMs). The synthesis mechanism, microstructures, thermal management capability, and photothermal conversion of NiO@CF/OD CPCMs were systematically studied. Additionally, the collaborative enhancement effects of CF and multiform NiO nanowalls on the thermal properties of OD PCMs were also investigated. NiO@CF not only maintains the porous 3D network structure of CF, but also effectively prevents the aggregation of NiO nanosheets. The chemical structures of NiO@CF/OD CPCMs were analyzed using XRD and FTIR spectroscopy. When combined with CF and NiO nanosheets, OD has high compatibility with NiO@CF. The thermal conductivity of NiO@CF/OD-L CPCMs was 1.12 W/m·K, which is 366.7% higher than that of OD. The improvement in thermal conductivity of CPCMs was theoretically analyzed according to the Debye model. NiO@CF/OD-L CPCMs have a photothermal conversion efficiency up to 77.6%. This article provided a theoretical basis for the optimal design and performance prediction of thermal storage materials and systems. Full article

Developing a reasonable design of a lithiophilic artificial solid electrolyte interphase (SEI) to induce the uniform deposition of Li⁺ ions and improve the Coulombic efficiency and energy density of batteries is a key task for the development of high-performance lithium metal anodes. Herein, a high-performance separator for lithium metal anodes was designed by the in situ growth of a metal–organic framework (MOF)-derived transition metal sulfide array as an artificial SEI on polypropylene separators (denoted as Co₉S₈-PP). The high ionic conductivity and excellent morphology provided a convenient transport path and fast charge transfer kinetics for lithium ions. The experimental data illustrate that, compared with commercial polypropylene separators, the Li//Cu half-cell with a Co₉S₈-PP separator can be cycled stably for 2000 h at 1 mA cm⁻² and 1 mAh cm⁻². Meanwhile, a Li//LiFePO₄ full cell with a Co₉S₈-PP separator exhibits ultra-long cycle stability at 0.2 C with an initial capacity of 148 mAh g⁻¹ and maintains 74% capacity after 1000 cycles. This work provides some new strategies for using transition metal sulfides to induce the uniform deposition of lithium ions to create high-performance lithium metal batteries. Full article

Carbon deposits consisting of vertically oriented multilayer graphene sheets on metallic foils represent an interesting alternative to activated carbon in electrical and electrochemical devices such as super-capacitors because of the superior electrical conductivity of graphene and huge surface–mass ratio. The graphene sheets were deposited on cobalt foils by plasma-enhanced chemical vapor deposition using propane as the carbon precursor. Plasma was sustained by an inductively coupled radiofrequency discharge in the H mode at a power of 500 W and a propane pressure of 17 Pa. The precursor effectively dissociated in plasma conditions and enabled the growth of porous films consisting of multilayer graphene sheets. The deposition rate varied with time and peaked at 100 nm/s. The evolution of surface wettability was determined by the sessile drop method. The untreated substrates were moderately hydrophobic at a water contact angle of about 110°. The contact angle dropped to about 50° after plasma treatment for less than a second and increased monotonously thereafter. The maximal contact angle of 130° appeared at a treatment time of about 30 s. Thereafter, it slowly decreased, with a prolonged deposition time. The evolution of the wettability was explained by surface composition and morphology. A brief treatment with oxygen plasma enabled a super-hydrophilic surface finish of the films consisting of multilayer graphene sheets. Full article

In this study, well-defined tungsten oxide (WO₃) nanowall (NW) thin films were synthesized via a controlled hot filament chemical vapor deposition (HFCVD) technique and applied for electrochemical detection of methylamine toxic substances. Herein, for the thin-film growth by HFCVD, the temperature of tungsten (W) wire was held constant at ~1450 °C and gasification was performed by heating of W wire using varied substrate temperatures ranging from 350 °C to 450 °C. At an optimized growth temperature of 400 °C, well-defined and extremely dense WO₃ nanowall-like structures were developed on a Si substrate. Structural, crystallographic, and compositional characterizations confirmed that the deposited WO₃ thin films possessed monoclinic crystal structures of high crystal quality. For electrochemical sensing applications, WO₃ NW thin film was used as an electrode, and cyclic voltammetry (CV) and linear sweep voltammetry (LSV) were measured with a wide concentration range of 20 μM~1 mM of methylamine. The fabricated electrochemical sensor achieved a sensitivity of ~183.65 μA mM⁻¹ cm⁻², a limit of detection (LOD) of ~20 μM and a quick response time of 10 s. Thus, the fabricated electrochemical sensor exhibited promising detection of methylamine with considerable stability and reproducibility. Full article

Explosive boiling is a fast-phase transition from an ultra-thin liquid film to vapor under an extremely high heat flux, which typically has been studied using the molecular dynamics simulation (MDS) method. The present MDS study investigated the explosive boiling of a liquid argon nanofilm over different solid copper surfaces with different nanowall patterns, including parallel and cross nanowalls. For each surface, atomic motion trajectories, the number of liquid and vapor argon atoms, heat flux, and, mainly, the onset time of explosive boiling were investigated. The simulation results indicated that explosive boiling occurs earlier on parallel and cross nanowall surfaces than on an ideally smooth surface, regardless of the topology and configuration of the nanowalls. Moreover, the results revealed that by using the cross nanowall surfaces, the onset time of explosive boiling decreased by 0.7–4% compared to the parallel nanowall surfaces. In addition, it was found that the onset time of explosive boiling strongly depends on the potential energy barrier and the movement space between nanowalls for both parallel and cross nanowall surfaces. Furthermore, the simulation findings showed that even though increasing the height of cross nanowalls increases the heat flux and temperature of the fluid argon domain, it does not necessarily result in a shorter onset time for explosive boiling. These findings demonstrate the capability of cross nanowall surfaces for explosive boiling, thereby being utilized in future surface design for thermal management applications. Full article

Developing non-precious metal-based electrocatalysts operating in high-current densities is highly demanded for the industry-level electrochemical hydrogen evolution reaction (HER). Here, we report the facile preparation of binder-free Mo₂C-Mo₂N heterostructures on carbon nanowalls/diamond (CNWs/D) via ultrasonic soaking followed by an annealing treatment. The experimental investigations and density functional theory calculations reveal the downshift of the d-band center caused by the heterojunction between Mo₂C/Mo₂N triggering highly active interfacial sites with a nearly zero ∆G_H* value. Furthermore, the 3D-networked CNWs/D, as the current collector, features high electrical conductivity and large surface area, greatly boosting the electron transfer rate of HER occurring on the interfacial sites of Mo₂C-Mo₂N. Consequently, the self-supporting Mo₂C-Mo₂N@CNWs/D exhibits significantly low overpotentials of 137.8 and 194.4 mV at high current densities of 500 and 1000 mA/cm², respectively, in an alkaline solution, which far surpass the benchmark Pt/C (228.5 and 359.3 mV) and are superior to most transition-metal-based materials. This work presents a cost-effective and high-efficiency non-precious metal-based electrocatalyst candidate for the electrochemical hydrogen production industry. Full article

We have developed surface acoustic wave (SAW) sensors with high sensitivity and a reversible response at room temperature (RT). The sensitive area of the sensor was prepared from vertically aligned graphene sheets, like carbon nanowalls (CNWs), which were deposited onto the quartz SAW sensor substrate. The CNWs were obtained by RF plasma-enhanced chemical vapor deposition (PECVD) at 600 °C, and their sensitivity was subsequently enhanced through hydrogen plasma treatment. The SAW sensors were tested at H₂ and CH₄ at RT, and they exhibited a reversible response for both gases at concentrations between 0.02% and 0.1%, with a detection limit of a few ppm. The additional hydrogen plasma treatment preserved the lamellar structure, with slight modifications to the morphology of CNW edges, as observed by scanning electron microscopy (SEM). X-ray photoelectron spectroscopy (XPS) investigations revealed the presence of new functional groups, a significant number of defects and electron transitions after the treatment. Changes in the chemical state on the CNW surface are most probably responsible for the improved gas adsorption after plasma treatment. These results identify CNWs as a promising material for designing new SAW sensors, with the possibility of using plasma treatments to enhance the detection limit below the ppm level. Full article

In this paper, a new synthesis of carbon nanofibers (CNFs)/carbon nanowalls (CNWs) was performed to improve the characteristics of anode materials of lithium-ion batteries by using the advantages offered by CNWs and CNFs. Among the carbon-based nanomaterials, CNWs provide low resistance and high specific surface area. CNFs have the advantage of being stretchable and durable. The CNWs were grown using a microwave plasma-enhanced chemical vapor deposition (PECVD) system with a mixture of methane (CH₄) and hydrogen (H₂) gases. Polyacrylonitrile (PAN) and N,N-Dimethyl Formamide (DMF) were stirred to prepare a solution and then nanofibers were fabricated using an electrospinning method. Heat treatment in air was then performed using a hot plate for stabilization. In addition, heat treatment was performed at 800 °C for 2 h using rapid thermal annealing (RTA) to produce CNFs. A field emission scanning electron microscope (FE-SEM) was used to confirm surface and cross-sectional images of the CNFs/CNWs anode materials. Raman spectroscopy was used to examine structural characteristics and defects. Cyclic voltammetry (CV), electrochemical impedance spectroscopy (EIS), and constant current charge/discharge tests were performed to analyze the electrical characteristics. The synthesized CNFs/CNWs anode material had a CV value in which oxidation and reduction reactions were easily performed, and a low Rct value of 93 Ω was confirmed. Full article

Surface-enhanced Raman scattering (SERS) is a highly sensitive technique for detecting DNA, proteins, and single molecules. The design of SERS substrates plays a crucial role, with the density of hotspots being a key factor in enhancing Raman spectra. In this study, we employed carbon nanowall (CNW) as the nanostructure and embedded plasmonic nanoparticles (PNPs) to increase hotspot density, resulting in robust Raman signals. To enhance the CNW’s performance, we functionalized it via oxygen plasma and embedded silver nanoparticles (Ag NPs). The authors evaluated the substrate using rhodamine 6G (R6G) as a model target molecule, ranging in concentration from 10⁻⁶ M to 10⁻¹⁰ M for a 4 min exposure. Our analysis confirmed a proportional increase in Raman signal intensity with an increase in concentration. The CNW’s large specific surface area and graphene domains provide dense hotspots and high charge mobility, respectively, contributing to both the electromagnetic mechanism (EM) and the chemical mechanism (CM) of SERS. Full article

In recent years, vertical graphene nanowalls (VGNWs) have gained significant attention due to their exceptional properties, including their high specific surface area, excellent electrical conductivity, scalability, and compatibility with transition metal compounds. These attributes position VGNWs as a compelling choice for various applications, such as energy storage, catalysis, and sensing, driving interest in their integration into next-generation commercial graphene-based devices. Among the diverse graphene synthesis methods, plasma-enhanced chemical vapor deposition (PECVD) stands out for its ability to create large-scale graphene films and VGNWs on diverse substrates. However, despite progress in optimizing the growth conditions to achieve micrometer-sized graphene nanowalls, a comprehensive understanding of the underlying physicochemical mechanisms that govern nanostructure formation remains elusive. Specifically, a deeper exploration of nanometric-level phenomena like nucleation, carbon precursor adsorption, and adatom surface diffusion is crucial for gaining precise control over the growth process. Hydrogen’s dual role as a co-catalyst and etchant in VGNW growth requires further investigation. This review aims to fill the knowledge gaps by investigating VGNW nucleation and growth using PECVD, with a focus on the impact of the temperature on the growth ratio and nucleation density across a broad temperature range. By providing insights into the PECVD process, this review aims to optimize the growth conditions for tailoring VGNW properties, facilitating applications in the fields of energy storage, catalysis, and sensing. Full article

The progress of advanced materials has invoked great interest in promising novel biosensing applications. Field-effect transistors (FETs) are excellent options for biosensing devices due to the variability of the utilized materials and the self-amplifying role of electrical signals. The focus on nanoelectronics and high-performance biosensors has also generated an increasing demand for easy fabrication methods, as well as for economical and revolutionary materials. One of the innovative materials used in biosensing applications is graphene, on account of its remarkable properties, such as high thermal and electrical conductivity, potent mechanical properties, and high surface area to immobilize the receptors in biosensors. Besides graphene, other competing graphene-derived materials (GDMs) have emerged in this field, with comparable properties and improved cost-efficiency and ease of fabrication. In this paper, a comparative experimental study is presented for the first time, for FETs having a channel fabricated from three different graphenic materials: single-layer graphene (SLG), graphene/graphite nanowalls (GNW), and bulk nanocrystalline graphite (bulk-NCG). The devices are investigated by scanning electron microscopy (SEM), Raman spectroscopy, and I-V measurements. An increased electrical conductance is observed for the bulk-NCG-based FET, despite its higher defect density, the channel displaying a transconductance of up to ≊$4.9\times {10}^{-3}$ A V${}^{-1}$, and a charge carrier mobility of ≊$2.86\times {10}^{-4}$ cm${}^2$ V${}^{-1}$ s${}^{-1}$, at a source-drain potential of 3 V. An improvement in sensitivity due to Au nanoparticle functionalization is also acknowledged, with an increase of the ON/OFF current ratio of over four times, from ≊$178.95$ to ≊$746.43$, for the bulk-NCG FETs. Full article

Graphene/silicon (Si) heterojunction photodetectors are widely studied in detecting of optical signals from near-infrared to visible light. However, the performance of graphene/Si photodetectors is limited by defects created in the growth process and surface recombination at the interface. Herein, a remote plasma-enhanced chemical vapor deposition is introduced to directly grow graphene nanowalls (GNWs) at a low power of 300 W, which can effectively improve the growth rate and reduce defects. Moreover, hafnium oxide (HfO₂) with thicknesses ranging from 1 to 5 nm grown by atomic layer deposition has been employed as an interfacial layer for the GNWs/Si heterojunction photodetector. It is shown that the high-k dielectric layer of HfO₂ acts as an electron-blocking and hole transport layer, which minimizes the recombination and reduces the dark current. At an optimized thickness of 3 nm HfO₂, a low dark current of 3.85 × 10⁻¹⁰, with a responsivity of 0.19 AW⁻¹, a specific detectivity of 1.38 × 10¹² as well as an external quantum efficiency of 47.1% at zero bias, can be obtained for the fabricated GNWs/HfO₂/Si photodetector. This work demonstrates a universal strategy to fabricate high-performance graphene/Si photodetectors. Full article
