Full-field optical angiography (FFOA) has considerable potential for clinical applications in the prevention and diagnosis of various diseases. However, owing to the limited depth of focus attainable using optical lenses, only information about blood flow in the plane within the depth of field can be acquired using existing FFOA imaging techniques, resulting in partially unclear images. To produce fully focused FFOA images, an FFOA image fusion method based on the nonsubsampled contourlet transform and contrast spatial frequency is proposed. Firstly, an imaging system is constructed, and the FFOA images are acquired by intensity-fluctuation modulation effect. Secondly, we decompose the source images into low-pass and bandpass images by performing nonsubsampled contourlet transform. A sparse representation-based rule is introduced to fuse the lowpass images to effectively retain the useful energy information. Meanwhile, a contrast spatial frequency rule is proposed to fuse bandpass images, which considers the neighborhood correlation and gradient relationships of pixels. Finally, the fully focused image is produced by reconstruction. The proposed method significantly expands the range of focus of optical angiography and can be effectively extended to public multi-focused datasets. Experimental results confirm that the proposed method outperformed some state-of-the-art methods in both qualitative and quantitative evaluations. Full article

To meet the challenge of preparing a high-resolution compound eye, this paper proposes a multi-focal-length meniscus compound eye based on MEMS negative pressure molding technology. The aperture is increased, a large field of view angle of 101.14° is obtained, and the ommatidia radius of each stage is gradually increased from 250 μm to 440 μm. A meniscus structure is used to improve the imaging quality of the marginal compound eye so that its resolution can reach 36.00 lp/mm. The prepared microlenses have a uniform shape and a smooth surface, and both panoramic image stitching and moving object tracking are achieved. This technology has great potential for application in many fields, including automatic driving, machine vision, and medical endoscopy. Full article

Fault age determination using the illite-age-analysis (IAA) method for fault gouges has played a key role in providing absolute age information in tectonic evolution studies for the last 20 years. The accuracy and precision of the IAA method depend on (1) how to reasonably quantify the relative content of 1M/1M_d illite generated from fault activity compared to detrital 2M₁ illite in the size fractions of the fault gouge, and (2) how to minimize the error factors in K-Ar or Ar-Ar dating analysis. XRD-based quantitative analysis of illite polytype has made great progress in accuracy by generating a simulated XRD pattern of 1M/1M_d polytype using WILDFIRE© and full-pattern-fitting it with the XRD pattern measured from size fractions of the fault gauge. Nevertheless, the results of quantitative analysis of illite polytypes may vary depending on the sample state of the size fractions for XRD analysis, especially the preferred orientation due to the layered crystal structure of illite. In addition, the radiometric dating results may be distorted depending on the error factor of the dating method itself and on the mineral composition of the size fractions, that is, the presence of K-containing minerals such as biotite and K-feldspar other than illite. In this study, we reviewed previous studies that determined fault activity ages by applying IAA to fault gouges. From this, the prerequisites and recommendations for each of the five steps (particle size separation process, XRD analysis process, polytype quantification, radiometric dating, IAA plot) for improving the IAA method are summarized and presented. The continuous application of the improved IAA is expected to greatly contribute to the study of tectonic evolution through geological time. Full article

Compared with a traditional optical system, the single-lens curved compound eye imaging system has superior optical performance, such as a large field of view (FOV), small size, and high portability. However, defocus and low resolution hinder the further development of single-lens curved compound eye imaging systems. In this study, the design of a nonuniform curved compound eye with multiple focal lengths was used to solve the defocus problem. A two-step gas-assisted process, which was combined with photolithography, soft photolithography, and ultraviolet curing, was proposed for fabricating the ommatidia with a large numerical aperture precisely. Ommatidia with high resolution were fabricated and arranged in five rings. Based on the imaging experimental results, it was demonstrated that the high-resolution and small-volume single-lens curved compound eye imaging system has significant advantages in large-field imaging and rapid recognition. Full article

Line focusing, which collects light into a line rather than a single point, has an advantage on variable fields such as machining and imaging. The 1-dimensional metallic zone plate is one of the candidates for line focusing, which is ultra-thin and simple to fabricate. Metallic nano-slits can replace the metal blocked region to increase the efficiency, however, the efficiency and stability are still low. Therefore, this paper proposes a structure with an additional dielectric layer to protect the metallic nano-slit layer—a buried metallic wire structure—and verify the idea based on numerical simulations. Two structures are proposed. In terms of stability, a flat surface structure is proposed and a corrugated surface structure with a consistent thickness with the nano-slit is proposed which has low fabrication difficulty. The optimization of the buried wire structure and performance after applying the buried wire structure to the dual-line focusing plate is calculated by numerical simulation. Finally, it was shown that the electric field intensity was 2.13 times greater. Full article

A transmitarray antenna is evaluated to generate a multi-focusing spot area in the Fresnel region of the antenna in the Ka-band. The antenna is designed to focus the radiated field at a certain point using a central feeding configuration. The number of feeds is increased to create as many focusing spots as feeds. The feeds are placed along an arc defined in the principal planes of the transmitarray, radiating independent near-field spots and providing a solution with a wide-angle spot scanning without an antenna displacement and a high isolation between feeds. To validate this concept, a transmitarray based on dielectric-only cells is designed and simulated under full-wave conditions. Then, this design is manufactured using a 3D printing technique, and the prototype is measured in a planar acquisition range. Measurements are performed for different feed positions in order to validate the multi-focusing capability of the antenna. Measurements and simulations show a high agreement and validate the proposed design technique. Full article

The powerful support vector regression framework is proposed in a novel method for near-field focusing using antenna arrays. By using this machine-learning method, the set of weights required in the elements of an array can be calculated to achieve an assigned near-field distribution focused on one or more positions. The computational cost is concentrated in an initial training process so that the trained system is fast enough for applications where moving devices are involved. The increased learning capabilities of support vector machines allow using a reduced number of training samples. Thus, these training samples may be generated with a prototype or a convenient electromagnetic analysis tool, and hence realistic effects, such as coupling or the individual radiation patterns of the elements of the arrays, are accounted for. Illustrative examples are presented. Full article

An extended method for Near-Field Multifocusing on antenna arrays, including the optimization of the locations for the elements of the array, is proposed. Multifocusing is gaining attention in recent years due to the growth of applications such as Internet of Things, or 5G, where a wireless link between a number of sensors and devices must be established, and energy or interference must be managed efficiently. Multifocusing requirements may be addressed by optimizing the feeding weights that must be applied to the elements of an array, but the proposed methodology also optimizes their locations, increasing the degrees of freedom by allowing a non-uniform structure for the array, leading to more efficient structures or better compliance with the specifications. Some experiments are presented to validate the method, showing that it is able to determine the weights and mesh of the array to fulfill the requirements, both obtaining an arbitrary distribution of elements or following a predefined geometric model. Full article

We propose a novel design method for multi-focal metallic Fresnel zone plates (MFZPs), which exploits the phase selection rule by putting virtual point sources (VPSs) at the desired focal points distant to the MFZP plane. The phase distribution at the MFZP plane reciprocally formed by the VPSs was quantized in a binary manner based on the phase selection rule, thereby leading to a corresponding on-off amplitude pattern for the targeted MFZP. The resultant phase distribution was dependent on the complex amplitudes of the VPSs, so that they could be determined from the perspective of both multi-focal functionality and fabrication feasibility. As a typical example, we utilized the particle swarm optimization algorithm to determine them. Based on the proposed method, we designed and numerically analyzed two types of novel MFZPs—one for a monochromatic multi-focal application and the other for a multi-chromatic mono-focal application—verifying the effectiveness and validity of the proposed method. We also fabricated them onto Au-deposited glass substrates, using electron beam evaporation and a focused ion beam milling process. We experimentally characterized them and also verified that they successfully demonstrated their feasibilities. The former produced distinct hot spots at three different focal distances of 10, 15, and 20 $\mathsf{\mu }\mathrm{m}$ for monochromatic incidence at 650 nm, and the latter produced a single hot spot at a focal distance of 15 $\mathsf{\mu }\mathrm{m}$ for multi-chromatic incidence at 660, 532, and 473 nm. The experimental results were also in good agreement with their corresponding numerical results. We expect that both MFZPs will have various applications, such as laser micromachining, optical trapping, biomedical sensing, confocal collimation, achromatic optics, etc. Full article

Disseminating lower-limb injury-prevention exercise programs (LL-IPEPs) with strategies that effectively reach coaches across sporting environments is a way of preventing lower-limb injuries (LLIs) and ensuring safe and sustainable sport participation. The aim of this study was to explore community-Australian Football (community-AF) coaches’ perspectives on the strategies they believed would enhance the dissemination and scale-up of LL-IPEPs. Using a qualitative multiple case study design, semi-structured interviews with community-AF coaches in Victoria, Australia, were conducted. Overall, coaches believed a range of strategies were important including: coach education, policy drivers, overcoming potential problem areas, a ‘try before you buy approach’, presenting empirical evidence and guidelines for injury-prevention exercise programs (IPEPs), forming strategic collaboration and working in partnership, communication and social marketing, public meetings, development of a coach hotline, and targeted multi-focused approaches. A shift to a culture whereby evidence-based IPEP practices in community-AF will take time, and persistent commitment by all involved in the sport is important. This will support the creation of strategies that will enhance the dissemination and scale-up of LL-IPEPs across community sport environments. The focus of research needs to continue to identify effective, holistic and multi-level interventions to support coaches in preventing LLIs. This could lead to the determination of successful strategies such as behavioural regulation strategies and emotional coping resources to implement LL-IPEPs into didactic curricula and practice. Producing changes in practice will require attention to which strategies are a priority and the most effective. Full article
