Search Results (27)

Frequency regulation (FR) constitutes a fundamental aspect of power system stability, particularly in the context of the growing integration of intermittent renewable energy sources (RES) and electric vehicles (EVs). The load frequency control (LFC) mechanism, essential for achieving FR, is increasingly reliant on communication infrastructures that are inherently vulnerable to cyber threats. Cyberattacks targeting these communication links can severely compromise coordination among smart grid components, resulting in erroneous control actions that jeopardize the security and stability of the power system. In light of these concerns, this study proposes a cyber-physical LFC framework incorporating a fuzzy linear active disturbance rejection controller (F-LADRC), wherein the controller parameters are systematically optimized using the quasi-opposition-based reptile search algorithm (QORSA). Furthermore, the proposed approach integrates a comprehensive cyberattack detection and prevention scheme, employing Haar wavelet transforms for anomaly detection and long short-term memory (LSTM) networks for predictive mitigation. The effectiveness of the proposed methodology is validated through simulations conducted on a restructured power system integrating RES and EVs, as well as a modified IEEE 39-bus test system. The simulation outcomes substantiate the capability of the proposed framework to deliver robust and resilient frequency regulation, maintaining system frequency and tie-line power fluctuations within nominal operational thresholds, even under adverse cyberattack scenarios. Full article

High-purity distillation columns typically give rise to multi-variable, strongly coupled nonlinear systems with substantial time delay and significant inertia. The control performance of high-purity distillation columns crucially influences the purity of the final product. Taking into account the process of a high-purity distillation column, this article puts forward a dual-loop modified active disturbance rejection control (MADRC) scheme to improve the control of product purity. During the stable operation of the distillation process, the structures of two control loops are, respectively, approximated by two linear transfer function models via open-loop experiments. Subsequently, the compensation part of the MADRC scheme is designed, respectively, for each approximate model. Furthermore, this paper employs singular perturbation theory to prove the stability of MADRC. The performance of the dual-loop MADRC scheme (MADRC) is compared with that of a proportional–integral–derivative (PID) control scheme, a cascade PID control scheme (CPID), and a regular ADRC scheme (ADRC). The simulations demonstrate that the dual-loop MADRC scheme is capable of efficiently tracking the reference value and exhibits optimal disturbance rejection capabilities. Additionally, the superiority of the dual-loop MADRC scheme is validated through Monte Carlo trials. Full article

During the operation of maglev trains, they are subjected to various disturbances. The presence of these disturbances presents a significant challenge for attaining high-performance control and even poses the risk of system instability. To further enhance the anti-disturbance capability of maglev trains, this paper proposes a model information-assisted modified active disturbance rejection control (MADRC) approach. A mathematical model of the single-point suspension system of maglev trains is constructed for the design of the extended state observer (ESO), which is a modified extended state observer (MESO), and a nonlinear mechanism is incorporated to boost the performance of the ESO. Owing to the introduction of model information, the estimated quantity of disturbances by MESO no longer considers the system model deviation as a disturbance. Hence, the linear feedback control law is modified accordingly. The MESO is regarded as an ESO with time-varying gain using the equivalent gain method, and its stability is proven using the Lyapunov method. The tracking and anti-disturbance performances of different controllers are compared via simulation experiments. Suspension and anti-disturbance experiments are conducted on the single-point suspension experimental platform, verifying that the proposed MADRC has a more potent suppression ability for load disturbances in the suspension system. Full article

To address the extended development cycle, high costs, and maintenance difficulties associated with existing microgravity simulation methods, this study has developed a semi-physical simulation platform for robotic arms tailored to different gravity environments and loading conditions. The platform represents difficult-to-model joints as physical objects, while the easily modeled components are simulated based on principles of similarity. In response to the strong coupling, nonlinearity, and excess force disturbance issues in the electric variable load loading system, a fractional-order linear active disturbance rejection control algorithm was employed. The controller parameters were tuned using an improved particle swarm algorithm with modified weight coefficients, and experimental results demonstrate that a fractional-order linear active disturbance rejection control improves response speed and disturbance rejection performance compared to linear sliding mode control. The study investigated the differences in the drive force of joint motors in space robotic arms under varying gravity environments and loading conditions. Experimental results indicate that load torque is the primary influencing factor on joint motor drive force, while radial force serves as a secondary influencing factor. Additionally, when the axis of the joint motor is perpendicular to the ground, it can, to some extent, simulate microgravity conditions on the ground. Full article

To overcome the possible gimbal lock problem of the dual-axis satcom-on-the-move (SOTM) antenna, a three-axis tracking satellite SOTM antenna structure appears. The three-axis SOTM antenna is realized by adding a roll axis to the azimuth axis and pitch axis in the dual-axis SOTM structure. There is coupling among the azimuth axis, pitch axis and roll axis in the mechanical structure of the three-axis SOTM antenna, which makes the kinematic modeling of the antenna difficult. This paper introduces a three-axis SOTM antenna kinematic modeling method based on the modified Denavit–Hartenberg (MDH) method, named the new modified Denavit–Hartenberg (NMDH) method. In order to meet the modeling requirements of the MDH method, the NMDH method adds virtual coordinate systems and auxiliary coordinate systems to the three-axis SOTM antenna and obtains the kinematic model of the three-axis SOTM antenna. During the motion of the carrier, the SOTM antenna needs to adjust the antenna pointing in real time according to the changes of the location and attitude of the moving carrier. Therefore, this paper designs a servo control system based on the active disturbance rejection controller (ADRC), introducing a smooth and continuous ADRC $\mathrm{f}\mathrm{a}\mathrm{l}$ function to enhance the tracking speed of the servo control system and reduce the overshoot of the output response. Finally, system experiments were carried out with a 60 cm caliber three-axis SOTM antenna. The experiment results show that the proposed servo control method achieves higher antenna tracking satellite accuracy and better communication effects. Full article

This paper investigates an anticipatory activation anti-windup approach based on Linear Active Disturbance Rejection Control (LADRC) to address the influences of accelerated saturation on the actuators in a Miniaturized Inertial Stabilized Platform (MISP) with extreme external disturbance. The proposed method aims to eliminate the high-frequency vibrations on the Line of Sight (LOS) of electro-optical devices during actuator saturation. To achieve this, the Linear Extended State Observer (LESO) is modified by adding saturation feedback to the total disturbance observed state variable, which is operated as an anticipatory activation anti-windup compensator. The stability of the proposed controller is discussed, and the gains are optimized by the Linear Matrix Inequality (LMI) constraints though quadratic programming and an H-infinite performance indicator. Additionally, as the multiple activated scheme for anti-windup, the effectiveness of immediate activation in dealing with accelerated saturation is compared and analyzed. These comparisons and verification are implemented through simulations, where the external disturbance is introduced using recorded attitude data from USV sailing. Finally, experiments are conducted on an MISP for a visual tracking system, demonstrating that the anticipatory activation mothed effectively suppresses high-frequency vibrations on the LOS during instances of accelerated saturation. Full article

The drum water level plays a crucial role in the safety and economy of heat recovery boilers. However, the control of the drum water level faces many challenges, such as external disturbances and system uncertainties. To enhance the control performance of the drum water level, a modified active disturbance rejection control (MADRC) optimized with sensitivity constraint is proposed in this paper. Firstly, the control structure of the three-element control system for the drum water level is introduced and analyzed. Based on the regular active disturbance rejection control (ADRC) structure, the structure of the MADRC is introduced and the convergence of the proposed MADRC is proven. Then a modified whale optimization algorithm (MWOA) with sensitivity constraint is applied to optimize the parameters of the MADRC. With different sensitivity constraints, the parameters of the MADRC and comparative controllers are obtained, and their control performance for tracking and disturbance rejection abilities is compared. Moreover, the ability to handle system uncertainties is analyzed. Simulation results and performance indexes show that the proposed MADRC can obtain the best tracking and disturbance rejection abilities with satisfactory robustness. The satisfactory control performance shows that the proposed MADRC has wide application potential for heat recovery boilers and other industrial processes. Full article

Linear active disturbance rejection control (LADRC) has been widely used to improve the tracking accuracy and anti-disturbance performance of telescope servo control under disturbances. However, the linear extended state observer (LESO) is sensitive to noise, and its bandwidth is limited by the resonant frequency of the telescope. To enhance the LARDC’s ability to attenuate disturbances, a novel cascade anti-disturbance structure (NCADS) with LADRC on the outer speed loop and a nonlinear disturbance observer (NDOB) on the inner current loop is proposed. The NDOB compensates for the dominant disturbance through feedforwarding the q-axis current reference, and the LESO compensates for the residual disturbance on the outer speed loop. First, the NCADS is introduced in a three-closed-loop control framework of PMSM. Then, the design method of the controller for each loop and the NDOB are presented, the parameter-tuning method based on bandwidth is demonstrated, and the convergence of the NDOB is proved. Furthermore, to improve the searching and tracking efficiency of wide-field survey telescopes, the nonlinear tracking differentiator (NTD) was modified to plan the transition process of the position loop, which only needs to set the maximum speed and acceleration of the telescope. Finally, simulations and experiments were performed on a 2.5-m-wide field survey telescope. The experimental results verify that the proposed NCADS method has a better anti-disturbance performance and higher tracking precision than the conventional method, and the improved NTD method does not need to tune parameters and achieved a fast and smooth transition process of the position loop. Full article

This paper presents a novel extended state observer (ESO) approach for a class of plants with nonlinear dynamics. The proposed observer estimates both the state variables and the total disturbance, which includes both exogenous and endogenous disturbance. The study’s changes can be summarized by developing a sliding mode higher-order extended state observer with a higher-order augmented state and a nonlinear function for the estimation error correction terms (SMHOESO). By including multiple enhanced states, the proposed observer can monitor total disturbances asymptotically, with the second derivative of the total disturbance serving as an upper constraint on the estimation error. This feature improves the observer’s ability to estimate higher-order disturbances and uncertainty. To extend the concept of the linear extended state observer (LESO), a nonlinear function can modify the estimation error in such a way that the proposed observer can provide faster and more accurate estimations of the state and total disturbance. The proposed nonlinearity also reduces the chattering issue with LESOs. This research thoroughly examines and analyzes the proposed SMHOESO’s convergence using the Lyapunov technique. According to this analysis, the SMHOESO is asymptotically stable, and the estimation error can be significantly reduced under real-world conditions. In addition to the SMHOESO, a modified Active Disturbance Rejection Control (ADRC) scheme is built, which includes a nonlinear state error feedback (NLSEF) controller and a nonlinear tracking differentiator (TD). Several nonlinear models, including the Differential Drive Mobile Robot (DDMR), are numerically simulated, and the proposed SMHOESO is compared to several alternative types, demonstrating a significant reduction in controller energy, increased control signal smoothness, and accurate tracking of the reference signal. Full article

In this paper, two new versions of modified active disturbance rejection control (MADRC) are proposed to stabilize a nonlinear quadruple tank system and control the water levels of the lower two tanks in the presence of exogenous disturbances, parameter uncertainties, and parallel varying input set-points. The first proposed scheme is configured from the combination of a modified tracking differentiator (TD), modified super twisting sliding mode (STC-SM), and modified nonlinear extended state observer (NLESO), while the second proposed scheme is obtained by aggregating another modified TD, a modified nonlinear state error feedback (MNLSEF), and a fal-function-based ESO. The MADRC schemes with a nonlinear quadruple tank system are investigated by running simulations in the MATLAB/SIMULINK environment and several comparison experiments are conducted to validate the effectiveness of the proposed control schemes. Furthermore, the genetic algorithm (GA) is used as a tuning algorithm to parametrize the proposed MADRC schemes with the integral time absolute error (ITAE), integral square of the control signal (ISU), and integral absolute of the control signal (IAU) as an output performance index (OPI). Finally, the simulation results show the robustness of the proposed schemes with a noticeable reduction in the OPI. Full article

Linear active disturbance rejection control (LADRC) has been extensively used in various areas due to its excellent disturbance suppression capability. When LADRC is applied to a single-phase inverter for tracking a sinusoidal reference signal, there is an inherent tracking inaccuracy problem. The steady-state error can be removed with the synchronous reference frame proportional-integral (SRFPI) control, which generates two orthogonal signals. In this paper, a modified control method based on compound SRFPI and LADRC for an off-grid single-phase inverter is put forward, where both output signals of SRFPI are employed as the reference signals of LADRC. Furthermore, a selective harmonic compensation method is performed by paralleling multiple SRFPI controllers to further reduce the selective harmonic components. Detailed theoretical analyses including system stability, robustness, performance of voltage tracking error and disturbance rejection are presented, which indicate that this organic combination fuses the merits of both SRFPI and LADRC without complicating the control design. Additionally, contrast experiments are conducted to demonstrate its effectiveness and superiority. These findings demonstrate that the system realizes a slight voltage tracking error and steady-state error, rapid dynamic response, and low total harmonic distortion (THD), especially under highly nonlinear load conditions. Full article

The piezoelectric smart structures, which can be labeled as the cream of the crop of smart structures without overstatement, are strongly impacted by a large number of uncertainties and disturbances during operation. The present paper reviews active disturbance rejection control (ADRC) technologies developed for application in piezoelectric smart structures, focusing on measurement, analysis, estimation, and attenuation of uncertainties/disturbances in systems. It first explained vast categories of uncertainties/disturbances with their adverse influences. Then, after a brief introduction to the application of basic ADRC in smart structures, a thorough review of recently modified forms of ADRC is analyzed and classified in terms of their improvement objectives and structural characteristics. The universal advantages of ADRC in dealing with uncertainties and its improvement on the particularity of smart structures show its broad application prospects. These improved ADRC methods are reviewed by classifying them as modified ADRC for specific problems, modified ADRC by nonlinear functions, composite control based on ADRC, and ADRC based on other models. In addition, the application of other types of active anti-disturbances technologies in smart structures is reviewed to expand horizons. The main features of this review paper are summarized as follows: (1) it can provide profound understanding and flexible approaches for researchers and practitioners in designing ADRC in the field and (2) light up future directions and unsolved problems. Full article

The latest research on disturbance rejection mechanisms has shown active disturbance rejection control (ADRC) to be an effective controller for uncertainties and nonlinear dynamics embedded in systems to be controlled. The significance of the ADRC controller is its model-free nature, as it requires minimal knowledge of the system model. In addition, it can actively estimate and compensate for the impact of internal and external disturbances present, with the aid of its crucial subsystem called the extended state observer (ESO). However, ADRC controller design becomes more challenging owing to different system disturbances, such as output disturbances, measurement noise, and varying time-delays persistent in the system’s communication channels. Most disturbance rejection techniques aim to reduce internal perturbations and external disturbances (input and output disturbance). However, output disturbance rejection with measurement noise under time-delay control is still a challenging problem. This paper presents a novel predictive ESO-based ADRC controller for time-delay systems by employing predictive methods to compensate for the disturbances originating from time delay. The prediction mechanism of the novel (proposed) controller design is greatly attributed to the extended state predictor observer (ESPO) integrated with the delay-based ADRC inside the proposed controller method. Thus, the proposed controller can predict the unknown system dynamics generated during the delay and compensate for these dynamics via disturbance rejection under time-delay control. This approach uses the optimization mechanism to determine controller parameters, where the genetic algorithm (GA) is employed with the integral of time-weighted absolute error (ITAE) as the fitness function. The proposed controller is validated by controlling second-order systems with time delay. Type 0, Type 1, and Type 2 systems are considered as the controlled plants, with disturbances (unknown dynamics due to delay and external disturbance), along with measurement noise present. The proposed controller method is compared with state-of-the-art methods, such as the modified time-delay-based ADRC method and the ESPO-based controller method. The findings indicate that the method proposed in this paper outperforms its existing competitors by compensating for the dynamics during the time delay and shows robust behaviour, improved disturbance rejection, and a fair extent of resilience to noise. Full article

In this paper, we presents an improved hybrid control scheme based on model predictive torque control using linear active disturbance rejection control (LADRC) for the torque drive system of a 12/14 bearingless switched reluctance motor. The proposed approach can considerably reduce the torque ripple and enhance the anti-disturbance ability. First, a modified piecewise torque sharing function (TSF) is applied to reduce the torque ripple in the commutation interval. Second, model predictive control is introduced to further reduce the torque ripple caused by the hysteresis control. The selection of the optimal weighting factor is avoided, as the current value corresponding to different positions of each phase is determined by the TSF; thus, the cost function can be simplified. Then, a speed controller is designed by an enhanced LADRC for improved tracking performance and anti-disturbance ability, whereby a proportional gain of observation error and a time-varying function are investigated in extended-state observer. Finally, experiments are carried out to verify the effectiveness of the hybrid control scheme by comparison with cosine TSF function and conventional LADRC. Full article

This article presents a modified active-disturbance-rejection control (ADRC) combined with a sliding mode control (SMC) regarding the tracking control problems for plants with unmatched uncertainty. The proposed modified active-disturbance-rejection control with sliding mode (ADRC-SM) employs a reduced-order extended state observer (ESO) for estimating various uncertainties of system in time, including unmatched and matched uncertainties. Meanwhile, a novel reaching law of SMC was designed by using the cycloid function as the main controller of ADRC, which ensures the robustness of the uncertain system. Due to the reduced-order ESO tracking and compensating for various uncertainties in the system as a total disturbance, the upper bound of the disturbance in the SMC is relaxed. The gain coefficient of the reaching law only needs to be designed to be larger than the limit of the lumped disturbance; thus, the chattering problem is greatly reduced. The designed new reaching law of the cycloid function shortens the time for the system state’s convergence to the sliding mode’s surface. The cycloid function replaces the switching function in the traditional reaching law, making the actual control input continuous and shortening the approach time. Compared with traditional ADRC-SM, the use of multiple ESOs or intelligent algorithms to approximate plant parameters can be avoided, the design is simplified, its robustness is enhanced, computational costs are reduced, and the convergence time is reduced. The controlled object with unmatched uncertainty is transformed into a system with matched uncertainty using state-space transformation, which reduces the complexity of the controller’s design. In addition, the stability analysis of the closed-loop system is carried out based on the Lyapunov method. Simulations and experiments verify that the modified ADRC-SM has the merits of fast response, small overshoot, small steady-state error, strong anti-interference competence, and high control accuracy. Full article
