The construction of pumped storage power stations (PSPSs) is undergoing rapid expansion globally. Detecting operational faults and defects in pumped storage units is critical, as effective diagnostic methods can not only identify fault types quickly and accurately but also significantly reduce maintenance costs. This study leverages the symmetry characteristics in the vibration signals of pumped storage units to enhance fault diagnosis accuracy. To address the challenges of selecting the key parameters (e.g., decomposition level and penalty factor) of the variational mode decomposition (VMD) algorithm during vibration signal analysis, this paper proposes an algorithm for an improved subtraction-average-based optimizer (ISABO). By incorporating piecewise linear mapping, the ISABO enhances parameter initialization and, combined with a balanced pool method, mitigates the algorithm’s tendency to converge to local optima. This improvement enables more effective vibration signal denoising and feature extraction. Furthermore, to optimize hyperparameter selection in the bidirectional long short-term memory (BILSTM) network—such as the number of hidden layer units, maximum training epochs, and learning rate—we introduce an ISABO-BILSTM classification model. This approach ensures robust fault diagnosis by fine-tuning the neural network’s critical parameters. The proposed method is validated using vibration data from an operational PSPS. Experimental results demonstrate that the ISABO-BILSTM model achieves an overall fault recognition accuracy of 97.96%, with the following breakdown: normal operation: 96.29%, thrust block loosening: 98.60%, rotor-stator rubbing: 97.34%, and rotor misalignment: 99.59%. These results confirm that the proposed framework significantly improves fault identification accuracy, offering a novel and reliable approach for PSPS unit diagnostics. Full article

The aim of this study is to develop sensorless high-speed tracking control for surface-mounted permanent magnet synchronous motors by taking the rotor position offset error and time-varying load torque into consideration. This proposal combines an extended state observer with an adaptation position algorithm, employing only the measurement of electrical variables for feedback. First, a rotatory coordinate model of the motor is proposed, wherein the rotor position offset error is considered as a perturbation function within the model. Second, based on the aforementioned model, a rotary coordinate model of the motor is extended in one state to estimate the load torque, as well as the rotor’s position and speed, despite the presence of the rotor position offset error. Through Lyapunov stability analysis, sufficient conditions were established to guarantee that the error estimations were bounded. Finally, to validate the feasibility of the proposed sensorless scheme, experiments were conducted on the Technosoft^® development platform, where the alignment routine was disabled and an intentional misalignment between the magnetic north pole and the stator’s south pole was established. Full article

The marine water-lubricated bearing’s (WLBs) dynamic properties are essential for ensuring the shaft system’s operational dependability. The coupled model of mixed lubrication and turbulence under the impact of bidirectional misalignment is proposed in this research, and the perturbation equations of marine WLBs with 32 coefficients are derived. The finite difference method (FDM) is used to solve the steady-state and perturbation equations, and the impacts of turbulence, bearing bush deformation, surface roughness, and bidirectional shaft misalignment on the dynamic characteristics of the WLBs are systematically investigated. The results reveal that under mixed lubrication, surface roughness and the turbulence effect can both greatly improve the stiffness and damping of the bearings, but that there is a threshold phenomenon for the turbulence effect’s influence on these properties. Neglecting the elastic deformation of the bush may lead to an overestimation of the bearings’ stiffness and damping, causing substantial inaccuracies in conditions of heavy load or declined Young’s modulus. The 32 coefficients of the WLB exhibit considerable variation with the misalignment angle; hence, a more comprehensive dynamic model should be developed for misaligned marine WLBs. The study’s findings provide valuable insights for rotor dynamics research and optimal design of lubrication performance in marine WLBs. Full article

The use of artificial intelligence-based techniques to solve engineering problems is increasing. One of the most challenging tasks facing industry is the timely diagnosis of failures in electromechanical systems, as they are an essential part of production systems. In this sense, the earlier the detection, the higher the economic loss reduction. For this reason, this work proposes the development of a new methodology based on infrared thermography and an artificial intelligence-based classifier for the detection of multiple faults in an electromechanical system. The proposal combines the intensity profile of the grey-scale image, the use of Fast Fourier Transform and an artificial neural network to perform the detection of twelve states for the state of an electromechanical system: healthy, bearing defect, broken rotor bar, misalignment and gear wear on the gearbox. From the experimental setup, 50 thermographic images were obtained for each state. The method was implemented and tested under different conditions to verify its reliability. The results show that the precision, accuracy, recall and F1-score are higher than 99%. Thus, it can be concluded that it is possible to detect multiple conditions in an electromechanical system using the intensity profile and an artificial neural network, achieving good accuracy and reliability. Full article

This study considered the issue of increasing the synchronizing capacity of a system for the coordinated rotation of asynchronous motors. Electromechanical relationships were obtained for changes in the value of the supply voltage of individual motors, the total rotor resistance (Ra), and the angular positions of the rotors (φ₁, φ₂, and φ₃), with possible changes in angular misalignment. Additionally, we created an algorithm for calculating the currents and torques of the system’s motors within 0 and 90° and constructed the relevant mechanical characteristics. Ultimately, we developed various versions of multi-motor asynchronous electric drives with regulation and supply voltages (U_n = 0.7 ÷ 1.0), featuring increasing and equalizing torques (M_n = 1.0 ÷ 1.4) in the system as a whole, along with the preliminary synchronization and synchronous braking of all motors. Full article

In the heavy-duty vehicle industry, unbalance in the armature is one of the most common problems affecting starters’ performance and durability. This research presents a comprehensive study to improve the balancing process for starting rotors in heavy-duty vehicles. The complete manufacturing process of armatures was analyzed to understand the contribution of assembly processes to unbalancing. The analysis revealed that the primary factor leading to high unbalance in these parts is the misalignment of conductors within the armature winding. During assembly, these conductors experience axial movements, resulting in non-uniform mass distribution and causing unbalanced values ranging from 150 to 350 g·mm. These values surpass the permissible limit, making rectification during the balancing process at the end of the assembly impossible. Consequently, a novel alignment tool was designed to address this issue, significantly reducing the effect and achieving the maximum allowable unbalance of 100 g·mm. This allowed the balancing machine used in the process to correct the initial unbalance of the reinforcements in a single work cycle, improving operation efficiency by about 15%. Full article

In order to ensure the vibration safety of rotor systems in the next generation of aero-engines and reduce the impact of misalignment faults, the effect of support misalignment on the vibration characteristics of rotor systems under ultra-high operating speeds is investigated in this paper. Firstly, an analytical excitation model of the rotor systems under ultra-high operating speeds is established, considering the impact of the support misalignment. Then, based on the model of the misaligned combined support system, the dynamic model of the flexible discontinuous rotor support system with the support misalignment is presented. Subsequently, based on the established model, the effects of support parameters and support misalignment amounts on the vibration characteristics of the rotor support system are analyzed. Finally, experimental validation of the research findings is conducted. The research result shows that the support misalignment increases the vibration response of the rotor, reduces the vibration reduction efficiency of the combined support system, and consequently decreases the vibration safety of the rotor support system. Full article

According to the characteristics of the rotor system in an aero-engine and the vibrational test requirements of the aero-engine ground test, suitable vibration measurement sensors and test positions were selected. The vibration signals at the casings for the compressor and turbine of a twin-spool turbo-jet engine were collected under the states of maximum power and afterburning respectively, and the power spectrum analysis was carried out to determine the positions and causes of vibration. Furthermore, methods and preventive measures for eliminating vibration have been proposed. The results indicated that the main rotor vibration excited by mass imbalance in the twin-spool turbo-jet engine was significant. Rotor spindle misalignment or rotor radial stiffness unevenness also induced the vibration. The aerodynamic pulse vibration formed by the rotor blades of the first stage of the low pressure compressor was large, and rub induced vibration fault may occur at the turbine rotor seals. Based on the power spectrum analysis technology, the rotor system faults information including the type, position, and the degree can be quickly identified, and useful attempts and explorations have been made to reduce the vibration faults of the twin-spool turbo-jet engine. Full article

The inter-shaft bearing is the core component of a high-pressure rotor support system of a high-thrust aero engine. One of the most challenging tasks for a PHM is monitoring its working condition. However, considering that in the bearing rotor system of a high-thrust aero engine bearings are prone to wear failure due to unbalanced or misaligned faults of the rotor system, especially in harsh environments, such as those at high operating loads and high rotation speeds, bearing wear can easily evolve into serious faults. Compared with aero engine fault diagnosis and RUL prediction, relatively little research has been conducted on bearing condition monitoring. In addition, considering how to evaluate future performance states with limited time series data is a key problem. At the same time, the current deep neural network model has the technical challenge of poor interpretability. In order to fill the above gaps, we developed a new framework of a residual space–time feature fusion focusing module named RTCA-Net, which focuses on solving the key problem. It is difficult to accurately monitor the wear state of aero engine inter-shaft bearings under special working conditions in practical engineering. Specifically, firstly, a residual space–time structure module was innovatively designed to capture the characteristic information of the metal dust signal effectively. Secondly, a feature-focusing module was designed. By adjusting the change in the weight coefficient during training, the RTCA-Net framework can select the more useful information for monitoring the wear condition of inter-shaft bearings. Finally, the experimental dataset of metal debris was verified and compared with seven other methods, such as the RTC-Net. The results showed that the proposed RTCA-Net framework has good generalization, superiority, and credibility. Full article

This study presents an efficient vibration-based fault detection method for rotating machines utilising the poly-coherent composite spectrum (pCCS) and machine learning techniques. pCCS combines vibration measurements from multiple bearing locations into a single spectrum, retaining amplitude and phase information while reducing background noise. The use of pCCS significantly reduces the number of extracted parameters in the frequency domain compared to using individual spectra at each measurement location. This reduction in parameters is crucial, especially for large industrial rotating machines, as processing and analysing extensive datasets demand significant computational resources, increasing the time and cost of fault detection. An artificial neural network (ANN)-based machine learning model is then employed for fault detection using these reduced extracted parameters. The methodology is developed and validated on an experimental rotating machine at three different speeds: below the first critical speed, between the first and second critical speeds, and above the second critical speed. This range of speeds represents the diverse dynamic conditions commonly encountered in industrial settings. This study examines both healthy machine conditions and various simulated fault conditions, including misalignment, rotor-to-stator rub, shaft cracks, and bearing faults. By combining the pCCS technique with machine learning, this study enhances the reliability, efficiency, and practical applicability of fault detection in rotating machines under varying dynamic conditions and different machine conditions. Full article

Through innovation in the data collection environment, data-driven fault diagnosis has become increasingly important. This study aims to develop an algorithm to improve the accuracy of fault diagnosis based on Internet of Things (IoT) sensor data. In this research, current data collected through IoT sensors is utilized, focusing on diagnosing four states: bearing defects, shaft misalignment, rotor imbalance, and belt looseness. Additionally, to enhance the efficiency of the fault diagnosis algorithm, we introduce a preprocessing technique that utilizes descriptive statistics to reduce the data dimensionality. The experiments are conducted based on current data and vibration data, ensuring reliability from both types of data. The experimental results indicate a significant improvement in the accuracy and computational time of the fault diagnosis algorithm. After experimenting with various candidate algorithms, XGBoost version 1.7.6 exhibited the highest performance of classification. This research contributes to enhancing safety and reliability based on IoT sensors and suggests potential applications in the field of fault diagnosis. Full article

To prevent critical failure of the functional machinery of a ship, condition monitoring technologies have been much studied in recent times. In this respect, securing a fault database is a top priority in technology development. In this paper, we developed a test bed that simulates the LNG (liquefied natural gas) re-liquefaction system installed on LNG carriers to obtain data in various types of faults of ship machinery. To maintain rotor-dynamics characteristics, the structure was scaled based on the critical speed margin of the dynamic system. The developed test bed includes a gearbox and multiple shafts. It can simulate mass imbalance, misalignment, bearing fault, gear fault and impeller fault. To verify the validity of the vibration data obtained from the developed test bed, experiments were conducted on three fault modes: main shaft imbalance, pinion shaft imbalance, and gear fault. The time series data and FFT results were analyzed, and time domain features were extracted and statistically validated. Additionally, a simple diagnosis model was developed using the acquired data to evaluate its performance. The test data show distinct data with respect to fault conditions, and we can expect that the diagnosis algorithm can be developed using the test data. The developed test bed can provide not only for the fault data of a single component of the rotating machine but also for the combined fault data of the total system. In addition, we expect that it will solve the problem of securing fault data in the development of condition diagnosis technology if reliability is verified by identifying correlations by comparing data from the real system and data from the scaled test bed. Full article

Induction motors (IM) play a fundamental role in the industrial sector because they are robust, efficient, and low-cost machines. Changes in the environment, installation errors, or modifications to working conditions can generate faults in induction motors. The trend on IM fault detection is focused on the design techniques and sensors capable of evaluating multiple faults with various signals using non-invasive analysis. The methodology is based on processing electric current signals by applying the short-time Fourier transform (STFT). Additionally, the computation of the mean and standard deviation of infrared thermograms is proposed as main indicators. The proposed system combines both parameters by means of Support Vector Machine and k-nearest-neighbor classifiers. The development of the diagnostic system was done with digital hardware implementations using a Xilinx PYNQ Z2 card that integrates an FPGA with a microprocessor, thus taking advantage of the acquisition and processing of digital signals and images in hardware. The proposed method has proved to be effective for the classification of healthy (HLT), misalignment (MAMT), unbalance (UNB), damaged bearing (BDF), and broken rotor bar (BRB) faults with an accuracy close to 99%. Full article

Rotor system of aviation engines is often made of multiple rotors connected by the clutch. Due to manufacturing and assembly errors, there is a clutch misalignment, including the parallel misalignment and the angle misalignment. This misalignment produces additional torque in the operation of the system, leading to an abnormal increase in its oscillation, which causes the rubbing between the stator and the rotor. The rub-collision poses great harm to the safety and stability of the aero-engine. The analytical model of the rotor system with misalignment and rubbing faults is established, and the influence of the rotational speed, the misalignment, and the rubbing on the nonlinear characteristics of the rotor is investigated. Considering the nonlinear Hertz contact force and bearing gap, the model of the inter-shaft bearing is built; the parallel and angle misalignments of clutch are taken into account to analyze the characteristic frequency of the faults. For raising the thrust-to-weight ratio of aviation engines, the hollow shaft is often adopted, and the effect of the wall thickness for the shaft on the nonlinear vibration of the system is also investigated. It is innovative to study the transfer mechanism from wall thickness to the nonlinear vibrational responses of the overall structure. The result indicates that, with the increase in the wall thickness of the shaft, the second critical rotating speed increases, while the first critical rotating speed is almost unchanged. The characteristic frequencies for the three-rotor system with coupling faults are obtained. Despite intuition, the parallel misalignment can inhibit rub-collision vibration to a certain extent. The research has important reference values for the fault recognition and structural optimization of the three-rotor system. Full article

The induction motors found in industrial and commercial applications are responsible for most of the energy consumption in the world. These machines are widely used because of their advantages like high efficiency, robustness, and practicality; nevertheless, the occurrence of unexpected faults may affect their proper operation leading to unnecessary breakdowns with economic repercussions. For that reason, the development of methodologies that ensure their proper operation is very important, and in this sense, this paper presents an evaluation of signal entropy as an alternative fault-related feature for detecting faults in induction motors and their kinematic chain. The novelty and contribution lie in calculating a set of entropy-related features from vibration and stator current signals measured from an induction motor operating under different fault conditions. The aim of this work is to identify changes and trends in entropy-related features produced by faulty conditions such as broken rotor bars, damage in bearings, misalignment, unbalance, as well as different severities of uniform wear in gearboxes. The estimated entropy-related features are compared to other classical features in order to determine the sensitivity and potentiality of entropy in providing valuable information that could be useful in future work for developing a complete methodology for identifying and classifying faults. The performed analysis is applied to real experimental data acquired from a laboratory test bench and the obtained results depict that entropy-related features can provide significant information related to particular faults in induction motors and their kinematic chain. Full article
