A low-profile tri-band metamaterial absorber is developed for microwave attenuation and electromagnetic shielding applications within the S-, C-, and X-band regions. The absorber employs a compact resonant topology comprising a square metallic ring and two nested decagonal resonators, fabricated on an FR-4 dielectric layer with a metallic backing. Numerical optimization results in three highly efficient absorption bands located at 3.6 GHz, 7.4 GHz, and 11 GHz, where the absorptivity exceeds 99%. The physical origin of the absorption response is examined through field localization, induced current distributions, constitutive parameter extraction, and impedance characteristics. The analysis demonstrates that the resonant modes generated by the coupled metallic elements promote strong confinement of electromagnetic energy within the structure, leading to dissipation of the incident power. The geometrical unit-cell symmetry further enables a nearly identical response for different polarization states, while maintaining stable operation for incoming angles up to 60° under both TE and TM excitations. To verify the simulation results, an array prototype was manufactured and tested using a free-space characterization technique. The measured absorption characteristics closely follow the simulated response, showing the effectiveness of the design methodology. Owing to its compact dimensions, near-unity absorption, angular stability, and strong shielding capability, the developed absorber offers significant potential for electromagnetic compatibility enhancement, microwave shielding, and radar-related applications. Full article

A novel microwave biosensor operating in the C-band is developed and characterised for enhanced glucose sensing applications. The sensor is based on a single metamaterial asymmetric split-ring resonator (SASR) and has been investigated in two configurations: a single semi-circular design (SASR-S) and a double semi-circular design (SASR-D). The structural modifications were introduced to enlarge the sensing area by creating two high-field hotspots, thereby increasing the interaction between the electromagnetic (EM) field and the sample, which consequently enhances the overall sensor sensitivity. The sensor is fabricated on a Rogers AD350A substrate and is optimised to detect glucose levels in a 1 µL solution applied within each semi-circle sensing region. To characterise the sensor’s enhanced sensitivity, we performed a 3D electromagnetic simulation of a small droplet positioned within a semicircular sensing region, varying the relative permittivity of the droplet from 45 to 65. The resulting shifts in resonant frequency served as a primary indicator of dielectric sensitivity. The sensor’s response was experimentally validated using a vector network analyser to measure the transmission coefficient (S₂₁) of samples with no glucose and at glucose concentrations of 97 mg/dL to 286 mg/dL. The results demonstrate that the resonator configuration strongly influences the resonance frequency shift and sensitivity, with the SASR-D configuration being the most effective design. This has also been confirmed by measurements demonstrating a sensitivity of approximately 2.4 MHz/(mg/dL), representing an approximately two-fold improvement over the SASR-S sensor (sensitivity: 1.27 MHz/(mg/dL)) and a notable enhancement over previously reported sensors. These findings demonstrate the practical potential of the proposed sensor for blood glucose monitoring applications. Full article

This paper presents a microwave sensing platform based on a 32-element dipole array designed for near-field dielectric contrast mapping. The sensor utilizes an $8\times 8$ tightly coupled dipole array (TCDA) topology, where pairs of dipoles form unit cells that exploit electromagnetic coupling variations. A 32-way equal power divider network ensures uniform excitation across the aperture. Operating at 830 MHz, the dipole array exhibits high absorption (>90%), which enhances near-field intensity and sensitivity to surface perturbations. Experimental validation with dielectric samples, saline liquids of varying concentrations (${ϵ}_r\approx$ 70–78), and biological tissues demonstrates the array’s capability to map spatial variations in electromagnetic properties through rectified DC voltage shifts. When compared to a state-of-the-art multi-port Vector Network Analyzer (VNA) configurations, the proposed architecture offers a robust, low-complexity, proof-of-concept alternative by eliminating complex RF routing networks and multi-port switches. Full article

The paradigm shift towards wellness, healthy lifestyles, and the deterrence of socially significant diseases has directed scientific interest towards the sustainable extraction of bioactive substances from plant biomass or biowaste. To achieve the recovery of high-quality, enriched extracts containing valuable compounds with preserved activity and stability, advanced techniques are essential. Microwave-assisted extraction (MAE) is a cutting-edge extraction method for the valorization of biomass and/or biowaste, which has a crucial role in promoting the principles of bio-innovations and bio-circular economy. When compared to conventional techniques, it can substantially decrease the risks to the environment and humans, particularly when eco-friendly solvents that are recommended in the CHEM21 selection guide are used. Though MAE may achieve high selectivity, it is still compound-dependent, driven by differences in microwave absorption, dielectric behavior, and matrix–solvent interactions across diverse metabolite classes. This advanced technique offers an eco-friendly replacement for conventional extraction, sharply decreasing environmental and health risks. This review presents the current state of plant biomass valorization to secondary metabolites of four classes of compounds by applying MAE, compares its efficiency with that of other techniques, addresses recent developments and challenges, and explores its future perspectives. Full article

This paper proposes a novel multi-frequency extended Deep Learning (DL) model for electromagnetic image reconstruction under Transverse Magnetic (TM) wave incidence in layered media, inspired by conventional microwave imaging techniques that combine nonlinear inversion algorithms with neural networks to improve reconstruction performance. The proposed framework adopts a two-stage neural network architecture. In the first stage, a Deep Residual Convolutional Neural Network (DRCNN) is employed to extrapolate multi-frequency scattered fields from single-frequency input data, thereby enriching the frequency-dependent scattering information available for reconstruction. Subsequently, the extrapolated multi-frequency scattered fields are fed into a Deep Convolutional Encoder–Decoder (DCED) network to reconstruct an accurate dielectric constant distribution within the imaging domain. To validate the effectiveness of the proposed approach, two representative comparison methods are considered: (1) a hybrid framework combining the Back-Propagation Scheme (BPS) with a Convolutional Neural Network (CNN), and (2) a framework integrating the Dominant Current Scheme (DCS) with a CNN. In both approaches, conventional inversion algorithms are first utilized to generate coarse initial reconstructions, which are subsequently refined by the neural network. Numerical simulations and experimental results show that the proposed multi-frequency extension model achieves lower reconstruction error and higher structural similarity than the reference methods. These results confirm the effectiveness and potential of the proposed framework for advanced electromagnetic imaging applications. Full article

Thermal energy storage using suitable materials is a strategic solution for integrating renewable energy and decarbonising industrial processes. Current Power-to-Heat systems using solar salt rely on electric heaters; however, the low thermal conductivity of molten solar salt promotes localised hot spots, leading to material degradation and reduced performance. Microwave heating is a promising alternative due to its volumetric heating capability and compatibility with renewable electricity. Nevertheless, dielectric characterisation shows that molten solar salt behaves as a highly conductive ionic medium with significant dielectric losses, limiting microwave penetration and resulting in predominantly surface-localised heating. To investigate this limitation, two cavity configurations were analysed using multiphysics simulations and parametric design studies: a single-mode elliptical cavity operating at 915 MHz with an iris, and a quasi-cylindrical multimode cavity operating at 2.45 GHz for scalable applications. The coupled electromagnetic, fluid-flow, and thermal behaviour was evaluated through the resulting field distributions and heating patterns. Complementary experiments assessed microwave-transparent container materials and determined the emissivity of molten solar salt from thermographic measurements, highlighting key engineering considerations for integrating microwave heating into next-generation Power-to-Heat technologies. The results demonstrate that microwave heating of highly conductive molten solar salt is fundamentally constrained by the limited electromagnetic penetration depth, defining practical design limits for its integration into next-generation Power-to-Heat systems. Full article

(Fe/C)/ABS resin electromagnetic metamaterials were fabricated via 3D printing, and the effect of iron salt loading (0, 1, 2, and 3 g) in the Fe/C filler on the microwave absorption performance of the resulting composites was systematically investigated. The results demonstrate that, with increasing iron salt content, the microwave absorption bandwidth of the samples exhibits a trend of initial significant broadening followed by saturation. At an iron salt loading of 1 g, the (Fe/C)/ABS resin composite achieves an effective absorption bandwidth (EAB) of 6.2 GHz at a matching thickness of 10 mm, representing an approximately 48% enhancement over that of the pure C/ABS resin composite (4.2 GHz). The incorporation of iron salts not only endows the material with magnetic loss capability but also promotes the formation of an sp²-hybridized carbon framework within the carbon matrix during Fe/C composite preparation, concurrently introducing abundant defect sites that augment the dielectric loss capacity. Under the synergistic magneto-dielectric loss mechanism, the microwave attenuation coefficient of the material is markedly enhanced, and the effective absorption bandwidth is substantially broadened, all at a filler loading of merely 2.5 wt%. This study elucidates the influence of iron salt loading on the microwave absorption performance of (Fe/C)/ABS resin composites, while the 3D printing-based fabrication approach employed herein offers a promising technical pathway for the development of novel microwave-absorbing materials. Full article

In view of the advantage of cross-polarized inspection (CrPI) in microwave nondestructive testing (MNT), in this paper a dual-polarized narrow-beam antenna as the pivotal reflectometric sensor is systematically designed and realized particularly for enhancement of detection and imaging of subsurface defects in dielectric structures. The antenna is equipped with a compact asymmetric waveguide orthomode transducer, with Teflon used as the internal filling material, in an effort to reduce its size and narrow the beamwidth. The internal dimensions of the realized dual-polarized narrow-beam antenna are optimized via numerical simulations. Based on the optimal design parameters, the antenna is fabricated and assessed through experiments. The experimental results reveal that the fabricated antenna has better metric indicators in terms of a return loss better than 10 dB, isolation better than 40 dB in 30.0 GHz~36.0 GHz and half-power beamwidths below 36.9° at 36.0 GHz. In order to further affirm the applicability of the fabricated antenna for CrPI, an MNT system is established to perform two-dimensional scanning and imaging of back-surface volumetric defects in polyethylene specimens. Based on the image characteristics of CrPI, a flaw-recovery algorithm is proposed to retrieve the defect opening profile. The averaged contrast-to-noise ratio of the processed CrPI-based image is found to be approximately five times larger than that of the raw CrPI-based image and fourteen times bigger than that of the raw CoPI-based image. Experimental results have further indicated that the fabricated antenna is feasible for not only co-polarized inspection (CoPI) but for CrPI, which exhibits higher testing sensitivity and defect-image contrast than CoPI. In conjunction with the flaw-recovery algorithm, by utilizing the dual-polarized narrow-beam antenna with the better metric indicators for CrPI, the image quality of the back-surface flaws in polyethylene slabs can be effectively improved. Full article

The rapid expansion of microwave and millimeter-wave telecommunication systems has intensified the need for precise dielectric material characterization at high frequencies. As operating frequencies increase, small uncertainties in permittivity and loss tangent significantly degrade resonance stability, bandwidth control, and quality factor, directly affecting RF system reliability and performance. However, the growing diversity of resonator architectures and extraction methodologies has led to fragmentation in the literature, making it difficult to identify optimal solutions for telecommunication-oriented applications. This review provides a structured and application-driven assessment of high-frequency resonator-based dielectric characterization techniques relevant to modern telecommunication systems. Resonator topologies—including cavity, planar, substrate-integrated, metamaterial-inspireds—are systematically classified and critically compared. Their sensing mechanisms and parameter-extraction approaches are analyzed in terms of frequency-shift sensitivity, Q-factor performance, scalability toward millimeter-wave bands, integration capability, and measurement robustness. By synthesizing performance trade-offs, practical limitations, and emerging research directions, this review establishes clear design guidelines and a forward-looking framework for advancing dielectric metrology in next-generation high-frequency telecommunication technologies. Full article

Microwave imaging of objects embedded in multilayer cylindrical structures is of practical importance in applications where inaccessible targets are surrounded by a known inhomogeneous host. In such problems, incorporating the known multilayer structure into the background model can improve reconstruction accuracy and reduce the complexity of the inverse problem. This paper presents an efficient imaging method for dielectric objects embedded in two-dimensional multilayer cylindrical structures with arbitrarily shaped layer boundaries. The proposed approach integrates the contrast source inversion method with a recursive eigenfunction expansion technique for noncircular geometries. The known multilayer host is treated as the background medium, while the inversion is restricted to the embedded scatterers. The recursive formulation is derived to compute the inhomogeneous-background Green’s function and the required cell-integrated Green’s functions in a semi-analytical and discretization-free manner. Numerical results suggest that the method is capable of providing satisfactory reconstructions of embedded objects under various host configurations, including cases with a Perfect Electric Conductor (PEC) core. Comparisons with Method of Moments reference solutions confirm the accuracy of the forward modeling and the reliability of the inversion, while demonstrating a significant reduction in computational cost. Full article

Spinel NiCo₂O₄ has emerged as a promising microwave absorption material due to its unique crystal structure and abundant defect sites. Nevertheless, its low intrinsic electrical conductivity leads to insufficient conductive loss and unsatisfactory high-frequency impedance matching, severely limiting the simultaneous realization of strong electromagnetic attenuation and broad absorption bandwidth. Fe³⁺ doping is an effective modification strategy for NiCo₂O₄ by virtue of its matched ionic radius and dual modulation capability for dielectric and magnetic properties. Herein, pristine and Fe-doped NiCo₂O₄ absorbers with different doping contents (4%, 6%, 8%) were fabricated via a hydrothermal–calcination route, and the correlation between Fe doping concentration, microstructure, electronic structure, electromagnetic properties, and microwave absorption performance was systematically investigated. Benefiting from moderate 6% Fe doping, the optimized F6 sample exhibits a refined porous nano-agglomerate structure, which provides abundant heterogeneous interfaces and pore channels for electromagnetic wave scattering and attenuation. The introduced oxygen vacancies and balanced Ni²⁺/Ni³⁺, Co²⁺/Co³⁺, and Fe²⁺/Fe³⁺ mixed-valence states effectively strengthen interfacial and dipole polarization, while the optimized electrical conductivity and magnetic properties synergistically boost conductive and magnetic losses. Owing to the dual-loss synergism and superior impedance matching (58% proportion of Δ < 0.4), the F6 sample achieves an excellent minimum reflection loss of −62.7 dB at 2.2 mm and a wide effective absorption bandwidth of 4.6 GHz. This work clarifies the intrinsic structure–performance mechanism of Fe-doped NiCo₂O₄, providing a reliable and feasible strategy for the design and preparation of high-performance spinel-type microwave-absorbing materials. Full article

Ionogels combining ionic liquids with polymer networks show promise for flexible electronics, but their mechanical and functional performance often needs enhancement. Here, we report a series of magnetic nanocomposite ionogels fabricated by doping triiron tetraoxid (Fe₃O₄) nanoparticles into a [C₂mim]⁺[EtSO₄]⁻-dispersed cross-linked PAA matrix. The effect of PAA content (10–20 wt%) on the optical, mechanical, and dielectric properties of pure imidazolium ionogels was first investigated. Increasing PAA concentration enhanced tensile strength (up to ~0.7 MPa) and compressive modulus (~0.65 MPa) while reducing optical transmittance; dielectric relaxation peaks around 6–8 GHz were observed, with the 15 wt% sample showing the highest permittivity. Subsequently, Fe₃O₄ nanoparticles (0–20 wt%) were incorporated into the 10 wt% PAA ionogel. The resulting magnetic ionogels exhibited reduced tensile strength, but significantly increased elongation (up to ~12 strain), indicating network softening. Magnetic hysteresis measurements confirmed superparamagnetic behavior with saturation magnetization reaching ~2.5 emu/g at 20 wt% Fe₃O₄ loading. This work demonstrates a facile strategy to simultaneously tune mechanical, dielectric, and magnetic properties in imidazolium ionogels, providing guidelines for designing soft multifunctional materials for microwave absorption, magnetic actuation, and flexible sensor applications. Full article

Perovskite manganites (AMnO₃) and perovskite-like manganites (A′_1−xA_xMnO₃) are complex oxide materials that have attracted significant attention from the scientific community in recent years due to their structural flexibility, mixed-valence state, tunable electronic configuration, and multifunctional properties. This review systematically analyzes the synthesis methods, structural classification, and physicochemical characterization of perovskite manganites, as well as their magnetic, optical, electrical, dielectric, and catalytic properties. The influence of solid-state reactions, sol–gel, Pechini, hydrothermal, co-precipitation, microwave, and other mild chemical approaches on phase purity, morphology, particle size, and oxygen stoichiometry was examined. The structural diversity of perovskite and perovskite-like manganites, including simple ABO₃, double perovskites, multilayer, and low-dimensional systems, was characterized in relation to their functional properties. The review discussed the capabilities of methods for synthesizing and analyzing morphological properties, demonstrating the role of doping, cation substitution, oxygen vacancies, and Jahn–Teller distortions in controlling material properties. Prospects for the application of perovskite manganites in spintronics, magnetocaloric cooling, photocatalysis, gas-sensing devices, and energy conversion and storage systems were analyzed. This review highlights the structure–property–application relationship in perovskite manganites. Full article

Grain moisture content is a key variable for safe storage, drying control, and quality management. Microwave sensing is attractive because water strongly modulates the complex relative permittivity ($\epsilon *={\epsilon }^{\prime }-j{\epsilon }^{″}$) of granular agricultural products, thereby shaping broadband scattering-parameter spectra. This study presents a meter-referenced feasibility evaluation of an interpretable S-parameter–permittivity–moisture chain using a vector network analyzer over 2–18 GHz. Wheat, maize, and mung bean were prepared at six moisture levels, and the moisture values were referenced to two commercial grain moisture meters (MC_ref) to represent rapid on-site benchmarking rather than absolute gravimetric moisture determination. Therefore, the reported errors should be interpreted as commercial-meter-referenced calibration indicators rather than absolute gravimetric moisture prediction accuracy. Two free-space configurations were compared on the same platform: a two-horn transmission setup under controlled packing and a metal-backed double-pass reflection setup intended to represent single-sided access under loose bulk packing. After SOLT calibration and empty-holder background normalization, ${\epsilon }^{\prime }$ and ${\epsilon }^{″}$ were retrieved via complex-domain nonlinear least-squares fitting of physics-based slab models to measured S21 spectra. The results show that moisture-dependent dielectric responses were grain- and configuration-dependent. In particular, ${\epsilon }^{″}$ generally provided a more robust moisture-sensitive feature in the free-space transmission configuration, whereas the optimal single-parameter predictor in the metal-backed configuration differed among grains. A mid-band frequency window of approximately 8–16 GHz provided more stable inversion by avoiding low-frequency coupling artefacts and high-frequency signal-to-noise degradation. The metal-backed configuration preserved moisture trends but yielded lower effective ${\epsilon }^{\prime }$ values, likely due to increased air fraction under loose packing. These results indicate that packing state, grain type, and frequency-window selection are critical factors for transferring microwave moisture calibration from laboratory measurements to practical grain-handling scenarios. Full article

Superparamagnetic materials have attracted increasing attention for high-frequency microwave absorption because superparamagnetic relaxation can partially overcome the high-frequency limitations of conventional magnetic absorbers. Herein, Fe₃O₄/rGO composite powders were prepared by electrostatic self-assembly and subsequently incorporated into an epoxy matrix, and magnetic-field-induced alignment was introduced during curing. Owing to the synergistic effects of interfacial polarization, magnetic dissipation, and improved impedance matching, the optimized composites exhibited markedly enhanced microwave absorption performance. In particular, when the rGO content was 10 wt% and an external magnetic field was applied, the composite achieved effective absorption across the entire X-band (8–12 GHz) within a thickness range of 1–3 mm, together with a minimum reflection loss of −40.3 dB. The enhanced performance is attributed to the combined contributions of abundant heterogeneous interfaces, superparamagnetic relaxation, and field-induced orientation of Fe₃O₄-decorated rGO sheets. This work provides a simple physical strategy for the microstructural regulation of magnetic–dielectric composites toward high-performance microwave absorption. Full article
