Search Results (23)

Laser beams are excellent projection sources due to their high brightness and color purity; however, their high coherence produces speckle noise, which reduces the clarity of images cast by compact projection systems. Existing suppression methods often require complex designs. Here, we propose a simple miniaturized speckle suppression structure (SSS) that consists of a low-absorption particle surface and a micro-vibrating unit. By generating and superimposing different speckle patterns over time, the structure simultaneously reduces both temporal and spatial coherence. A time-varying functional model was developed using a simulation to optimize its dynamic operation. The results of the experimental validation show that at 50 Hz vibration, the speckle contrast decreases from 30.23% to 6.98%, closely matching the simulated prediction of 7.12% and outperforming static configurations by 24%. The results indicate that the SSS is a straightforward, effective solution for enhancing the image quality of compact laser projection displays. Full article

The Survey Camera (SC) is the key instrument of the China Space Station Telescope (CSST), with its imaging performance significantly constrained by microvibrations from internal sources such as the shutter and cryocoolers. This paper proposes a systematic microvibration suppression scheme integrating disturbance source control, payload isolation, and transfer path optimization to meet the stringent requirements. The Cryocooler Assembly (CCA) compressor adopts a symmetric piston layout and a real-time vibration cancellation algorithm to reduce the vibration. Coupled with a vibration isolator designed by combining hydraulic damping and a flexible structure, it achieves a vibration isolation efficiency of 95%. The shutter adopts dual-blade symmetric design with sinusoidal angular acceleration control, ensuring its vibrations fall within the compensable range of the Fast Steering Mirror (FSM). And the finite element optimization method is used to optimize the dynamic characteristics of the Support Structure (SST) made of M55J carbon fiber composite material, to avoid resonance in the critical frequency bands. System-level tests on the integrated SC show that the RMS values of vibration force and torque within 8–300 Hz are 0.25 N and 0.08 N·m, respectively, meeting design specifications. This scheme validates effective microvibration control, guaranteeing the SC’s high-resolution imaging capability for the CSST mission. Full article

This paper addresses the degradation of imaging quality in high-resolution CubeSats caused by micro-vibrations from attitude control flywheels. It proposes a micro-vibration suppression scheme that incorporates multi-disciplinary integrated modeling, dual passive vibration isolation, and multi-level verification. A comprehensive model encompassing flywheel disturbance, optics, attitude control, and structure is developed to elucidate the transmission dynamics of micro-vibrations from the source to the optical payload. A dual suppression system utilizing silicone rubber isolators is engineered for both the disturbance source (flywheel) and the payload (optical camera). By optimizing stiffness matching and damping, it achieves a balance between isolation efficiency and stability in attitude control. A three-tier verification system comprising “numerical simulation–ground microgravity testing–on-orbit imaging” has been established. The findings indicate that the dual isolation system diminishes the pixel offset amplitude of the optical payload to under 0.1 pixels (down to the 0.02 pixel level in the high-frequency band), with an isolation efficiency of 80%. Consistent outcomes from terrestrial and orbital validation affirm the engineering viability of the plan. This research offers theoretical backing for the precise control of micro-vibrations in micro-nano satellites, thereby enhancing their utility in high-resolution remote sensing applications. Full article

Aiming at the nonlinear high-frequency micro-vibration (HFMV) phenomenon that would cause hidden faults of blade fracture failure of a wind turbine, this study calibrated a new type of HFMV aerodynamic force, elaborated on the nonlinear aeroelastic behavior of a 2D airfoil-based structural nonlinear system driven by HFMV aerodynamic forces, and proposed a control plan based on flutter suppression. Based on structural reinforcement based on a nonlinear tuned vibration absorber (NTVA), the flutter wind speed was increased, and artificial structural damping was introduced to analyze the flutter wind speed. The control planning adopted a new unified pitch control system based on the “screw rod–translational slider (nut)” transmission, which was driven by the hydraulic system to drive the ball screw and further drive the slider translation, achieving pitch motion. The control method adopted an optimal trajectory control and the optimal proportional-derivative (PD) controller adjustment technology based on the differential evolution algorithm (DEA). It achieved analysis of flap-wise bending/twist displacement responses, analysis of pitch angle changing, and display of slider driving force. The robustness of the control algorithm was validated by the control results displayed at different wind speeds near the flutter wind speed. The robustness of engineering applications for controlling performance was also validated on the controller hardware-in-the-loop simulation platform through an “object linking and embedding (OLE)” technology based on process control. Finally, the driving performance and wear consumption in engineering applications were discussed. On the basis of ensuring the control effect, the control algorithm was improved, and the fractional-order optimal PD control was adopted, so that the system could stabilize at the “0” consumption state when achieving flutter suppression. Full article

Agricultural machinery components suffer from severe soft abrasive wear when interacting with flexible materials like rice stalks. To address this, we investigate the friction-reduction mechanism, parameter optimization, and experimental validation of a biomimetic non-smooth surface inspired by the dung beetle’s microstructure. The bionic design was first established by characterizing the beetle’s unique micro-bump array. To ensure simulation accuracy, the critical bonding parameters of a flexible rice stalk DEM model were precisely calibrated via three-point bending tests combined with Response Surface Methodology (RSM). Subsequent DEM simulations revealed that the bionic surface disrupts continuous sliding by reducing the contact area and inducing high-frequency micro-vibrations in the stalk. Using RSM, the bump geometry was systematically optimized, yielding an optimal combination of a 2.975 mm diameter and a 1.0 mm spacing, which theoretically reduces the average normal contact force by 69.3%. Finally, reciprocating wear tests confirmed that the optimized bio-inspired surface exhibited significantly lower mass loss and effectively suppressed the formation of plowing grooves compared to a smooth surface, showing high agreement with simulation predictions. This study provides both a fundamental understanding of the friction-reduction mechanism and precise quantitative guidance for engineering wear-resistant agricultural components. Full article

Laser vibrometers are known for their high precision, long-range capabilities, and non-contact measurement characteristics. However, in long-range applications, spike noise often arises, primarily due to the laser speckle effect induced by rough targets. To address this challenge, this paper develops a light field transmission model for laser vibrometers. By exploiting the differences in speckle patterns formed by lasers of different wavelengths on the same rough target, a dual-wavelength laser vibrometry technique utilizing wavelength division multiplexing devices is proposed, along with a dual-channel signal enhancement method based on orthogonal demodulation. This approach effectively reduces the likelihood of spike noise and enhances the system’s velocity measurement resolution. The experimental results demonstrate that, compared to the single-wavelength system, the dual-wavelength system significantly suppresses laser speckle noise, mitigates measurement spike noise, and improves the stability of micro-vibration measurements. Additionally, the system’s velocity resolution improves from 0.165 μm/s/Hz^1/2 in the single-wavelength system to 0.122 μm/s/Hz^1/2 in the dual-wavelength system, thereby enhancing the system’s sensitivity to micro-vibrations. In engineering applications, the dual-wavelength approach provides higher stability and resolution for micro-vibration signal measurements. Full article

In order to meet the application requirements for high-precision and low-noise accelerometers in micro-vibration measurement and navigation fields, this paper presents the design and testing of an ultra-high-capacitance resolution capacitive readout circuit with attofarad-level precision. First, a differential charge amplifier circuit is employed for the first stage of capacitance detection. To suppress noise interference in the circuit, a frequency-domain modulation technique is utilized to mitigate low-frequency noise. Subsequently, a differential subtraction circuit is implemented to reduce common-mode noise. Additionally, an improved filtering circuit is designed to suppress noise interference in the final stage. The test results indicate that the designed circuit operates at a carrier frequency of 1 MHz, achieving a capacitance resolution of up to 0.103 aF/H${\mathrm{z}}^{1/2}$ and a noise floor of 25.6 $\mathsf{\mu }$g/H${\mathrm{z}}^{1/2}$, thereby meeting the requirements for high-precision and low-noise capacitance detection in MEMS accelerometers. Full article

Physical stimulation, which is a key factor affecting the metabolism of osteoblasts and their precursor cells, plays an important role in bone remodeling; however, the role of micro-vibrations in osteoblast differentiation is unclear. In the present study, we determined the effects of frequency-regulated repeated micro-vibration (FRMV) on cell proliferation and established a method to induce osteoblast differentiation through FRMV using the mouse pre-osteoblast-like cell line MC3T3-E1, which is widely used in bone metabolism research. The results indicated that FRMV significantly influenced the proliferation of MC3T3-E1 cells in a normal growth medium. FRMV at 42.2 Hz significantly promoted proliferation, whereas FRMV at 92.1 Hz showed no effect on the proliferation rate. Moreover, FRMV at 42.2 Hz significantly increased alkaline phosphatase (ALP) enzyme activity and ALP gene expression in MC3T3-E1 cells. Treatment with LDN193189, a bone morphogenetic protein (BMP) signaling inhibitor, revealed that the FRMV-induced upregulation in ALP enzyme activity and ALP gene expression were significantly suppressed in MC3T3-E1 cells. The results suggest that the FRMV protocol developed in the present study induces osteoblast differentiation through the BMP signaling pathway. Thus, FRMV may contribute to the development of effective bone regeneration technologies. Full article

With the advancement of space exploration and optical communication toward deep space, the high-precision evaluation and image stabilization of space optical payloads under micro-vibration have become increasingly critical. To address these challenges and ensure sub-micro-radian pointing accuracy for high-precision space optical payloads (HPSOPs), this paper proposes a high-precision micro-vibration testing scheme and a two-stage image stabilization system. The micro-vibration testing scheme is based on an automated quasi-zero stiffness suspension device (AQZSSD), which enhances testing sensitivity and environmental disturbance resistance, ensuring the accuracy of the results. The two-stage image stabilization system integrates three bipod vibration isolation legs (BVILs) and a decoupled fast steering mirror (FSM), extending control bandwidth and achieving comprehensive vibration suppression. Micro-vibration testing and image stabilization experiments were conducted under disturbances from multiple vibration sources. Experimental results demonstrate that the AQZSSD introduces disturbances below 0.4 Hz, confirming its quasi-zero stiffness characteristics in alignment with theoretical predictions. Furthermore, the line-of-sight (LOS) jitter root mean square (RMS) value is reduced from 1.253 μrad to 0.276 μrad, achieving sub-micro-radian stability. Additionally, due to the coupling effect of the micro-vibration response, the collaborative testing results were found to be lower than the linear superposition of individual sources. This work offers critical theoretical and technical support for the development of HPSOPs, with potential applications in future space missions and advanced optical technologies. Full article

This paper designs a spatial photoelectric scanning mechanism that utilizes the large transmission ratio and reverses the self-locking performance of worm gears and gears. The institution uses a stepper motor to drive the worm gear component, thereby driving the worm gear to drive the alarm camera for spatial alarm imaging work. The stepper motor provides the driving force for motion, and, simultaneously, the alarm camera image can be compared with the star map to achieve position feedback. Therefore, this mechanism can achieve closed-loop control without angle measuring devices, achieving the lightweight design of the photoelectric scanning mechanism. Although this driving mechanism has many advantages, due to the micro-vibration formed by the gear backlash between teeth during the operation of the worm gear and worm, micro-vibrations are generated in the system, which can interfere with satellites with high precision requirements and affect their normal operation. This paper analyzes and experimentally verifies the principle of micro-vibrations in the worm gear and worm movement mechanism, and takes a certain photoelectric scanning turntable as an example to suppress micro-vibrations. The micro-vibration momentum level has been reduced from 7 N (at its peak) to 3.5 N (at its peak), with the number of targets increased by 50%, resulting in an effective suppression effect. Full article

The application of active magnetic bearings (AMBs) in high-speed rotating machinery faces the challenge of micro-vibration. This research addresses the vibration control of a high-speed magnetically suspended turbo molecular pump (MSTMP) with rotor mass imbalance vibration and multi-stage-blade modal vibration. A novel integrated AMB controller consisting of parallel co-frequency adaptive notch filter (ANF) and cascaded multi-frequency improved double-T notch filters (DTNFs) is proposed. To suppress rotor mass imbalance vibration, a bandwidth factor rectification method of the ANF based on displacement stiffness perturbation is designed. To suppress multi-stage-blade modal vibration, a multi-objective constrained optimization method of cascaded improved DTNFs based on linear normalization is designed. Simulation and experimental results validate that the proposed structure improvement of the addition of an AMB controller and multi-parameter optimization of the algorithm can effectively improve not only the phase stability margin and the notch vibration performance of the magnetically suspended rotor (MSR) system but also the efficiency and practicability of the algorithm. At rotational speeds of 12,000 $\mathrm{rpm}$, 15,000 $\mathrm{rpm}$, 18,000 $\mathrm{rpm}$, and 21,000 $\mathrm{rpm}$, the suppression of co-frequency synchronous vibration is approximately maintained between −30.94 $\mathrm{dB}$ and −30.56 $\mathrm{dB}$. At the rated speed of 24,000 $\mathrm{rpm}$, compared with other algorithms, the value of the rotor displacement converges from 0.08 $\mathrm{mm}$ to 0.03 $\mathrm{mm}$, a reduction of 62.50%. The convergence time decreases from 3.67 $\mathrm{s}$ to 2.85 $\mathrm{s}$, a reduction of 22.34%. Full article

In this paper, the main excitation sources of micro vibration of spacecraft flywheel rotor systems (SFRSs) are briefly described, and then the research progress is systematically reviewed from four perspectives, including modeling methods, suppression means, vibration isolation techniques, and ground simulation tests. Finally, the existing problems of current research and the direction of further research are given to better serve the micro-vibration prediction and sensitivity analysis of existing models, and provide reference points for the micro-vibration suppression and isolation of the next generation of high-precision spacecraft. Full article

Micro-vibrations significantly influence the imaging quality and pointing accuracy of high-precision space-borne payloads. To mitigate this issue, vibration isolation technology must be employed to reduce the transmission of micro-vibrations to payloads. In this paper, a novel active–passive hybrid isolation (APHI) system based on a strain sensor is proposed for high-precision space payloads, and corresponding theoretical and experimental studies are implemented. First, a theoretical analysis model of the APHI system is established using a two-degrees-of-freedom system, and an integral control method based on strain sensing is presented. Then, an electromagnetic damper, active piezoelectric actuator, and strain sensor are designed and manufactured. Finally, an APHI experimental system is implemented to validate the effectiveness of electromagnetic damping and strain-sensing active control. Additionally, the control effects of acceleration, displacement, and strain sensors are compared. The results demonstrate that strain sensors can achieve effective active damping control, and the control method based on strain sensors can effectively suppress the payload response while maintaining stability. Both displacement and strain sensors exhibit superior suppression effects compared with the acceleration sensor, with the strain sensor showing greater potential for practical engineering applications than the displacement sensor. Full article

The AMB-rotor system is complex and has strong coupling characteristics, which allows multi-harmonic disturbances to enter the system through different ways to produce vibrations with rich spectrum components, which has a great influence on the improvement of micro-vibration accuracy of the rotor system. To further achieve active control of the micro-vibration in the AMB-rotor system, firstly, the mechanism of multi-source disturbance is analyzed according to the working principle of the AMB-rotor system, and the mathematical and physical relationship between the mechanism of disturbance generation and the inducement is deeply studied. Then, the structure of a novel adaptive notch filter, the method of adaptive frequency estimation and analysis of harmonic current suppression in the AMB system are presented. Finally, simulation and experimental research using an MSCMG system demonstrate the feasibility of the proposed method regarding the elimination of harmonic control current. Full article

The spaceborne solar observation system is crucial for the study of space phenomena such as solar flares, which requires high tracking accuracy. This study presents a coupling model that integrates mechanical, electrical, and control models to investigate the structural flexibility effect on the micro-vibration response. We established a rigid–flexible model using mechanical parts. We considered the influence of flexible features while studying the dynamic responses in its operation. The state-space equations of the system showed that modal frequency, damping, and modal participation factors played significant roles. We derived transfer functions using the Laplace transform of the coupling models to better understand this mechanism, and Simulink models were thereby established. We simulated the acceleration responses of the rigid–flexible and rigid models under angle tracking modes, and the results showed significant differences. We also simulated the acceleration responses of the models under various control frequencies, and the optimal control frequency was thus obtained. Finally, we performed experiments, and the results indicated that the rigid–flexible model could better predict the motion and acceleration responses for the spaceborne solar observation system. This study provides valuable information for understanding the role of flexible features in space performance high-tracking accuracy instruments and for micro-vibration suppression research. Full article
