This paper presents the results of a detailed theoretical study of the bending properties of all-glass leakage channel microstructured optical fibers (LC MOFs) with a polymer coating over a bending radius range from 4.8 cm to 10 cm. The dependencies of the effective refractive indices of the LC MOF modes on the bending radius have a number of crossings and anticrossings for different mode pairs. A detailed analysis showed that eight modes for each polarization have to be considered to correctly calculate the bending losses. These modes can be classified into relatively strong modes (three for each polarization) and relatively weak modes. The three strong modes have the most direct effect on the loss calculation. However, the relatively weaker modes also play a role through their coupling with the stronger modes, resulting in the appearance of local loss maxima in the loss dependencies for the strong modes. At a bending radius of 10 cm, the final leakage loss of the LC MOFs with a polymer coating is approximately four times lower than that of the LC MOFs without a coating. The significant reduction in losses paves the way for further optimization of the LC MOF geometric structure, leading to a reduction in the allowable bending radius. Full article

Multicomponent clay and cenosphere linings protecting ceramic parts exposed to contact with liquid metal during continuous steel casting (CSC) are intended to diminish thermo-mechanical stresses at the beginning of this process. They are effective in their role, but due to their brittle nature, parts of them come off during transport or mounting. The admixture of polypropylene fibers into linings helps to alleviate problems with handling such parts, though the interaction of such a modified material with liquid steel should be re-assessed. The present experiment involved the preparation of a crucible with a Thermacoat™ (Vesuvius, Skawina, Poland) lining with the addition of Belmix™ (Belgian Fibers Group NV, Mouscron, Belgium) fibers and filling it with a drop of liquid steel. Next, the crucible was sectioned and the changes in its microstructure and phase composition were investigated with optical, scanning and transmission electron microscopy (OM/SEM/TEM) methods. This showed that the modified lining retained its non-wetting property against the steel of the non-modified material. The part with the lining, being in direct contact with the liquid steel, developed a highly porous layer filled with AlSiOx amorphous flakes with some larger blocky Al₂O₃ and SiO₂ particles. Right below this, a heat-affected zone (HAZ) consisting of fine γ-Al₂O₃ platelets immersed in amorphous silica was formed. Some of the voids with a size corresponding to polymer fiber diameter carried significant carbon deposits on their walls. The performed investigation indicated that the polymer fiber-modified linings were capable of withstanding at least short-term contact with liquid steel without instantaneous defragmentation, i.e., they retained the good high-temperature properties of the non-modified material. Full article

Structural fiber-reinforced polymer (FRP) composite materials consisting of a polymer matrix reinforced with layers of high-strength fibers are used in numerous applications, including but not limited to spacecraft, vehicles, buildings, and bridges. Researchers in the past few decades have suggested the necessary integration of sensors (e.g., fiber optic sensors) in polymer composites to enable health monitoring of composites’ performance over their service lives. This work introduces an innovative cognizant composite that can self-sense, compute, and implement decisions based on sensed values. It is a critical step towards smart, resilient infrastructure. We describe a method to fabricate textile sensors with flexible circuitry and a microcontroller within the polymer composite, enabling computational operations to take place in the composite without impacting its integrity. A microstructural investigation of the sensors showed that the amount of oxidative agent and soaking time of the fabric play a major role in the adsorption of polypyrrole (PPy) on fiberglass (FG). XPS results showed that the 10 g ferric chloride solution with 6 h of soaking time had the highest degree of protonation (28%) and, therefore, higher adsorption of PPy on FG. A strain range of 30% was achieved by examining different circuitry and sensor designs for their resistance and strain resolution under mechanical loading. A microcontroller was added to the circuit and then embedded within a composite material. This composite system was tested under flexural loading to demonstrate its self-sensing, computing, and actuation capabilities. The resulting cognizant composite demonstrated the ability to read resistance values and measure strain using the embedded microcontroller and autonomously actuate an LED light when the strain exceeds a predefined limit of 2000 µε. The application of the proposed FRP system would provide in situ monitoring of structural composite components with autonomous response capabilities, as well as reduce manufacturing, production, and maintenance costs. Full article

Recently, fiber-reinforced, epoxy-based, optically transparent composites were successfully produced using resin transfer molding (RTM) techniques. Generally, the production of structural, optically transparent composites is challenging since it requires the combination of a very smooth mold surface with a sufficient control of resin flow that leads to no visible voids. Furthermore, it requires a minimum deviation of the refractive indices (RIs) of the matrix polymer and the reinforcement fibers. Here, a new mold design is described and three plates of optically transparent glass fiber-reinforced polymers (tGFRP) with reproducible properties as well as high fiber volume fractions were produced using the RTM process and in situ polymerization of an epoxy resin system enclosing E-glass fiber textiles. Their mechanical (flexural), microstructural (fiber volume fraction, surface roughness, etc.), thermal (DSC, TGA, etc.), and optical (dispersion curves of glass fibers and polymer as well as transmission over visible spectra curves of the tGFRP at varying tempering states) properties were evaluated. The research showed improved surface quality and good transmission data for samples manufactured by a new Optical-RTM setup compared to a standard RTM mold. The maximum transmission was reported to be ≈74%. In addition, no detectable voids were found in these samples. Furthermore, a flexural modulus of 23.49 ± 0.64 GPa was achieved for the Optical-RTM samples having a fiber volume fraction of ≈42%. Full article

We investigate mode coupling in a multimode graded-index microstructured polymer optical fiber (GI mPOF) with a solid core by solving the time-independent power flow equation (TI PFE). Using launch beams with various radial offsets, it is possible to calculate for such an optical fiber the transients of the modal power distribution, the length L_c at which an equilibrium mode distribution (EMD) is reached, and the length z_s for establishing a steady-state distribution (SSD). In contrast to the conventional GI POF, the GI mPOF explored in this study achieves the EMD at a shorter length L_c. The earlier shift to the phase of slower bandwidth decrease would result from the shorter L_c. These results are helpful for the implementation of multimode GI mPOFs as a part of communications and optical fiber sensory systems. Full article

The use of simpler and less bulky equipment, with a reliable performance and at relative low cost is increasingly important when assembling sensing configurations for a wide variety of applications. Based on this concept, this paper proposes a simple, efficient and relative low-cost fiber Bragg grating (FBG) interrogation solution using ultra-short FBGs (USFBGs) as edge filters. USFBGs with different lengths and reflection bandwidths were produced in silica optical fiber and in poly(methyl methacrylate) (PMMA) microstructured polymer optical fiber (mPOF), and by adjusting specific inscription parameters and the diffraction pattern, these gratings can present self-apodization and unique spectral characteristics suitable for filtering operations. In addition to being a cost-effective edge filter solution, USFBGs and standard uniform FBGs in silica fiber have similar thermal sensitivities, which results in a straightforward operation without complex equipment or calculations. This FBG interrogation configuration is also quite promising for dynamic measurements, and due to its multiplexing capabilities multiple USFBGs can be inscribed in the same optical fiber, allowing to incorporate several filters with identical or different spectral characteristics at specific wavelength regions in the same fiber, thus showing great potential to create and develop new sensing configurations. Full article

An innovative optical-chemical sensor has been used to detect the 2-furaldehyde (2-FAL) in milk. The proposed sensing approach exploits the refractive index changing in a microstructured chip based on a plastic optical fiber (POF) with orthogonal micro-holes containing a specific molecularly imprinted polymer (MIP). This POF-MIP chemical chip modifies the surface plasmon resonance (SPR) phenomena excited in another sensor chip realized in POFs (SPR-POF) and connected in series. The proposed sensor configuration exploits MIP receptors avoiding any modification of the gold film of the SPR platform. This work reports the performance, particularly the high sensitivity and low detection limit, in complex matrices such as buffalo milk fortified with 2-FAL and in different commercial kinds of cow milk thermally treated for pasteurization. The measurements were carried out in about ten minutes by dropping the solution under-test on the planar D-shaped POF surface of the chemical chip. In contrast, on the gold surface of the SPR-POF platform, a water drop is always placed to excite the SPR phenomenon, which is modulated by the chemical chip via MIP-2-FAL binding. Furthermore, the experimental results demonstrated the pros and cons of the proposed sensor system. Thanks to the high sensitivity of the sensor system, the detection of 2-FAL in the diluted milk sample (1:50) was achieved. The dilution is required to reduce the interferent effect of the complex matrix. Full article

Recent events involving the rupture of tailings dams in Brazil have motivated the search for alternatives to incorporate the material into the production chain. At the same time, the consumption of raw materials by the civil construction sector is high, requiring the incorporation of alternative materials to achieve sustainable development. Thus, this paper proposes a new construction material based on the mechanical and microstructural behavior of polymer-stabilized and fiber-reinforced gold ore tailings composites. Unconfined Compressive Strength tests were performed on different polymer contents (6% and 9%), dry unit weights (1.7 g/cm³ and 1.8 g/cm³), and curing periods (7 and 28 days), according to 2K Experimental Design. Microstructural tests were performed using X-ray Diffraction, X-ray Fluorescence Spectrometry, Optical Microscopy, Scanning Electron Microscopy, and X-ray Micro-Computed Tomography. The results demonstrate that adding polymer increased tailings’ mechanical behaviors by forming packages with the lamellar particle, which was observed in microstructural tests. The polymeric composites’ brittle behavior was improved using fiber insertion, leading to an increase of the strain energy absorption capacity. The polymer-stabilized and fiber-reinforced gold ore tailings composites demonstrated its potential as a construction material, especially in landfill structures, tailings stockpiles, and paving base layers. The association of mechanical and microstructural analysis established a new understanding of the effect of the stabilizer and the reinforcement. Full article

Metal oxide nanocomposites (MON) have gained significant attention in the literature for the possibility of improving the optical and electronic properties of the hybrid material, compared to its pristine constituent oxides. These superior properties have been observed for TiO₂ — based MON, which exhibit improved structural stability and photoactivity in environmental decontamination processes. In addition, the use of polymer membrane-supported MON is preferable to prevent further aggregation of particles, increase the surface area of the semiconductor in contact with the contaminant, and enable material reuse without considerable efficiency loss. In this work, $\mathrm{V}$⁵⁺-doped ${\mathrm{TiO}}_2/{\mathrm{WO}}_3 \mathrm{MON}$ nanostructures were prepared by the sintering process at 500 °C and supported in electrospun fiber membranes for application as photocatalyst devices. Microstructural characterization of the samples was performed by XRD, SEM, EDS, Raman, and DSC techniques. The reflectance spectra showed that the bandgap of the MON was progressively decreased (3.20 to 2.11 eV) with the V⁵⁺ ions doping level increase. The fiber-supported MON showed photoactivity for rhodamine B dye degradation using visible light. In addition, the highest photodegradation efficiency was noted for the systems with 5 wt% vanadium oxide dispersed in the fibers (92% dye degradation in 120 min of exposure to the light source), with recyclability of the composite material for use in new photocatalysis cycles. The best results are directly related to the microstructure, lower bandgap and aggregation of metal oxide nanocomposite in the electrospun membrane, compared to the support-free MON. Full article

Carbon nanodots (CNDs) are interesting materials due to their intrinsic fluorescence, electron-transfer properties, and low toxicity. Here, we report a sustainable, cheap, and scalable methodology to obtain CNDs from sugarcane syrup using a domestic microwave oven. The CNDs were characterized by infrared spectroscopy, dynamic light scattering, atomic force microscopy, absorption, and emission spectroscopies. The CNDs have 3 nm in diameter with low polydispersity and are fluorescent. A fluorescent hydrogel–CNDs composite was obtained using gelatin polypeptide as the polymeric matrix. The new hydrogel–CNDs composite was incorporated in the cavities of a double-clad optical fiber using an innovative approach that resulted in a microstructured polymer optical fiber with intrinsic fluorescence. This work shows a promising alternative for the fabrication of fluorescent materials since the CNDs synthesis is sustainable and environmentally friendly. These CNDs might substitute the rare-earth and other heavy metals of high cost and toxicity, which are usually incorporated in double-clad fibers for applications on lasers, amplifiers, and spectroscopy. Full article

Additive manufacturing is an emerging technology and provides high design flexibility to customers. Fused deposition modeling (FDM) is an economical and promising additive manufacturing method. Due to its many advantages, FDM received great attention in recent years, and comprehensive studies are being undertaken to investigate the properties of FDM-printed polymers and polymer composites. As a result of the manufacturing technology employed in FDM, inner structures are changed with different process parameters, and thus, anisotropic properties are observed. Moreover, composite filaments such as particle- or fiber-reinforced polymers already have anisotropy before FDM printing. In this study, we investigate the effect of different process parameters, namely layer thickness and raster width on FDM-printed copper-reinforced poly(lactic acid) (PLA). Mechanical characterizations with a high-resolution camera are carried out for analyzing the deformation behaviors. Optical microscopy characterizations are performed to observe the mesostructural changes with various process parameters. Scanning electron microscopy (SEM) and an energy-dispersive X-ray spectroscopy (EDS) analysis are conducted for investigating the microstructure, specifically, copper particles in the PLA matrix. A 2D digital image correlation code with a machine learning algorithm is applied to the optical characterization and SEM-EDS images. In this way, micro- and mesostructural features, as well as the porosity ratios of the specimens are investigated. We prepare the multiscale homogenization by finite element method (FEM) simulations to capture the material’s response, both on a microscale and a mesoscale. We determined that the mesostructure and, thereby, the mechanical properties are significantly changed with the aforementioned process parameters. A lower layer thickness and a greater raster width led to a higher elasticity modulus and ultimate tensile strength (UTS). The optical microscopy analysis verified this statement: Decreasing the layer thickness and increasing the raster width result in larger contact lines between adjacent layers and, hence, lower porosity on the mesoscale. Realistic CAD images were prepared regarding the mesostructural differences and porosity ratios. Ultimately, all these changes are accurately modeled with mesoscale and multiscale simulations. The simulation results are validated by laboratory experiments. Full article

By solving the Langevin equation, mode coupling in a multimode step-index microstructured polymer optical fibers (SI mPOF) with a solid core was investigated. The numerical integration of the Langevin equation was based on the computer-simulated Langevin force. The numerical solution of the Langevin equation corresponded to the previously reported theoretical data. We demonstrated that by solving the Langevin equation (stochastic differential equation), one can successfully treat a mode coupling in multimode SI mPOF as a stochastic process, since it is caused by its intrinsic random perturbations. Thus, the Langevin equation allowed for a stochastic mathematical description of mode coupling in SI mPOF. Regarding the efficiency and execution speed, the Langevin equation was more favorable than the power flow equation. Such knowledge is useful for the use of multimode SI mPOFs for potential sensing and communication applications. Full article

Polymer microtips are 3D microstructures manufactured on the end face of an optical fiber by using the photopolymerization process. Such micro-optic elements made on a multi-mode optical fiber were previously tested as a transducer of refractive index sensor. These studies were an inspiration to investigate the possibility of using this type of transducer to measure the presence of volatile organic compounds in the air. The experimental results of microtips polymerized with UV and VIS were reported. It was possible to detect the presence of five different volatile compounds in the air due to the sensitivity of the transducer to the refractive indices changes. These changes were induced by the vapors condensed on the microtip surface. The measured time responses have shown that the return loss decreases rapidly as the microtip is inserted inside a glass vial filled with the tested compound. Moreover, correlations between calculated dynamic ranges and refractive indices and volumes of the volatile compounds inside the vials were negligible. Therefore, this type of sensor can be categorized as a condensed material threshold sensor. This sensor can be used in warning systems for monitoring leakages of pipelines carrying volatile chemicals. Full article

In this paper we report on the theoretical analysis and fabrication of a dual-core microstructured polymer optical fiber (mPOF) and demonstrate how the coupling characteristics of a dual-core mPOF may be a key factor to assess the quality of the fabrication process. The coupling characteristics of this fiber have been tested and, for comparison purposes, simulations regarding the effects of inaccuracies during the manufacturing process were carried out to evaluate the fabrication quality. Results indicate that theoretical, simulation and experimental data are in good agreement, which highlights the uniformity of the microstructure along the fiber and the quality of its fabrication process. In fact, the manufactured mPOF reached a coupling efficiency up to 95.26%, which makes this mPOF appealing for applications in which highly efficient power couplers are required. Full article
