Hybrid materials based on porous organic polymers (POPs) and metal–organic frameworks (MOFs) are increasing attention for advanced separation processes due to the possibility to combine their properties. POPs provide high surface areas, chemical stability, and tunable porosity, while MOFs contribute a high variety of defined crystalline structures and enhanced separation characteristics. The combination (or hybridization) with PIMs gives rise to mixed-matrix membranes (MMMs) with improved permeability, selectivity, and long-term stability. However, interfacial compatibility remains a key limitation, often addressed through polymer functionalization or controlled dispersion of the MOF phase. MOF/COF hybrids are more used as biochemical sensors with elevated sensitivity, catalytic applications, and wastewater remediation. They are also very well known in the gas sorption and separation field, due to their tunable porosity and high electrical conductivity, which also makes them feasible for energy storage applications. Last but not less important, hybrids with other POPs, such as hyper-crosslinked polymers (HCPs), covalent triazine frameworks (CTFs), or conjugated microporous polymers (CMPs), offer enhanced functionality. MOF/HCP hybrids combine ease of synthesis and chemical robustness with tunable porosity. MOF/CTF hybrids provide superior thermal and chemical stability under harsh conditions, while MOF/CMP hybrids introduce π-conjugation for enhanced conductivity and photocatalytic activity. These and other findings confirm the potential of MOF-POP hybrids as next-generation materials for gas separation and carbon capture applications. Full article

Microporous soluble polymers attract great attention as materials for membrane gas separation, gas storage and transportation, as sorbents, supports for catalysts, and matrices for mixed matrix membranes. The key problems in the development of this area of polymer chemistry include the search for methods of controlling the porous structure parameters and ensuring the stability of their properties over time. In this connection, a fruitful approach is to introduce bulky and rigid, often framework carbocyclic moieties into the polymer backbones and side chains. This review discusses the effect of carbocyclic moieties on gas transport properties, BET surface area, and FFV of glassy polymers, such as polyacetylenes, polynorbornenes, polyimides, and ladder and partially ladder polymers. In the majority of cases, the incorporation of carbocyclic moieties makes it possible to controllably increase these three parameters. Carbocyclic moieties can also improve CO₂/gas separation selectivity, which is displayed for ladder polymers and polynorbornenes. Full article

This study introduces an innovative approach to designing membranes capable of separating CO₂ from industrial gas streams at higher temperatures. The novel membrane design seeks to leverage a well-researched, high-temperature CO₂ adsorbent, hydrotalcite, by transforming it into a membrane. This was achieved by combining it with an amorphous organo-silica-based matrix, extending the polymer-based mixed-matrix membrane concept to inorganic compounds. Following the membrane material preparation and investigation of the individual membrane in Part 1 of this study, we examine its permeation and selectivity here. The pure 200 nm thick hydrotalcite membrane exhibits Knudsen behavior due to large intercrystalline pores. In contrast, the organo-silica membrane demonstrates an ideal selectivity of 13.5 and permeance for CO₂ of 1.3 × 10⁻⁷ mol m⁻² s⁻¹ Pa⁻¹ at 25 °C, and at 150 °C, the selectivity is reduced to 4.3. Combining both components results in a hybrid microstructure, featuring selective surface diffusion in the microporous regions and unselective Knudsen diffusion in the mesoporous regions. Further attempts to bridge both components to form a purely microporous microstructure are outlined. Full article

As the atmospheric carbon dioxide (CO₂) concentration rapidly rises, carbon capture, utilization, and storage (CCUS) is an emerging field for climate change mitigation. Various carbon capture technologies are in development with the help of adsorbents, membranes, solvent-based systems, etc. One of the main challenges in this field is the removal of CO₂ from nitrogen (N₂) gas. This paper focuses on mixed matrix membrane technology, for which the CO₂/N₂ separation performance is based on differences in gas permeations. Membrane separation and purification technologies are widely studied for carbon capture. Microporous adsorbents such as zeolites and metal organic frameworks (MOFs) for carbon capture have been attracting researchers’ attention due to their highly porous structures, high selectivity values, and tunable porosities. Utilizing microporous adsorbents dispersed within a novel, blended polymer matrix, fourteen membranes were prepared with the commercial MOF ZIF-8, zeolite 13X, and kaolin, with methyl cellulose (MC) and polyvinyl alcohol (PVA), which were tested using a single gas permeation setup in this study. The addition of polyallylamine (PAH) as a chemisorbent was also investigated. These membranes were synthesized both with and without a polyacrylonitrile (PAN) support to compare their performances. MC was found to be an ideal polymeric matrix component to develop free-standing MMMs. At 24 °C and a relatively low feed pressure of 2.36 atm, a free-standing zeolite-13X-based membrane (MC/PAH/13X/PVA) exhibited the highest N₂/CO₂ selectivity of 2.8, with a very high N₂ permeability of 6.9 × 10⁷ Barrer. Upon the optimization of active layer thickness and filler weight percentages, this easily fabricated free-standing MMM made of readily available materials is a promising candidate for CO₂ purification through nitrogen removal. Full article

Constructing efficient and continuous transport pathways in membranes is a promising and challenging way to achieve the desired performance in the pervaporation process. The incorporation of various metal–organic frameworks (MOFs) into polymer membranes provided selective and fast transport channels and enhanced the separation performance of polymeric membranes. Particle size and surface properties are strongly related to the random distribution and possible agglomeration of MOFs particles, which may lead to poor connectivity between adjacent MOFs-based nanoparticles and result in low-efficiency molecular transport in the membrane. In this work, ZIF−8 particles with different particle sizes were physically filled into PEG to fabricate mixed matrix membranes (MMMs) for desulfurization via pervaporation. The micro-structures and physi-/chemical properties of different ZIF−8 particles, along with their corresponding MMMs, were systematically characterized by SEM, FT-IR, XRD, BET, etc. It was found that ZIF−8 with different particle sizes showed similar crystalline structures and surface areas, while larger ZIF−8 particles possessed more micro-pores and fewer meso-/macro-pores than did the smaller particles. ZIF−8 showed preferential adsorption for thiophene rather than n−heptane molecules, and the diffusion coefficient of thiophene was larger than that of thiophene in ZIF−8, based on molecular simulation. PEG MMMs with larger ZIF−8 particles showed a higher sulfur enrichment factor, but a lower permeation flux than that found with smaller particles. This might be ascribed to the fact that larger ZIF−8 particles provided more and longer selective transport channels in one single particle. Moreover, the number of ZIF−8−L particles in MMMs was smaller than the number of smaller ones with the same particle loading, which might weaken the connectivity between adjacent ZIF−8−L nanoparticles and result in low-efficiency molecular transport in the membrane. Moreover, the surface area available for mass transport was smaller for MMMs with ZIF−8−L particles due to the smaller specific surface area of the ZIF−8−L particles, which might also result in lower permeability in ZIF−8−L/PEG MMMs. The ZIF−8−L/PEG MMMs exhibited enhanced pervaporation performance, with a sulfur enrichment factor of 22.5 and a permeation flux of 183.2 g/(m⁻²·h⁻¹), increasing by 57% and 389% compared with the results for pure PEG membrane, respectively. The effects of ZIF−8 loading, feed temperature, and concentration on desulfurization performance were also studied. This work might provide some new insights into the effect of particle size on desulfurization performance and the transport mechanism in MMMs. Full article

As a low energy consumption, simple operation and environmentally friendly separation method, membrane separation has attracted extensive attention. Therefore, researchers have designed and synthesized various types of separation membrane, such as metal organic framework (MOF), covalent organic framework (COF), polymer of intrinsic micro-porosity (PIM) and mixed matrix membranes. Some substituted polyacetylenes have distorted structures and formed micropores due to the existence of rigid main chains and substituted side groups, which can be applied to the field of membrane separation. This article mainly introduces the development and application of substituted polyacetylenes in gas separation and liquid separation based on membrane technology. Full article

Copoly(o-hydroxyamide)s (HPA) and copoly(o-hydroxyamide-amide)s (PAA) have been synthesized to be used as continuous phases in mixed matrix membranes (MMMs). These polymeric matrices were blended with different loads (15 and 30 wt.%) of a relatively highly microporous porous polymer network (PPN). SEM images of the manufactured MMMs exhibited good compatibility between the two phases for all the membranes studied, and their mechanical properties have been shown to be good enough even after thermal treatment. The WAX results show that the addition of PPN as a filler up to 30% does not substantially change the intersegmental distance and the polymer packing. It seems that, for all the membranes studied, the free volume that determines gas transport is in the high end of the possible range. This means that gas flow occurs mainly between the microvoids in the polymer matrix around the filler. In general, both HPA- and PAA-based MMMs exhibited a notable improvement in gas permeability, due to the presence of PPN, for all gases tested, with an almost constant selectivity. In summary, although the thermal stability of the PAA is limited by the thermal stability of the polyamide side chain, their mechanical properties were better. The permeability was higher for the PAA membranes before their thermal rearrangement, and these values increased after the addition of moderate amounts of PPN. Full article

Fillers play a critical role in the performance of mixed matrix membranes (MMMs). Microporous metal azolate frameworks (MAFs) are a subclass material of metal–organic frameworks (MOFs). Due to the uncoordinated nitrogen of the organic ligands, MAF-7 (SOD-[Zn(mtz)₂], Hmtz = 3-methyl-1,2,4-triazole, window: d = 0.34 nm) shows excellent CO₂ adsorption performance. In this work, Pebax 1657/MAF-7 MMMs were prepared by a sample solution casting method with MAF-7 particles as fillers for the first time. By means of X-ray diffraction (XRD), scanning electron microscope (SEM), infrared radiation (IR), and thermogravimetry (TG), the compositional and structural properties of the mixed matrix membrane with different filler content were analyzed. The results show that the compatibility of MAF-7 and Pebax is good with a filler content of 5 wt.%. The pure gas testing showed that mixed matrix membrane has a high ideal CO₂/N₂ selectivity of 124.84 together with a better CO₂ permeability of 76.15 Barrer with the optimized filler content of 5 wt.%. The obtained membrane showed 323.04% enhancement in selectivity of CO₂/N₂ and 27.74% increase in the permeability of CO₂ compared to the pristine membrane at 25 °C and 3 bar. The excellent separation performance may be due to the ligands that can afford a Lewis base active site for CO₂ binding with the uniform dispersion of MAF-7 particles in Pebax and the favorable interface compatibility. The obtained membrane overcomes the Robeson’s upper bound in 2008 for CO₂/N₂ separation. This work provides a new strategy by utilizing MAFs as fillers with triazole ligand to enhance the gas separation performance of mixed matrix membranes. Full article

A set of thermally rearranged mixed matrix membranes (TR-MMMs) was manufactured and tested for gas separation. These membranes were obtained through the thermal treatment of a precursor MMM with a microporous polymer network and an o-hydroxypolyamide,(HPA) created through a reaction of 2,2-bis(3-amino-4-hydroxyphenyl)-hexafluoropropane (APAF) and 5′-terbutil-m-terfenilo-3,3″-dicarboxylic acid dichloride (tBTmCl). This HPA was blended with different percentages of a porous polymer network (PPN) filler, which produced gas separation MMMs with enhanced gas permeability but with decreased selectivity. The thermal treatment of these MMMs gave membranes with excellent gas separation properties that did not show the selectivity decreasing trend. It was observed that the use of the PPN load brought about a small decrease in the initial mass losses, which were lower for increasing PPN loads. Regarding the glass transition temperature, it was observed that the use of the filler translated to a slightly lower Tg value. When these MMMs and TR-MMMs were compared with the analogous materials created from the isomeric 5′-terbutil-m-terfenilo-4,4″-dicarboxylic acid dichloride (tBTpCl), the permeability was lower for that of tBTmCl, compared with the one from tBTpCl, although selectivity was quite similar. This fact could be attributed to a lower rigidity as roughly confirmed by the segmental length of the polymer chain as studied by WAXS. A model for FFV calculation was proposed and its predictions compared with those evaluated from density measurements assuming a matrix-filler interaction or ideal independence. It turns out that permeability as a function of FFV for TR-MMMs follows an interaction trend, while those not thermally treated follow the non-interaction trend until relatively high PPN loads were reached. Full article

Mixed matrix membranes (MMMs), derived from three aromatic polyimides (PIs), and an affordable porous organic polymer (POP) having basic bipyridine moieties were prepared. Matrimid and two fluorinated polyimides, which were derived from 4,4′-(hexafluoroisopropylidene)diphthalic anhydride and 2,2′-bis(4-aminophenyl)hexafluoropropane (6F6F) or 2,4,6-trimethyl-m-phenylenediamine (6FTMPD), were employed as polymer matrixes. The used POP was a highly microporous material (surface area of 805 m² g⁻¹) with excellent thermal and chemical stability. The MMMs showed good compatibility between the PIs and POP, high thermal stabilities and glass transition temperatures superior to those of the neat PI membranes, and good mechanical properties. The addition of POP to the matrix led to an increase in the gas diffusivity and, thus, in permeability, which was associated with an increase in the fractional free volume of MMMs. The increase in permeability was higher for the less permeable matrix. For example, at 30 wt.% of POP, the permeability to CO₂ and CH₄ of the MMMs increased by 4- and 7-fold for Matrimid and 3- and 4-fold for 6FTMPD. The highest CH₄ permeability led to a decrease in CO₂/CH₄ selectivity. The CO₂/N₂ separation performance was interesting, as the selectivity remained practically constant. Finally, the POP showed no molecular sieving effect towards the C₂H₄/C₂H₆ and C₃H₆/C₃H₈ gas pairs, but the permeability increased by about 4-fold and the selectivity was close to that of the matrix. In addition, because the POP can form metal ion bipyridine complexes, modified POP-based MMMs could be employed for olefin/paraffin separations. Full article

Studying the effect of different sizes of multi-walled carbon nanotubes (CNTs) on mixed matrix membranes in nanofiltration applications has not been widely reported in the literature. In this study, two different lengths of functionalized CNTs were used to investigate such effect. First, CNTs were shortened by using high-energy ball milling at 400 RPM, with a ball-to-powder weight ratio (BPR) of 120:1. Characterization of the structure of the CNTs was carried out using TEM, XRD, SEM, BET, and Raman Spectroscopy. Second, 0.001 wt % of unmilled and milled CNTs were incorporated into cellulose acetate nanocomposite membranes, Eli-0 (unmilled), and Eli-400 (milled at 400 RPM) to study their effects on the membranes’ morphology, porosity, hydrophilicity, and performance analysis in terms of permeation and salt retention rates of 5000 ppm Na₂SO₄. Results showed that shortening CNTs enhanced the membranes’ hydrophilicity and affected macrovoid and micropore formation. Furthermore, shortening CNTs resulted in opening their caps and improved the permeation rates with a slight adverse effect on salt retention. Full article

In this work, eight different types of optical oxygen sensing films were prepared by impregnating indicator and matrix solution on the surface of a polypropylene microporous filter membrane. The polymer matrix of the sensing films was ethyl cellulose (EC), polymethyl methacrylate (PMMA), and their blends with different mixing ratios. Scanning electron microscopy (SEM), laser confocal microscopy, and fluorescence spectrometer were used to investigate the morphologies and optical properties of the sensing films. Phase delay measurements under different oxygen partial pressures (P_O2) and temperatures were applied to investigate the analytical performances of the sensing film for gaseous O₂ monitoring. Results show that the response time of all the sensing films was extremely fast. The sensitivities and dynamic ranges of the sensing films with the blended polymer matrix were separately decreased and increased as the EC/PMMA ratio decreased, and the S-V curve of the sensing films blended with equal content of EC and PMMA exhibited good linearity under different temperatures, showing a promising prospect in practical application. Full article

To improve the interfacial compatibility of mixed matrix membranes (MMMs) for gas separation, microporous polyimide particle (AP) was designed, synthesized, and introduced into intrinsic microporous polyimide matrix (6FDA-Durene) to form “all polyimide” MMMs. The AP fillers showed the feature of thermal stability, similar density with polyimide matrix, high porosity, high fractional free volume, large microporous dimension, and interpenetrating network architecture. As expected, the excellent interfacial compatibility between 6FDA-Durene and AP without obvious agglomeration even at a high AP loading of 10 wt.% was observed. As a result, the CO₂ permeability coefficient of MMM with AP loading as low as 5 wt.% reaches up to 1291.13 Barrer, which is 2.58 times that of the pristine 6FDA-Durene membrane without the significant sacrificing of ideal selectivity of CO₂/CH₄. The improvement of permeability properties is much better than that of the previously reported MMMs, where high filler content is required to achieve a high permeability increase but usually leads to significant agglomeration or phase separation of fillers. It is believed that the excellent interfacial compatibility between the PI fillers and the PI matrix induce the effective utilization of porosity and free volume of AP fillers during gas transport. Thus, a higher diffusion coefficient of MMMs has been observed than that of the pristine PI membrane. Furthermore, the rigid polyimide fillers also result in the excellent anti-plasticization ability for CO₂. The MMMs with a 10 wt.% AP loading shows a CO₂ plasticization pressure of 300 psi. Full article

A microporous carboxylate metal-organic framework MIL-100 Fe was prepared as submicron particles by microwave-assisted hydrothermal synthesis (Fe-MOF-MW). This product was explored, for the first time, for the preparation of polylactic acid (PLA) mixed matrix membranes. The produced MOF was characterised by powder X-ray diffraction (PXRD), environmental scanning electron microscopy (ESEM) as well as by thermogravimetric analysis (TGA) and nitrogen adsorption/desorption. The effect of different Fe-MOF-MW concentrations (0.1 and 0.5 wt%) on the membrane properties and performance were evaluated. These membranes were used in the pervaporation process for the separation of methanol/methyl tert-butyl-ether mixtures at the azeotropic point. The influence of the feed temperature and vacuum pressure on the membrane performance was evaluated and the results were compared with PLA pristine membranes. Moreover, the produced membranes have been characterised in terms of morphology, MOF dispersion in the polymeric membrane matrix, wettability, thickness, mechanical resistance and swelling propensity. The presence of Fe-MOF-MW was found to have a beneficial effect in improving the selectivity of mixed matrix membranes towards methanol at both concentrations. The highest selectivity was obtained for the PLA membranes embedded with 0.5 wt% of Fe-MOF-MW and tested at the temperature of 25 °C and vacuum pressure of 0.09 mbar. Full article

Development of mixed matrix membranes (MMMs) with excellent permeance and selectivity applied for gas separation has been the focus of world attention. However, preparation of high-quality MMMs still remains a big challenge due to the lack of enough interfacial interaction. Herein, ionic liquid (IL)-modified UiO-66-NH₂ filler was first incorporated into microporous organic polymer material (PIM-1) to prepare dense and defect-free mixed matrix membranes via a coating modification and priming technique. IL [bmim][Tf₂N] not only improves the hydrophobicity of UiO-66-NH₂ and facilitates better dispersion of UiO-66-NH₂ nanoparticles into PIM-1 matrix, but also promotes the affinity between MOFs and polymer, sharply reducing interface non-selective defects of MMMs. By using this strategy, we can not only facilely synthesize high-quality MMMs ignoring non-selective interfacial voids, but also structurally regulate MOF nanoparticles in the polymer substrate and greatly improve interface compatibility and stability of MMMs. The method also gives suitable level of generality for fabrication of versatile defect-free MMMs based on different combination of MOFs and PIMs. The prepared UiO-66-NH₂@IL/PIM-1 membrane exhibited outstanding gas separation behavior with large CO₂ permeation of 8283.4 Barrer and high CO₂/N₂ selectivity of 22.5. Full article
