Search Results (28)

Laminar flow offers significant potential for increasing the energy efficiency of future transport aircraft. At the Cluster of Excellence SE²A—Sustainable and Energy-Efficient Aviation—the laminarization of the wing by means of hybrid laminar flow control (HLFC) is being investigated. The aim is to maintain the boundary layer as laminar for up to 80% of the chord length of the wing. This is achieved by active suction on the leading edge and the rear part of the wing. The suction panels are constructed with a thin micro-perforated skin and a supporting open-cellular core structure. The mechanical requirements for this kind of sandwich structure vary depending on its position of usage. The suction panel on the leading edge must be able to sustain bird strikes, while the suction panel on the rear part must sustain bending loads from the deformation of the wing. The objective of this study was to investigate the energy absorption properties of a triply periodic minimal surface (TPMS) structure that can be used as a bird strike-resistant core in the wing leading edge. To this end, cubic-sheet-based gyroid specimens of different polymeric materials and different geometric dimensions were manufactured using additive manufacturing processes. The specimens were then tested under quasi-static compression and dynamic crushing loading until failure. It was found that the mechanical behavior was dependent on the material, the unit cell size, the relative density, and the loading rate. In general, the weight-specific energy absorption (SEA) at 50% compaction increased with increasing relative density. Polyurethane specimens exhibited an increase in SEA with increasing loading rate, as opposed to the specimens of the other investigated polymers. A smaller unit cell size induced a more consistent energy absorption, due to the higher plateau force. Full article

Hybrid Laminar Flow Control (HLFC) is a promising technology for reducing aircraft drag and, therefore, emissions and fuel consumption. The integration of HLFC systems within the small space of the wing leading edge, together with de-icing and high lift systems, is one of the main challenges of this technology. This challenge can be tackled by using microholes along the outer skin panels to control suction without the need for an internal chamber. However, microperforations modify the mechanical properties of titanium sheets, which bring new challenges in terms of wing manufacturability. These modified properties create uncertainty that must be investigated. The present paper studies the mechanical properties of micro-drilled titanium grade 2 sheets and their modeling using the Finite Element Method (FEM). First, an experimental campaign consisting of tensile and Nakajima tests is conducted. Then, an FEM model is developed to understand the role of the anisotropy in sheet formability. The anisotropy ratios are found by combination of Design of Experiments (DoE) and the Response Surface Method (RSM); these ratios are as follows: 1.050, 1.320, and 0.975 in the directions Y, Z, and XY, respectively. Some mechanical properties are affected by the presence of microholes, especially the elongation and formability that are significantly reduced. The reduction in elongation depends on the orientation: 20% in longitudinal, 17% in diagonal, and 31% in transversal. Full article

This study investigates lightweight and efficient candidates for sound absorption to address the growing demand for sustainable and eco-friendly materials in noise attenuation. Juncus effusus (JE) is a natural fiber known for its unique three-dimensional network, providing a viable and sustainable filler for enhanced sound absorption in honeycomb panels. Microperforated-panel (MPP) honeycomb absorbers incorporating JE fillers were fabricated and designed, focusing on optimizing the absorber designs by varying JE filler densities, geometrical arrangements, and MPP parameters. At optimal filling densities, the MPP-type honeycomb structures filled with JE fibers achieved high noise reduction coefficients (NRC) of 0.5 and 0.7 at 20 mm and 50 mm thicknesses, respectively. Using an analytical model and an artificial neural network (ANN) model, the sound absorption characteristics of these absorbers were successfully predicted. This study demonstrates the potential of JE fibers in improving noise mitigation strategies across different industries, offering more sustainable and efficient solutions for construction and transportation. Full article

Noise pollution is a major threat to the health and well-being of the entire world; this issue forces researchers to find new sound absorption and insulating material. In this paper, the sound absorption coefficient and vibration damping factor of panels manufactured from Cyperus pangorei rottb and ramie fiber reinforced with epoxy resin are explored. Cyperus pangorei rottb grass fiber and ramie fiber are widely available natural fibers. Cyperus pangorei rottb grass fiber is used in mat manufacturing, whereas ramie is widely used as a fabric. Using both of these fibers, six variant panels using a vacuum resin infusion process (VRIP) were fabricated. The panels were named C, R, CR, RCR-Flat, RCR-Curved, and RCR-Perforated. All the panels were tested for the sound absorption coefficient using an impedance tube with a frequency ranging up to 6300 Hz. Modal analysis was carried out by using the impulse hammer excitation method. A micro X-ray computed tomography (CT) scan was used to study the voids present in the panels. The results were compared among the six variants. The results show that the RCR-curved panel had the highest sound-absorbing coefficient of 0.976 at a frequency range between 4500 Hz to 5000 Hz. These panels also showed better natural frequency and damping factors. The presence of internal voids in these panels enhances sound absorption properties. These panels can be used at higher frequencies. Full article

Recently, increased attention has been given to minimize the effects of noise pollution on living beings. The attenuation and manipulation of sound waves with low-frequency components are quite difficult with traditional absorbers due to inherent properties induced by large wavelengths and yet are particularly critical to modern designs. In this study, a parallel arrangement of a coiled-up space cavity and micro-perforated panel (MPP) is considered as the absorber configuration. The coiled-up space consists of a front panel with an orifice and a rigid backing panel enclosing an arch-shaped concentric channel. The entire coiled-up space length is provided with two varying cross-sections. By this arrangement, the sound path is squeezed into a reasonably small volume enabling sound absorption at low frequencies. A thin panel with numerous perforations is the main constituent of MPP. It is backed by an air cavity and terminated by a rigid backing. Here in this configuration, micro perforations are provided on the front panel of the coiled-up space, which ensures simultaneous entry of acoustic waves into the micro-perforations and coiled-up space structure. The absorption characteristics of the present configuration are studied numerically and analytically. The combined structure with parallel combination of coiled-up space and MPP resulted in the abatement of more than 70% of sound in the frequency range of 321 Hz to 853 Hz. The present absorber has only a 5.5 cm thickness, which is subwavelength$\left(\frac{\lambda }{19}\right)$ also. Full article

A challenging issue is currently the design of non-fibrous ultra-thin acoustic absorbers that are able to provide broadband performance in demanding environments. The objective of this study is to compare using simulations and measurements the broadband absorption performance of highly porous micro-capillary plates (MCPs) to that of micro-perforated panels (MPPs) under normal incidence while considering unbacked or backed configurations. MCPs are unusual materials used for sound absorption with micron-sized channels and a high perforation ratio. Impedance-based modeling and Kundt tube experiments show that MCPs with suitable channel diameters have a pure constant resistance that outperforms the acoustic efficiency of MPP absorbers. Unbacked MCPs exhibit a controllable amount of high absorption that can exceed 0.8 over more than five octaves starting from 80 Hz, thereby achieving a highly sub-wavelength absorber. MCPs still provide broadband high absorption when backed by a rigid cavity. Their bandwidth-to-thickness ratio increases toward its causal limit when the cavity depth decreases. A parallel MCP resonant absorber partly backed by closed and open cavities is proposed. Such MCP-based absorbers could serve as short anechoic terminations for the characterization of acoustic materials at low frequencies. Full article

Broadband noise reduction over the low–mid frequency range in the building and transportation sectors requires compact lightweight sound absorbers of a typical subwavelength size. The use of multi-layered, closely spaced (micro-)perforated membranes or panels, if suitably optimized, contributes to these objectives. However, their elasticity or modal behaviors often impede the final acoustical performance of the partition. The objective of this study is to obtain insights into the vibrational effects induced by elastic limp membranes or panel volumetric modes on the optimized sound absorption properties of acoustic fishnets and functionally graded partitions (FGP). The cost-efficient global optimization of the partitions’ frequency-averaged dissipation is achieved using the simulated annealing optimization method, while vibrational effects are included through an impedance translation method. A critical coupling analysis reveals how the membranes or panel vibrations redistribute the locations of the Hole-Cavity resonances, as well as their cross-coupling with the panels’ first volumetric mode. It is found that elastic limp micro-perforated membranes broaden the pass-band of acoustic fishnets, while smoothing out the dissipation ripples over the FGP optimization bandwidth. Moreover, the resonance frequency of the first panels mode sets an upper limit to the broadband optimization of FGPs, up to which a high dissipation, high absorption, and low transmission can be achieved. Full article

The high level of noise in helicopter cabins considerably compromises the comfort and safety of the pilot and passengers. To verify the feasibility and effectiveness of microperforated panel composite sound absorption structures for noise suppression in helicopter cabins, simulation and experimental studies were conducted on a model of a light helicopter cabin. First, three microperforated composite sound absorption structures for the helicopter cabin wall panel were designed. Then, a finite element model of the main gear/body acoustic vibration coupling was established to obtain the target frequencies of the microperforated composite sound absorption structures; the acoustic effect was verified via simulation. Finally, a model helicopter cabin equipped with the three microperforated composite sound absorption structures was built, and a cabin noise test was performed. The test results showed that the combined microperforated panel acoustic structure and microperforated panel–porous material composite structure realized an overall cabin sound pressure level attenuation of 8–10 dB, on average, in a wide frequency range of 500–2000 Hz, with an amplitude of more than 20 dB. The microperforated panel–acoustic supermaterial composite structure achieved low-frequency sound absorption in the frequency range of 300–450 Hz. The sound absorption effect reached 50%, and it also exhibited good noise reduction effects in the middle- and high-frequency bands. Full article

Woven fabric perforation is helpful to be adopted to meet the microstructure requirement of a micro-perforated panel (MPP) absorber. Unlike conventional MPP, the woven fabric micro-perforations are formed by yarn in the x (weft) and y (warp)-directions. Hence, minute holes of the MPP with a diameter of 0.1–0.3 mm or a high perforation ratio are expected to be easily fabricated, while such a specification is difficult to realize on a solid surface, as found in some studies. The study presented here focuses on the use of minute holes in MPP absorbers by woven fabrics and discusses the minute hole properties of woven fabrics and their associated absorption characteristics. Theoretical results by Maa’s model are also used to validate resulting characteristics found from the experimental investigations. It is found that minute holes with around 0.10–0.20 mm diameter have been successfully fabricated by controlling weft yarn density. The woven fabrics are capable of producing half-absorption bandwidth of up to 5000 Hz (>3 octaves), while the peak of the absorption coefficient can be more than 0.8. In addition, varying hole diameter with the order of 10⁻² mm can change the absorption behavior for both peak absorption and absorption bandwidth. Such behavior is confirmed by comparing the results with the theoretical model. This study also indicates that Maa’s model is still applicable for predicting absorption of MPP developed based on woven fabric material. Full article

In this study, we designed a novel hybrid underwater sound-absorbing material of the metastructure that contains a viscoelastic substrate with a microperforated panel. Two types of sound-absorbing metastructures were combined to achieve satisfactory sound absorption performance in the low-frequency range. A homogenized equivalent layer and the integrated transfer matrix method were used to theoretically evaluate the sound absorption performance of the designed nonhomogeneous hybrid metastructure. The theoretical results were then compared with the results obtained using the finite-element method. The designed hybrid sound-absorbing metastructure exhibited two absorption peaks because of its different sound-absorbing mechanisms. The acoustic performance of the developed metastructure is considerably better than that of a traditional sound absorber, and the sound absorption coefficient of the developed metastructure is 0.8 in the frequency range of 3–10 kHz. In addition, an adjustment method for the practical underwater application of the designed metastructure is described in this research. Further studies show that the sound absorption coefficient of the adjusted metastructure still has 0.75 in the frequency range of 3–10 kHz, which indicates that this metastructure has the potential to be used as an underwater sound-absorbing structure. The results of this study can be used as a reference in the design of other novel hybrid underwater sound-absorbing structures. Full article

Acoustic deficiencies due to lack of absorption in indoor spaces may sometime render significant buildings unfit for their purpose, especially the ones used as speech auditoria. This study investigates the potential of designing wideband acoustic absorbers composed of parallel-arranged micro-perforated panels (MPPs), known as efficient absorbers that do not need any other fibrous/porous material to have a high absorptive performance. It aims to integrate architectural trends such as transparency and the use of raw materials with acoustical constraints to ensure optimal indoor acoustic conditions. It proposes a structure composed of four parallel-arranged MPPs, which have been theoretically modelled using the electrical Equivalent Circuit Model (ECM) and implemented on an acrylic prototype using recent techniques such as CNC machining tools. The resulting samples are experimentally analysed for their absorption efficiency through the ISO-10534-2 method in an impedance tube. The results show that the prediction model and the experimental data are in good agreement. Afterward, the investigation focuses on applying the most absorptive MPP structure in a classroom without acoustic treatment through numerical simulations in ODEON 16 Acoustics Software. When the proposed material is installed as a wall panel, the results show an improvement toward optimum values in Reverberation Time (RT30) and Speech Transmission Index (STI). Full article

Recently, dotted-art MPPs have been proposed in which a designed pattern is made with the holes. In such a case, the MPP becomes heterogeneous in general. However, existing theories used for the prediction of the absorption characteristics of MPPs assume homogeneity. Therefore, the elaboration of a method for heterogeneous MPPs needs to be performed. In previous work, the authors proposed a method to predict the absorption characteristics of a heterogeneous MPP by using synthesized impedances of each part with different parameters; this is called the synthetic impedance method (SIM) in the present paper. The SIM can potentially be used for various heterogeneous MPPs; however, its scope of applicability needs to be clarified. Furthermore, in proposing a design concept of dotted-art heterogeneous MPPs, the condition that would make the designed MPPs fall within the scope of the SIM needs to be determined. Therefore, in this study, in order to clarify the scope of the applicability of the SIM, twelve samples are first prepared, and then measured sound absorption characteristics and predicted ones are compared and examined in terms of prediction errors. The results show that there are two conditions that should be met to produce predictable heterogeneous MPPs: (1) holes are distributed over the entire surface of the specimen, and (2) the hole spacing is constant. Considering these conditions, a design concept for a dotted-art heterogeneous MPP is proposed: two types of holes, larger holes for the pattern and smaller holes for the background, should be used to meet the above two conditions. Case studies with nine prototypes show that the SIM can make predictions for dotted-art heterogeneous MPPs fabricated according to the concept described above. Full article

A micro-perforated plate or panel (MPP) is a device used to absorb sound. It consists of a thin flat plate made from several different materials with small holes and a back cavity. Several reported modifications and enhancements to the original design of the MPP acoustic absorber were modified by the holes or the back-cavity shape and sizes following the original idea. The present study attempts to artistically beautify the MPP acoustic absorbers by incorporating dotted arts into the design of MPP. The perforation for micro-perforated panels could be dotted arts with a perforation size smaller than 1 mm for enhanced acoustic absorption performance in the form of various artistic designs. Small LED lights could be placed inside the acoustic chamber to create the color lights emanating from the perforations instead of dots with different colors. Several MPP incorporated artistic designs of dotted patterns were presented and their acoustic absorption performance was analyzed using impedance tube in this paper. Full article

Although the original proposal of microperforated panels by Maa consisted of an array of minute circular holes evenly distributed in a thin plate, other hole geometries have been recently suggested that provide similar absorption curves to those of circular holes. With the arrival of modern machining technologies, such as 3D printing, panels microperforated with slit-shaped holes are being specially considered. Therefore, models able to predict the absorption performance of microperforated panels with variable hole geometry are needed. The aim of this article is to analyze three models for such absorbing systems, namely, the Maa model for circular holes, the Randeberg–Vigran model for slit-shaped holes, and the Equivalent Fluid model for both geometries. The absorption curves predicted for these three models are compared with the measured curves of three panels microperforated with spirally shaped slits. Full article

Micro-perforated panels (MPPs) are one of the most promising alternatives to conventional porous sound-absorbing materials. Traditionally, the theory of the sound absorption properties of MPPs is based on the assumption that MPPs are a homogeneous material with identical pores at regular intervals. However, in recent years, some MPPs have not met these conditions, and although a variety of designs have been created, their properties and prediction methods were studied in only fewer works. In this paper, considering the wide variety of MPP designs, we made a trial production of heterogeneous MPPs, which are MPPs with holes of different diameters, and studied the prediction method applicable to these MPPs. We measured the normal incidence sound absorption characteristics of those MPPs, backed by a rigid backing and air-cavity in-between, in an impedance tube. The prediction method proposed in this work is to treat the heterogeneous MPPs as combinations of several homogeneous components, and to combine them after applying the existing theory on homogeneous MPPs to each component. As a result, except in a few cases, the measured and predicted values of the absorption properties agreed relatively well. We also found that the arrangement of the holes in the material and the depth of the back cavity affected the agreement between the measured and predicted results. Full article
