Search Results (51)

Speech recognition in noisy environments has long posed a challenge. Air conduction microphone (ACM), the devices typically used, are susceptible to environmental noise. In this work, a customized bone conduction microphone (BCM) system based on a piezoelectric micromachined ultrasonic transducer is developed to capture speech through real-time bone conduction (BC), while a commercial ACM is integrated for simultaneous capture of speech through air conduction (AC). The system enables simpler and more robust BC speech capture. The BC speech capture achieves a signal-to-noise amplitude ratio over five times greater than that of AC speech capture in an environment with a noise level of 68 dB. Instead of using only AC-captured speech, both BC- and AC-captured speech are input into a speech enhancement module. The noise-insensitive BC-captured speech serves as a speech reference to adapt the SE backbone of AC-captured speech. The two types of speech are fused, and noise suppression is applied to generate enhanced speech. Compared with the original noisy speech, the enhanced speech achieves a character error rate reduction of over 20%, approaching the speech recognition accuracy of clean speech. The results indicate that this speech enhancement method based on the fusion of BC- and AC-captured speech efficiently integrates the features of both types of speech, thereby improving speech recognition accuracy in noisy environments. This work presents an innovative system designed to efficiently capture BC speech and enhance speech recognition in noisy environments. Full article

The development of a universal method for real-time gas leak localisation imaging is crucial for preventing substantial financial losses and hazardous incidents. To achieve this objective, this study integrates array signal processing and electronic techniques to construct an ultrasonic sensor array for gas leak detection and localisation. A digital microelectromechanical system microphone array is used to capture spatial ultrasonic information. By processing the array signals using beamforming algorithms, an acoustic spatial power spectrum is obtained, which facilitates the estimation of the locations of potential gas leak sources. In the pre-processing of beamforming, the Hilbert transform is employed instead of the fast Fourier transform to save computational resources. Subsequently, the spatial power spectrum is fused with visible-light images to generate acoustic localisation images, which enables the visualisation of gas leak sources. Experimental validation demonstrates that the system detects minor and multiple gas leaks in real time, meeting the sensitivity and accuracy requirements of embedded industrial applications. These findings contribute to the development of practical, cost-effective, and scalable gas leak detection systems for industrial and environmental safety applications. Full article

The calibration of Micro-Electro-Mechanical System (MEMS) microphones remains a critical challenge due to their miniaturized geometry and sensitivity to non-uniform acoustic fields. This study presents an advanced calibration methodology that integrates Finite Element Method (FEM) simulations with experimental corrections to improve the accuracy of pressure comparison calibrations using active couplers. A key innovation is the incorporation of asymmetric acoustic field analysis, which systematically quantifies and corrects discrepancies arising from cavity geometry, sensor positioning, and resonance effects peculiar of MEMS microphones. The proposed approach significantly reduces measurement uncertainties, especially in the high-frequency range above 5 kHz, where standard calibration techniques face challenges in taking into account localized pressure variations. Furthermore, the implementation of a measurement set-up, which includes the insert voltage technique, allows for an accurate assessment of the preamplifier gain and minimizes systematic errors. Experimental validation shows that the refined calibration methodology produces highly reliable correction values, ensuring a robust performance over a wide frequency range (20 Hz–20 kHz). These advances establish a rigorous framework for standardizing the calibration of MEMS microphones, strengthening their applicability in acoustic monitoring, sound source localization, and environmental sensing. Full article

Background/Objectives: Respiratory diseases are common and result in high mortality, especially in the elderly, with pneumonia and chronic obstructive pulmonary disease (COPD). Auscultation of lung sounds using a stethoscope is a crucial method for diagnosis, but it may require specialized training and the involvement of pulmonologists. This study aims to assist medical professionals who are non-pulmonologist doctors in early screening for pneumonia and COPD by developing a smart stethoscope with cloud server-embedded machine learning to diagnose lung sounds. Methods: The smart stethoscope was developed using a Micro-Electro-Mechanical system (MEMS) microphone to record lung sounds in the mobile application and then send them wirelessly to a cloud server for real-time machine learning classification. Results: The model of the smart stethoscope classifies lung sounds into four categories: normal, pneumonia, COPD, and other respiratory diseases. It achieved an accuracy of 89%, a sensitivity of 89.75%, and a specificity of 95%. In addition, testing with healthy volunteers yielded an accuracy of 80% in distinguishing normal and diseased lungs. Moreover, the performance comparison between the smart stethoscope and two commercial auscultation stethoscopes showed comparable sound quality and loudness results. Conclusions: The smart stethoscope holds great promise for improving healthcare delivery in the post-COVID-19 era, offering the probability of the most likely respiratory conditions for early diagnosis of pneumonia, COPD, and other respiratory diseases. Its user-friendly design and machine learning capabilities provide a valuable resource for non-pulmonologist doctors by delivering timely, evidence-based diagnoses, aiding treatment decisions, and paving the way for more accessible respiratory care. Full article

Different microstructures significantly affect the acoustic performance of MEMS capacitive microphones, particularly in key specifications of interest. This paper presents several microstructures, including rib-reinforced backplates, suspended diaphragms, and outer vent holes. Three MEMS microphone designs were implemented to analyze the impact of these microstructures. Equivalent circuit models corresponding to each design were constructed to simulate specifications such as sensitivity, signal-to-noise ratio (SNR), and low corner frequency (LCF), which were validated through experimental measurements. Finite Element Analysis (FEA) was also employed to calculate the acoustic damping of certain microstructures, the mechanical lumped parameters of the diaphragm, and the pre-deformation of the MEMS structure. A compressed air test (CAT) was conducted to evaluate the mechanical reliability of microphone samples. The results of simulations and measurements indicate that rib-reinforced backplates effectively improve microphone reliability, increasing the pass rate in CAT. Compared to fully clamped diaphragms, suspended diaphragms exhibit higher mechanical compliance, which enhances SNR performance but reduces AOP. Outer vent holes can achieve similar functionality to diaphragm vent holes, but their impact on improving AOP requires further design and testing. Full article

This paper presents a comprehensive review of cardiorespiratory auscultation sensing devices (i.e., stethoscopes), which is useful for understanding the theoretical aspects and practical design notes. In this paper, we first introduce the acoustic properties of the heart and lungs, as well as a brief history of stethoscope evolution. Then, we discuss the basic concept of electret condenser microphones (ECMs) and a stethoscope based on them. Then, we discuss the microelectromechanical systems (MEMSs) technology, particularly focusing on piezoelectric transducer sensors. This paper comprehensively reviews sensing technologies for cardiorespiratory auscultation, emphasizing MEMS-based wearable designs in the past decade. To our knowledge, this is the first paper to summarize ECM and MEMS applications for heart and lung sound analysis. Full article

Quartz-Enhanced Photoacoustic Spectroscopy (QEPAS) is a technique in which the sound wave is detected by a quartz tuning fork (QTF). It enables particularly high specificity with respect to the excitation frequency and is well known for an extraordinarily sensitive analysis of gaseous samples. We have developed the first photoacoustic (PA) cell for QEPAS on solid samples. Periodic heating of the sample is excited by modulated light from an interband cascade laser (ICL) in the infrared region. The cell represents a half-open cylinder that exhibits an acoustical resonance frequency equal to that of the QTF and, therefore, additionally amplifies the PA signal. The antinode of the sound pressure of the first longitudinal overtone can be accessed by the sound detector. A 3D finite element (FE) simulation confirms the optimal dimensions of the new cylindrical cell with the given QTF resonance frequency. An experimental verification is performed with an ultrasound micro-electromechanical system (MEMS) microphone. The presented frequency-dependent QEPAS measurement exhibits a low noise signal with a high-quality factor. The QEPAS-based investigation of three different solid synthetics resulted in a linearly dependent signal with respect to the absorption. Full article

A photoacoustic sensor system (PAS) intended for carbon dioxide (CO₂) blood gas detection is presented. The development focuses on a photoacoustic (PA) sensor based on the so-called two-chamber principle, i.e., comprising a measuring cell and a detection chamber. The aim is the reliable continuous monitoring of transcutaneous CO₂ values, which is very important, for example, in intensive care unit patient monitoring. An infrared light-emitting diode (LED) with an emission peak wavelength at 4.3 µm was used as a light source. A micro-electro-mechanical system (MEMS) microphone and the target gas CO₂ are inside a hermetically sealed detection chamber for selective target gas detection. Based on conducted simulations and measurement results in a laboratory setup, a miniaturized PA CO₂ sensor with an absorption path length of 2.0 mm and a diameter of 3.0 mm was developed for the investigation of cross-sensitivities, detection limit, and signal stability and was compared to a commercial infrared CO₂ sensor with a similar measurement range. The achieved detection limit of the presented PA CO₂ sensor during laboratory tests is 1 vol. % CO₂. Compared to the commercial sensor, our PA sensor showed less influences of humidity and oxygen on the detected signal and a faster response and recovery time. Finally, the developed sensor system was fixed to the skin of a test person, and an arterialization time of 181 min could be determined. Full article

This paper presents a compact Micro-Electro-Mechanical System (MEMS) microphone digital readout system. The system is characterized by a low-dropout regulator (LDO) and a pre-amplifier and programmable-gain amplifier (PPA)-less voltage controlled oscillator (VCO)-based $\Delta$$\Sigma$ modulation technique, which improve compactness and design scalability. Specifically, to improve signal accuracy and maintain loop stability without a gain-tuning range trade-off, an active low pass filter (ALPF) and a current mode feed-forward path (CMFFP) are incorporated in a VCO-based delta-sigma modulation loop. By means of VCOs and SCG phase variation robustness and current source array feedback (CSAFB), the system achieves a high power supply rejection ratio (PSRR) and gain tuning without the need to design an extra regulator and PPA. The design was fabricated using a 180 nm Bipolar-CMOS-DMOS (BCD) process and measured at a 1.2 V supply voltage. According to the measurement results, the signal-to-noise and distortion ratio (SNDR) achieves 62 dB@1 kHz with 40 dB gain and a 10 kHz bandwidth. Furthermore, PSRR@1 kHz is below −55 dB, and power dissipation is within 57 µW. Full article

This paper presents comprehensive guidelines for the design and analysis of a thin diaphragm that is used in a variety of microsystems, including microphones and pressure sensors. It highlights the empirical relations that can be utilized for the design of thin diaphragm-based microsystems (TDMS). Design guidelines developed through a Finite Element Analysis (FEA) limit the iterative efforts to fabricate TDMS. These design guidelines are validated analytically, with the assumption that the material properties are isotropic, and the deviation from anisotropic material is calculated. In the FEA simulations, a large deflection theory is taken into account to incorporate nonlinearity, such that a critical dimensional ratio of $a/h$ or $2r/h$ can be decided to have the linear response of a thin diaphragm. The observed differences of 12% in the deflection and 13% in the induced stresses from the analytical calculations are attributed to the anisotropic material consideration in the FEA model. It suggests that, up to a critical ratio ($a/h$ or $2r/h$), the thin diaphragm shows a linear relationship with a high sensitivity. The study also presents a few empirical relations to finalize the geometrical parameters of the thin diaphragm in terms of its edge length or radius and thickness. Utilizing the critical ratio calculated in the static FEA analysis, the basic conventional geometries are considered for harmonic analyses to understand the frequency response of the thin diaphragms, which is a primary sensing element for microphone applications and many more. This work provides a solution to microelectromechanical system (MEMS) developers for reducing cost and time while conceptualizing TDMS designs. Full article

Nowadays, sensors with built-in sigma–delta modulators (ΣΔMs) are widely used in consumer, industrial, automotive, and medical applications, as they have become a cost-effective and convenient way to deliver data to digital processors. This is the case for micro-electro-mechanical system (MEMS), digital microphones that convert analog audio to a pulse-density modulated (PDM) bitstream. However, as the ΣΔMs output a PDM signal, sensors require either built-in or external high-order decimation filters to demodulate the PDM signal to a baseband multi-bit pulse-code modulated (PCM) signal. Because of this extra circuit requirement, the implementation of sensor array algorithms, such as beamforming in embedded systems (where the processing resources are critical) or in very large-scale integration (VLSI) circuits (where the power and area are crucial) becomes especially expensive as a large number of parallel decimation filters are required. This article proposes a novel architecture for beamforming algorithm implementation that fuses delay and decimation operations based on maximally flat (MAXFLAT) filters to make array processing more affordable. As proof of concept, we present an implementation example of a delay-and-sum (DAS) beamformer at given spatial and frequency requirements using this novel approach. Under these specifications, the proposed architecture requires 52% lower storage resources and 19% lower computational resources than the most efficient state-of-the-art architecture. Full article

A prototype optical bionic microphone with a dual-channel Mach–Zehnder interferometric (MZI) transducer was designed and prepared for the first time using a silicon diaphragm made by microelectromechanical system (MEMS) technology. The MEMS diaphragm mimicked the structure of the fly Ormia Ochracea’s coupling eardrum, consisting of two square wings connected through a neck that is anchored via the two torsional beams to the silicon pedestal. The vibrational displacement of each wing at its distal edge relative to the silicon pedestal is detected with one channel of the dual-channel MZI transducer. The diaphragm at rest is coplanar with the silicon pedestal, resulting in an initial phase difference of zero for each channel of the dual-channel MZI transducer and consequently offering the microphone strong temperature robustness. The two channels of the prototype microphone show good consistency in their responses to incident sound signals; they have the rocking and bending resonance frequencies of 482 Hz and 1911 Hz, and their pressure sensitivities at a lower frequency exhibit an “8”-shaped directional dependence. The comparison indicates that the dual-channel MZI transducer-based bionic microphone proposed in this work is advantageous over the Fabry–Perot interferometric transducer-based counterparts extensively reported. Full article

In recent years, Micro-Electro-Mechanical Systems (MEMS) technology has had an impressive impact in the field of acoustic transducers, allowing the development of smart, low-cost, and compact audio systems that are employed in a wide variety of highly topical applications (consumer devices, medical equipment, automotive systems, and many more). This review, besides analyzing the main integrated sound transduction principles typically exploited, surveys the current State-of-the-Art scenario, presenting the recent performance advances and trends of MEMS microphones and speakers. In addition, the interface Integrated Circuits (ICs) needed to properly read the sensed signals or, on the other hand, to drive the actuation structures are addressed with the aim of offering a complete overview of the currently adopted solutions. Full article

Can ordinary Micro-Electro-Mechanical-Systems (MEMS) microphones be used for near-ultrasonic applications? Manufacturers often provide little information about the signal-to-noise ratio (SNR) in the ultrasound (US) range and, if they do, the data are often determined in a manufacturer-specific manner and are generally not comparable. Here, four different air-based microphones from three different manufacturers are compared with respect to their transfer functions and noise floor. The deconvolution of an exponential sweep and a traditional calculation of the SNR are used. The equipment and methods used are specified, which makes it easy to repeat or expand the investigation. The SNR of MEMS microphones in the near US range is mainly affected by resonance effects. These can be matched for applications with low-level signals and background noise such that the highest possible SNR can be achieved. Two MEMS microphones from Knowles performed best for the frequency range from 20 to 70 kHz; above 70 kHz, an Infineon model delivered the best performance. Full article

Research has shown that pulse transit time (PTT), which is the time delay between the electrocardiogram (ECG) signal and the signal from a photoplethysmogram (PPG) sensor, can be used to estimate systolic blood pressure (SBP) and diastolic blood pressure (DBP) without the need for a cuff. However, the LED of the PPG sensor requires the precise adjustment of both light intensity and light absorption rates according to the contact status of the light-receiving element. This results in the need for regular calibration. In this study, we propose a cuffless blood pressure monitor that measures real-time blood pressure using a microphone instead of a PPG sensor. The blood pulse wave is measured in the radial artery of the wrist using a microphone that can directly measure the sound generated by a body rather than sending energy inside the body and receiving a returning signal. Our blood pressure monitor uses the PTT between the R-peak of the ECG signal and two feature points of the blood pulse wave in the radial artery of the wrist. ECG electrodes and circuits were fabricated, and a commercial microelectromechanical system (MEMS) microphone was used as the microphone to measure blood pulses. The peak points of the blood pulse from the microphone were clear, so the estimated SBP and DBP could be obtained from each ECG pulse in real time, and the resulting estimations were similar to those made by a commercial cuff blood pressure monitor. Since neither the ECG electrodes nor the microphone requires calibration over time, the real-time cuffless blood pressure monitor does not require calibration. Using the developed device, blood pressure was measured three times daily for five days, and the mean absolute error (MAE) and standard deviation (SD) of the SBP and DBP were found to be 2.72 ± 3.42 mmHg and 2.29 ± 3.53 mmHg, respectively. As a preliminary study for proof-of-concept, these results were obtained from one subject. The next step will be a pilot study on a large number of subjects. Full article
