Touch is a crucial sense for advanced organisms, particularly humans, as it provides essential information about the shape, size, and texture of contacting objects. In robotics and automation, the integration of tactile sensors has become increasingly relevant, enabling devices to properly interact with their environment. This study aimed to develop a biomimetic, skin-inspired tactile sensor device capable of sensing applied force, characterizing it in three dimensions, and determining the point of application. The device was designed as a 4 × 4 matrix of tunneling magnetoresistive sensors, which provide a higher sensitivity in comparison to the ones based on the Hall effect, the current standard in tactile sensors. These detect magnetic field changes along a single axis, wire-bonded to a PCB and encapsulated in epoxy. This sensing array detects the magnetic field from an overlayed magnetorheological elastomer composed of Ecoflex and 5 µm neodymium–iron–boron ferromagnetic particles. Structural integrity tests showed that the device could withstand forces above 100 N, with an epoxy coverage of 0.12 mL per sensor chip. A 3D movement stage equipped with an indenting tip and force sensor was used to collect device data, which was then used to train neural network models to predict the contact location and 3D magnitude of the applied force. The magnitude-sensing model was trained on 31,260 data points, being able to accurately characterize force with a mean absolute error ranging between 0.07 and 0.17 N. The spatial sensitivity model was trained on 171,008 points and achieved a mean absolute error of 0.26 mm when predicting the location of applied force within a sensitive area of 25.5 mm × 25.5 mm using sensors spaced 4.5 mm apart. For points outside the testing range, the mean absolute error was 0.63 mm. Full article

Vibration sensors are important in many engineering fields, including industry, surgery, space, and mechanics, such as for remote and autonomous driving. We propose a novel, cutting-edge vibratory sensor that mimics human tactile receptors, with a configuration different from current sensors such as strain gauges and piezo materials. The basic principle involves the perception of vibration via touch, with a cutaneous mechanoreceptor that is sensitive to vibration. We investigated the characteristics of the proposed vibratory sensor, in which the mechanoreceptor was covered either in hard rubber (such as silicon oil) or soft rubber (such as urethane), for both low- and high-frequency ranges. The fabricated sensor is based on piezoelectricity with a built-in voltage. It senses applied vibration by means of hairs in the sensor and the hardness of the outer cover. We also investigated two proposed parameters: the sensor response time to stimuli to the vibration aiding the equivalent firing rate (e.f.r.) and the gauge factor (GF_,pe) proposed as treated in piezo-resistivity. The evaluation with the parameters was effective in designing a sensor based on piezoelectricity. These parameters were enhanced by the hairs in the sensor and the hardness of the outer cover. Our results were helpful for designing the present novel vibratory sensor. Full article

Flexible magnetic tactile sensors hold transformative potential in robotics and human–computer interactions by enabling precise force detection. However, existing sensors face challenges in balancing sensitivity, detection range, and structural adaptability for sensing force. This study proposed a pre-compressed magnetization method to address these limitations by amplifying the magnetoelastic effect through optimized magnetization direction distribution of the elastomer. A body-centered cubic lattice-structured magnetoelastomer featuring regular deformation under compression was fabricated via digital light processing (DLP) to validate this method. Finite element simulations and experimental analyses revealed that magnetizing the material under 60% compression strain optimized magnetization direction distribution, enhancing force–magnetic coupling. Integrating the magnetic elastomer with a hall sensor, the prepared tactile sensor demonstrated a low detection limit (1 mN), wide detection range (0.001–10 N), rapid response/recovery times (40 ms/50 ms), and durability (>1500 cycles). By using machine learning, the sensor enabled accurate 3D force prediction. Full article

Soft transportation devices with high flexibility, good stability, and quick controllability have attracted increasing attention. However, a smart soft transportation device with tactile perception and a non-contact actuating mode remains a challenge. This work reports a magnetic soft pipeline (MSP) composed of sensor film, a magnetorheological elastomer (MRE) cavity pipeline, and heater film, which can not only respond well to tactile compression stimuli but also be transported by magnetic actuation. Notably, the sensor film was integrated on the upper surface of an MRE pipeline, and the relative resistance change (∆R/R₀) of the MSP was maintained at 55.8% under 2.2 mm compression displacement during 4000 loading cycles. Moreover, the heater film was integrated on the lower surface of the MRE pipeline, which endows the MSP with an electrothermal heating characteristic. The temperature of the MSP can be increased from 26.7 °C to 38.1 °C within 1 min under 0.6 V. Furthermore, the MSP was attracted and deformed under the magnetic field, and the ∆R/R₀ of the MSP reached 69.1% under application of a 165 mT magnetic field density. Benefiting from the excellent perception and magnetic deformation performances, the magnetic actuate transportation of the MSP with self-sensing was successfully achieved. This multi-functional soft pipeline integrated with in situ self-sensing, electrothermal heating, and non-contact magnetic actuating transportation performance possess high potential in smart flexible electronic devices. Full article

This paper comprehensively reviews sensors and sensing devices developed or/and proposed so far utilizing two smart materials: electrorheological fluids (ERFs) and magnetorheological materials (MRMs) whose rheological characteristics such as stiffness and damping can be controlled by external stimuli; an electrical voltage for ERFs and a magnetic field for MRMs, respectively. In this review article, the MRMs are classified into magnetorheological fluids (MRF), magnetorheological elastomers (MRE) and magnetorheological plastomers (MRP). To easily understand the history of sensing research using these two smart materials, the order of this review article is organized in a chronological manner of ERF sensors, MRF sensors, MRE sensors and MRP sensors. Among many sensors fabricated from each smart material, one or two sensors or sensing devices are adopted to discuss the sensing configuration, working principle and specifications such as accuracy and sensitivity. Some sensors adopted in this article include force sensors, tactile devices, strain sensors, wearable bending sensors, magnetometers, display devices and flux measurement sensors. After briefly describing what has been reviewed in a conclusion, several challenging future works, which should be undertaken for the practical applications of sensors or/and sensing devices, are discussed in terms of response time and new technologies integrating with artificial intelligence neural networks in which several parameters affecting the sensor signals can be precisely and optimally tuned. It is sure that this review article is very helpful to potential readers who are interested in creative sensors using not only the proposed smart materials but also different types of smart materials such as shape memory alloys and active polymers. Full article

The design of arrays of anisotropic magnetoresistive (AMR) sensors capable of detecting and reconstructing the 3D motion of a permanent magnet, and thus, suitable for the development of a 3D magnetic tactile sensor, is reported. The proposed structure allows for probing the 3D magnet displacements—and, hence, to infer the three components of the applied force—via a purely planar arrangement of monolithically microfabricated AMR sensors. The concept presented here also holds potential for the realization of a wide spectrum of easy-to-fabricate, miniaturized and low-cost sensors suitable for the detection of a broad variety of physical observables. Full article

Tactile sensory organs for three-dimensional (3D) force perception are essential for most living organisms and enable them to perform complex and sophisticated tasks to survive and evolve. Magnetic-based tactile sensors have been developed rapidly in recent years due to the exploitability of 3D force decoupling. Here, a method of magnet splicing is introduced, which can be applied to a magnetic tactile sensor to realize 3D self-decoupling of magnets’ displacements. This method enables the magnets to produce a completely consistent magnetic field distribution as the ideal magnetization model within a certain working range, eliminating the compensation and correction of the 3D magnetic flux density signal. This method carves out a new way for the practical application of 3D decoupling theory, showcasing the great potential in the fields of magnetic sensors and magnetic actuators. Full article

It is well known that the rheological properties of magnetorheological (MR) material change under a magnetic field. So far, most works on MR materials have been oriented toward actuating characteristics instead of sensing functions. In this work, to realize dynamic tactile motion, a spherical MR structure was designed as a sensor, incorporating a magnetic circuit core to provide maximum dynamic motion. After manufacturing a prototype (sample), a sinusoidal magnetic field of varying exciting frequency and magnitude was applied to the sample, and the dynamic contraction and relaxation motion depending on the exciting magnetic field was observed. Among the test results, when 10% deformation occurred, the instantaneous force generated was from 2.8 N to 8.8 N, and the force when relaxed was from 1.2 N to 3.5 N. It is also shown that the repulsive force within this range can be implemented using an acceptable input current. The special tactile sensing structure proposed in this work can be used as a sensor to measure the field-dependent viscoelastic properties of human tissues such as stomach, liver, and overall body. In addition, it could be usefully applied to robot surgery, because it can mimic the dynamic motions of various human organs under various surgical conditions. Full article

The sorting and processing of food raw materials is an important step in the food production process, and the quality of the sorting operation can directly or indirectly affect the quality of the product. In order to improve production efficiency and reduce damage to food raw materials, some food production enterprises currently use robots for sorting operations of food raw materials. In the process of robot grasping, some food raw materials such as fruits, vegetables and meat have a soft appearance, complex and changeable shape, and are easily damaged by the robot gripper. Therefore, higher requirements have been put forward for robot grippers, and the research and development of robot grippers that can reduce damage to food raw materials and ensure stable grasping has been a major focus. In addition, in order to grasp food raw materials with various shapes and sizes with low damage, a variety of sensors and control strategies are required. Based on this, this paper summarizes the low damage grasp principle and characteristics of electric grippers, pneumatic grippers, vacuum grippers and magnetic grippers used in automated sorting production lines of fruit, vegetable and meat products, as well as gripper design methods to reduce grasp damage. Then, a grasping control strategy based on visual sensors and tactile sensors was introduced. Finally, the challenges and potential future trends faced by food robot grippers were summarized. Full article

Over the past few decades, tactile sensors have become an emerging field of research with direct applications in the area of biomedical engineering. New types of tactile sensors, called magneto-tactile sensors, have recently been developed. The aim of our work was to create a low-cost composite whose electrical conductivity depends on mechanical compressions that can be finely tuned using a magnetic field for magneto-tactile sensor fabrication. For this purpose, 100% cotton fabric was impregnated with a magnetic liquid (EFH-1 type) based on light mineral oil and magnetite particles. The new composite was used to manufacture an electrical device. With the experimental installation described in this study, we measured the electrical resistance of an electrical device placed in a magnetic field in the absence or presence of uniform compressions. The effect of uniform compressions and the magnetic field was the induction of mechanical–magneto–elastic deformations and, as a result, variations in electrical conductivity. In a magnetic field with a flux density of 390 mT, in the absence of mechanical compression forces, a magnetic pressure of 5.36 kPa was generated, and the electrical conductivity increased by 400% compared to that of the composite in the absence of a magnetic field. Upon increasing the compression force to 9 N, in the absence of a magnetic field, the electrical conductivity increased by about 300% compared to that of the device in the absence of compression forces and a magnetic field. In the presence of a magnetic flux density of 390 mT, and when the compression force increased from 3 N to 9 N, the electrical conductivity increased by 2800%. These results suggest the new composite is a promising material for magneto-tactile sensors. Full article

The anatomical complexity of brachial plexus injury requires specialized in-depth diagnostics. The clinical examination should include clinical neurophysiology tests, especially with reference to the proximal part, with innovative devices used as sources of precise functional diagnostics. However, the principles and clinical usefulness of this technique are not fully described. The aim of this study was to reinvestigate the clinical usefulness of motor evoked potential (MEP) induced by a magnetic field applied over the vertebrae and at Erb’s point to assess the neural transmission of brachial plexus motor fibers. Seventy-five volunteer subjects were randomly chosen to participate in the research. The clinical studies included an evaluation of the upper extremity sensory perception in dermatomes C5–C8 based on von Frey’s tactile monofilament method, and proximal and distal muscle strength by Lovett’s scale. Finally, 42 healthy people met the inclusion criteria. Magnetic and electrical stimuli were applied to assess the motor function of the peripheral nerves of the upper extremity and magnetic stimulus was applied to study the neural transmission from the C5–C8 spinal roots. The parameters of compound muscle action potential (CMAP) recorded during electroneurography and MEP induced by magnetic stimulation were analyzed. Because the conduction parameters for the groups of women and men were comparable, the final statistical analysis covered 84 tests. The parameters of the potentials generated by electrical stimulus were comparable to those of the potentials induced by magnetic impulse at Erb’s point. The amplitude of the CMAP was significantly higher following electrical stimulation than that of the MEP following magnetic stimulation for all the examined nerves, in the range of 3–7%. The differences in the potential latency values evaluated in CMAP and MEP did not exceed 5%. The results show a significantly higher amplitude of potentials after stimulation of the cervical roots compared to potentials evoked at Erb’s point (C5, C6 level). At the C8 level, the amplitude was lower than the potentials evoked at Erb’s point, varying in the range of 9–16%. We conclude that magnetic field stimulation enables the recording of the supramaximal potential, similar to that evoked by an electric impulse, which is a novel result. Both types of excitation can be used interchangeably during an examination, which is essential for clinical application. Magnetic stimulation was painless in comparison with electrical stimulation according to the results of a pain visual analog scale (3 vs. 5.5 on average). MEP studies with advanced sensor technology allow evaluation of the proximal part of the peripheral motor pathway (between the cervical root level and Erb’s point, and via trunks of the brachial plexus to the target muscles) following the application of stimulus over the vertebrae. Full article

In this paper, we report the preparation of two new composite materials based on cotton fibers and magnetic liquid consisting of magnetite nanoparticles and light mineral oil. Using the composites and two simple textolite plates plated with copper foil assembled with self-adhesive tape, electrical devices are manufactured. By using an original experimental setup, we measured the electrical capacitance and the loss tangent in a medium-frequency electric field superimposed on a magnetic field. We found that in the presence of the magnetic field, the electrical capacity and the electrical resistance of the device change significantly with the increase of the magnetic field, then, the electrical device is suitable to be used as a magnetic sensor. Furthermore, the electrical response functions of the sensor, for fixed values of the magnetic flux density, change linearly with the increase in the value of the mechanical deformation stress, which gives it a tactile function. When applying mechanical stresses of fixed values, by increasing the value of the magnetic flux density, the capacitive and resistive functions of the electrical device change significantly. So, by using the external magnetic field, the sensitivity of the magneto-tactile sensor increases, therefore the electrical response of this device can be amplified in the case of low values of mechanical tension. This makes the new composites promising candidates for the fabrication of magneto-tactile sensors. Full article

The manipulation of delicate objects remains a key challenge in the development of industrial robotic grippers. Magnetic force sensing solutions, which provide the required sense of touch, have been demonstrated in previous work. The sensors feature a magnet embedded within a deformable elastomer, which is mounted on top of a magnetometer chip. A key drawback of these sensors lies in the manufacturing process, which relies on the manual assembly of the magnet–elastomer transducer, impacting both the repeatability of measurements across sensors and the potential for a cost-effective solution through mass-manufacturing. In this paper, a magnetic force sensor solution is presented with an optimized manufacturing process that will facilitate mass production. The elastomer–magnet transducer was fabricated using injection molding, and the assembly of the transducer unit, on top of the magnetometer chip, was achieved using semiconductor manufacturing techniques. The sensor enables robust differential 3D force sensing within a compact footprint (5 mm × 4.4 mm × 4.6 mm). The measurement repeatability of these sensors was characterized over multiple samples and 300,000 loading cycles. This paper also showcases how the 3D high-speed sensing capabilities of these sensors can enable slip detection in industrial grippers. Full article

In order to advance engineering applications of robotics such as wearable health-monitoring devices, humanoid robots, etc., it is essential to investigate the tactile sensations of artificial haptic sensors mimicking bioinspired human cutaneous mechanoreceptors such as free nerve endings, Merkel’s cells, Krause end bulbs, Meissner corpuscles, Ruffini endings, and Pacinian corpuscles. The generated receptor’s potential response to extraneous stimuli, categorized as slow adaption (SA) or fast adaption (FA), is particularly significant as a typical property. The present study addressed the estimation of SA and FA by utilizing morphologically fabricated mechanoreceptors made of our proposed magnetically responsive intelligent fluid, hybrid fluid (HF), and by applying our proposed electrolytic polymerization. Electric circuit models of the mechanoreceptors were generated using experimental data on capacitance and inductance on the basis of the electric characteristics of impedance. The present results regarding equivalent firing rates based on FA and SA are consistent with the FA and SA findings of vital mechanoreceptors by biomedical analysis. The present investigative process is useful to clarify the time of response to a force on the fabricated artificial mechanoreceptor. Full article

Biomedical receptors such as cutaneous receptors or intelligent cells with tactile, auditory, gustatory, and olfactory sensations function in the five senses of the human body. Investigations focusing on the configuration of such receptors are useful in the fields of robotics and sensors in the food industry, among others, which involve artificial organs or sensory machines. In the present study, we aimed to produce the receptors for four senses (excepting vision) by morphologically mimicking virtual human ones. The mimicked receptors were categorized into eight types of configured structure. Our proposed magnetic-responsive hybrid fluid (HF) in elastic and soft rubber and proposed electrolytic polymerization technique gave the solidified HF rubber electric characteristics of piezoelectricity and piezo-capacity, among others. On the basis of these electric characteristics, the mimicked receptors were configured in various types of electric circuits. Through experimental estimation of mechanical force, vibration, thermal, auditory, gustatory, and olfactory responses of each receptor, the optimum function of each was specified by comparison with the actual sensations of the receptors. The effect of hairs fabricated in the receptors was also clarified to viably reproduce the distinctive functions of these sensations. Full article
