Article
Solid-State Circuit Breaker Topology Design Methodology for Smart DC Distribution Grids with Millisecond-Level Self-Healing Capability
by Baoquan Wei, Haoxiang Xiao, Hong Liu, Dongyu Li, Fangming Deng, Benren Pan and Zewen Li
Energies 2025, 18(14), 3613; https://doi.org/10.3390/en18143613 - 9 Jul 2025
Viewed by 340
Abstract
To address the challenges of prolonged current isolation times and high dependency on varistors in traditional flexible short-circuit fault isolation schemes for DC systems, this paper proposes a rapid fault isolation circuit design based on an adaptive solid-state circuit breaker (SSCB). By introducing [...] Read more.
To address the challenges of prolonged current isolation times and high dependency on varistors in traditional flexible short-circuit fault isolation schemes for DC systems, this paper proposes a rapid fault isolation circuit design based on an adaptive solid-state circuit breaker (SSCB). By introducing an adaptive current-limiting branch topology, the proposed solution reduces the risk of system oscillations induced by current-limiting inductors during normal operation and minimizes steady-state losses in the breaker. Upon fault occurrence, the current-limiting inductor is automatically activated to effectively suppress the transient current rise rate. An energy dissipation circuit (EDC) featuring a resistor as the primary energy absorber and an auxiliary varistor (MOV) for voltage clamping, alongside a snubber circuit, provides an independent path for inductor energy release after faults. This design significantly alleviates the impact of MOV capacity constraints on the fault isolation process compared to traditional schemes where the MOV is the primary energy sink. The proposed topology employs a symmetrical bridge structure compatible with both pole-to-pole and pole-to-ground fault scenarios. Parameter optimization ensures the IGBT voltage withstand capability and energy dissipation efficiency. Simulation and experimental results demonstrate that this scheme achieves fault isolation within 0.1 ms, reduces the maximum fault current-to-rated current ratio to 5.8, and exhibits significantly shorter isolation times compared to conventional approaches. This provides an effective solution for segment switches and tie switches in millisecond-level self-healing systems for both low-voltage (LVDC, e.g., 750 V/1500 V DC) and medium-voltage (MVDC, e.g., 10–35 kV DC) smart DC distribution grids, particularly in applications demanding ultra-fast fault isolation such as data centers, electric vehicle (EV) fast-charging parks, and shipboard power systems. Full article
(This article belongs to the Special Issue AI Solutions for Energy Management: Smart Grids and EV Charging)
Show Figures

Figure 1

25 pages, 7806 KiB
Article
A Simple Single-Ended Post-Fault Location Technique for DC Lines Based on Controlled Re-Energizations
by Kumar Mahtani, José M. Guerrero, Julien Decroix and Carlos A. Platero
Electronics 2025, 14(2), 275; https://doi.org/10.3390/electronics14020275 - 11 Jan 2025
Cited by 2 | Viewed by 843
Abstract
Fault location in medium-voltage direct current (MVDC) systems is an essential yet underexplored area compared to high-voltage (HVDC) and low-voltage (LVDC) systems. MVDC systems, characterized by intermediate line lengths and fault resistances, as well as rapid fault clearance requirements, demand specialized solutions. This [...] Read more.
Fault location in medium-voltage direct current (MVDC) systems is an essential yet underexplored area compared to high-voltage (HVDC) and low-voltage (LVDC) systems. MVDC systems, characterized by intermediate line lengths and fault resistances, as well as rapid fault clearance requirements, demand specialized solutions. This paper proposes a novel single-ended, offline fault location method based on controlled re-energizations after fault clearance. This approach employs a switched grounding resistor and a bypass connection through the current-limiting inductor to extract fault parameters from the discharge curves of two re-energization cycles. By analyzing the time constants derived from these curves, the method estimates fault location and resistance with high accuracy. The proposed method eliminates the need for additional active injection sources and circuit breaker modifications, ensuring seamless integration into existing MVDC infrastructure. Furthermore, the method avoids inter-terminal communication delays and sampling delays before fault clearance. Validation through electromagnetic transient simulations demonstrates fault location errors below 5% for fault resistances up to 50 Ω. Results show that the method performs better for faults farther from the active terminal, with the higher errors seen for short distances and elevated resistances. The proposed technique offers a robust and practical solution for post-fault location in DC lines. Full article
Show Figures

Figure 1

17 pages, 7732 KiB
Article
A Three-Port Power Electronic Transformer Based on Magnetic Integration
by Zhixian Liao, Yingzong Jiao, Zhiwen Suo, Binbin Li, Xiaodong Zhao, Linjie Han and Dianguo Xu
Appl. Sci. 2022, 12(22), 11607; https://doi.org/10.3390/app122211607 - 15 Nov 2022
Cited by 3 | Viewed by 2165
Abstract
This paper proposes a three-port power electronic transformer (PET) based on magnetic integration, where the modular multilevel converter (MMC) arm inductors and high-frequency transformer are integrated; thus, the low-voltage DC (LVDC) port can be directly obtained. Such a magnetic integration structure has advantages [...] Read more.
This paper proposes a three-port power electronic transformer (PET) based on magnetic integration, where the modular multilevel converter (MMC) arm inductors and high-frequency transformer are integrated; thus, the low-voltage DC (LVDC) port can be directly obtained. Such a magnetic integration structure has advantages of reduction in magnetic volume and number of active switches, implying a compact structure and reduced cost. Compared with existing PETs, the proposed PET can save more than 60% of magnetic volume and more than 19% of device cost. The proposed PET is suitable for AC/DC hybrid distribution applications with medium-voltage DC (MVDC), medium-voltage AC (MVAC), and LVDC ports, especially for scenarios where moderate amounts of power (100 s of kW) are tapped from an LVDC port. The feasibility of the proposed three-port PET has been verified by simulation and experimental results. Full article
(This article belongs to the Special Issue DC Grids: Recent Advances and Future Trends)
Show Figures

Figure 1

11 pages, 39918 KiB
Article
Aging Characteristics of Contact Electrodes of Low Voltage DC Switches
by Hyosung Kim
Energies 2021, 14(20), 6838; https://doi.org/10.3390/en14206838 - 19 Oct 2021
Cited by 3 | Viewed by 2997
Abstract
With the present state of the direct current (DC) distribution market, securing the safety of the DC distribution system is emerging as a major issue. Like AC distribution systems, DC switches and circuit breakers are one of the main means to ensure safety. [...] Read more.
With the present state of the direct current (DC) distribution market, securing the safety of the DC distribution system is emerging as a major issue. Like AC distribution systems, DC switches and circuit breakers are one of the main means to ensure safety. However, in the DC system, since there is no current zero point in the load current, the phenomenon occurring when the circuit is cut off is different from that of the AC system, so technical research is required to cope with this. In this study, the aging characteristics of the contact electrode of a 400 V class low voltage DC (LVDC) switch is studied for the development of wall-mount switches or circuit breakers for residential houses. As an arc extinguishing method to break DC load current, a prototype experimental circuit breaker that uses a magnetic extinguishing method that is effective for blocking low voltage low power DC is invented, and an automated experiment system is established. The DC switch test repeats the operation of turning it on and off 13,000 times, and continuously evaluates the performance of the electric contacts by calculating the voltage drop between the electrode contacts and the corresponding Ohmic resistance value when conducting every 500 times. This paper tests six contact materials to compare the aging characteristics of them by evaluating contact resistance during the test period. AW18-Cu composite material showed the most stable and excellent contact performance for LVDC switches during the entire test operation period. Full article
(This article belongs to the Special Issue DC Circuit Breaker Technologies State of Art)
Show Figures

Figure 1

19 pages, 3291 KiB
Article
Grounding Fault Model of Low Voltage Direct Current Supply and Utilization System for Analyzing the System Grounding Fault Characteristics
by Jie Liu, Kaiqi Sun, Zhao Ma, Zhijie Liu and Kejun Li
Symmetry 2021, 13(10), 1795; https://doi.org/10.3390/sym13101795 - 26 Sep 2021
Cited by 2 | Viewed by 2344
Abstract
Grounding fault analysis is of vital importance for low voltage direct current (LVDC) supply and utilization systems. However, the existing DC grounding fault model is inappropriate for LVDC supply and utilization system. In order to provide an appropriate assessment model for the DC [...] Read more.
Grounding fault analysis is of vital importance for low voltage direct current (LVDC) supply and utilization systems. However, the existing DC grounding fault model is inappropriate for LVDC supply and utilization system. In order to provide an appropriate assessment model for the DC grounding fault impact on the LVDC supply and utilization system, an LVDC supply and utilization system grounding fault model is proposed in this paper. Firstly, the model is derived by utilizing capacitor current and voltage as the system state variable, which considers the impact of the converter switch state on the topology of the fault circuit. The variation of system state parameters under various fault conditions can be easily obtained by inputting system state data in normal conditions as the initial value. Then, a model solution algorithm for the proposed model is utilized to calculated the maximum fault current, the system maximum fault current with different grounding resistance is simple to acquired based on the solution algorithm. The calculation results demonstrate that grounding resistance and structure of LVDC supply and utilization system have remarkable impacts on the transient current. The effectiveness of the proposed model is verified in PSCAD/EMTDC. The simulation results indicate that the proposed method is appropriate for the system fault analysis under various fault conditions with different grounding resistance and the proposed model can offer theoretical guidance for system fault protection. Full article
(This article belongs to the Section Engineering and Materials)
Show Figures

Figure 1

9 pages, 2282 KiB
Review
Gate Drive Controller for Low Voltage DC Hybrid Circuit Breaker
by Hyosung Kim
Energies 2021, 14(6), 1753; https://doi.org/10.3390/en14061753 - 22 Mar 2021
Cited by 7 | Viewed by 2639
Abstract
With the advent of direct current (DC) loads such as LED lighting, IT equipment, electric vehicles, and DC powers generated from renewable energy sources, low voltage DC (LVDC) distribution system is becoming a hot issue. One of the hurdles in the LVDC distribution [...] Read more.
With the advent of direct current (DC) loads such as LED lighting, IT equipment, electric vehicles, and DC powers generated from renewable energy sources, low voltage DC (LVDC) distribution system is becoming a hot issue. One of the hurdles in the LVDC distribution system is arc flash at the contact points that occurs during the circuit is opening. Unlike alternating current, direct current has no zero points and sustains constantly. Therefore, there is a risk of electric fire due to continuous generating arcs when the load current is interrupted with an existing electrical contact type circuit breaker. Recently, the concept of a hybrid circuit breaker that takes advantage of traditional electrical contact type switch and the arcless semiconductor switch has been proposed, but how to cooperatively operate the two switches has become an issue. This paper analyzes the principle of a hybrid circuit breaker for blocking LVDC current and proposes a gate drive controller for it. Through 400V class LVDC cutoff test, the operation of the proposed hybrid circuit breaker is verified and the characteristics are analyzed. Full article
(This article belongs to the Special Issue DC Circuit Breaker Technologies State of Art)
Show Figures

Figure 1

19 pages, 6400 KiB
Article
Practical Controller Design of Three-Phase Dual Active Bridge Converter for Low Voltage DC Distribution System
by Hyun-jun Choi, Won-bin Lee and Jee-hoon Jung
Electronics 2020, 9(12), 2101; https://doi.org/10.3390/electronics9122101 - 9 Dec 2020
Cited by 4 | Viewed by 5942
Abstract
In a low voltage DC (LVDC) distribution system, isolated bi-directional DC-DC converters are key devices to control power flows. A three-phase dual-active-bridge (3P-DAB) converter is one of the suitable candidates due to inherent soft-switching capability, low conduction loss, and high-power density. However, the [...] Read more.
In a low voltage DC (LVDC) distribution system, isolated bi-directional DC-DC converters are key devices to control power flows. A three-phase dual-active-bridge (3P-DAB) converter is one of the suitable candidates due to inherent soft-switching capability, low conduction loss, and high-power density. However, the 3P-DAB converter requires a well-designed controller due to the influence of the equivalent series resistance (ESR) of an output filter capacitor, degrading the performance of the 3P-DAB converter in terms of high-frequency noise. Unfortunately, there is little research that considers the practical design methodology of the 3P-DAB converter’s controller because of its complexity. In this paper, the influence of the ESR on the 3P-DAB converter is presented. Additionally, the generalized average small-signal model (SSM) of the 3P-DAB converter including the ESR of the capacitive output filter is presented. Based on this model, an extended small-signal model and appropriate controller design guide, and performance comparison are presented based on the frequency domain analysis. Finally, experimental results verify the validity of the proposed controller using a 25 kW prototype 3P-DAB converter. Full article
(This article belongs to the Special Issue State-of-the-art Power Electronics in Korea)
Show Figures

Figure 1

16 pages, 5655 KiB
Article
Analysis and Design of Coupled Inductor for Interleaved Buck-Type Voltage Balancer in Bipolar DC Microgrid
by Jung-min Park, Hyung-jun Byun, Bum-jun Kim, Sung-hun Kim and Chung-yuen Won
Energies 2020, 13(11), 2775; https://doi.org/10.3390/en13112775 - 1 Jun 2020
Cited by 10 | Viewed by 3144
Abstract
A voltage balancer (VB) can be used to balance voltages under load unbalance in either a bipolar DC microgrid or LVDC (Low voltage DC) distribution system. An interleaved buck-type VB has advantages over other voltage balance topologies for reduction in output current ripple [...] Read more.
A voltage balancer (VB) can be used to balance voltages under load unbalance in either a bipolar DC microgrid or LVDC (Low voltage DC) distribution system. An interleaved buck-type VB has advantages over other voltage balance topologies for reduction in output current ripple by an aspect of configuration of a physically symmetrical structure. Similarly, magnetic coupling such as winding two or more magnetic components into a single magnetic component can be selected to enhance the power density and dynamic response. In order to achieve these advantages in a VB, this paper proposes a VB with a coupled inductor (CI) as a substitute for inductors in a two-stage interleaved buck-type VB circuit. Based on patterns of switch poles under load variation, the variation in inductor currents under four switching patterns is induced. The proposed CI is derived from self-inductance based on the configuration structure that has a two-stage interleaved buck type and mathematical design results based on the coupling coefficient, where the coupling coefficient is a key factor in the determination of the dynamic response of the proposed VB in load variation. According to the results, a prototype scale is implemented to confirm the feasibility and effectiveness of the proposed VB. Full article
(This article belongs to the Section A1: Smart Grids and Microgrids)
Show Figures

Figure 1

17 pages, 2864 KiB
Article
Simulation Test of a DC Fault Current Limiter for Fault Ride-Through Problem of Low-Voltage DC Distribution
by Bing Han and Yonggang Li
Energies 2020, 13(7), 1753; https://doi.org/10.3390/en13071753 - 6 Apr 2020
Cited by 6 | Viewed by 2944
Abstract
The low voltage direct current (LVDC) distribution networks are connected with too many kinds of loads and sources, which makes them prone to failure. Due to the small damping value in the DC lines, the fault signal propagates so fast that the impact [...] Read more.
The low voltage direct current (LVDC) distribution networks are connected with too many kinds of loads and sources, which makes them prone to failure. Due to the small damping value in the DC lines, the fault signal propagates so fast that the impact current with the wave front of millisecond and the transient voltage pose great challenges for fault detection. Even worse, some faults with small currents are difficult to detect and the communication is out of sync, resulting in protection misoperation. These problems have severely affected the new energy utilization. In view of this, a DC fault current limiter (FCL) composed of inductance, resistance, and power electronic switch was designed in this paper. The rising speed of fault current can be decreased by the series inductance and the peak value of the fault current can be limited by series impedance, thus in this way the running time can be gained for fault detection and protection. For distributed energy access, by deducing the short circuit fault characteristic expression of LVDC distribution network, the feasibility of FCL was verified. Based on the structure of the bridge-type alternating current (AC) current limiter, the structure and parameters of the DC FCL were determined according to the fault ride-through target. Then, a low voltage ride-through strategy based on DC FCL was proposed for the bipolar short-circuit fault of LVDC distribution network. Finally, MATLAB/Simulink simulation was used to verify the rationality of the proposed FCL and its ride-through strategy. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1

14 pages, 4292 KiB
Article
High-Efficiency Bi-Directional Single-Phase AC/DC Converter Design and Field Application for LVDC Distribution
by Juyong Kim, Hongjoo Kim, Jintae Cho and Youngpyo Cho
Energies 2019, 12(11), 2191; https://doi.org/10.3390/en12112191 - 8 Jun 2019
Cited by 1 | Viewed by 3087
Abstract
This paper describes the design and field application of a high-efficiency single-phase AC/DC converter that is suitable for distribution lines. First, an appropriate AC/DC converter was designed in consideration of the environment of the application system. In order to ensure high efficiency and [...] Read more.
This paper describes the design and field application of a high-efficiency single-phase AC/DC converter that is suitable for distribution lines. First, an appropriate AC/DC converter was designed in consideration of the environment of the application system. In order to ensure high efficiency and high reliability, we designed an optimum switching element and capacitor suitable for the converter, and the protection element of the AC/DC converter was designed based on these elements. The control function for the power converter suitable for an LVDC distribution system is proposed for highly reliable operation. The AC/DC converter was manufactured based on the design and its performance was verified during application in an actual low-voltage DC (LVDC) distribution grid through tests at the demonstration site. The application to a DC distribution system in an actual grid is very rare and it is expected that it will contribute to the expansion of LVDC distribution. Full article
(This article belongs to the Special Issue Reliability of Power Electronic Systems)
Show Figures

Figure 1
