We are working on an innovative approach to outdoor human motion capture, using a wearable device that integrates a low-cost GNSS (Global Navigation Satellite System) receiver and an INS (Inertial Navigation System) via a zero-velocity update (ZUPT) methodology. In this study, we focused on using these devices to reconstruct the foot trajectory. Our work addresses the challenge of capturing precise foot movements in uncontrolled outdoor environments, a task traditionally constrained by the limitations of laboratory settings. We equipped devices that combine inertial measurement units (IMUs) with GNSS receivers in the following configuration: one on each foot and one on the head. We experimented with different GNSS data processing techniques, such as Post-Processed Kinematic (PPK) positioning with and without Moving Base (MB), and after the integration with the IMU, we obtained centimeter-level precision in horizontal and vertical positioning for various walking speeds. This integration leverages a loosely coupled GNSS/INS approach, where the GNSS solution is independently processed and subsequently used to refine the INS outputs. Enhanced by ZUPT and Madgwick filtering, this method significantly improves the trajectory reconstruction accuracy. Indeed, our research includes a study of the impact of moving speed on the performance of these low-cost GNSS receivers. These insights pave the way for future exploration into tightly coupled GNSS/INS integration using low-cost GNSS receivers, promising advancements in fields like sports science, rehabilitation, and well-being. This work seeks not only to contribute to the field of wearable technology, but also to open possibilities for further innovation in affordable, high-accuracy personal navigation and activity monitoring devices. Full article

The integration of the global navigation satellite system (GNSS) and the inertial navigation system (INS) is a well-established method for achieving accurate positioning, especially in applications involving unmanned aerial vehicles (UAVs). UAVs are increasingly used across various fields, yet they face challenges such as the need for real-time processing and the impact of low-quality measurements from cost-effective devices. To address these challenges, we propose a velocity-constrained, enhanced, real-time, low-cost, GNSS/INS integrated navigation algorithm and design an algorithmic platform based on the open-source software KF_GINS. The algorithm supports loosely coupled integration of GNSS position data and raw inertial measurement unit (IMU) data, utilizing a 4G data transmission unit (DTU) for real-time data transmission and performing loosely coupled computations on the received data. Subsequently, we successfully applied this algorithm to low-cost integrated navigation devices, such as UAVs. We tested the algorithm platform using one set of vehicle-mounted data and six UAV datasets. Experimental results indicate that the algorithm platform effectively performs computations under various conditions, improving single-point positioning (SPP) accuracy by up to 15.38% horizontally and 6.78% vertically. These findings demonstrate the algorithm platform’s capability to significantly enhance the accuracy and stability of integrated navigation positioning for UAVs. Full article

This study evaluates the potential of GNSS/IMU buoys for sea surface height observations and depth datum verification. GNSS/IMU buoys were deployed alongside 34 tide gauges around Taiwan for synchronous sea surface height measurements. The collected GNSS data were processed through relative positioning and loosely coupled GNSS/IMU integration methods. Analysis revealed that the average of the means of the differences was −2.5 cm across all stations, indicating that most tide gauge datums agreed well with the GNSS/IMU buoy measurements. Significant discrepancies were observed at only a few stations, likely due to local subsidence. Notably, the Shuitou station showed a mean difference of 63.4 cm, resulting from its remarkable deviation from tidal zero since 2019, suggesting a potential datum issue. The mean of the standard deviation (STD) of the differences across the stations was 3.8 cm, with the highest STD observed at the Shuitou station (9.4 cm). These findings demonstrate that GNSS/IMU buoys can effectively complement tide gauge measurements for observing sea surface heights and defining the depth datum, particularly in areas where local vertical land movements affect tide gauge data accuracy. Full article

With the development of advanced driver assistance systems (ADAS) and autonomous vehicles (AV), recent years have seen an increasing evolution of onboard sensors and communication interfaces capable of interacting with available infrastructures, including satellite constellations, road structures, modern and heterogeneous network systems (e.g., 5G and beyond) and even adjacent vehicles. Consequently, it is essential to develop architectures that cover data fusion (multi–sensor approach), communication, power management, and system monitoring to ensure accurate and reliable perception in several navigation scenarios. Motivated by the EMERGE project, this paper describes the definition and implementation of an On Board Unit (OBU) dedicated to the navigation process. The OBU is equipped with the Xsens MTi–630 AHRS inertial sensor, a multi–constellation/multi–frequency Global Navigation Satellite System (GNSS) receiver with the u–blox ZED–F9P module and communication interfaces that afford access to the PointPerfect augmentation service. Experimental results show that GNSS, with corrections provided by augmentation, affords centimetre accuracy, with a Time To First Fix (TTFF) of about 30 s. During the on–road tests, we also collect: the output of fusion with inertial sensor data, monitoring information that assess correct operation of the module, and the OBU power consumption, that remains under 5 W even in high–power operating mode. Full article

Accurate and stable positioning is significant for vehicle navigation systems, especially in complex urban environments. However, urban canyons and dynamic interference make vehicle sensors prone to disturbance, leading to vehicle positioning errors and even failures. To address these issues, an adaptive loosely coupled IMU/GNSS/LiDAR integrated navigation system based on factor graph optimization with sensor weight optimization and fault detection is proposed. First, the factor nodes and system framework are constructed based on error models of sensors, and the optimization method principle is derived. Second, the interactive multiple-model algorithm based on factor graph optimization (IMMFGO) is utilized to calculate and adjust sensor weights for global optimization, which will reduce the impact of disturbed sensors. Finally, a multi-stage fault detection, isolation, and recovery (MSFDIR) strategy is implemented based on the IMMFGO results and IMU pre-integration measurements, which can detect significant sensor faults and optimize the system structure. Vehicle experiments show that our IMMFGO method generally obtains better performance in positioning accuracy by 23.7% compared to adaptive factor graph optimization (AFGO) methods, and the MSFDIR strategy possesses the capability of fault sensor detection, which provides an essential reference for multi-source vehicle navigation systems in urban canyons. Full article

Inertial measurement units (IMUs) are key components of various applications including navigation, robotics, aerospace, and automotive systems. IMU sensor characteristics have a significant impact on the accuracy and reliability of these applications. In particular, noise characteristics and bias stability are critical for proper filter settings to perform a combined GNSS/IMU solution. This paper presents an analysis based on the Allan deviation of different IMU sensors that correspond to different grades of micro-electromechanical systems (MEMS)-type IMUs in order to evaluate their accuracy and stability over time. The study covers three IMU sensors of different grades (ascending order): Rokubun Argonaut navigator sensor (InvenSense TDK MPU9250), Samsung Galaxy Note10 phone sensor (STMicroelectronics LSM6DSR), and NovAtel PwrPak7 sensor (Epson EG320N). The noise components of the sensors are computed using overlapped Allan deviation analysis on data collected over the course of a week in a static position. The focus of the analysis is to characterize the random walk noise and bias stability, which are the most critical for combined GNSS/IMU navigation and may differ or may not be listed in manufacturers’ specifications. Noise characteristics are calculated for the studied sensors and examples of their use in loosely coupled GNSS/IMU processing are assessed. This work proposes a structured and reproducible approach for working with sensors for their use in navigation tasks in combination with GNSS, and can be used for sensors of different levels to supplement missing or incorrect sensor manufacturers’ data. Full article

Recently, factor graph optimization (FGO)-based GNSS/INS integrated navigation has garnered widespread attention for its ability to provide more robust positioning performance in challenging environments like urban canyons, compared to traditional extended Kalman filter (EKF)-based methods. In existing GNSS/INS integrated navigation methods based on FGO, the primary approach involves combining single point positioning (SPP) or real-time kinematic (RTK) with INS by constructing factors between consecutive epochs to resist outliers and achieve robust positioning. However, the potential of a high-precision positioning system based on the FGO algorithm, combining INS and PPP-B2b and that does not rely on reference stations and network connections, has not been fully explored. In this study, we developed a loosely coupled PPP-B2b/INS model based on the EKF and FGO algorithms. Experiments in different urban road and overpass scenarios were conducted to investigate the positioning performance of the two different integration navigation algorithms using different degrades of inertial measurement units (IMUs). The results indicate that the FGO algorithm outperforms the EKF algorithm in terms of positioning with the combination of GNSS and different degrades of IMUs under various conditions. Compared to the EKF method, the application of the FGO algorithm leads to improvements in the positioning accuracy of approximately 15.8%~45.9% and 19%~41.3% in horizontal and vertical directions, respectively, for different experimental conditions. In scenarios with long and frequent signal obstructions, the advantages of the FGO algorithm become more evident, especially in the horizontal direction. An obvious improvement in positioning results is observed when the tactical-grade IMU is used instead of the microelectron-mechanical system (MEMS) IMU in the GNSS/INS combination, which is more evident for the FGO algorithm than for the EKF algorithm. Full article

High-precision navigation solutions are a main requirement for autonomous vehicle (AV) applications. Global navigation satellite systems (GNSSs) are the prime source of navigation information for such applications. However, some places such as tunnels, underpasses, inside parking garages, and urban high-rise buildings suffer from GNSS signal degradation or unavailability. Therefore, another system is required to provide a continuous navigation solution, such as the inertial navigation system (INS). The vehicle’s onboard inertial measuring unit (IMU) is the main INS input measurement source. However, the INS solution drifts over time due to IMU-associated errors and the mechanization process itself. Therefore, INS/GNSS integration is the proper solution for both systems’ drawbacks. Traditionally, a linearized Kalman filter (LKF) such as the extended Kalman filter (EKF) is utilized as a navigation filter. The EKF deals only with the linearized errors and suppresses the higher orders using the Taylor expansion up to the first order. This paper introduces a loosely coupled INS/GNSS integration scheme using the invariant extended Kalman filter (IEKF). The IEKF state estimate is independent of the Jacobians that are derived in the EKF; instead, it uses the matrix Lie group. The proposed INS/GNSS integration using IEKF is applied to a real road trajectory for performance validation. The results show a significant enhancement when using the proposed system compared to the traditional INS/GNSS integrated system that uses EKF in both GNSS signal presence and blockage cases. The overall trajectory 2D-position RMS error reduced from $19.4$ m to $3.3$ m with $82.98\%$ improvement and the 2D-position max error reduced from $73.9$ m to $14.2$ m with $80.78\%$ improvement. Full article

The integration of global navigation satellite system (GNSS) precise point positioning (PPP) and inertial navigation system (INS) is widely used in navigation for its robustness and resilience, especially in case of GNSS signal blockage. With GNSS modernization, a variety of PPP models have been developed and studied, which has also led to various PPP/INS integration methods. In this study, we investigated the performance of a real-time GPS/Galileo zero-difference ionosphere-free (IF) PPP/INS integration with the application of uncombined bias products. This uncombined bias correction was independent of PPP modeling on the user side and also enabled carrier phase ambiguity resolution (AR). CNES (Centre National d’Etudes Spatiales) real-time orbit, clock, and uncombined bias products were used. Six positioning modes were evaluated, including PPP, PPP/INS loosely coupled integration (LCI), PPP/INS tightly coupled integration (TCI), and three of these with uncombined bias correction through a train positioning test in an open sky environment and two van positioning tests at a complex road and city center. All of the tests used a tactical-grade inertial measurement unit (IMU). In the train test, we found that ambiguity-float PPP had almost identical performance with LCI and TCI, which reached an accuracy of 8.5, 5.7, and 4.9 cm in the north (N), east (E) and up (U) direction, respectively. After AR, significant improvements on the east error component were achieved, which were 47%, 40%, and 38% for PPP-AR, PPP-AR/INS LCI, and PPP-AR/INS TCI, respectively. In the van tests, frequent signal interruptions due to bridges, vegetation, and city canyons make the IF AR difficult. TCI achieved the highest accuracies, which were 32, 29, and 41 cm for the N/E/U component, respectively, and also effectively eliminated the solution re-convergence in PPP. Full article

This study presents the filter design of GNSS/IMU integration for wearable EPTS (Electronic Performance and Tracking System) of football players. EPTS has been widely used in sports fields recently, and GNSS (Global Navigation Satellite System) and IMU (Inertial Measurement Unit) in wearable EPTS have been used to measure and provide players’ athletic performance data. A sensor fusion technique can be used to provide high-quality analysis data of athletic performance. For this reason, the integration filter of GNSS data and IMU data is designed in this study. The loosely-coupled strategy is considered to integrate GNSS and IMU data considering the specification of the wearable EPTS product. Quaternion is used to estimate a player’s attitude to avoid the gimbal lock singularity in this study. Experiment results validate the performance of the proposed GNSS/IMU loosely-coupled integration filter for wearable EPTS of football players. Full article

The BeiDou global navigation satellite system (BDS-3) has been officially providing a real-time precise point positioning (PPP) augmentation service, known as the PPP-B2b service, since 2020. Decimeter-level positioning accuracy is expected to be achieved based on the PPP-B2b service. It shows great potential for global navigation satellite system (GNSS) real-time applications, including, for example, vehicle positioning on land. However, the application of the PPP-B2b service is still full of challenges in the urban environment because of GNSS signal blockage. The inertial navigation system (INS) is a popular technology which can provide continuous positions under GNSS challenging scenarios. In this study, we constructed a BDS-3 PPP-B2b/INS loosely coupled integration system for vehicle positioning and evaluated its performance through two automotive experiments. In the first experiment, four periods of 30 s GNSS outages were simulated to evaluate the performance of PPP-B2b/INS loosely coupled integration during GNSS outages. During the simulated GNSS outages, PPP-B2b positioning did not work. Nevertheless, PPP-B2b/INS loosely coupled integration provided continues solution through INS mechanization. The averaged positioning errors at the last epoch of outages were 300.6/498.0/41.0 cm for PPP-B2b/MEMS-IMU and 18.6/21.8/6.1 cm for PPP-B2b/Tactical-IMU loosely coupled integration, in the east, north and up directions, respectively. In the second experiment, we drove the land vehicle in a complex urban environment for 15 min. During this period, two GNSS signal interruptions occurred due to the occlusion of bridges, lasting 15 s and 5 s, respectively. The results show that the improvement of positioning accuracy in the east, north, and up components were 64.1%, 77.8%, and 73.8% respectively for PPP-B2b/MEMS-IMU loosely coupled integration, and 63.9%, 79.5%, and 74.4% respectively for PPP-B2b/Tactical-IMU loosely coupled integration, as compared to the positioning accuracy of PPP-B2b only. Full article

When satellite navigation terminal sensors encounter malicious signal spoofing or interference, if attention is not paid to improving their anti-spoofing ability, the performance of the sensors will be seriously affected. The global navigation satellite system (GNSS) spoofing has gradually become a research hotspot of the jammer because of its great harm and high concealment. In the face of more and more sensors coupling GNSS and inertial measurement unit (IMU) to varying degrees and configuring a variety of anti-spoofing techniques to effectively detect spoofing, even if the spoofer intends to gradually pull the positioning results, if the spoofing strategy is unreasonable, the parameters of the coupled filter output and spoofing observation measurement will lose their rationality, which will lead to the spoofing being detected. To solve the above problems, in order to effectively counter the non-cooperative target sensors of assembling loosely coupled GNSS/IMU using GNSS spoofing, based on the analysis of the influence mechanism of spoofing on the positioning of loosely coupled GNSS/IMU, a slowly varying spoofing algorithm to avoid loosely coupled GNSS/IMU with multiple anti-spoofing techniques is proposed in this paper, and a measurement deviation determination method to avoid multiple anti-spoofing techniques is proposed, which can gradually pull the positioning results of the coupled system and successfully avoid the detection of anti-spoofing techniques of innovation sequence monitoring and a rationality check on parameters. Simulation experimental results show that the proposed algorithm gradually changes the positioning of loosely coupled GNSS/IMU, the north and east displacements achieve the purpose of spoofing, and error with expected offset is −0.2 m and 2.3 m, respectively. Down displacement also basically achieves the purpose of spoofing, and error with the expected offset is 13.2 m. At the same time, the spoofer avoids the detection of multiple anti-spoofing techniques, does not trigger the system alarm, and realizes the purpose of spoofing; thus, the effectiveness and high concealment of the spoofing algorithm are verified. Full article

The loosely coupled integration of Global Navigation Satellite System (GNSS) and Inertial Navigation System (INS) have been widely used to improve the accuracy, robustness and continuity of navigation services. However, the integration systems possibly affected by spoofing attacks, since integration algorithms without spoofing detection would feed autonomous INSs with incorrect compensations from the spoofed GNSSs. This paper theoretically analyzes and tests the performances of GNSS/INS loosely coupled integration systems with the classical position fusion and position/velocity fusion under typical meaconing (MEAC) and lift-of-aligned (LOA) spoofing attacks. Results show that the compensations of Inertial Measurement Unit (IMU) errors significantly increase under spoofing attacks. The compensations refer to the physical features of IMUs and their unreasonable increments likely result from the spoofing-induced inconsistency of INS and GNSS measurements. Specially, under MEAC attacks, the IMU error compensations in both the position-fusion-based system and position/velocity-fusion-based system increase obviously. Under LOA attacks, the unreasonable compensation increments are found from the position/velocity-fusion-based integration system. Then a detection method based on IMU error compensations is tested and the results show that, for the position/velocity-fusion-based integration system, it can detect both MEAC and LOA attacks with high probability using the IMU error compensations. Full article

Currently Global Navigation Satellite Systems (GNSSs) are the primary source for the determination of absolute position, navigation, and time (PNT) for merchant vessel navigation. Nevertheless, the performance of GNSSs can strongly degrade due to space weather events, jamming, and spoofing. Especially the increasing availability and adoption of low cost jammers lead to the question of how a continuous provision of PNT data can be realized in the vicinity of these devices. In general, three possible solutions for that challenge can be seen: (i) a jamming-resistant GNSS receiver; (ii) the usage of a terrestrial backup system; or (iii) the integration of GNSS with other onboard navigation sensors such as a speed log, a gyrocompass, and inertial sensors (inertial measurement unit—IMU). The present paper focuses on the third option by augmenting a classical IMU/GNSS sensor fusion scheme with a Doppler velocity log. Although the benefits of integrated IMU/GNSS navigation system have been already demonstrated for marine applications, a performance evaluation of such a multi-sensor system under real jamming conditions on a vessel seems to be still missing. The paper evaluates both loosely and tightly coupled fusion strategies implemented using an unscented Kalman filter (UKF). The performance of the proposed scheme is evaluated using the civilian maritime jamming testbed in the Baltic Sea. Full article

Global Navigation Satellite Systems (GNSSs) remain the principal mean of positioning in many applications and systems, but in several types of environment, the performance of standalone receivers is degraded. Although many works show the benefits of the integration between GNSS and Inertial Navigation Systems (INSs), tightly-coupled architectures are mainly implemented in professional devices and are based on high-grade Inertial Measurement Units (IMUs). This paper investigates the performance improvements enabled by the tight integration, using low-cost sensors and a mass-market GNSS receiver. Performance is assessed through a series of tests carried out in real urban scenarios and is compared against commercial modules, operating in standalone mode or featuring loosely-coupled integrations. The paper describes the developed tight-integration algorithms with a terse mathematical model and assesses their efficacy from a practical perspective. Full article
