Search Results (35)

Strong earthquake activity along fault zones can lead to the displacement of geomorphic units such as gullies and terraces while preserving earthquake event data through changes in sedimentary records near faults. The quantitative analysis of these characteristics facilitates the reconstruction of significant earthquake activity history along the fault zone. Recent advancements in acquisition technology for high-precision and high-resolution topographic data have enabled more precise identification of displacements caused by fault activity, allowing for a quantitative assessment of the characteristics of strong earthquakes on faults. The 1920 Haiyuan earthquake, which occurred on the Haiyuan fault in the northeastern Tibetan Plateau, resulted in a surface rupture zone extending nearly 240 km. Although clear traces of surface rupture have been well preserved along the fault, debate regarding the maximum displacement is ongoing. In this study, we focused on two typical offset geomorphic sites along the middle segment of the Haiyuan fault that were previously identified as having experienced the maximum displacement during the Haiyuan earthquake. High-precision geomorphologic images of the two sites were obtained through unmanned aerial vehicle (UAV) surveys, which were combined with light detection and ranging (LiDAR) data along the fault zone. Our findings revealed that the maximum horizontal displacement of the Haiyuan earthquake at the Shikaguan site was approximately 5 m, whereas, at the Tangjiapo site, it was approximately 6 m. A cumulative offset probability distribution (COPD) analysis of high-density fault displacement measurements along the ruptures indicated that the smallest offset clusters on either side of the Ganyanchi Basin were 4.5 and 5.1 m long. This analysis further indicated that the average horizontal displacements of the Haiyuan earthquake were approximately 4–6 m. Further examination of multiple gullies and geomorphic unit displacements at the Shikatougou site, along with a detailed COPD analysis of dense displacement measurements within a specified range on both sides, demonstrated that the cumulative displacement within 30 m of this section of the Haiyuan fault exhibited at least five distinct displacement clusters. These dates may represent the results of five strong earthquake events in this fault segment over the past 10,000–13,000 years. The estimated magnitude, derived from the relationship between displacement and magnitude, ranged from M_w 7.4 to 7.6, with an uneven recurrence interval of approximately 2500–3200 years. Full article

Drilling long horizontal wells in naturally cracked/fractured unconventional shale gas/oil formations presents a huge challenge to the energy industry because of wellbore clogging complications that cause pipe sticking problems. This work proposes to use smooth catenary well trajectories to reduce drilling friction to mitigate these problems. A mathematical model was developed in this study for designing well trajectory profiles with a smooth transition from the kick-out point (KOP) to the catenary section. This model consists of closed-form equations for the radius of curvature and inclination angle in the catenary section. Using the radius of curvature at the top point of the catenary section to design the arc section below the KOP eliminates the trial-and-error procedure required for achieving the smooth transition between the two sections. The result of a field case study with Tuscaloosa Marine Shale (TMS) data shows that the drilling drag (hook load) can be reduced by 15% to 30% with the use of smooth catenary well trajectories to replace the conventional arc-type well trajectories. Model-calculated reduction in the hook load drops linearly with the horizontal borehole friction coefficient (clog indicator). The reduction increases non-linearly from 15% to 30% with drill collar weight increasing from 20 lb/ft to 92 lb/ft. Full article

The choke effect of hydraulic fractures on a horizontal shale oil well during production is shown using a coupled matrix–fracture–wellbore flow simulation model. The effect is the consequence of a significant loss in hydraulic fracture conductivity near the wellbore due to fracture closure stress. A consequence of the choke effect is that the fluid pressure in the fractures is maintained high enough to keep gas in the solution. The gas leaves the solution only after the choke region is passed when the oil with its solution gas begins the flow in the wellbore, and when it abruptly experiences a steep pressure gradient. This phenomenon has a long period of producing a constant gas–oil ratio (flat GOR) as its signature. The influence of the choke effect on the wellbore flow regimes is also investigated in the hydraulic-fractured horizontal section of the reservoir. During horizontal pipe flow, a distributed–intermittent flow sequence develops from the toe to the heel of the shale oil well over the production time. However, in the presence of the hydraulic fractures, a sequence of distributed–intermittent–transient–segregated flows develops. This indicates that the choke has the potential to affect the flow regimes in the horizontal section. Full article

The most common type of well in the Fuling shale gas field is the long horizontal section well. Once the energy attenuates, it is difficult to discharge the accumulated liquid. So, it is particularly important to determine the time of accumulation. Through indoor experiments, it was observed that droplets in the gas core flowing under critical conditions and the liquid film adhering to the tube wall cannot be ignored. It was also discovered that the liquid phase on the tube wall can form fluctuations due to the shear effect of the gas phase. Based on the observed distribution of gas–liquid phases in experiments, a critical liquid-carrying velocity calculation method considering the coexistence of droplets and liquid films, as well as the frictional resistance coefficient at the gas–liquid interface under wave morphology, was established. Integrating production data from 106 wells at home and abroad, as well as testing data from the Fuling example well, the new model was validated. The results showed that the new model can accurately diagnose fluid accumulation in different gas fields, with an accuracy rate of 86.8%, and it can provide an accurate diagnosis for fluid accumulation in gas wells in different water-producing gas fields. Full article

Cuttings beds in horizontal wells significantly affect the frictional torque and drag along the drill string; however, their quantification and modeling have been relatively underexplored. To gain deeper insights into the impact mechanisms of the cuttings bed distribution on drilling mechanics, this study establishes a model linking the cuttings bed height with variations in axial and tangential forces on the drill string through experimental investigations. By integrating this model with previously developed transient cuttings transport and torque–drag models, a coupled transient hole cleaning and drill string mechanics model is constructed. This comprehensive model simulates the dynamic distribution of cuttings along the entire well trajectory and its influence on the drill string torque and drag. The results reveal that accumulated cuttings significantly reduce the weight on bit (WOB), increase the drill string torque, and cause problems related to a high equivalent circulation density (ECD). For long horizontal sections, the key to achieving effective hole cleaning lies in optimizing the design of the tripping circulation time to ensure that all cuttings are removed from the wellbore. Using the proposed coupled model, a methodology is developed to minimize the tripping circulation time by solving optimization problems within a constrained 2D domain, providing scientific guidance for drilling operations. The findings demonstrate that dynamically managing the cuttings distribution in the wellbore can significantly mitigate issues arising from insufficient hole cleaning, thereby ensuring drilling safety and efficiency. This study provides a scientific foundation for the optimized design of long horizontal well drilling operations and highlights the critical role of cuttings management in enhancing hole cleaning performance and mitigating drilling risks. Full article

In order to enhance the development efficiency of thick and complex carbonate reservoirs in the Middle East, a case study was conducted on M oilfield in Iraq. This study focused on reservoir characterization, injection-production modes, well pattern optimization, and other related topics. As a result, key techniques for the high-efficiency development of thick carbonate reservoirs were established. The research findings include the following: (1) the discovery of hidden “low-velocity” features within the thick gypsum-salt layer, which led to the development of a new seismic velocity model; (2) the differential dissolution of grain-supported limestones is controlled by lithofacies and petrophysical properties, resulting in the occurrence of “porphyritic” phenomena in core sections. The genetic mechanism responsible for reversing petrophysical properties in dolostones is attributed to “big hole filling and small hole preservation” caused by dense brine refluxing; (3) fracture evaluation technology based on anisotropy and dipole shear wave long-distance imaging was developed to address challenges associated with quantitatively assessing micro-fractures; (4) through large-scale three-dimensional physical models and numerical simulations, it was revealed that water–oil displacement mechanisms involving “horizontal breakthrough via hyper-permeability” combined with vertical differentiation due to gravity occur in thick and heterogeneous reservoirs under spatial injection-production modes; (5) a relationship model linking economic profit with well pattern density was established for technical service contracts in the Middle East. Additionally, an innovative stepwise conversion composite well patterns approach was introduced for thick reservoirs to meet production ramp-up requirements while delaying water cut rise; (6) a prediction technology for the oilfield development index, considering asphaltene precipitation, has been successfully developed. These research findings provide robust support for the efficient development of the M oilfield in Iraq, while also serving as a valuable reference for similar reservoirs’ development in the Middle East. Full article

In the process of mining, a large area of hard roof will be exposed above a goaf and may suddenly break. This can easily induce rock burst and has a significant impact on production safety. In this study, based on the engineering background of the hard roof of the 2102 working face in the Balasu coal mine, the spatial and temporal characteristics of the strain energy of the roof during the initial mining process were explored in depth. Based on a theoretical calculation, it is proposed that hydraulic fracturing should be carried out in the medium-grained sandstone layer that is 4.8–22.43 m above the roof, and that the effective fracturing section in the horizontal direction should be within 30.8 m of the cutting hole of the working face. The elastic strain energy fish model was established in FLAC^3D to analyze the strain energy accumulation of the roof during the initial mining process. The simulation and elastic strain energy results show that, as the working face advances to 70–80 m, the hard roof undergoes significant bending deformation. The energy gradient increases with the rapid accumulation of strain energy to a peak value of 140.54 kJ/m³. If the first weighting occurs at this moment in time, the sudden fracture of the roof will be accompanied by the release of elastic energy, which will induce rock burst. Therefore, it is necessary to implement roof cutting and pressure relief before reaching the critical step of 77 m. To this end, the comprehensive hydraulic fracturing technology of ‘conventional short drilling + directional long drilling’ is proposed. A field test shows that the hydraulic fracturing technology effectively weakens the integrity of the rock layer. The first weighting interval is 55 m, and it continues until the end of the pressure at the 70 m position. The roof collapses well, and the mining safety is improved. This study provides an important reference for hard roof control. Full article

Unconventional tight oil and gas resources, including shale oil and gas, have become the main focus for increasing reserves and production. The safe and efficient development of unconventional oil and gas is a crucial demand for the energy development strategy. Deep tight oil and gas resource development generally adopts horizontal well drilling methods. During drilling, especially in long horizontal sections, the high temperature frequently causes failures of downhole drilling tools and rotary steering tools. The temperature rises sharply during rock breaking with the drill bit. Existing wellbore heat transfer models do not fully consider the impact of heat generated by the drill bit on the wellbore temperature field. This paper aims to experimentally study the temperature rise law of the cutting tooth of the bottom polycrystalline diamond compact (PDC) bit during rock breaking. A set of evaluation devices was developed to study the temperature field distribution characteristics at the bottom of the PDC bit during rock breaking under different experimental conditions. The results indicate that the flow rate of drilling fluid, bit rotation speed, and weight on bit (WOB) significantly affect the distribution of the temperature field at the well bottom. This experimental research on the temperature field distribution characteristics at the bottom of the PDC bit during rock breaking helps reveal the heat transfer characteristics of the long horizontal section wellbore, guide the optimization of drilling parameters, and develop temperature control methods. It is of great significance for the advancement of efficient development technologies for unconventional resources in long horizontal wells. Full article

A Leica RTC360 laser scanner was investigated using a linear horizontal comparator system with four targets of different reflectance. Several thousand panorama scans were conducted along the 30 m long comparator, basically in 40 mm steps. For a selected target, more detailed investigations were carried out with a 2 mm step width for a 2 m wide section. The absolute offset between the scanner and the relative interferometer measurements was determined with a calibrated total station. The investigations revealed several systematic effects like an offset in the distance measurement of about 1.3 mm. Furthermore, sections with stochastic behavior as well as sections with pseudo-cyclic parts were observed, depending on the reflectance of the target. The deterministic sections showed curved and striped patterns with some discontinuities of about 2 mm at 20 m, resulting in a saw-tooth like pattern along the distances. Within all the experiments, the distance deviations were below the manufacturer specifications of the 3D point accuracy. However, it was demonstrated that the distance measurements had clear systematic components. In using these new findings, the specification of the measurement “noise” in the data sheet has to be seen as critical. Full article

In order to mitigate the risk of roof-dominated coal burst in underground coal mining, horizontal long borehole staged hydraulic fracturing technology has been prevailingly employed to facilitate the weakening treatment of the hard roof in advance. Such weakening effect, however, can hardly be evaluated, which leads to a lack of a basis in which to design the schemes and parameters of hydraulic fracturing. In this study, a combined underground–ground integrated microseismic monitoring and transient electromagnetic detection method was utilized to carry out simultaneous evaluations of the seismic responses to each staged fracturing and the apparent resistivity changes before and after all finished fracturing. On this basis, the comparable and applicable fracturing effects on coal burst prevention were evaluated and validated by the distribution of microseismic events and their energy magnitude during the mining process. Results show that the observed mining-induced seismic events are consistent with the evaluation results obtained from the combined seismic-electromagnetic detection method. However, there is a limited reduction effect on resistivity near the fractured section that induces far-field seismic events. Mining-induced seismic events are concentrated primarily within specific areas, while microseismic events in the fractured area exhibit high frequency but low energy overall. This study validates the rationality of combined seismic-electromagnetic detection results and provides valuable insights for optimizing fracturing construction schemes as well as comprehensively evaluating outcomes associated with underground directional long borehole staged hydraulic fracturing. Full article

Horizontal gas wells are one of the key technologies for the production of shale gas reservoirs. Compared with conventional gas reservoirs, horizontal shale gas wells have ultra-long and complex lateral sections. Overall, toe-up, toe-down, and horizontal trajectories will be exhibited in the lateral section. The statistical results of field production data indicate that the lateral trajectory has a significant impact on the estimated ultimate recovery. However, the mechanism has not yet been fully revealed owing to the complicated two-phase flow in lateral pipes. Therefore, taking horizontal shale gas wells’ lateral section as the research object, we designed our experimental parameter ranges based on horizontal shale gas wells in the Changning shale gas field. Simulation experimental tests were conducted on the pipe with an inclined angle from −15° to 15° to analyze the effects of different gas velocities, liquid velocities, and pipe inclinations on flow patterns and liquid holdup. Based on our observations and measurements, we evaluated the flow pattern prediction methods and drew a new flow pattern map for pipes with an inclined angle from −15° to 15°. Based on the momentum conservations between the gas and liquid phases and measured liquid holdup data, a new liquid holdup model was established in the pipes with inclined angle from −15° to 15°. Experimental and field-measured data were collected to verify the new method’s accuracy. Full article

Well structures with ultra-long sections have become one of the most applied technologies in the field of shale gas development. While there have been many technical challenges, enhancing the breaking efficiency and stability of polycrystalline diamond compact (PDC) bits has become an essential issue of focus. Since 2013, the well structure in the Duvernay area has been optimized multiple times, and the rate of penetration (ROP) of the entire wellbore has nearly doubled. However, there are significant differences in terms of the performances of different PDC bits, and there is still room for improvement to optimize these drill bits. For this reason, a confined compressive strength test was conducted to obtain the rock mechanical parameters from shale cores extracted from the long horizontal section. Using these data, a finite element model (FEM) was developed with a corresponding scale. A calibration of the elastic-plastic damage constitutive models was then performed using the FEM. The breaking mechanism of three different PDC bits was examined using a “PDC bit-bottom hole” interaction FEM model, facilitating guidance for bit selection and design optimization: (1) The type B PDC bit, which has four blades and 20 cutters, exhibited the highest mechanical specific energy (MSE) and the lowest vibration across three directional mechanical characteristics. This design is recommended for engineering applications. (2) Lower axial vibrations were produced when the CDE was used as the rear element when compared to those when using the BHE. However, an increase within an acceptable range was observed in the TOB and circumferential vibrations. Thus, for redesigning work on the type B bit, the assembly of the CDE is suggested. (3) A decrease in the MSE and vibration in three directional mechanical characteristics was observed when the depth of cut (DOC) was varied between 1.5 and 2.0 mm. A broadening in the range of lateral forces was noted when a DOC of 2.0 mm was used. Therefore, for the redesign of the type B bit, the assembly of CDEs as rear elements at a DOC of 1.5 mm is recommended. In conclusion, a new practical method for the selection and optimization of PDC bit design, based on rock mechanics and the FEM theory, is proposed. Full article

Successful matrix acidizing for extremely thick carbonate reservoirs with long horizontal well sections and strong heterogeneity requires efficient temporary plugging and diverting of acid fluid, ensuring acid fluid distribution to each production layer. Foamed-viscoelastic-surfactant (Foamed-VES) acid combines the benefits of both foam acid and viscoelastic surfactant (VES) acid, integrating foam plugging and viscous plugging. It can achieve uniform acid distribution in highly heterogeneous reservoirs. However, little research has been conducted on the wormhole propagation law of foamed-VES acid. To address this gap, this study established a mathematical model of foamed-VES acid wormhole propagation based on the dual-scale model. The model was coupled with a random porosity distribution generated with geological statistical software. The effects of different factors on foamed-VES acid etching were simulated. Numerical results show that foamed-VES acid can stimulate low-permeability reservoirs with a permeability differential of 20. Its inherent mechanism lies in the synergy of foam plugging and VES viscous plugging. This study enhances our understanding of the acid diversion mechanism of foamed-VES acid, providing a theoretical foundation for on-site acidizing treatment. Full article

The Weihe Fault is an important basement fault that is buried deep and controls the formation, evolution, and seismicity of the Weihe Basin. It has been quiescent for more than 300 years with only a few moderate and small earthquakes distributed unevenly. Therefore, it is necessary to investigate the current tectonic deformation pattern in order to assess regional seismic risk. In this context, the tectonic deformation velocities of the Weihe Fault were analyzed using an interferometric synthetic aperture radar (InSAR), a global navigation satellite system (GNSS) and leveling observations. The line of slight (LOS) deformation rates spanning from 2015 to 2019 were estimated from stacking-InSAR technology. Subsequently, the three-dimensional deformation rates in the north–south, east–west, and vertical directions were separated through the integration of GNSS-derived horizontal deformation and InSAR-derived LOS deformation. After that, the long-wavelength tectonic deformation was decomposed from the separated vertical deformation based on the spherical wavelet multiscale approach. Finally, the slip rate and locking depth were inverted for the assessment of the seismic hazard and tectonic activity of the Weihe Fault. The results show that the separated vertical deformation is consistent with the leveling observations, where the standard deviation between them is 1.69 mm/yr and the mean value is 0.6 mm/yr, demonstrating the reliability of the proposed method. The decomposed long-wavelength tectonic deformation exhibits uplift in the north and subsidence in the south, as well as the obvious vertical velocity gradient. The inversion result shows that the slip rate of the Weihe Fault gradually decreases from the west to the east, and the dip gradually increases from the west to the east, indicating a segmented activity and the geometric characteristics of the fault. The locking depth of the Weihe Fault gradually increases from the west (~5 km) to the east (~14 km), implying a higher stress accumulation and seismic risk on the eastern section of the fault. Taking into account the higher locking depth and frequent historical earthquakes on the eastern section of the Weihe Fault, further attention should be paid to the earthquake risk of the eastern section of the Weihe Fault. Full article

Problems such as well loss and collapses in deep shale gas drilling are most often due to the development of cracks in the shale formation, resulting in significant leaks of drilling fluid, the sticking and burrowing of drilling tools, and other engineering accidents. In addition, the horizontal sections of wells are very long and issues of friction, rock transport, and formation contamination loom large. As a result, the performance of drilling fluids directly affects drilling efficiency, engineering accident rates, and reservoir protection effects. We first analyze the mechanisms of each emulsifier in an oil-based drilling fluid formulation and the filtration reduction mechanisms, taking into account the collapse-prone and abnormally high-pressure characteristics of shale formations. We undertake an experimental evaluation and optimization of polymeric surfactants, such as primary and secondary emulsions for high-performance oil-based drilling fluids. The design of rigid and deformable nano-micron plugging materials with a reasonable particle size range was achieved, and we obtained a low Oil—Water ratio and high-density oil-based drilling fluid system, with temperature resistance of 200 °C, an Oil—Water ratio as low as 70:30, compressive fracturing fluid pollution of 10%, and a maximum density of 2.6 g/cm³. The reuse rate reached 100%. The developed oil-based drilling fluid system with strong plugging, a high density, and a low Oil—Water ratio suitable for deep shale gas can effectively seal the well wall, reduce liquid invasion, prevent the wall from collapsing, reduce mud leakage, reduce the consumption of oil-based drilling fluid, improve the utilization rate of old mud, and reduce drilling costs. Full article
