Search Results (56)

Wireless power transfer (WPT) systems are critical for enabling safe and efficient charging of inspection drones in flammable oilfield environments, yet existing solutions struggle with multi-target compatibility and reactive power losses. This study proposes a novel frequency-regulated LCC-S topology that achieves both constant current (CC) and constant voltage (CV) charging modes for heterogeneous drones using a single hardware configuration. By dynamically adjusting the operating frequency, the system minimizes the input impedance angle (θ < 10°) while maintaining load-independent CC and CV outputs, thereby reducing reactive power by 92% and ensuring spark-free operation in explosive atmospheres. Experimental validation with two distinct oilfield inspection drones demonstrates seamless mode transitions, zero-phase-angle (ZPA) resonance, and peak efficiencies of 92.57% and 91.12%, respectively. The universal design eliminates the need for complex alignment mechanisms, offering a scalable solution for multi-drone fleets in energy, agriculture, and disaster response applications. Full article

Viscoelastic materials are commonly used in civil engineering, biomedical sciences, and polymers, where understanding their creep and relaxation behaviors is essential for predicting long-term performance. This paper introduces an operator-based method for modeling viscoelastic materials, providing a unified framework to describe both creep and relaxation functions. The method utilizes stiffness and compliance operators, offering a systematic approach for analyzing viscoelastic problems. The operator-based method enhances the mathematical duality between the creep and relaxation functions, providing greater physical intuition and understanding of time-dependent material behavior. It directly reflects the intrinsic properties of materials, independent of input and output conditions. The method is extended to dynamic problems, with complex modulus and compliance derived through operator representations. The fractal tree model, with its constant loss factor across the frequency spectrum, demonstrates potential engineering applications. By incorporating a damage-based variable coefficient, the model now also accounts for the accelerated creep phase of rocks, capturing damage evolution under prolonged loading. While promising, the current method is limited to one-dimensional problems, and future research will aim to extend it to three-dimensional cases, integrate experimental validation, and explore broader applications. Full article

For the double-sided inductor–capacitor–capacitor (DS-LCC) compensation topology, the parametric deviation of compensation elements results in the mismatch between the resonant frequency and operating frequency. Furthermore, this mismatch leads to the loss of the load-independent constant output characteristics. Therefore, an innovative design approach based on the reduction in the capacitance ratio is proposed to attain the load-independent constant current under the parametric deviation. With the presented method, simply by reducing the compensation capacitor ratio, the load-independent constant current output characteristics can be preserved, and fluctuations in the transmission gain caused by the parametric deviation are minimized. This implies that when the constant transmission gain is achieved by the frequency modulation (FM) control, the required FM range can be reduced. Finally, from the experimental results, in the load range of 3 Ω to 33 Ω, compared to the high capacitance ratio, the load-independent constant current characteristics can be maintained at the low capacitance ratio. In addition, without parametric deviation, the transmission efficiencies at different capacitance ratios are basically the same at 93.5% and 94.2%, respectively. However, the transmission efficiencies under different parametric deviations at the low capacitance ratio are 87.4% and 84.9%, but only 73.9% and 68.2% at the high capacitance ratio. Full article

Based on the requirement of the Antarctic Space Physics Observatory (ASPO) for a clean energy supply, this study proposes a clean energy generation system incorporating proton exchange membrane fuel cells (PEMFCs) within a “wind–solar–hydrogen-storage-load” framework, which complements inherent wind and solar power generation modes. Addressing the paucity of hydrogen low-temperature coupled-power-supply technology in renewable energy systems, and the insufficient accuracy of data monitoring and system control, electric power output and thermal balance models of PEMFCs are presented, and an analysis of PEMFCs’ operating mechanism was conducted. Simulations of a PEMFC’s internal mechanisms were carried out to address its need for reliable energy supply needs. Furthermore, a real-time monitoring and control strategy is proposed to obtain the operational status of a PEMFC power generation system. The monitored data exhibited high accuracy, with the error between the monitoring parameters and set values being less than 1%, including the voltage, current, electric power, temperature, and speed of the fans. These data are better than the monitoring error of the electrical parameters in Antarctica which is higher than 5%, fulfilling PEMFCs’ requirement for real-time monitoring of their operational parameters, which is necessary for their reliable operation. This precise control lays the foundation for the application of PEMFCs in energy systems at independent Antarctic observatory stations. Full article

The diverse array of sensors deployed on meteorological observation towers, tasked with the observation of meteorological gradients, requires distinct power supplies and effective power regulation. In this article, a multi-frequency, multi-receiver (MFMR) inductively coupled power transfer (ICPT) system using a time-sharing frequency strategy is proposed, which enables coupled power transfer to multiple nodes through only one cable. The time-sharing frequency control (TSFC) method is introduced to produce time-sharing multi-frequency currents. By incorporating a controllable resonant capacitor array at the transmitter, the system can operate at various resonance frequencies over specific intervals, allowing it to supply power to multiple loads with unique resonance frequencies. First, an in-depth analysis of the power transmission characteristics of MFMR-ICPT systems is conducted, with the three-frequency, three-receiver (TFTR) ICPT system circuit serving as an example. The frequency cross-coupling effects are then analyzed, and the TSFC method is explained. Finally, experiments are conducted on a TFTR-ICPT system. The results demonstrated that independent power regulation of multiple loads could be achieved by adjusting the duty cycle of different frequency input voltages through the time-sharing frequency strategy. The system achieved a total power output of 38.7 W, with an efficiency of 64.8%. Full article

The integration of hybrid alternating current (AC) and direct current (DC) networks has gained relevance due to the growing demand for more flexible, efficient, and reliable electrical systems. A key aspect of this integration is the parallelization of power converters, which presents several technical challenges, such as current sharing imbalances, circulating currents, and control complexity. This paper proposes a distributed control architecture for parallel resonant CLLC dual active bridge (DAB) converters to address these issues in hybrid AC–DC networks and microgrids. The approach includes a master voltage controller to regulate the output voltage and distributed local current controllers to ensure load balance. The approach minimizes the difference between the output and input voltages, allowing for independent control of power flow. Simulation and experimental results show significant improvements. The system stability has been demonstrated experimentally. Transient response has been improved with response time 80% lower using the feed-forward term. The system maintained stability with current sharing deviations below 3% under full and low load conditions. Finally, scalability is ensured by the proposed distributed controller because the central power controller is not affected by the number of units in parallel used in the application. This solution is suitable for advanced hybrid networks and microgrid applications. Full article

The constant current followed by constant voltage (CC-CV) charging method is commonly employed for battery charging, effectively extending battery life and reducing charging time. However, as charging progresses, the battery’s internal resistance increases, complicating the charging circuit. This paper designs a wireless power transfer system utilizing an LCL coupling network for battery charging. The system employs frequency modulation (FM) to manage its CC and CV output characteristics at two fixed frequency points. The influence of the LCL coupling network parameters on system output characteristics was investigated using MATLAB. A simulation model was developed in the PSIM environment to validate the CC and CV output characteristics. The simulation results show that the system has load-independent constant-current and constant-voltage characteristics at two different frequency points. In order to verify the theoretical analysis, an experimental platform was also established. Experimental results demonstrate that the proposed system operates effectively in CC mode, maintaining constant output current across various loads, while in CV mode, it effectively regulates output voltage for different loads. The designed frequency modulation controller ensures a rapid response to sudden changes in load resistance, regardless of operating in CC or CV modes. Full article

This paper presents an efficiency optimization method for laser wireless power transmission (LWPT) system, focusing on the coordination and control of multiple laser diodes. A distributed laser wireless power transmission (D-LWPT) system is proposed, which includes multiple independent and parallel power transmission chains. The system has the characteristics of power scalability, redundancy, and control flexibility. The efficiency characteristics of each key component in the LWPT system are discussed. Due to the internal losses of the laser, the transmission efficiency is also affected by the transmission power. For distributed architecture, its flexibility allows for the rational allocation of transmission power. To achieve optimal efficiency, a central scheduling controller is designed to regulate the current of LDs. A swarm intelligence-based optimization algorithm is used to determine the optimal operating current. This significantly improves the system’s efficiency and ensures real-time control. Experimental results validate the effectiveness of the proposed techniques. The DC to DC efficiency of the power transmission chain can reach over 14%, and the photovoltaic array can output a maximum power of over 130 W. The impact of beam combination on the efficiency and output power of PV arrays is less than 3%, indicating that the distributed structure does not affect system performance. The experimental results show that the proposed efficiency optimization method has excellent power following performance (algorithm execution time < 10 ms) and effective efficiency optimization performance. Under light load conditions, the LDs’ efficiency is optimized from 27.5% to 45.0%, and under medium load conditions, it is optimized from 41.5% to 44.5%. This distributed structure and efficiency optimization method provide a solution for improving the performance of LWPT systems. Full article

In an underground inductive power transfer (IPT), it is inevitable to produce the phenomenon of misalignment between the transmitter and the receiver, which will reduce the output current, voltage and output efficiency of the whole IPT system. Aiming to solve this problem, a universal hybrid coupler is proposed, which can still stabilize the output in the expected range and has the ability of anti-misalignment when the X and Z directions are misaligned. The coupler is composed of a BP coupler and $\Gamma$ type network. The secondary edge of the coupler introduces a $\Gamma$ network, which decouples the two main coils on the same side of the receiver from the auxiliary coil and reduces the complexity of the system. The coupler can effectively reduce the coupling fluctuation caused by physical movement between the downhole transmitting end and the receiving end, thereby ensuring the stable output of the coupler. As a widely used IPT system, it can access the rest of the circuit topology whose output is independent of the load and achieve misalignment-tolerant output. Finally, based on the proposed hybrid IPT coupler theory, a 500 W misalignment-tolerant coupler prototype was built, and the compensation topologies were configured as series–series (SS) and series/inductance/capacitance/capacitor (S/LCC) structures. When the X and Z direction is misaligned, the constant current and voltage independent of the load can be output by switching the compensation topology. The experimental results are the same as the theoretical analysis. Full article

The intersectional relationship in bridge health monitoring refers to the mapping function that correlates bridge responses across different locations. This relationship is pivotal for estimating structural responses, which are then instrumental in assessing a bridge’s service status and identifying potential damage. The current research landscape is heavily focused on high-frequency responses, especially those associated with single-mode vibration. When it comes to low-frequency responses triggered by multi-mode vehicle loading, a prevalent strategy is to regard these low-frequency responses as “quasi-static” and subsequently apply time-series prediction techniques to simulate the intersectional relationship. However, these methods are contingent upon data regarding external loading, such as traffic conditions and air temperatures. This necessitates the collection of long-term monitoring data to account for fluctuations in traffic and temperature, a task that can be quite daunting in real-world engineering contexts. To address this challenge, our study shifts the analytical perspective from a static analysis to a dynamic analysis. By delving into the physical features of bridge responses of the vehicle–bridge interaction (VBI) system, we identify that the intersectional relationship should be inherently time-independent. The perceived time lag in quasi-static responses is, in essence, a result of low-frequency vibrations that are aligned with driving force modes. We specifically derive the intersectional relationship for low-frequency bridge responses within the VBI system and determine it to be a time-invariant transfer matrix associated with multiple mode shapes. Drawing on these physical insights, we adopt a time-independent machine learning method, the backpropagation–artificial neural network (BP-ANN), to simulate the intersectional relationship. To train the network, monitoring data from various cross-sections were input, with the responses at a particular section designated as the output. The trained network is now capable of estimating responses even in scenarios where time-related traffic conditions and temperatures deviate from those present in the training data set. To substantiate the time-independent nature of the derived intersectional relationship, finite element models were developed. The proposed method was further validated through the in-field monitoring of a continuous highway bridge. We anticipate that this method will be highly effective in estimating low-frequency responses under a variety of unknown traffic and air temperature conditions, offering significant convenience for practical engineering applications. Full article

This article presents an integrated double-sided inductance and double capacitances (DS-LCC) compensation based dual-frequency compatible wireless power transfer (WPT) system. A cascaded single-phase multi-frequency inverter (CSMI) is constructed to generate the independent dual-frequency power transfer signals. In order to achieve the load-independent constant-current output (CCO) at two frequencies, an integrated DS-LCC compensated topology is reconstructed. By configuring the frequency-selective resonating compensation (FSRC) network in the primary side, the power transfer signals at two frequencies can be superimposed into a single transmitting coil, reducing the cost and volume of the system. Furthermore, to implement zero-voltage switching (ZVS) of the CSMI throughout the entire power range, a general parameter design method of the proposed system is also introduced. A 1.5-kW experimental prototype is built to validate the practicability of the presented dual-frequency compatible WPT System. The system can supply power to different loads at two frequencies simultaneously with CCO and ZVS properties. The peak efficiency reaches 91.75% at a 1.2-kW output power. Full article

With the high integration of power electronic devices, wireless power transfer (WPT) systems are required to have output characteristics of different specifications that are independent of the load. However, existing methods for realizing dual-output WPT systems have problems such as complex circuits, cumbersome control schemes, low system stability, insufficient system space utilization, and unnecessary cross-coupling. Therefore, in order to solve the above problems, this paper proposes a dual-receiver WPT system with dual constant current (CC) output based on an integrated decoupling coil. In this system, the DD coil is wound vertically in series with the solenoid coil and serves as the first receiving coil to achieve energy transmission in the system. While the solenoid coil is used in the transmitting coil and the second receiving coil, and the coils are perpendicular to each other to achieve natural decoupling. Furthermore, the receiving coils are integrated together on the receiving side ferrite plate. Therefore, there is no cross-coupling interference in the system, which simplifies the system design. Firstly, the natural decoupling characteristics of the magnetic coupler and the coil optimization method are analyzed in detail theoretically. Secondly, a detailed mathematical analysis is performed on the dual CC output characteristics with different specifications that are load-independent and have zero phase angle operation. Again, the zero voltage switching of the inverter can be achieved by changing the compensation component parameters through simulation verification. Finally, a prototype with a rated power of 283 W is constructed for validation purposes. The first receiver delivers a CC output of 3 A, while the second receiver provides a CC output of 4 A, with the DC–DC conversion efficiency reaching a peak of 90.2%. The experimental results confirm the accuracy of the theoretical analysis. Full article

The increasing penetration of renewable energy sources (RESs) in transmission and distribution systems presents several challenges for grid operators. In particular, the unpredictable behavior of RESs can disrupt the balance between energy production and load demand, potentially affecting the stability of the entire system. Grid-connected energy storage systems (ESSs) offer a possible solution to manage the uncertainty associated with RESs. In fact, ESSs exchange power with the grid through the adoption of suitable energy management strategies, which are typically implemented by power electronics-based grid interfaces. Unlike other current source converter (CSC) solutions described in the literature, which only interface with a single energy storage device, this paper introduces a novel topology for a three-phase delta-type current source converter (D-CSC), which is capable of integrating three independent ESSs using the same number of semiconductors as traditional CSC solutions. Thus, it considerably enhances the flexibility of a power conversion system (PCS) without increasing the number of converter components. In addition, an innovative energy management control strategy is also introduced. This strategy enables the D-CSC to compensate for energy imbalances arising between the three ESSs, which might be caused by several factors, such as different aging characteristics, converter component tolerances, operating conditions, and temperature drifts. Hence, the D-CSC-based interface is capable of proper grid operation even if the three ESSs have different characteristics, thus opening the possibility of employing this converter to integrate both first and second-life devices. First, the topology of the proposed D-CSC is introduced, followed by a detailed mathematical description of its control strategy. The proper grid operation of the D-CSC was tested under different scenarios, considering the grid integration of three independent superconducting magnetic energy storage systems in a marine vessel. The proposed D-CSC is compared to traditional CSC solutions, highlighting the superior performances of the novel converter topology in terms of efficiency, total harmonic distortion of the output currents, and overall cost reduction for the PCS. Full article

Resultant hip joint forces can currently only be recorded in situ in a laboratory setting using instrumented total hip replacements (THRs) equipped with strain gauges. However, permanent recording is important for monitoring the structural condition of the implant, for therapeutic purposes, for self-reflection, and for research into managing the predicted increasing number of THRs worldwide. Therefore, this study aims to investigate whether a recently proposed THR with an integrated piezoelectric element represents a new possibility for the permanent recording of hip joint forces and the physical activities of the patient. Hip joint forces from nine different daily activities were obtained from the OrthoLoad database and applied to a total hip stem equipped with a piezoelectric element using a uniaxial testing machine. The forces acting on the piezoelectric element were calculated from the generated voltages. The correlation between the calculated forces on the piezoelectric element and the applied forces was investigated, and the regression equations were determined. In addition, the voltage outputs were used to predict the activity with a random forest classifier. The coefficient of determination between the applied maximum forces on the implant and the calculated maximum forces on the piezoelectric element was R² = 0.97 (p < 0.01). The maximum forces on the THR could be determined via activity-independent determinations with a deviation of 2.49 ± 13.16% and activity-dependent calculation with 0.87 ± 7.28% deviation. The activities could be correctly predicted using the classification model with 95% accuracy. Hence, piezoelectric elements integrated into a total hip stem represent a promising sensor option for the energy-autonomous detection of joint forces and physical activities. Full article
