The present reported work deals with the preparation of an energy-efficient smart window based on liquid crystal (LC) using a polymer-dispersed liquid crystal (PDLC) technique. The smart window was prepared using an LC–polymer composite by mixing photopolymer NOA-71 into nematic liquid crystal (NLC) 4-cyano-4’-pentylbiphenyl (5CB). The liquid crystal cell was prepared, the LC–polymer composite was filled inside the cell, and voltage was applied after the exposure of ultraviolet (UV) light. Textural analysis was carried out, and microscope images were taken out with the variation in voltage. Optical measurements were also performed for the smart window based on the PDLC system. Threshold voltage and saturation voltages were measured to carry out the operating voltage analysis. Transmittance was measured as a function of wavelength at different voltages. An absorbance study was also performed, varying the voltage and wavelength. The change in the power of the laser beam passing through the prepared smart window as a function of voltage was also investigated. The working of a prepared smart window using liquid crystal and a photopolymer composite is also demonstrated in opaque and transparent states in the absence and presence of voltage. The output of the present investigation into a PDLC-based smart window can be useful in the applications of adaptive or light shutter devices and in aerospace technology, as it shows the dual nature of opaque and transparent states in the absence and presence of electric field. Full article

Modern applications of molecular liquid crystals span from high-resolution displays for augmented and virtual reality to miniature tunable lasers, reconfigurable microwave devices for space exploration and communication, and tunable electro-optical elements, including spatial light modulators, waveguides, lenses, light shutters, filters, and waveplates, to name a few. The tunability of these devices is achieved through electric-field-induced reorientation of liquid crystals. Because the reorientation of the liquid crystals can be altered by ions normally present in mesogenic materials in minute quantities, resulting in their electrical resistivity having finite values, the development of new ways to control the concentration of the ions in liquid crystals is very important. A promising way to enhance the electrical resistivity of molecular liquid crystals is the addition of nano-dopants to low-resistivity liquid crystals. When nanoparticles capture certain ions, they immobilize them and increase their resistivity. If properly implemented, this method can convert low-resistivity liquid crystals into high-resistivity liquid crystals. However, uncontrolled ionic contamination of the nanoparticles can significantly alter this process. In this paper, building on our previous work, we explore how physical parameters such as the size of the nanoparticles, their concentration, and their level of ionic contamination can affect the process of both enhancing and lowering the resistivity of the molecular liquid crystals. Additionally, we analyze the use of two types of nano-dopants to achieve better control over the electrical resistivity of molecular liquid crystals. Full article

The applications of liquid crystals continue to expand. They include conventional and advanced liquid crystal displays, electrically controlled lenses, tunable optical elements such as filters, light shutters, waveplates, and spatial light modulators, smart windows and sensors, and reconfigurable antennas and microwave devices, to name a few. As a rule, liquid crystal devices are controlled by applying an external electric field. This field reorients liquid crystals in a desirable way, thus leading to the tunability of their physical properties. The electric-field-induced reorientation of liquid crystals can be affected by ions typically present in molecular liquid crystals. In the case of liquid crystal displays, ions in liquid crystals can lead to image sticking, a reduced voltage holding ratio, and altered electro-optical performance. Therefore, the development of efficient ways to better control ions in liquid crystal devices is of utmost importance to existing and future liquid crystal technologies. In this paper, we discuss how nanomaterials can affect the electrical properties of molecular liquid crystals. In general, nanomaterials in molecular liquid crystals can behave as ion-capturing objects or act as a source of ions. Ion-capturing nanomaterials in molecular liquid crystals can enhance their electrical resistivity. On the other hand, ion-releasing nanoparticles can lead to the opposite effect. By considering the competition between two nanoparticle-induced ionic processes, namely the ion capturing and ion releasing effects, the electrical resistivity of liquid crystals can be controlled in a desirable way. Full article

Polymer-dispersed liquid-crystal (PDLC) films have wide applications in light shutters, smart windows for cars and buildings, dimming glasses, and smart peep-proof films due to their switchable optical states under electrical fields as well as large area processibility. They are usually prepared with liquid crystals (LCs) and non-liquid crystalline monomers (NLCMs). Introduction of liquid crystalline monomers (LCMs) into PDLCs might spark new functionality or high-performance devices such as polymer-dispersed and -stabilized liquid crystals. In this study, the effect of molecular structures and doping concentrations of acrylate LCMs on the electro-optical properties and micro-structures of PDLC films is systematically studied. The pore size of polymer networks and the driving voltage of the PDLC films are affected by the molecular polarity and degree of functionality of the LCMs. The electro-optical properties of the PDLC films are affected by the synergistic influence of molecular structure of LCMs and micro-structures of PDLCs. These results might provide the experimental and theoretical basis for constructing the relationship between the molecular structure of LCM, micro-structure and electro-optical response of PDLC films. Full article

The performance of a Fe:ZnSe laser was investigated in different schemes of excitation by a pulsed diode side-pumped Er:YAG laser. At the temperature of liquid nitrogen, the Fe:ZnSe laser, pumped by a free running 360-μs Er:YAG laser and demonstrated a pulse energy of 53 mJ with a slope efficiency of 42% relative to absorbed pump energy. When operating at room temperature, two optical schemes were considered. In the first one, the Fe:ZnSe laser crystal was pumped by a Q-switched Er:YAG laser with a passive shutter based on an additional Fe:ZnSe crystalline plate, and the cavities of both lasers were independent. In the second scheme, the cavities of the Fe:ZnSe and Er:YAG lasers were coupled, and the Fe:ZnSe crystal simultaneously served as an active element of the Fe:ZnSe laser and a passive shutter of the Er:YAG laser. Pulses with a duration of less than 200 ns and an energy of ~1 mJ were obtained from the Fe:ZnSe laser with a repetition rate of up to 50 kHz. The experimental waveforms of the laser pulses were approximated by rate equations. Full article

Bistable liquid crystal (LC) shutters have attracted much interest due to their low energy consumption and fast response time. In this paper, we demonstrate an electrically tunable/switchable biostable LC light shutter in biological optics through a three–step easy–assembly, inexpensive, multi–channel shutter. The liquid crystal exhibits tunable transparency (100% to 10% compared to the initial light intensity) under different voltages (0 V to 90 V), indicating its tunable potential. By using biomedical images, the response time, resolution, and light intensity changes of the LC under different voltages in three common fluorescence wavelengths are displayed intuitively. Particularly, the shutter’s performance in tumor images under the near–infrared band shows its application potential in biomedical imaging fields. Full article

The directionality of optical signals provides an opportunity for efficient space reuse of optical links in visible light communication (VLC). Space reuse in VLC can enable multiple-access communication from multiple light emitting transmitters. Traditional VLC system design using photo-receptors requires at least one receiving photodetector element for each light emitter, thus constraining VLC to always require a light-emitter to light-receptor element pair. In this paper, we propose, design and evaluate a novel architecture for VLC that can enable multiple-access reception using a photoreceptor receiver that uses only a single photodiode. The novel design includes a liquid-crystal-display (LCD) based shutter system that can be automated to control and enable selective reception of light beams from multiple transmitters. We evaluate the feasibility of multiple access on a single photodiode from two light emitting diode (LED) transmitters and the performance of the communication link using bit-error-rate (BER) and packet-error-rate (PER) metrics. Our experiment and trace based evaluation through proof-of-concept implementation reveals the feasibility of multiple LED reception on a single photodiode. We further evaluate the system in controlled mobile settings to verify the adaptability of the receiver when the LED transmitter changes position. Full article

We reported electrical circuit modeling to analyze the optical performance degradation in an ion-doped liquid-crystal (LC) cell, which exhibited advantages, such as excellent optical performance and simple switching process, but suffered from long-term reliability issues. When an electric field was applied to the cell for an extended period of time, the optical performance became nonuniform, and the haze in the opaque state decreased. By measuring the impedance and fitting the measured data by using an equivalent circuit model, we confirmed the changes of the parameters in the electrochemical impedance spectroscopy and electrophysical properties of the ion-doped LC cell with time. According to the measurement of the optical and physical characteristics, the optical performance degradation was caused mainly by the ionic materials. Full article

The research field of liquid crystals and their applications is recently changing from being largely focused on display applications and optical shutter elements in various fields, to quite novel and diverse applications in the area of nanotechnology and nanoscience. Functional nanoparticles have recently been used to a significant extent to modify the physical properties of liquid crystals by the addition of ferroelectric and magnetic particles of different shapes, such as arbitrary and spherical, rods, wires and discs. Also, particles influencing optical properties are increasingly popular, such as quantum dots, plasmonic, semiconductors and metamaterials. The self-organization of liquid crystals is exploited to order templates and orient nanoparticles. Similarly, nanoparticles such as rods, nanotubes and graphene oxide are shown to form lyotropic liquid crystal phases in the presence of isotropic host solvents. These effects lead to a wealth of novel applications, many of which will be reviewed in this publication. Full article

Low-threshold-voltage (V_th) and electrically switchable, polarization-selective scattering mode light shutters (PSMLSs) using polymer-dispersed liquid crystals (PDLCs) are demonstrated in this work. The optimized weight ratio of the nematic liquid crystals (LCs) to the adopted monomer (NBA107, Norland Optics) in the low-V_th PDLCs based on NBA107 is 7:3, [7:3]-PDLCs_NBA107. The properties of the low-V_th PDLCs_NBA107, such as light-scattering performance, initial transmission, V_th, and droplet size were investigated. Experiment results show that the surface anchoring (threshold-voltage) of NBA107 is weaker (lower) than or equal to that of the common NOA65. The cost is that the response time of the proposed PDLCs_NBA107 is relatively long. A method to reduce the decay time, which can be applied to all other PDLC devices, will be elucidated. In addition to the low V_th of the proposed PDLCs_NBA107, the operation voltage (~6 V_rms) to approach the maximum transmission is relatively low in a 7 μm-thick PDLCs_NBA107 cell. Moreover, the polarization-selective light-scattering performances of the proposed PSMLSs based on the [7:3]-PDLCs_NBA107, mainly driven by in-plane and vertical fields, are also demonstrated. Full article

This study proposes a hybrid structure for a one-dimensional (1D) photonic crystal (PC) comprising a tristable cholesteric liquid crystal (CLC) as the defect layer. The CLC exhibits three optically stable states: the Grandjean planar (P), focal conic (FC), and uniform lying helix (ULH) configurations. Specifically, the reflection band of the CLC is set within the photonic bandgap (PBG) of the 1D PC. While the ULH and the FC states can be regarded as the light-on and light-off states for defect-mode peaks in the visible spectrum, respectively, switching the device from the ULH to the P state enables suppression of the transmission of partial defect modes within the PBG. This device possesses many alluring features, such as optical tristability at null applied voltage and transmission tunability of the defect modes, providing a new pathway for the design of multifunctional and energy-efficient optical switches, light shutters, multichannels, and wavelength selectors. Full article

IR sensor synchronizing active shutter glasses for three-dimensional high definition television (3D HDTV) were developed using a flexible liquid crystal (FLC) lens. The FLC lens was made on a polycarbonate (PC) substrate using conventional liquid crystal display (LCD) processes. The flexible liquid crystal lens displayed a maximum transmission of 32% and total response time of 2.56 ms. The transmittance, the contrast ratio and the response time of the flexible liquid crystal lens were superior to those of glass liquid crystal lenses. Microcontroller unit and drivers were developed as part of a reception module with power supply for the IR sensor synchronizing active shutter glasses with the flexible liquid crystal lens prototypes. IR sensor synchronizing active shutter glasses for 3D HDTV with flexible liquid crystal lenses produced excellent 3D images viewing characteristics. Full article

The capture of covert spatial attention by salient visual events influences subsequent gaze behavior. A task irrelevant stimulus (cue) can reduce (Attention capture) or prolong (Inhibition of return) saccade reaction time to a subsequent target stimulus depending on the cue-target delay. Here we investigated the mechanisms that underlie the sensory-based account of AC/IOR by manipulating the visual processing stage where the cue and target interact. In Experiment 1, liquid crystal shutter goggles were used to test whether AC/IOR occur at a monocular versus binocular processing stage (before versus after signals from both eyes converge). In Experiment 2, we tested whether visual orientation selective mechanisms are critical for AC/IOR by using oriented “Gabor” stimuli. We found that the magnitude of AC and IOR was not different between monocular and interocular viewing conditions, or between iso- and ortho-oriented cue-target interactions. The results suggest that the visual mechanisms that contribute to AC/IOR arise at an orientation-independent binocular processing stage. Full article

We demonstrate a polarizer-free electro-optical switch using dye-doped liquid crystal (LC) gels. The mechanism of dye-doped LC gels mainly involves the combination of polymer scattering and dye absorption. However, the domain size of polymer networks, dye concentration, LC concentration, and fabrication process can all affect the phase separation process and thus result in dye-doped LC gels with different electro-optical performance. We have studied experimentally the factors which can affect the dye-doped LC gels. The potential applications for dye-doped LC gels are flexible displays and electrically tunable light shutters. Full article
