A new lift enhancement scheme is designed for the cruise flight process of a tail-sitter UAV (Unmanned Aerial Vehicle), proposing a fusion configuration with embedded grid channels on the duct wall. The low pressure zone at the lip of the duct is induced to expand through the grid channels, forming a significant force component difference with the non-grid side, thereby generating significant lift effects for the propeller of the ducted fan during level flight. Taking a ducted fan system as an example, a design method for embedding grids into the ducted wall is established. By using the sliding mesh technique to simulate propeller rotation, the effects of annular distribution angle, grid channel width, circumferential and flow direction grid quantity on its aerodynamic performance are evaluated. The results indicate that the ducted fan embedded in the grid can generate a lift about 22.16% of total thrust without significantly affecting thrust and power characteristics. The increase in circumferential distribution angle increases within a reasonable range and benefits the lift of the propeller. However, the larger the grid width, the more it affects the lip and tail of the duct. Ultimately, the overall effect actually deteriorates the performance. The number of circumferential grids has a relatively small impact. As the number of flow grids increases, the aerodynamic characteristics of the entire fusion configuration significantly improves, due to its favorable induction of airflow at the lip and tail of the duct, as well as blocking the dissipation of blade-tip vortices. Full article

Metal inert gas (MIG) brazing was used to join galvanized thin sheets with thicknesses in the range of 0.8 to 2 mm in a lap joint configuration using CuAl₈ wire as filler. The process was used to manufacture built-up cold-formed steel beams composed of corrugated steel webs and flanges made from thin-walled cold-formed steel lipped channel profiles. The effect of heat input and sheet thickness on joint properties, such as macro- and microstructure, wettability, and mechanical characteristics such as microhardness and tensile strength were investigated. The bead geometry was assessed by studying the wettability of the filler material. The microstructure was investigated by digital and scanning electron microscopy, and the composition in the heat-affected zone (HAZ), interface, and bead was determined by energy dispersive spectroscopy. Formation of Fe–Al intermetallics was observed in the bead at the bead–base material interface. Some pores were noticed that formed due to the evaporation of the zinc coating. The bead shape and mechanical properties were found to be the best when 1.2 and 2 mm sheets were brazed using a heat input of 121.4 J/mm. This suggests that not only the heat input but also the thickness of the sheet metal play a crucial role in the production of MIG brazed joints. Full article

The sliding suction robots designed for wall-climbing functions could have accuracy defects due to suction cup sealing, friction interference, and surface adaptability. Hence, this work develops a biomimetic, flexible, sliding suction cup suitable for crawling on curved surfaces. Inspired by the hypostomus plecostomus’s mouth, we designed a biomimetic low-contact force flow channel structure and a matrix of friction-reducing protrusions along the lip edge of the sliding suction cup. This design reduces frictional resistance on the sliding interface and the flexible nature of the suction cup, allowing it to be used on curved or vertical surfaces of different materials. Several simulation-based optimization analyses and experimental tests are conducted on the biomimetic low-contact force flow channel structure, and various structural design principles are explored for achieving high adhesion and low-contact force. Additionally, a friction reduction model for the matrix structure is designed to verify the effects of parameters such as load, protrusion size, and quantity on the friction coefficient of the matrix structure surface through friction tests. The sliding suction cup prototype presents an average crawling speed of about 0.4 m/s on a horizontal plane and 0.7 m/s for crawling on vertical walls and the inner surface of a cylindrical rail. Full article

This study investigates the toughness and load capacity of various innovative beam configurations of cold-formed steel beams (CFSB) using both ordinary concrete slabs and engineered cementitious composite (ECC) slabs. A finite element analysis with ABAQUS 20 was conducted on double-channel, sigma, G, and omega sections, both with and without inverted lips, as well as the effects of L, channel, and trapezoidal stiffeners and length-to-depth ratios. The double-omega section with ordinary concrete achieved the highest first peak load of 365.2 kN and a toughness increase of 181.1%. Inverted lips enhanced toughness in the double-G and sigma sections, with increases of 156.9% and 158.3%, respectively. Among ECC configurations, the double-omega section with ECC3 slab reached 387.4 kN and a toughness increase of 199.5%. Thinner ordinary concrete sections (70 mm and 90 mm) negatively impacted toughness, emphasizing the need for adequate thickness. Trapezoidal stiffeners also improved toughness. These findings highlight the importance of geometrical design and material selection in optimizing CFSB performance, offering valuable insights for future design practices. Full article

This study conducted experiments to investigate the flexural behavior of steel–concrete composite beams with U-shaped sections, utilizing cold-formed lipped channels as web components. To enhance both flexural and shear performance, trapezoidal plates were added to the lower sides of the composite beams. A total of ten specimens were fabricated, with variables defined according to the following criteria: presence of bottom tension reinforcement and bottom studs, thickness of the trapezoidal side plates (6 mm and 8 mm), and the welding method. Four-point bending tests were conducted, and all specimens exhibited typical flexural failure at the ultimate state. Specimens with bottom tension reinforcement, specifically those in the H5-T6 and H5-T8 series, demonstrated increases in ultimate load of 28.8% and 33.5%, respectively, compared to specimens without tension reinforcement. The use of lipped channels enabled full composite action between the concrete and the steel web components, eliminating the need for stud anchors. Additionally, it was confirmed that the plastic neutral axis, reflecting the material test strengths, was located within the concrete slab as intended. This study also compared the design flexural strengths, calculated using the yield stress distribution method from structural steel design standards such as AISC 360 and KDS 14, with the experimental flexural strengths. The comparison was used to evaluate the applicability of current design standards. Full article

A short tribute to pioneers in the development of the plastic design of metal thin-walled cross-sections is presented. This large study investigates altogether fourteen steel and four extruded aluminum cross-sections in detail. Six groups of the cross-sections with various shapes consist of four I-shaped doubly symmetric sections with or without lips; three monosymmetric sections with an axis of symmetry z including T- and diamond sections; four monosymmetric channels with or without lips; two point-symmetric Z-sections; and four asymmetric sections. The four extruded aluminum cross-sections are an I 200a section, a diamond section, and closed oblique and irregular sections. For all 18 cross-sections, the plastic section moduli of three kinds were calculated, namely W_pl,y,nB and W_pl,z,nB for bimoment not considered as a constraint; W_pl,y, W_pl,z, and W_pl,w for bimoment considered as a restraint; and maximum values W_pl,y,max, W_pl,z,max, and W_pl,w,max. The values of cross-section plastic resistances N_pl, M_pl,y,Rd, M_pl,z,Rd, and B_pl are calculated in numerical examples too. The values of cross-section properties are calculated in different ways to verify the correctness of the results. The following methods of calculation are used: the rules given in Eurocode EN 1993-1-1:2022; MathCad programs; and freeware. Recommendations for educational institutes and designers in practice are given, including simple formulae for all cross-sectional properties for doubly and monosymmetric I-shaped sections, channels, and Z-sections. The formulae are presented in three tables containing formulae in dimensionless form convenient for parametrical studies and formulae for direct design. The background of the Eurocode rules given in EN 1993-1-1:2022 is explained together with recommendations for how to avoid the problems with using them. Full article

To enhance the efficiency of irrigation water utilisation, China is progressively converting irrigation ditches into pipelines. The water distribution outlets in irrigation zones are predominantly right-angled, and there are typically occurrences of erosion, sedimentation, and structural deterioration in the surrounding areas. This article employs a synthesis of indoor physical model experiments and theoretical analysis to examine the distribution of channel flow velocity and variations in water surface profile, pipeline flow rate, diversion ratio, circulation intensity, and turbulence energy across different relative water depths. The experimental results indicate that the water surface adjacent to the main canal wall demonstrates a pattern of initial decline, followed by an increase and subsequently another decline; furthermore, as the water level in the main channel rises, the magnitude of this fluctuation progressively diminishes. In some sections of the canal, the water surface elevation progressively increases, albeit with minimal amplitude. With a constant relative water depth, an increase in main channel flow results in a corresponding increase in pipeline flow; however, the diversion ratio is inversely related to the main channel flow. Conversely, when the main channel flow rate is constant, the diversion ratio increases as relative water depth rises. The vertical flow velocity near the water diversion outlet has a negative value, signifying the existence of a backflow zone, while the horizontal flow velocity varies considerably, facilitating the formation of circulation and resulting in localised deposition and erosion. The water flow near the pipe inlet downstream of the lower lip of 0.5 times the pipe diameter is impacted by the return zone, which has a higher turbulence energy and circulation strength and is more susceptible to siltation. The turbulence energy of the water flow is higher in the range of 0.5 times the pipe diameter upstream and downstream of the pipe inlet. This research is highly significant in facilitating the conversion of irrigation channels into pipelines. Full article

The verification of a column made from a lipped cold-formed channel section, subjected to pure axial compression relative to the gross cross-section, often results in a combined verification of bending and compression due to the appearance of a shift of the centroid of its effective cross-section. Following Eurocode 3 rules, this requires the determination of two distinct effective cross-sections and various interaction factors. This paper, based on an analytic approach, offers a modification to the actual buckling curve, based on Ayrton–Perry formulation, to include the second-order effects raised by the eventual shift of the effective centroid due to local buckling of the compressed web plate. This eliminates the need to use an interaction formula. The modified buckling curve is verified based on a GMNIA analysis performed on a numerical parametric model, which was previously validated by laboratory tests. In addition, the results are compared with strength results provided by appropriate Eurocode 3 formulas and AISI Direct Strength Method for global-local interaction and with classic experimental results. Full article

As a better alternative to lithium-ion batteries (LIBs), lithium–sulfur batteries (LSBs) stand out because of their multi-electron redox reactions and high theoretical specific capacity (1675 mA h g⁻¹). However, the long-term stability of LSBs and their commercialization are significantly compromised by the inherently irreversible transition of soluble lithium polysulfides (LiPS) into solid short-chain S species (Li₂S₂ and Li₂S) and the resulting substantial density change in S. To address these issues, we used activated carbon cloth (ACC) coated with Ni₁₂P₅ as a porous, conductive, and scalable sulfur host material for LSBs. ACC has the benefit of high electrical conductivity, high surface area, and a three-dimensional (3D) porous architecture, allowing for ion transport channels and void spaces for the volume expansion of S upon lithiation. Ni₁₂P₅ accelerates the breakdown of Li₂S to increase the efficiency of active materials and trap soluble polysulfides. The highly effective Ni₁₂P₅ electrocatalyst supported on ACC drastically reduced the severity of the LiPS shuttle, affected the abundance of adsorption–diffusion–conversion interfaces, and demonstrated outstanding performance. Our cells achieved near theoretical capacity (>1611 mA h g⁻¹) during initial cycling and superior capacity retention (87%) for >250 cycles following stabilization with a 0.05% decay rate per cycle at 0.2 C. Full article

Krause’s corpuscles are typical of cutaneous mucous epithelia, like the lip vermillion or the glans clitoridis, and are associated with rapidly adapting low-threshold mechanoreceptors involved in gentle touch or vibration. PIEZO1 and PIEZO2 are transmembrane mechano-gated proteins that form a part of the cationic ion channels required for mechanosensitivity in mammalian cells. They are involved in somatosensitivity, especially in the different qualities of touch, but also in pain and proprioception. In the present study, immunohistochemistry and immunofluorescence were used to analyze the occurrence and cellular location of PIEZO1 and PIEZO2 in human clitoral Krause’s corpuscles. Both PIEZO1 and PIEZO2 were detected in Krause’s corpuscles in both the axon and the terminal glial cells. The presence of PIEZOs in the terminal glial cells of Kraus’s corpuscles is reported here for the first time. Based on the distribution of PIEZO1 and PIEZO2, it may be assumed they could be involved in mechanical stimuli, sexual behavior, and sexual pleasure. Full article

The paper presents a static analysis of the buckling and post-buckling state of thin-walled cold-formed steel (TWCFS) lipped channel section beam-columns subjected to eccentric compression. Eccentricity is taken into consideration relative to both major and minor principal axes. An analytical–numerical solution to the buckling and post-buckling problems is described. The solution is based on the theory of thin plates. Equations of equilibrium of section walls are derived from the principle of stationary energy. Then, to solve the problem, the finite difference (FDM) and Newton–Raphson methods are applied. Linear (buckling) and nonlinear (post-buckling) analyses are performed. As a result, pre- and post-buckling equilibrium paths are determined. Comparisons of the obtained numerical results, FE simulation results, and experimental test results are carried out and presented in comparative load-shortening diagrams. Additionally, a comparison of the buckling forces and buckling modes obtained from theoretical analysis and experiments is presented. Full article

This paper concerns the Eurocode 3 Part 1-3 (EN 1993-1-3) methods for calculating the distortional buckling (bifurcation) load of cold-formed steel-lipped channels subjected to axial force, major and minor axis bending. More specifically, the paper presents the results of a parametric study that assesses the accuracy of the simplified method in EN 1993-1-3, which relies on direct/iterative hand calculations and an approximate mechanical model, through comparison with “exact” numerical results, obtained using semi-analytical linearized buckling analyses based on Generalized Beam Theory, which are also allowed by the code. Isoline error maps are presented for a wide range of geometric and material parameters, covering common commercial profiles and corresponding to a dataset of more than 24,000 cases. These maps make it possible to identify the parameter ranges leading to an acceptable error and, even though they strongly depend on the loading, general remarks concerning the expected error pertaining to the simplified method are drawn. Full article

Steel structures are widely employed in the construction industry because of their simplicity, speed of construction, and ease of handling. Cold-formed steel is becoming more popular in the construction industry as the sections are created using thin-gauge sheets, as a result of which the weight of the structure is reduced. This saves a lot of steel compared to normal steel structures, providing cost benefits and material savings. Finding a cross-section that is both cost-effective and able to carry more weight without buckling presents a challenge. The objective of this investigation was to analyze the effects of a stiffener on the behavior of cold-formed steel columns. An experimental study was carried out on two long columns made of cold-formed steel with back-to-back lipped channel sections—one with stiffener and the other without stiffener. A finite element model was developed and validated using the experimental and theoretical results. The theoretical investigation was based on the direct strength method and effective width method using IS codes. From the results, it was observed that intermediate V-shaped web stiffeners improved the distortional and local buckling strength. A non-linear behavior of the stress–strain curve was observed. The applied stiffener did not increase the dimensions or required material of the section, but the results predicted an increase in strength of 32%. This model could be further utilized for various parametric studies and more effective sections could be achieved. Full article

The Spanish Golden Age tragedy is assembled around the conflict of passions, which does not find an adequate channel of expression in words because there are feelings that cannot be confessed if one wants to preserve life. However, such intense emotions cannot be hidden for a long time, either. The characters discover that the eyes speak in silence and cannot lie, so they appeal to their sincerity at crucial moments. Such examples can be found in the declarations of love addressed to inaccessible or forbidden women or in the narratives of women who report sexual assault or husbands who believe they have been dishonored. In this article, we will analyze all these circumstances to demonstrate that, if they contradict the lips, the eyes are the windows of the soul, and they speak a language that is as expressive as it is eloquent. Full article

As the load increases, most composite beams generally experience failure in both shear and flexural behavior. This outcome highlights the critical challenges of achieving sufficient strength and structural integrity in such beams. The proposed study has used the cold-formed behavior of an Enhanced C-channel (EC) shear connectors and Light Weight Concrete (LWC) to examine the new Steel-Lightweight Concrete-Steel sandwich Beams (SLCSB). The ECs have provided significant shear resistance at the faceplate-LWC interfacial interface and the tension separation resistance for faceplates (cold form steel) from the LWC core. Cold Form Steel (CFS) is the most often used substitute because of its high productivity and practicality in the field. Four different composite beams are examined in the proposed research with different ECs spacing. The beams’ top and bottom face plates are covered using CFS (1.6 mm). In addition to that, two different types of shear connectors are used. Two unique longitudinal spacing of 100 mm and 150 mm are also used for one with lipped ECs and without lipped ECs. Importantly, self-tapping screws are used to secure ECs in place between the top and bottom of the face plates. The effectiveness of the composite beams with various shear connector spacing subjected to a two-point load test is assessed through a series of experiments. Full article
