To investigate the interference effects of lightning on unmanned aerial vehicle (UAV) navigation receivers, an analytical approach for the evaluation of indirect lightning effects is suggested. The blocking mechanism of lightning pulses on the receiver is analyzed using the vector method. A behavioral-level simulation model of the receiver’s radio frequency (RF) front-end is constructed, and a lightning pulse injection simulation is performed based on the advanced design system (ADS). The simulation results indicate that lightning pulses induce blocking interference on the RF front-end of the navigation receiver, reducing its sensitivity and dynamic range. This interference is attributed to gain compression and degradation of the noise figure in the low-noise amplifier (LNA). To further validate the simulation results, a pin injection test is carried out to examine the influence of lightning pulses with different peak voltages on receiver sensitivity. The test results indicate a notable reduction in the receiver sensitivity when the lightning pulse peak reaches 250 V. The sensitivity trends across various test panels are consistent, and the damage thresholds are similar. These findings confirm the accuracy of the simulation results. Full article

The widespread use of composite materials with low electrical conductivity in modern advanced aircraft has placed higher requirements on lightning protection for airborne equipment. To ensure the safe operation of aircraft under a lightning environment, the internal cables and cable tracks of composite aircraft are modeled. The lightning protection performance of cables is calculated for different types and shielding parameters, and the effect of the cable layout inside a composite aircraft on the protection performance is analyzed. The role of the cable track in lightning protection is also verified. The calculation results show that the cable shield and track structure can provide good lightning protection for the cable in the electromagnetic exposure area, and the layout of the cable inside the aircraft has a greater impact on the protection performance. The analysis of cable shielding measures and their influencing factors can provide a reference for the performance improvement of cable screening measures for the lightning protection of composite aircraft. Full article

The impact of a lightning electromagnetic pulse (LEMP) on a power line or power station produces an effect similar to that of switching between a significant power source and a power line circuit. This switch closure causes a sudden change in routing conditions, creating a transient state. This situation has been studied in terms of electrostatic and electromagnetic induction, as well as overvoltage changes. Appropriate mathematical models were used to analyze these changes. While vertical electric field analysis has been carried out in a few studies, magnetic field and horizontal electric field vectors have not been studied. In this study, the Rusck formulation and the Heidler current formulation are combined at the current level, developed and analyzed. This is because the Rusck expression can sometimes give incorrect results at the current level. Also, in the analysis, electromagnetic field formulations based on accelerating charges are used instead of the dipole approximation to eliminate the need for interpolation in the graphical results. In contrast to other studies in the literature, this study proposes the use of moving and accelerating load techniques to better understand the effects of LEMPs on power transmission lines. Also, in this study, the double exponential problem of the current form in Rusck’s formulation is addressed in order to obtain a close approximation of the physical form of the LEMP. Additionally, the field–line (coupling) relationship is studied according to a unique closed formulation, leading to important determinations about the overvoltages generated on a line depending on the propagation speed of the LEMP sprout and the electrical changes in the area where the LEMP first occurs. Full article

In order to analyze the interference mechanisms of indirect lightning effects on a low-noise amplifier (LNA), a circuit model of the LNA was constructed based on the advanced design system 2020 (ADS 2020) software. Lightning pulse injection simulations were conducted to explore the influence of lightning pulses on the performance of the LNA. A pin injection test was performed to investigate the interference and damage threshold of the LNA. A protective circuit incorporating the transient voltage suppressor (TVS) and Darlington structure was designed through simulation, employing the ADS 2020 for the LNA. The research findings reveal that the interference threshold for the LNA is 60 V, while the damage threshold is determined to be 100 V. The protective circuit demonstrates a measured insertion loss of 0.1 dB, a response time of 1.5 ns, and a peak output voltage of 20 V. The research results indicate that the protective circuit can effectively reduce the impact of lightning’s indirect effects on the LNA. In the future, we will continue the design work of the protective circuit and proceed with physical fabrication and experimental validation. Full article

Lightning represents one of the most critical issues for electrical infrastructure. In dealing with overhead distribution line systems, indirect lightning strikes can lead to induced voltages overcoming the critical flashover value of the line, thus damaging the insulators. The computation of lightning-induced voltages requires the modeling of the lightning current, the evaluation of the lightning electromagnetic fields and the solution of the field-to-line coupling equations. The numerical calculation of the lightning electromagnetic fields is time-consuming and is strongly dependent on the lightning channel modeling and soil properties. This article presents a review of the most widely adopted methods to calculate the lightning electromagnetic fields, starting from the classical formulation, which requires numerical integration, and highlighting the most effective approaches that have been developed to reduce computational effort. This is done first for the case of a perfectly conducting ground, then the available formulations to account for the ground finite conductivity are presented together with their possible implementations in both the frequency and time domains. Full article

Fast-front transients play an important role in the insulation design of any power system. When a stroke hits the shield wire or the tower of high-voltage overhead power lines, flashover may occur either along the span or across tower insulators, depending on the relevant voltages and insulation strength. As a result, backflashover may take place from the tower structure to the phase conductor whenever a huge impulse current flows along the tower towards considerably high footing impedances. For these reasons, tower modeling for transients studies is an important step in the insulation design, and also for lower voltage applications, where indirect lightning effects may play a predominant role. However, after decades of research on tower modeling, starting from the 1930s with the first model proposed by Jordan, no consensus has been reached neither on a widely accepted tower model nor on the quantitative effect of the tower models on insulation design. Moreover, the fundamental mechanisms at the base of the transient response of towers and the definition of some fundamental parameters have not been totally clarified yet. The aim of this review is to present the available tower models developed through the years in the power community, focussing mainly on lumped/distributed circuit models, and to help the reader to obtain a deeper understanding of them. Full article

Carbon fiber reinforced polymer (CFRP) composites are lightweight and an increasingly used material with good mechanical properties. In the aviation industry, they are also required to have specific electrical properties that guarantee resistance to the direct and indirect lightning effects. The paper is focused on the description of a test stand and development of a method used to determine the electrical characteristics of conductive CFRP laminate samples with the use of high current impulses of lightning nature. Samples of three laminates (square format with side 30 × 30 cm) with a different composition were tested on the constructed stand, confirming the possibility of characterizing this type of laminate sample in terms of electrical conductivity and resistance to the effects of lightning current. It was possible to observe the impulse current flow (with a peak value up to 15 kA and a rise time above 6 µs) from the high voltage electrode placed in the center of the sample in all directions towards the edge. The optical fiber measuring system was used to record the voltage and current time waveforms. The energy stored in the impulse current generator was sufficient to simulate the mechanical damage, such as burnout and delamination, that accompanies the direct lightning strike to structural elements made of CFRP. The influence of the matrix composition used for laminate fabrication on the test results describing the electrical properties of the tested CFRP samples was noted. The experimental setup allows the testing of specimens with a maximum width and length of 50 × 50 cm and any thickness with a peak current of up to 50 kA. Full article

With increased electrical energy demands projected in the future, the development of a hybrid solar photovoltaic (PV)–battery energy storage system is considered a good option. However, since such systems are normally installed outdoors and in open areas, they are vulnerable to lightning strikes and may suffer from malfunctions or significant damage to sensitive components, which may result in a major breakdown and loss of revenue due to equipment replacement costs and inefficient operation. Thus, the objective of this paper is to investigate the effect of lightning-induced overvoltage on a hybrid solar PV–battery energy storage system, considering indirect lightning strikes nearby the system. The presented hybrid solar PV–battery energy storage system and lightning-induced overvoltage are modeled in Electro-Magnetic Transient Program-Restructured Version (EMTP-RV) software. The lightning-induced overvoltage is simulated based on a lightning waveshape of 10/350 µs using the Heidler expression, whilst the Rusck model is used to simulate the lightning-induced overvoltage. Different lightning current amplitudes (3, 19, and 169 kA), lightning strike locations (20, 50, and 100 m), and cable lengths (5, 10, and 20 m) are used to investigate the induced effects on the system and on the impulse withstand voltage of 6kV, as stated in MS IEC 60664-1 for solar PV–battery systems and inverters at the DC side. The results indicate that as the lightning strike distance increases from 20 to 100 m, the percentage of strikes exceeding the impulse withstand voltage reduces from 67% to 54% at 19 kA. At 169 kA, the impulse withstand voltage is exceeded by more than 100%, regardless of the strike distance (from 20 to 100 m). Furthermore, differences in cable length do not have much impact on the lightning-induced overvoltage due to the small voltage drop across the short cable length. This study provides useful information for PV systems owners and will be useful in assigning appropriate lightning protection schemes for PV farms. Full article

This paper presents the obtained results of experimental tests and modelling of lightning disturbances that were propagated in a model of aircraft cable bundle and caused by multiple lightning return-strokes interactions. The work is a continuation of previous research, which was concerned mainly with the interaction of lightning discharge with a single return-stroke. The section of the cable harness arranged above the metal plate was investigated. In one of its wires, a multiple-stroke current representing indirect lightning effects was injected from an impulse current generator dedicated to avionics immunity tests. Overvoltages induced at the ends of other wires surrounded by a braided shield, as well as the influence of line parameters and shield grounding condition on the shape and level of observed transients, were examined. The computer simulation results match the measurement data with satisfactory accuracy, and therefore, the presented model can be used to estimate indirect lightning effects in the wiring harness of avionics. Full article

Lightning-induced voltages are one of the main causes of shutdown in distribution lines. In this work, attention is focused on the effects of wideband modeling of electric grounding in the overvoltage calculation along insulator strings due to indirect lightning strikes. This study is done directly in the time-domain with the grounding being represented with an equivalent circuit accounting for its dynamics. Results show that the adoption of commonly adopted simplified grounding models, such as low-frequency resistance, may lead to an underestimation of the overvoltage. According to the results, differences in the order of 25% can be found in some studied cases. Full article

Since high voltage transmission line towers or wind turbines structures are installed in high-altitude areas, it is essential to achieve a high overvoltage protection system against direct and indirect lightning strikes collisions. The lightning current must be discharged quickly into the protective earth, to prevent the dangerous over-voltages formation and define a reference voltage node. This paper presents a novel model to assess the behavior of the grounding system, based on Pocklington integral equations under lightning magnetic fields and variations in soil ionization, in which an explicit circuit-based vector fitting RLC admittance branches are proposed. The frequency-dependent behavior of grounding system frequency response and soil ionization effect is modeled in time domain, straightly to implement into the electro-magnetic transient program (EMTP). The model verification contains horizontal, vertical, and their combinations of grounding grids to represent the complete investigations under lightning strikes. The harmonic impedance mathematical formulations and principles are derived based on a rational function, that could be applicable on ground potential rise (GPR) investigation. Full article

Overhead distribution lines can be seriously damaged from lightning events because both direct and indirect events can cause flashovers along the line. The lightning performance of such power lines is usually computed neglecting the effect of corona discharge along the conductors: in particular, the corona discharge determined by the indirect lightning event is taken into account only by few researchers because it can have meaningful impacts only in few cases. However, when we deal with overhead distribution lines with high Critical Flashover value (CFO) and small diameters, the corona discharge caused by indirect events has to be taken into account. This paper shows the effects of corona discharge in the lightning performance computation of overhead distribution lines. The analysis will involve different configurations in terms of line diameter and air conditions, focusing on the negative effect of corona discharge in the number of dangerous events that determine line flashovers. Full article

Wind generators are exposed to numerous destructive forces such as lightning and are therefore vulnerable to these phenomena. To evaluate the transient behavior of a wind power plant during direct and indirect strikes, modeling of all relevant components is required. Among the protective and control components of wind turbines, the grounding system is the most important element for protection against lightning strikes. This paper examines the impact of nonlinear soil ionization behavior and frequency dependency on a wind turbine in order to model a sufficient protection scheme to reduce overvoltage and make the system tolerable against transitions. The high frequency models of other equipment such as transformers, horizontal conductors, vertical rods, surge arresters and underground cables must also be taken into account to design the grounding system. Our Proposed Modified Grounding Scheme (PMGS) is to reduce the maximum transient overvoltages. We simulate the model in a restructured version of the Electromagnetic Transient Program (EMTP-RV) software to examine the effectiveness of the system. We then apply the simulated results to pair of turbines that are interconnected with a frequency-dependent cable. We carry out the simulation for direct and indirect lightning strikes. The results indicate that the MGS can lead to considerably more than a 50% reduction in transient voltages for lightning and thus leads to more reliable networks. Full article
