Double buffer layers composed of (Al_xGa_1−x)₂O₃/Ga₂O₃ structures were employed to grow a Sn-doped α-Ga₂O₃ epitaxial thin film on a sapphire substrate using mist chemical vapor deposition. The insertion of double buffer layers improved the crystal quality of the upper-grown Sn-doped α-Ga₂O₃ thin films by blocking dislocation generated by the substrates. Rapid thermal annealing was conducted for the double buffer layers at phase transition temperatures of 700–800 °C. The slight mixing of κ and β phases further improved the crystallinity of the grown Sn-Ga₂O₃ thin film through local lateral overgrowth. The electron mobility of the Sn-Ga₂O₃ thin films was also significantly improved due to the smoothened interface and the diffusion of Al. Therefore, rapid thermal annealing with the double buffer layer proved advantageous in achieving strong electrical properties for Ga₂O₃ semiconductor devices within a shorter processing time. Full article

We fabricated an air-tunnel structure between a gallium nitride (GaN) layer and trapezoid-patterned sapphire substrate (TPSS) through the in situ carbonization of a photoresist layer to enable rapid chemical lift-off (CLO). A trapezoid-shaped PSS was used, which is advantageous for epitaxial growth on the upper c-plane when forming an air tunnel between the substrate and GaN layer. The upper c-plane of the TPSS was exposed during carbonization. This was followed by selective GaN epitaxial lateral overgrowth using a homemade metal organic chemical vapor deposition system. The air tunnel maintained its structure under the GaN layer, whereas the photoresist layer between the GaN layer and TPSS disappeared. The crystalline structures of GaN (0002) and (0004) were investigated using X-ray diffraction. The photoluminescence spectra of the GaN templates with and without the air tunnel showed an intense peak at 364 nm. The Raman spectroscopy results for the GaN templates with and without the air tunnel were redshifted relative to the results for free-standing GaN. The CLO process using potassium hydroxide solution neatly separated the GaN template with the air tunnel from the TPSS. Full article

We report on the epitaxial lateral overgrowth (ELO) of high-quality AlN on stripe-patterned Si(111) substrates with various trench widths. By narrowing down the trench and ridge widths of patterned Si substrates, crack-free, 6-micrometer-thick, high-quality AlN films on Si substrates were produced. The full-width-at-half-maximum values of the X-ray-diffraction rocking curves for the AlN (0002) and (10$\overline{1}2$) planes were as low as 260 and 374 arcsec, respectively, corresponding to a record low dislocation density of 1.3 × 10⁹ cm⁻². Through the combination of a micro-Raman study and the X-ray diffraction analysis, it was found that narrowing the stripe width from 5 μm to 3 μm can reduce the vertical growth thickness before coalescence, resulting in a large decrease in the internal tensile stress and tilt angle, and, therefore, better suppression in the cracks and dislocations of the ELO–AlN. This work paves the way for the fabrication of high-performance Al(Ga)N-based thin-film devices such as ultraviolet light-emitting diodes and AlN bulk acoustic resonators grown on Si. Full article

Epitaxial lateral overgrowth (ELO) of GaN epilayers on a sapphire substrate was studied by using a laser-patterned graphene interlayer. Monolayer graphene was transferred onto the sapphire substrate using a wet transfer technique, and its quality was confirmed by Raman spectroscopy. The graphene layer was ablated using a femtosecond laser, which produced well-defined patterns without damaging the underlying sapphire substrate. Different types of patterns were produced for ELO of GaN epilayers: stripe patterns were ablated along the ${\left[\overline{1}100\right]}_{\mathrm{sapphire}}$ and ${\left[11\overline{2}0\right]}_{\mathrm{sapphire}}$ directions, a square island pattern was ablated additionally. The impact of the graphene pattern on GaN nucleation was analyzed by scanning electron microscopy. The structural quality of GaN epilayers was studied by cathodoluminescence. The investigation shows that the laser-ablated graphene can be integrated into the III-nitride growth process to improve crystal quality. Full article

This article summarizes our understanding of the interplay between diffusion and segregation during epitaxial growth of InGaAs and InAs quantum dots. These quantum dots form spontaneously on flat GaAs (001) single-crystalline substrates by the so-called Stranski-Krastanow growth mechanism once a sufficient amount of indium has accumulated on the surface. Initially a perfectly flat wetting layer is formed. This strained layer then starts to roughen as strain increases, leading first to small, long-range surface undulations and then to tiny coherent islands. These continue to grow, accumulating indium both from the underlying wetting layer by lateral indium segregation and from within these islands by vertical segregation, which for InGaAs deposition results in an indium-enriched InGaAs alloy in the centre of the quantum dots. For pure InAs deposition, interdiffusion also results in an InGaAs alloy. Further deposition can lead to the formation of misfit dislocations that nucleate at the edges of the islands and are generally sought to be avoided. Overgrowth by GaAs or InGaAs alloys with low indium content commences preferentially between the islands, avoiding their strained edges, which initially leads to trench formation. Further deposition is necessary to cap these quantum dots effectively and to re-gain an almost flat surface that can then be used for subsequent deposition of multiple layers of quantum dots as needed for many optoelectronic devices. Full article

We report the growth and characterization of thick, completely relaxed {11-22}-oriented InGaN layers using epitaxial lateral overgrowth (ELO). Although it was difficult to grow ELO-InGaN layers on patterned GaN templates, we succeeded in growing ELO-InGaN layers on a patterned InGaN template. The full width at half maximum of the X-ray rocking curve of ELO-InGaN on the InGaN templates was less than that of non-ELO InGaN. The photoluminescence intensity of InGaN/GaN multiple quantum wells on ELO-InGaN was approximately five times stronger than that on the {11-22} GaN template. Full article

Si-based group III-V material enables a multitude of applications and functionalities of the novel optoelectronic integration chips (OEICs) owing to their excellent optoelectronic properties and compatibility with the mature Si CMOS process technology. To achieve high performance OEICs, the crystal quality of the group III-V epitaxial layer plays an extremely vital role. However, there are several challenges for high quality group III-V material growth on Si, such as a large lattice mismatch, highly thermal expansion coefficient difference, and huge dissimilarity between group III-V material and Si, which inevitably leads to the formation of high threading dislocation densities (TDDs) and anti-phase boundaries (APBs). In view of the above-mentioned growth problems, this review details the defects formation and defects suppression methods to grow III-V materials on Si substrate (such as GaAs and InP), so as to give readers a full understanding on the group III-V hetero-epitaxial growth on Si substrates. Based on the previous literature investigation, two main concepts (global growth and selective epitaxial growth (SEG)) were proposed. Besides, we highlight the advanced technologies, such as the miscut substrate, multi-type buffer layer, strain superlattice (SLs), and epitaxial lateral overgrowth (ELO), to decrease the TDDs and APBs. To achieve high performance OEICs, the growth strategy and development trend for group III-V material on Si platform were also emphasized. Full article

Edge-emitting laser diodes (LDs) were fabricated on a reduced dislocation density epitaxial lateral overgrown (ELO) wing of a semipolar {$20\overline{2}1$} GaN substrate, termed an ELO wing LD. Two types of facet feasibility studies were conducted: (1) “handmade” facets, wherein lifted-off ELO wing LDs were cleaved manually, and (2) facets formed on wafers through reactive ion etching (RIE). Pulsed operation electrical and optical measurements confirmed the laser action in the RIE facet LDs with a threshold current of ~19 kAcm⁻² and maximum light output power of 20 mW from a single uncoated facet. Handmade facet devices showed spontaneous, LED-like emission, confirming device layers remain intact after mechanical liftoff. Full article

Two types of a trench with conventional vertical and new reverse-V-shaped cross-sections were fabricated on single crystal diamond (SCD) substrate using a micro-jet water-assisted laser. In addition, a microwave plasma chemical vapor deposition device was used to produce multiple micrometer-sized channels using the epitaxial lateral overgrowth technique. Raman and SEM methods were applied to analyze both types of growth layer characterization. The hollowness of the microchannels was measured using an optical microscope. According to the findings, the epitaxial lateral overgrowth layer of the novel reverse-V-shaped trench produced improved SCD surface morphology and crystal quality. Full article

GaN layers on sapphire substrates were prepared by using metal organic vapor phase epitaxy (MOVPE) combined with an in-situ ${\mathrm{H}}_2$ etching process for the purpose of later self-separation of thick GaN crystals produced by hydride vapor phase epitaxy (HVPE) on such substrates. The etching process results in deep pits and long voids that formed on the surface and along the lower interface between GaN and sapphire, respectively. The pits, which were investigated by SEM analysis, can be modified in their aspect ratio and density by controlling the etching parameters. Using a proper set of in-situ etching parameters, a seed layer with internal voids can be prepared, which is suitable for HVPE overgrowth and the self-separation process. The quality of the in-situ-etched seed GaN layer and overgrown GaN crystal were characterized by X-ray diffraction (XRD) and defect selective etching (DSE). With the aid of atomic force microscopy (AFM) in tapping mode, the interface morphology of the separated GaN crystal was analyzed. The crystal quality of the separated HVPE-GaN crystal is comparable to the crystal grown on untreated GaN MOVPE-seed, which did not separate from the sapphire substrate. The introduced technique to promote the crystal separation during the HVPE process has no obvious drawback on the quality of the grown GaN crystals. Using this technique, the self-separation occurs more gently due to a weakened interface between GaN/sapphire. The conventional separation from an untreated seed by pure thermomechanical action results in higher mechanical forces on the crystal and consequently much higher risk of crystal breakage. Full article

A distributed Bragg reflector (DBR) is a key building block in the formation of semiconductor microcavities and vertical cavity surface emitting lasers (VCSELs). The success in epitaxial GaAs DBR mirrors paved the way for the ubiquitous deployment of III-V VCSELs in communication and mobile applications. However, a similar development of GaN-based blue VCSELs has been hindered by challenges in preparing DBRs that are mass producible. In this article, we provide a review of the history and current status of forming DBRs for GaN VCSELs. In general, the preparation of DBRs requires an optimization of epitaxy/fabrication processes, together with trading off parameters in optical, electrical, and thermal properties. The effort of epitaxial DBRs commenced in the 1990s and has evolved from using AlGaN, AlN, to using lattice-matched AlInN with GaN for DBRs. In parallel, dielectric DBRs have been studied since 2000 and have gone through a few design variations including epitaxial lateral overgrowth (ELO) and vertical external cavity surface emitting lasers (VECSEL). A recent trend is the use of selective etching to incorporate airgap or nanoporous GaN as low-index media in an epitaxial GaN DBR structure. The nanoporous GaN DBR represents an offshoot from the traditional epitaxial approach and may provide the needed flexibility in forming manufacturable GaN VCSELs. The trade-offs and limitations of each approach are also presented. Full article

This paper reviews past research and the current state-of-the-art concerning gallium nitride-based vertical-cavity surface-emitting lasers (GaN-VCSELs) incorporating distributed Bragg reflectors (DBRs). This paper reviews structures developed during the early stages of research into these devices, covering both major categories of GaN-based VCSELs: hybrid-DBR and all-dielectric-DBR. Although both types exhibited satisfactory performance during continuous-wave (CW) operation in conjunction with current injection as early as 2008, GaN-VCSELs have not yet been mass produced for several reasons. These include the difficulty in controlling the thicknesses of nitride semiconductor layers in hybrid-DBR type devices and issues related to the cavity dimensions in all-dielectric-DBR units. Two novel all-dielectric GaN-based VCSEL concepts based on different structures are examined herein. In one, the device incorporates dielectric DBRs at both ends of the cavity, with one DBR embedded in n-type GaN grown using the epitaxial lateral overgrowth technique. The other concept incorporates a curved mirror fabricated on (000-1) GaN. Both designs are intended to mitigate challenges regarding industrial-scale processing that are related to the difficulty in controlling the cavity length, which have thus far prevented practical applications of all-dielectric GaN-based VCSELs. Full article

Epitaxial lateral growth will be required if complex diamond-based device architecture, such as, for example, Metal-oxide-semiconductor Field-effect transistors (MOSFETs) or epitaxial lateral overgrowth (ELO) substrates, need to be developed for high-power applications. To this end, undoped and doped non-planar homoepitaxial diamond were overgrown on (001)-oriented diamond-patterned substrates. Defects induced by both the heavy boron doping and three-dimensional (3D) growth were studied by transmission electron microscopy (TEM). At high methane and boron concentrations, threading dislocations with Burgers vectors b = 1/6 ⟨211⟩, b = 1/2 ⟨110⟩, or both were observed. Their generation mechanisms were established, revealing boron proximity effects as precursors of dislocations generated in boron-doped samples and providing clues as to the different Burgers vectors. The concentration ranges of boron and methane resulting in good crystalline quality depended on the plane of growth. The microwave plasma-enhanced chemical vapour deposition (MPCVD) growth conditions and the maximum boron concentration versus plane orientation yielding a dislocation-free diamond epitaxial layer were determined. Full article

Almost all modern inorganic light-emitting diode (LED) designs are based on double heterojunctions (DHJs) whose structure and current injection principle have remained essentially unchanged for decades. Although highly efficient devices based on the DHJ design have been developed and commercialized for energy-efficient general lighting, the conventional DHJ design requires burying the active region (AR) inside a pn-junction. This has hindered the development of emitters utilizing nanostructured ARs located close to device surfaces such as nanowires or surface quantum wells. Modern DHJ III-N LEDs also exhibit resistive losses that arise from the DHJ device geometry. The recently introduced diffusion-driven charge transport (DDCT) emitter design offers a novel way to transport charge carriers to unconventionally placed ARs. In a DDCT device, the AR is located apart from the pn-junction and the charge carriers are injected into the AR by bipolar diffusion. This device design allows the integration of surface ARs to semiconductor LEDs and offers a promising method to reduce resistive losses in high power devices. In this work, we present a review of the recent progress in gallium nitride (GaN) based DDCT devices, and an outlook of potential DDCT has for opto- and microelectronics. Full article

We overview recent progress in growth aspects of group III-nitride heterostructures for deep ultraviolet (DUV) light-emitting diodes (LEDs), with particular emphasis on the growth approaches for attaining high-quality AlN and high Al-molar fraction AlGaN. The discussion commences with the introduction of the current status of group III-nitride DUV LEDs and the remaining challenges. This segues into discussion of LED designs enabling high device performance followed by the review of advances in the methods for the growth of bulk single crystal AlN intended as a native substrate together with a discussion of its UV transparency. It should be stated, however, that due to the high-cost of bulk AlN substrates at the time of writing, the growth of DUV LEDs on foreign substrates such as sapphire still dominates the field. On the deposition front, the heteroepitaxial growth approaches incorporate high-temperature metal organic chemical vapor deposition (MOCVD) and pulsed-flow growth, a variant of MOCVD, with the overarching goal of enhancing adatom surface mobility, and thus epitaxial lateral overgrowth which culminates in minimization the effect of lattice- and thermal-mismatches. This is followed by addressing the benefits of pseudomorphic growth of strained high Al-molar fraction AlGaN on AlN. Finally, methods utilized to enhance both p- and n-type conductivity of high Al-molar fraction AlGaN are reviewed. Full article
