Search Results (41)

Unmanned Aerial Vehicles (UAVs) have revolutionized various industries due to their adaptability, efficiency, and capability to operate in diverse environments. However, conventional UAV designs face trade-offs between flight endurance and maneuverability. This study explores the design, analysis, and optimization of a biplane quadrotor UAV, integrating the vertical takeoff and landing (VTOL) capabilities of multirotors with the aerodynamic efficiency of fixed-wing aircraft to enhance flight endurance while maintaining high maneuverability. The UAV’s structural design incorporates biplane wings with different NACA airfoil configurations (NACA4415, NACA0015, and NACA0012) to assess their impact on drag reduction, stress distribution, and flight efficiency. Computational Fluid Dynamics (CFD) simulations in ANSYS Fluent 2023 R2 (Canonsburg, PA, USA).reveal that the NACA0012 airfoil achieves the highest drag reduction (75.29%), making it the most aerodynamically efficient option. Finite Element Analysis (FEA) further demonstrates that NACA4415 exhibits the lowest structural stress (95.45% reduction), ensuring greater durability and load distribution. Additionally, a hybrid flight control system, combining Backstepping Control (BSC) and Integral Terminal Sliding Mode Control (ITSMC), is implemented to optimize transition stability and trajectory tracking. The results confirm that the biplane quadrotor UAV significantly outperforms conventional quadcopters in terms of aerodynamic efficiency, structural integrity, and energy consumption, making it a promising solution for surveillance, cargo transport, and long-endurance missions. Future research will focus on material enhancements, real-world flight testing, and adaptive control strategies to further refine UAV performance in practical applications. Full article

To address heading instability in electric vertical take-off and landing (eVTOL) aircraft at low speeds and large pitch angles, a rotational speed feedback compensation control scheme based on Active Disturbance Rejection Control (ADRC) is proposed for variable-pitch propellers. This scheme integrates propeller speed into the heading control inner loop and employs a state observer to process the measured speed. Simulation results demonstrate that under dynamic propeller speed variations of 0.5%, 1%, and 2%, the proposed compensation scheme reduces yaw angle oscillation amplitudes by 22.2%, 30.6%, and 37.8%, and yaw angular velocity fluctuations by 32.5%, 43.4%, and 33.3%, respectively, compared to a basic speed feedback scheme, showcasing significantly superior robustness. Experimental bench tests further validate that the proposed strategy enhances overall propeller force efficiency from 2.479 kg/kW to 3.05 kg/kW at 120 km/h cruise, resulting in a power saving of 0.48 kW and extending the cruising range by 8.5 km. The stability and energy efficiency of the proposed method are rigorously validated through both simulation and experimental testing. Full article

This paper presents the development, modeling, and validation of a scaled UAV-VTOL low-cost prototype equipped with a jet propulsion system with vertical take-off and landing capabilities. The prototype is designed as an experimental testbed for reusable rocket control strategies, with a particular focus on thrust vectoring and landing stabilization. The study begins with the evolution of the CAD, followed by a guide for the correct assembly of the device. The development of the electronic system included the integration of an ARM Cortex-M7 microcontroller, inertial sensors, and a LIDAR-based altitude measurement system; this was enhanced by a Kalman estimator to mitigate the sensor’s noise. A series of experimental tests were conducted to characterize the key subsystems. Actuator characterization improved the linearized nozzle control model, ensuring predictable thrust redirection. The test bench results confirmed the EDF’s thrust curve and its ability to sustain controlled flight, despite minor losses due to battery discharge variations. Furthermore, state-space modeling aided the development of controllers for altitude stabilization and attitude control, with simulations proving the feasibility of maintaining stable flight conditions. Experimental validation confirmed that the prototype provides a practical platform for future research in reusable rocket dynamics and autonomous landing algorithms. Full article

In recent decades, the deployment of quadcopters has significantly expanded, particularly in outdoor applications such as parcel delivery. These missions require highly stable aerial platforms capable of maintaining balance under diverse environmental conditions, ensuring the safe operation of both the drone and its payload. This paper focuses on the stabilization of a quadcopter designed for outdoor use. A detailed dynamic model of a compact vertical takeoff and landing (VTOL) drone forms the basis for a non-linear control strategy targeting stability during the critical takeoff phase. The control law is designed using a quasi-linear parameter-varying (quasi-LPV) model that captures the system’s non-linear dynamics. Lyapunov theory and linear matrix inequalities (LMIs) are employed to validate the stability and design the controller. Numerical simulations demonstrate the controller’s effectiveness, and a comparative study is conducted to benchmark its performance against a reference quadrotor model. Full article

This paper addresses inherent limitations in unmanned aerial vehicle (UAV) undercarriages hindering vertical takeoff and landing (VTOL) capabilities on uneven slopes and obstacles. Robotic landing gear (RLG) designs have been proposed to address these limitations; however, existing designs are typically limited to ground slopes of 6–15°, beyond which rollover would happen. Moreover, articulated RLG concepts come with added complexity and weight penalties due to multiple drivetrain components. Previous research has highlighted that even a minor 3-degree slope change can increase the dynamic rollover risks by 40%. Therefore, the design optimization of robotic landing gear for enhanced VTOL capabilities requires a multidisciplinary framework that integrates static analysis, dynamic simulation, and control strategies for operations on complex terrain. This paper presents a novel, hybrid, compliant, belt-driven, three-legged RLG system, supported by a multidisciplinary design optimization (MDO) methodology, aimed at achieving enhanced VTOL capabilities on uneven surfaces and moving platforms like ship decks. The proposed system design utilizes compliant mechanisms featuring a series of three-flexure hinges (3SFH), to reduce the number of articulated drivetrain components and actuators. This results in a lower system weight, improved energy efficiency, and enhanced durability, compared to earlier fully actuated, articulated, four-legged, two-jointed designs. Additionally, the compliant belt-driven actuation mitigates issues such as backlash, wear, and high maintenance, while enabling smoother torque transfer and improved vibration damping relative to earlier three-legged cable-driven four-bar link RLG systems. The use of lightweight yet strong materials—aluminum and titanium—enables the legs to bend 19 and 26.57°, respectively, without failure. An animated simulation of full-contact landing tests, performed using a proportional-derivative (PD) controller and ship deck motion input, validate the performance of the design. Simulations are performed for a VTOL UAV, with two flexible legs made of aluminum, incorporating circular flexure hinges, and a passive third one positioned at the tail. The simulation results confirm stable landings with a 2 s settling time and only 2.29° of overshoot, well within the FAA-recommended maximum roll angle of 2.9°. Compared to the single-revolute (1R) model, the implementation of the optimal 3R Pseudo-Rigid-Body Model (PRBM) further improves accuracy by achieving a maximum tip deflection error of only 1.2%. It is anticipated that the proposed hybrid design would also offer improved durability and ease of maintenance, thereby enhancing functionality and safety in comparison with existing robotic landing gear systems. Full article

The distributed electric tilt-rotor Unmanned Aerial Vehicle (UAV) combines the vertical take-off and landing (VTOL) capability of helicopters with the high-speed cruise performance of fixed-wing aircraft, offering a transformative solution for Urban Air Mobility (UAM). However, aerodynamic interference between rotors is a new challenge to improving their flight efficiency, especially the dynamic interactions during the transition phase of non-parallel tandem dual-rotor systems, which require in-depth investigation. This study focuses on the aerodynamic performance evolution of the tilt-rotor system during asynchronous transition processes, with an emphasis on quantifying the influence of rotor tilt angles. A customized experimental platform was developed to investigate a counter-rotating dual-rotor model with fixed axial separation. Key performance metrics, including thrust, torque, and power, were systematically measured at various tilt angles (0–90°) and rotational speeds (1500–3500 RPM). The aerodynamic coupling mechanisms between the front and rear rotor disks were analyzed. The experimental results indicate that the relative tilt angle of the dual rotors significantly affects aerodynamic interference between the rotors. In the forward tilt mode, the thrust of the aft rotor recovers when the tilt angle reaches 45°, while in the aft tilt mode, it requires a tilt angle of 75°. By optimizing the tilt configuration, the aerodynamic performance loss of the aft rotor due to rotor-to-rotor aerodynamic interference can be effectively mitigated. This study provides important insights for the aerodynamic performance optimization and transition control strategies of the distributed electric tilt-rotor UAV. Full article

Quad-tilt-wing (QTW) Unpiloted Aerial Vehicles (UAVs) combine the vertical takeoff and landing capabilities of rotary-wing designs with the high-speed, long-range performance of fixed-wing aircraft, offering significant advantages in both civil and military applications. The unique configuration of QTW UAVs presents complex control challenges due to nonlinear dynamics, strong coupling between translational and rotational motions, and significant variations in aerodynamic characteristics during transitions between flight modes. To address these challenges, this study develops an optimal control framework tailored for real-time operations. A State-Dependent Riccati Equation (SDRE) approach is employed for attitude control, addressing nonlinearities, while a Linear Quadratic Regulator (LQR) is used for position and velocity control to achieve robustness and optimal performance. By integrating these strategies and utilizing the inverse dynamics approach, the proposed control system ensures stable and efficient operation. This work provides a solution to the optimal control complexities of QTW UAVs, advancing their applicability in demanding and dynamic operational environments. Full article

Compared with conventional drones, distributed powered drones have significant advantages in handling stability characteristics, lift and drag characteristics, and takeoff and landing performance. However, there are also challenges such as aerodynamic interference of multi powered slipstream, distributed-power/wing strong-coupling dynamic modeling, and redundant control allocation of distributed-power control mechanisms. The paper has carried out the research on the dynamic modeling method, flight dynamics characteristics analysis, and the design of the control strategy of the jump and steep descent of the distributed dynamic configuration fixed wing unmanned aerial vehicle. A comprehensive aircraft dynamic model considering the influence of propeller slip on aerodynamics was established by combining theoretical derivation with flight experiment data correction. By comparing and analyzing the longitudinal and lateral heading control efficiency of unmanned aerial vehicles under rudder deflection and dynamic differential, a control concept of roll co-ordination control yaw combined with left and right dynamic differential is proposed. Digital simulation and flight tests showed that the established full aircraft dynamics model can accurately reflect the motion laws of distributed-power takeoff and landing unmanned aerial vehicles. The designed takeoff and landing strategy and control scheme can successfully achieve unmanned aerial vehicle takeoff and landing and perform cruising flight tasks. Full article

Work on trajectory optimization is evolving rapidly due to the introduction of Artificial-Intelligence (AI)-based algorithms. Small UAVs are expected to execute versatile maneuvers in unknown environments. Prior studies on these UAVs have focused on conventional controller design, modeling, and performance, which have posed various challenges. However, a less explored area is the usage of reinforcement-learning algorithms for performing agile maneuvers like transition from hover to cruise. This paper introduces a unified framework for the development and optimization of a tilt-rotor tricopter UAV capable of performing Vertical Takeoff and Landing (VTOL) and efficient hover-to-cruise transitions. The UAV is equipped with a reinforcement-learning-based control system, specifically utilizing algorithms such as Deep Deterministic Policy Gradient (DDPG), Trust Region Policy Optimization (TRPO), and Proximal Policy Optimization (PPO). Through extensive simulations, the study identifies PPO as the most robust algorithm, achieving superior performance in terms of stability and convergence compared with DDPG and TRPO. The findings demonstrate the efficacy of DRL in leveraging the unique dynamics of tilt-rotor UAVs and show a significant improvement in maneuvering precision and control adaptability. This study demonstrates the potential of reinforcement-learning algorithms in advancing autonomous UAV operations by bridging the gap between dynamic modeling and intelligent control strategies, underscoring the practical benefits of DRL in aerial robotics. Full article

This study investigates the impact of rotor spacing on the aerodynamic performance of a coaxialcopter and promotes an innovative regulated control strategy for the coaxial drone. The present research introduces a coaxialcopter with variable rotor spacing, and employing finite element numerical simulations, we assess the aerodynamic behavior of this novel configuration. Through comprehensive measurements and analysis of its aerodynamic performance across varying rotor spacings from 0.1 R to 1 R, we validate the effectiveness of a rotor-spacing control strategy for enhancing takeoff maneuvers. The numerical simulation and experiment results reveal that the performance characteristics of both the upper and lower rotors converge toward that of a single rotor as the space ratio increases, along with a reduction in their thrust fluctuations and aerodynamic performance periodicity. Considering stable power consumption patterns and endurance performance, we analyzed the interrelations binding the pitch distance of the rotors, rotational speed, and pitch angle, vis à vis the thrust coefficient and power coefficient. Through the parameter optimization method, we demonstrate that adjusting rotor spacing offers a practical means to enhance payload capacity without increasing the power input, thereby improving efficiency, which validates the practicality and efficacy of the parameter optimization approach. Furthermore, optimizing rotor spacing for specific operational scenarios enhances overall aerodynamic performance, suggesting a viable flight control strategy for takeoff and landing conditions for coaxial drones. Full article

Current research on ground-effect unmanned aerial vehicles (UAVs) predominantly centers on numerical aerodynamic optimization and stability analysis in the ground effect, leaving a significant gap in the thorough examination of flight performance through flight tests. This study presents the design of a vertical takeoff and landing (VTOL) ground-effect UAV, featuring a vector motor configuration. The control system utilizes a decoupled strategy based on position and attitude, enabling stable altitude control in the low-altitude ground-effect region. Comprehensive flight tests were conducted to evaluate the UAV’s flight stability and energy consumption in the ground-effect region. The results reveal that the ground-effect UAV successfully performed rapid takeoff maneuvers and maintained stable forward flight in the designated ground-effect region. In the span-dominated ground-effect region, a significant 33% reduction in flight current was observed, leading to a corresponding 33% decrease in total power consumption compared to flight conditions outside the ground effect. These findings highlight a substantial improvement in flight performance under the influence of ground effect. The real-time flight data produced by this system provides valuable insights for optimizing the design of VTOL ground-effect UAVs. Full article

The unmanned quad tilt-rotor eVTOL (QTRV) is a variable-configuration aircraft that combines the features of vertical takeoff and landing (VTOL), hovering, and high-speed cruising, making its control system design particularly challenging. The flight dynamics of the QTRV differ significantly between the VTOL and cruise modes, and are further influenced by rotor tilt and external wind disturbances. Developing a unified, highly coupled nonlinear full-flight dynamics model facilitates flight control system design and simulation verification. To ensure stable tilt of the QTRV, a tilt corridor was established, along with the design of its tilt route and manipulation strategy. An adaptive neural network active disturbance rejection controller (ANN-ADRC) is proposed to ensure stable flight across all modes, reducing the control parameters and simplifying tuning while effectively estimating and compensating for unknown disturbances in real time. A hardware-in-the-loop (HIL) simulation system was designed for full-mode flight control simulation, and the results demonstrated the effectiveness of the proposed control method. Full article

This research focuses on a novel convertible unmanned aerial vehicle (CUAV) featuring four rotors with tilting capabilities combined with a tapered form. This paper studies the transition motion between multirotor and fixed-wing modes based on the mechanical and aerodynamics design as well as the control strategy. The proposed CUAV involves information about design, manufacturing, operation, modeling, control strategy, and real-time experiments. The CUAV design considers a fixed-wing with tiltrotors and provides the maneuverability to perform take-off, hover flight, cruise flight, and landing, having the characteristics of a helicopter in hover flight and an aircraft in horizontal flight. The manufacturing is based on additive manufacturing, which facilitates the creation of a lattice structure within the wing. The modeling is obtained using the Newton–Euler equations, and the control strategy is a PID controller based on a geometric approach on SE(3). Finally, the real-time experiments validate the proposed design for the complete regime of flight, and the research meticulously evaluates the feasibility of the prototype and its potential to significantly enhance the mission versatility. Full article

This study examines the thermal behavior of lithium-ion battery modules intended for Urban Air Mobility (UAM), a forthcoming urban transport system designed to facilitate efficient and secure passenger and cargo transport within city centers. UAM applications necessitate batteries with high energy densities capable of sustaining elevated discharge rates during critical phases such as takeoff and landing. The battery module evaluated in this study comprises four cells arranged in series and configured as a submodule for UAM applications. A three-dimensional thermal model was utilized to analyze the impact of external temperature fluctuations and high discharge rates on the performance of the battery module. The numerical findings indicated considerable variations in temperature and internal resistance among the cells, especially under high discharge rates at low temperatures, with a maximum temperature deviation of 32.952 °C observed at an 8 C discharge rate. These thermal non-uniformities were attributed to variations in cell capacity and internal resistance, which were amplified by manufacturing inconsistencies and operational conditions. The study underscores the necessity of robust thermal management strategies to mitigate the risk of thermal runaway and ensure the operational safety and reliability of UAM systems. The results emphasize the critical role of advanced Battery Management Systems (BMS) in monitoring and controlling cell voltage and temperature to achieve consistent performance across the battery module. This research contributes valuable insights into the design of more efficient and reliable battery modules for UAM, highlighting the importance of addressing cell-to-cell performance discrepancies to enhance overall module efficacy and durability. Full article

Nowadays, due to climate change and disappearance of fossil fuels, hybrid electric UAVs using renewable energy sources are being developed. In addition, although research on UAVs with a large wingspan and high weight is common due to their long endurance, research on mini UAVs has remained limited. This study aims to increase the energy capacity of solar-powered mini UAVs and thus extend their endurance by developing a fixed-wing hybrid UAV that can fly with solar energy as much as possible, especially during the cruise phase. In this study, a solar-powered mini VTOL (vertical take-off and landing) UAV with a wingspan of 1.8 m and weight of 3.3 kg is developed and a model of the system consisting of solar cells, a battery, a super capacitor, and a DC/DC converter is created in MATLAB/Simulink software (R2023b). Additionally, state machine control (SMC), a rule-based (RB) energy management strategy (EMS), has been applied to this model. While the power obtained from the sun is divided among the other energy components, the durability of the UAV is increased, and the excess energy is stored as altitude energy to be used when necessary. As a result, in this study, an energy management algorithm including altitude energy has been successfully applied to a solar-powered UAV, achieving an 11.11% energy saving. Full article
