The dynamics of the vibrational mode of motion of the driving member of a nonideal system, a mixing–whipping device based on a simple slide-crank mechanism, was studied. The highly nonlinear differential equations of motion were solved numerically by the Runge–Kutta method. The interaction of the mixing–whipping device with the nonideal excitation source causes the rotational speed of the engine shaft and the rotation angle of the driving member to fluctuate, accomplishing a damped process. The parameters of the device and the nonideal energy source have an effect on the kinematic, vibrational and energy characteristics of the system. An increase in the engine’s torque, crank length, number and radius of piston holes, and piston mass, as well as a decrease in the fluid’s density, leads to a reduction in the oscillation range of the crank angle, amplitude and period of angular velocity oscillations of the engine shaft and the mixing–whipping force power. The effects of a nonideal energy source may be used in designing a mixing–whipping device based on a slider-crank mechanism to select effective system parameters and an energy-saving motor in accordance with the requirements of technological processes and products. Full article

Accurate kinematic calibration of subreflector actuators is essential for pointing precision of large radio telescopes, particularly at high frequencies. Conventional least-squares methods are vulnerable to noise and outliers, and their accuracy may degrade when limited pose diversity leads to poor parameter excitation. To address these challenges, this paper proposes a novel robust self-calibration framework that integrates Huber loss and $L_2$ regularization into the Levenberg–Marquardt (LM) algorithm—yielding a hybrid optimization approach that combines residual robustness, numerical stability, and convergence reliability. A comprehensive simulation study was conducted under varying workspace sizes and sensor noise levels. The proposed method maintained stable performance even under reduced excitation and high-noise conditions, where traditional LM methods typically degrade, confirming its robustness and applicability to realistic calibration scenarios. The framework was further validated using a structured-light 6-DOF pose measurement system, the proposed method achieved over 90% improvement in both position and orientation accuracy compared to the traditional LM approach. These findings confirm the method’s effectiveness for high-precision 6-DOF calibration in parallel mechanisms, and its suitability for real-world applications in radio telescope subreflector alignment. Full article

Pile foundations are commonly used to support structures subjected to complex loading conditions. In seismic-prone regions, understanding the soil–pile interaction under cyclic loading is essential for ensuring the stability and safety of these foundations. Numerical modeling is an effective tool for predicting the nonlinear behavior of soil under seismic excitation, but selecting an appropriate constitutive model remains a significant challenge. This study investigates the seismic behavior of pile groups embedded in soft clay using advanced finite element analysis. The piles are modeled as aluminum with a linear elastic response and are analyzed within a soil domain characterized by two kinematic hardening constitutive models based on the Von Mises failure criterion. Model parameters are calibrated using a combination of experimental and numerical data. The study also examines the influence of pile spacing within the group on seismic response, revealing notable differences in the response patterns. The results show that the nonlinear kinematic hardening model provides a more accurate correlation with experimental centrifuge test results compared to the multilinear model. These findings contribute to enhancing the understanding of soil–pile interaction under seismic loading and improving the design of pile foundations. Full article

A comprehensive literature review on the kinematics and dynamics modeling and virtual prototyping (V.P) of the Cartesian robots with a flexible configuration is presented in this paper. Different modeling approaches of the main components of the Cartesian robot, which includes linear belt drives and structural components, are presented and discussed in this paper. Furthermore, the vibrations modeling, trajectory planning, and control strategies of the Cartesian robot are also presented. The performance optimization of the Cartesian robot is discussed here, which is affected by the highly flexible configuration of the robot incurred due to high-mix, low-volume production. The importance of virtual prototyping techniques, like finite element analysis and multi-body dynamics, for modeling Cartesian robots or its components is presented. Design and performance optimization methods for robots with a flexible configuration are discussed, although their application to Cartesian robots is rare in the literature and it presents an exciting opportunity for future research in this area. This review paper focuses on the importance of further research on the virtual prototyping tools for flexibly configured robots and their integration with experimental validation. The findings offer useful insights to industries looking to maximize their production processes while keeping the customization, reliability, and efficiency. Full article

This study investigates the dynamic performance of a road sign equipped with a multi-material electronic signboard subjected to mining-induced seismic tremors. The key innovative aspect lies in providing new insights into the dynamic performance of multi-material electronic signboards under high-energy mining tremors, enhancing their safety assessment in mining areas. Experimental modal analysis and finite element analysis were conducted, and the numerical model of the sign was calibrated by adjusting ground stiffness to align experimental and computational data. The fundamental natural frequencies and their corresponding mode shapes were identified as 2.75 Hz, 3.09 Hz, 8.46 Hz, and 13.50 Hz. Numerical results were validated using MAC methods, demonstrating strong agreement with experimental values and confirming the accuracy of the numerical predictions. Damping ratios of 3.79% and 3.71% for the first and second modes, respectively, were measured via hammer tests. To evaluate the sign’s dynamic performance under high-energy mining-induced tremors, two events were applied as kinematic excitation of the structure. These tremors, recorded in different mining regions, exhibited significant variations in peak ground acceleration (PGA) and dominant frequency range. A key finding was that frequency matching between the dominant frequencies of the tremor and the natural frequencies of the sign had a greater impact on the sign’s dynamic response than PGA. The Szombierki tremor, with dominant frequencies of 1.6–4.8 Hz, induced significantly higher stress and displacement compared to the Moskorzyn tremor (5–10 Hz) despite the latter having twice the PGA. These results highlight that a road sign structure can exhibit widely varying dynamic behaviors depending on the seismic characteristics of the mining zone. Therefore, a comprehensive assessment of mining-induced tremors in relation to the seismicity of specific areas is crucial for understanding their potential impact on such structures. The dynamic performance assessment also revealed that the electronic multi-material signboard did not undergo plastic deformation, confirming it as a safe material solution for use in mining areas. Full article

In this article, an attempt was made to model the body of a person moving in a passive manner (movement forced by another person) in a wheelchair. For this purpose, the Wan–Schimmels model was modified by 4 DOF, supplementing it with the weight of the wheelchair and a polyurethane cushion. The study was designed to test the effectiveness of utilizing a polyurethane cushion to reduce the whole-body vibration acting on a person while moving in a wheelchair. The study used a rheological model of polyurethane (PU) foam with concentrated parameters. Harmonic and random vibration analysis was carried out for this model. At the same time, the model with 5 DOF seems to be sufficient to describe vibrations transmitted to wheelchair users. The model presented in this paper can become a tool for future analysis of vibrations of people of different weights, moving passively on various types of wheelchairs on surfaces whose irregularities can be given by an appropriate form of kinematic excitation. The approach used in this study is likely to be useful in selecting a wheelchair and seat cushion so as to counteract and minimize vibrations perceived by humans. Full article

This paper highlights the optimisation of a key design parameter essential to the development of PMUTs, which are part of the transmitting components of microsensors. These microsensors are designed for use in the Structural Health Monitoring of reinforced concrete structures. Enhancing the effectiveness of the transmitting component allows for greater spacing between microsensors, which in turn reduces the number of devices needed to implement a full structural health monitoring system. PMUTs designed for integration into the pore solution of reinforced concrete structures need to operate effectively with liquid coupling fluids to ensure optimal sonic energy transfer into the structure. This paper outlines the techniques employed to optimize the central electrode’s percentage radial cover of the piezoelectric layer, in circular PMUTs resonating at around 100 kHz. This optimisation was achieved using Finite Element Modelling, laser vibrometry, and hydrophone experimental techniques. The results demonstrated that a radial electrode cover between 65 and 70% significantly enhances the kinematic and dynamic characteristics of a PMUT’s diaphragm when subjected to the excitation of a sine wave electrical signal. The paper also includes advanced time domain finite element analysis, through which the authors aimed to illustrate the diaphragm’s movements at various levels of radial electrode coverage. Full article

In order to solve the problem of mowing between plants in Xinjiang trunk orchards, an obstacle avoidance mower suitable for trunk orchard planting mode was designed. The whole structure, working principle and main parameter design of the obstacle avoidance mower are introduced. The finite element analysis and kinematic analysis of the cutter are carried out on the premise of using a Y-shaped cutter and its arrangement, and the condition that the inter-row mower does not leak is determined. Through the modal analysis of the frame, the range of the first six natural frequencies of the frame is determined and compared with the frequency of the main excitation source of the machine to determine the rationality of the frame design. On the premise of simplifying the inter-plant obstacle avoidance mechanism into a two-dimensional model for kinematics analysis, the motion parameters of the key components of the machine were determined. At the same time, the virtual kinematics simulation single-factor test of the designed inter-plant obstacle avoidance device was carried out with the help of ADAMS 2020 software. Through the reduction in and calculation of the motion trajectory of the simulation test, it was finally determined that the forward speed of the machine, the elastic coefficient of the reset spring and the compression speed of the hydraulic cylinder were the main influencing factors of the inter-plant obstacle avoidance mower. The orthogonal test was designed and the optimal solution of the three test factors was determined. The optimal solution is taken for further field test verification. The results show that when the tractor forward speed is 1.5 km∙h⁻¹, the hydraulic cylinder compression speed is 225 mm∙s⁻¹, and the elastic coefficient of the reset spring is 29 N∙mm⁻¹, the average leakage rate between the orchard plants is 7.64%, and the obstacle avoidance pass rate is 100%. The working stability is strong and meets the design requirements. Full article

This study primarily presents a numerical investigation of the dynamic behavior and vibration control in thin-walled, additively manufactured (AM) beam structures, validated through experimental results. Vibration control in thin-walled structures has gained significant attention recently because vibrations can severely affect structural integrity. Therefore, it is necessary to minimize these vibrations or keep them within acceptable limits to ensure the structure’s integrity. In this study, the AM beam structures were made of polylactic acid polymer (PLAP), short carbon fiber reinforced in PLAP (SCFR|PLAP), and continuous carbon fiber reinforced in PLAP (CCFR|PLAP), with 0°|0° layer orientations. The finite element modeling (FEM) of the AM beam structures integrated with macro fiber composite (MFC) was carried out in Abaqus. The initial four modal frequencies of bending modes (BMs) and their respective modal shapes were acquired through numerical simulation. It is crucial to highlight the numerical findings that reveal discrepancies in the 1st modal frequencies of the beams, ranging up to 1.5% compared to their respective experimental values. For the 2nd, 3rd, and 4th modal frequencies, the discrepancies are within 10%. Subsequently, frequency response analysis (FRA) was carried out to observe the frequency-dependent vibration amplitude spectrum at the initial four BM frequencies. Despite discrepancy in the amplitude values between the numerical and experimental datasets, there was consistency in the overall amplitude behavior as frequency varied. THz spectroscopy was performed to identify voids or misalignment errors in the actual beam models. Finally, vibration amplitude control using MFC (M8507-P2) was examined in each kinematically excited numerical beam structure. After applying a counterforce with the MFC, the controlled vibration amplitudes for the PLAP, SCFR|PLAP, and CCFR|PLAP configurations were approximately ±19 µm, ±16 µm, and ±13 µm, respectively. The trend in the controlled amplitudes observed in the numerical findings was consistent with the experimental results. The numerical findings of the study reveal valuable insights for estimating trends related to vibration control in AM beam structures. Full article

The traditional shrub fruits harvesting method is manual picking, while the efficiency is low, which seriously restricts the development of Lycium barbarum L. industry. In order to mechanize the harvesting process of Lycium barbarum L. and improve the correct picking rate while reducing the damage rate of Lycium barbarum L. harvesting, it is very important to analyze the kinematic model of the fruit-bearing branch during vibration harvesting. Through the measurement and analysis of the natural characteristics and physical parameters of the branches, a simplified model of Lycium barbarum L. shrub fruit-bearing branch was built by Solidworks 2023 software, and the appropriate material properties were selected. Through modal analysis and harmonious response analysis, the response characteristics data of fruit-bearing branches of Lycium barbarum L. shrub were obtained. In Qinghai Nuomuhong Farm, the field vibration harvesting kinematic model feature analysis test was carried out, and the acceleration data of the vibration harvesting process were collected by using the acceleration sensor, and through the analysis of the frequency spectrum characteristics of the data, it was concluded that when the excitation frequency was maintained between 8 and 14 Hz, the Lycium barbarum L. fell off well and the picking rate can reach 97.56%, the efficiency can reach 6.88 pieces of fruit per second, and the branch damage was acceptable, which theoretically met the needs of harvesting. Full article

True ternary fission, the fission of a nucleus into three fragments of nearly equal mass, is an elusive and poorly known process influenced by shell effects. An increase in the probability of this process with respect to binary fission, which is very low in spontaneous and neutron-induced fission, has been envisaged. Heavy-ion-induced reactions are adopted due to the possibility of an increase in the fissility parameter and the excitation energy of the compound nuclei. Nuclei with mass number around A = 250, accessible in heavy-ion-induced reactions, are favorable and should be investigated. It is still debated if the process takes place in a single step, direct ternary fission, or in a two step, sequential ternary fission. The purpose of this work is to define experimental conditions and observables that allow the disentangling of the products from the direct and sequential ternary fission, as well as from the usual most probable binary fission. This step is essential for gaining insights into the ternary fission dynamics and the binary to ternary fission competition. The method proposed here is for simulating the kinematics of the ternary and binary fission processes to compute the energy distributions and angular correlations of direct and sequential ternary fission products, as well as those of binary fission. The reaction taken as a benchmark is ⁴⁰Ar + ²⁰⁸Pb at 230 MeV and is supposed to form the ²⁴⁸Fm* compound nucleus. The simulation results have been filtered by considering the response function of a multi-coincidence detection system virtually constructed using the Geant4 simulation toolkit. The simulations support the possibility of separating the products of different multimodal fission decays with the proposed setup that consequently represents an effective tool to obtain insights into ternary fission from the observables selected. Full article

This paper aims to investigate using FOAM to analyze the dynamic instability in the APPR for ADFTV based on a dynamic model (DMADFTV). The DMADFTV considers the following aspects: AD kinematic nonuniformity (ADKN), AD geometric nonuniformity (ADGN) of inertial characteristics for the spinning movements (ICSM) of the AD elements (ADE), and the excitations induced by the gearbox–internal combustion engine modulations. The DMADFTV is considered the already-designed dynamic model developed by the first author of the ADFTV in a previous publication. This DMADFTV was used to compute the stationary frontiers of instability and the nonstationary spectral velocity amplitude (NSVA) versus nonstationary spectral amplitude (NSA) in the configuration space in transition through APPR, using the FOAM. The use of FOAM is much more versatile, from the analytical point of view, than the method of multiple scales and allows the computation of the NSA and the NSVA in the APPR. In contrast, these computations cannot be performed using the harmonic balance method. MATLAB Software R 2017 was developed based on DMADFTV and used the FOAM to compute the stationary frontiers of instability and the NSVA versus the NSA in transition through APPR for the ADFTV. The numerical results were compared with the experimental and numerical data published in the literature, finding agreements. The computation of the NSVA versus NSA in the configuration space using FOAM represents a method of detection of the chaotic manifestation of ADFTV. Full article

The submerged floating tunnel is a marine transportation infrastructure that links two shorelines. The tunnel tube body’s buoyancy exceeds gravity, with anchoring ensuring equilibrium. Anchoring reliability is crucial. This study presents a three-way coupled kinematic model for the mooring structure, formulated on Hamilton’s principle and Kirchhoff’s assumption. It explores the impact of the tube body’s buoyancy-to-weight ratio and the sea current’s angle of incidence on mooring motion response. By solving the motion analysis model, Hill’s equation system is derived to assess the parameter instability of the anchor cable structure. The coefficient of excitation instability intervals for the submerged floating tunnel is determined and validated. The findings indicate the following: (1) Increasing the float-weight ratio reduces displacement response amplitudes in all directions, bringing downstream and transverse currents closer to their initial positions; (2) Changes in current direction angles result in decreased downstream excitation strength and increased transverse displacement response with the same excitation direction; (3) The instability interval visualization effectively predicts anchor cable structure instability under parametric excitation. Structures within the instability region are deemed unstable, while those outside are considered stable. Full article

High-Static-Low-Dynamic Stiffness (HSLDS) mechanisms exploit nonlinear kinematics to improve the effectiveness of isolators, preserving controlled static deflections while maintaining low natural frequencies. Although extensively studied under harmonic base excitation, there are still few applications considering real seismic signals and little experimental evidence of real-world performance. This study experimentally demonstrates the beneficial effects of HSLDS isolators over linear ones in reducing the vibrations transmitted to the suspended mass under near-fault earthquakes. A tripod mechanism isolator is presented, and a lumped parameter model is formulated considering a piecewise nonlinear–linear stiffness, with dissipation taken into account through viscous and dry friction forces. Experimental shake table tests are conducted considering harmonic base motion to evaluate the isolator transmissibility in the vertical direction. Excellent agreement is observed when comparing the model to the experimental measurements. Finally, the behavior of the isolator is investigated under earthquake inputs, and results are presented using vertical acceleration time histories and spectra, demonstrating the vibration reduction provided by the nonlinear isolator. Full article

The present paper is concerned with a magnetorheological (MR)-damper-based vibration-reduction system with energy harvesting capability considering sprung mass changes. The system represents a mechanical harmonic oscillator with electrical coupling, set in motion by kinematic excitation. The authors examine the system performance in the case when the MR damper control coil (damper control coil) is powered directly by the alternating current resulting from the voltage generated in an electromagnetic harvester in the assumed frequency range of sine excitation. Such a system is able to attenuate vibration in the near-resonance frequency range when the current in the damper control coil increases; however, its drawback is vibration amplification at higher frequencies. To eliminate this negative feature, it is proposed to connect shunt capacitors in parallel with the damper control coil. Then, the system can be tested experimentally in terms of current in the damper control coil, sprung mass, and the capacity of shunt capacitors in order to evaluate system performance according to the assumed performance index. The obtained results demonstrate significant improvement in system performance at higher frequencies of excitation. Full article
