Background: Accuracy of optical impressions—defined by the intraoral scanner (IOS)’s trueness and precision per International Organization for Standardization (ISO) standards—is influenced by both operator- and patient-related factors. Thus, this in vitro study aimed to (1) evaluate how scanning distance affects the accuracy of three different intraoral scanners (IOSs), and (2) identify the optimal scanning distance for each scanner. Methods: A maxillary arch model was obtained using polyvinyl siloxane impression material and poured with Type IV stone (Octa-rock royal^®, Kulzer, Germany). Using three different types of IOSs—the trios 3 shape (TRIOS ^® cart, 3Shape, Copenhagen, Denmark); the Helios 500 (Eighteeth ^®, Changzhou, China); and the Heron (3Disc ^®, Herndon, VA 20170, USA)—ten scans were performed with each of the IOSs with five predetermined distances: 0 mm, 2.5 mm, 5 mm, 7.5 mm, and 10 mm. Spacers of varying heights were designed using Meshmixer version 3.5 (Autodesk, Inc., Mill Valley, CA, USA) and three-dimensional printed with the Form 2 printer (Formlabs, Somerville, MA, USA). The scanned data was processed using Geomagic Control X (Version 16.0.2.16496, 3D Systems, Wilsonville, OR, USA). Statistical analyses were performed using R Statistical Software (version 4.2.2), with significance set at α = 0.05. Results: Scanning distance significantly influenced scan accuracy for all three scanners. The 3Disc scanner (3Disc, Herndon, VA, USA) demonstrated the highest accuracy at a 7.5 mm distance, while both the Helios 500 (Eighteeth, Changzhou, China) and Trios 3 (3Shape, Copenhagen, Denmark) scanners achieved their best accuracy at a 5 mm distance, as indicated by the lowest root mean square (RMS) values (p < 0.05). Conclusions: To conclude, each IOS has an optimal scanning distance for best accuracy. Trios 3 (3Shape, Copenhagen, Denmark) outperformed the others in both trueness and precision. Future studies should examine these effects under full-arch and clinical conditions. Full article

Background: The increasing adoption of digital workflows in implant dentistry necessitates rigorous assessment of intraoral scanning, particularly for complex full-arch rehabilitations like All-on-Four prostheses, where posterior implant angulation may impact the accuracy of optical data acquisition. Objectives: This in vitro study aimed to assess the accuracy of digital intraoral scanners in scanning All-on-Four implant models with different posterior implant angulations. Methods: Two epoxy resin All-on-Four implant models were fabricated with two posterior implant angulations (30-degree and 45-degree). Both models were digitized to obtain control datasets using a Smart Optics reference scanner (REF). Four intraoral scanners were comparatively assessed: Cerec Omnicam AC (OMN), Trios 4 (TRI), Cerec Primescan AC (PRI), and Medit i700 (MED), with nine scans per each scanner (n = 9). All STL files were exported and analyzed using Geomagic Control X with root mean square (RMS) values computed for trueness and precision assessments. Results: The comparison between IOS types in terms of trueness revealed that with 30° angulation, the MED group showed the statistically significant least deviation (p = 402). With 45° angulation, both PRI and OMN scanners showed the statistically significant highest deviation values (p = 0.047 and 0.007, respectively). MED again showed the statistically significant least deviation (p = 402). For precision evaluation in 30° angulation models, PRI and OMN scanners showed the statistically significant least deviation values (p = 402 and <0.001, respectively). While, in 45° angulation models, no statistically significant inter-scanner differences were observed. Conclusions: While MED, PRI, and OMN scanners demonstrated clinical validity for 30° angled posterior implants, only the MED system achieved sufficient accuracy for 45° tilt. These findings emphasize the critical relationship between scanner selection and extreme implant angulations in full-arch digital workflows. Full article

Background: Dental implantology has undergone significant advancements with the integration of digital workflows, transforming the processes of planning, designing, surgical delivery, and prosthetic rehabilitation. Among these innovations, intraoral optical scanning (IOS) has emerged as a preferred method over traditional analogue impressions. This preference is due to its cost-effectiveness, efficiency, and streamlined patient-friendly use while producing clinically acceptable results in terms of trueness and precision, particularly for short-span implant prostheses. Methods: However, the clinical utility of intraoral scanning is significantly affected by the lack of reference points and difficulties in moisture and bleeding control at the time of immediate implant placement surgery in the fully edentulous arch. Current evidence supports the general consensus that the traditional analog impression technique still provides superior trueness and precision compared to IOS, specifically in full-arch implant cases. Results: The continuous quest for precision in dental implantology has led to the introduction of photogrammetry, which is now considered the most accurate technique for the digital scanning of dental implants. Photogrammetry has demonstrated superior results compared to those obtained using the analog technique. Conclusions: The aim of this case report is to provide an overview of analog techniques, digital intraoral optical scanning, and photogrammetry, setting the stage for the introduction of a novel technique involving a dedicated optical scan-transfer device (IPD^®) that can be scanned with ease using IOS, either intra- or extra-orally, due to its unique design features and digital properties. Full article

Background/Objectives: The technical development of implant-supported fixed dental prostheses (iFDP) initially concentrated on the computer-aided manufacturing of prosthetic restorations (CAM). Advances in information technologies have shifted the focus for optimizing digital workflows to AI-based processes for design (CAD). This pre-clinical pilot trial investigated the feasibility of the automatic design of three-unit iFDPs using CAD software (Dental Manger 2021, 3Shape; DentalCAD 3.1 Rijeka, exocad GmbH). Methods: Two clinical scenarios based on a full dentition were created virtually. Physical models were produced and digitized using two intraoral scanners applying quadrant or full-arch scans (Trios3, 3Shape, Copenhagen, Denmark; and Primescan AC, Dentsply Sirona, Bensheim, Germany). For each scenario, iFDP designs were generated automatically using two laboratory software systems (Dental Manger 2021, 3Shape; DentalCAD 3.1 Rijeka, exocad GmbH), resulting in 80 STL datasets (2 scenarios × 2 scan strategies × 2 IOS systems × 5 scan repetitions × 2 software). The files were analyzed clinically for the contact schemes and pontic area. One of the automated designs for each scenario was manually post-processed and one iFDP design for each scenario was manually created by experienced dental technicians (control). The time required for all the design processes was recorded. Results: The automatic design of iFDPs without manual adjustment did not lead to clinically acceptable restorations. The time required for the automatically generated/manually adjusted iFDPs designs was not significantly different to that for the manually designed restorations. Conclusions: Current laboratory software can not automatically generate three-unit iFDPs with clinically acceptable results in terms of the interproximal and occlusal contacts and the pontic design. The automatic iFDP design process currently requires manual adjustment, which means there is no benefit in terms of the working time compared with manually created restorations. Full article

Background: The aim of the present study was to investigate the accuracy of a new digital impression system, comparing it to the plaster impression technique in the realization of full-arch implant-supported metal frameworks. Methods: We took 11 scans (8 of the upper maxilla and 3 of the lower jaw) on a sample of nine patients previously rehabilitated with fixed full-arch screw-retained prostheses following the Columbus Bridge Protocol (CBP) with four to six implants (total: 51) since at least 4 months. Two impressions were taken for each dental arch: one analogic plaster impression using pick-up copings and an open tray technique and a second one using an intra-oral scanner. Two milled metal substructures were realised. The precision and passivity of the substructures were clinically analysed through the Sheffield test and endo-oral radiographs. Laboratory scans of the plaster casts obtained from an intra-oral scanner (IOS) and of the plaster casts obtained from traditional impression were compared with the intraoral scans following Hausdorff’s method and an industrial digital method of optical detection to measure discrepancies. A Mann–Whitney test was performed in order to investigate average distances between surfaces after the superposition. Results: The Sheffield test demonstrated an excellent passivity of the frameworks obtained through both the digital and the analogic method. In 81.81% of cases (n = 9) both substructures were found to have a perfect fit with excellent passivity, while in 18.18% (n = 2) of cases the substructures were found to have a very slight discrepancy. From the radiographic examination, no gaps between the frameworks and the implant heads or multiunit abutments were observed, with 100% accuracy. By superimposing digital files of scans according to Hausdorff’s method, a statistically significant discrepancy (p = 0.006) was found between the digital scans and the digital models obtained from plaster impressions. Three-dimensional optical detection found a mean discrepancy of 0.11 mm between the analogic cast and the cast derived from the digital impression. Conclusions: The present study clinically demonstrates that milled implant-supported full-arch frameworks obtained through a digital scan and the herein described technique have an accuracy comparable to those obtained with traditional plaster impression. Full article

This in vitro study aimed to compare the accuracy of maxilla and mandible full-arch scans from an intraoral scanner via one scan path with six different head movements. Standard maxilla and mandible models via holder were set in a dental chair to simulate position and posture. The reference models’ standard tessellation language (STL) files were formatted via desktop scanner, and operative models’ files were obtained via IOS TRIOS 3 Pod as superimposed by Exocad CAD software. The same scan path with six head movements (Linear, Circle, Wave, 8-figure, S-figure, and A-P) were designed to scan 10 times per jaw, and a total of 120 scan files were then compared with reference files. The data were recorded and deviations of both occlusal and B-L sides were compared, with statistical analysis being performed by one-way analysis of variance (ANOVA) and post hoc comparisons with Tukey test. The trueness of optical impression for full-arch via one path with six head movements differed from maxilla and mandible and depended on the different movements (p < 0.05). In the same path, peak deviation was found at the turning points for left central incisor, left first premolar, left second molar, and right second molar in maxilla, and for right first premolar, second molar, and left second molar in the mandible. The 8-figure movement showed the highest deviation (0.128 ± 0.086 mm) in the maxilla and (0.105 ± 0.069 mm) in the mandible. The Linear movement presented the lowest deviation (0.096 ± 0.07 mm) in the maxilla while the Circle movement presented the lowest deviation (0.073 ± 0.041 mm) in the mandible, with the 8-figure movement showing the worst precision among six movements. In the maxilla, the S- and 8-figure movements were not recommended, while the Linear and Circle movements showed high trueness. In the mandible, the 8-figure movement was not recommended, while the other five presented similar lower deviations. Full article

This in-vitro study aimed to investigate whether intraoral scanners (IOS) are suitable for wear measurement compared to optical profilometry (WLP). A zirconia cast representing the teeth (24–28) was fabricated. It was digitized six times using three different intraoral scanners, Cerec Omnicam AC (OC), Trios 3 (Tr3), and True Definition (TD). The scans were conducted at baseline (t0) and at three different stages of simulated wear (t1–t3), each at one wear-facet on FDI 26 and FDI 27. WLP was used as a reference method. Within each acquisition system, the maximum wear at each facet was analyzed by superimposing the STL data of t0 with t1–t3. A power analysis was performed (G*Power), and the Wilcoxon-signed-rank-test was used to evaluate whether there were statistically significant differences between the groups (Bonferroni corrected) (α = 0.05). At wear-facet FDI 27, differences from +4% t1 TD up to +19% t2 OC, corresponding to a metric value of 8 µm and 45 µm, were measured. At FDI 26 deviations between −2% t1 Tr3, and +10% OC and Tr3, were observed. Considering some limitations, the IOS are a promising alternative to wear measurement based on WLP due to its simple application to capture surface changes in a reasonable and quick way. Full article

Background: The aim of this randomized controlled trial was to evaluate the capability of an IOS (Intra Oral Scanner) device, used in standardized conditions, to detect margins of abutments prepared with knife-edge finishing line located at three different levels in relation to the gingival sulcus. Methods: sixty abutment teeth for treatment with full crowns were selected and randomly divided in three groups accordingly to the depth of the finishing line: Group A: supragingival margin; Group B: 0.5–1.0 mm into the sulcus; Group C: 1.5–2.0 mm into the sulcus. Temporary crowns were placed for two weeks and then digital impressions (Aadva IOS 100, GC, Japan) were made of each abutment. As controls, analog impressions were taken, poured, and scanned using a laboratory scanner (Aadva lab scanner, GC, Japan). Two standard tessellation language (STL) files were generated for each abutment, subsequently processed, and superimposed by Exocad software (Exocad GmbH, Darmstadt, Germany), applying the “best-fit“ algorithm in order to align the scan of the conventional with the digital impressions. The distances between each preparation margin and the adjacent gingival tissue were measured. Four measures were taken, two interproximally and buccally, for a total of six measures of each abutment considering three modes of impressions. The data were statistically evaluated using two-way analysis of variance (ANOVA) for each site and the Bonferroni test. Results: there was no difference between the two kinds of impression in Group A in both sites, in Group B a difference of 0.483 mm and 0.682 mm at interproximal and buccal sites, respectively, and in Group C 0.750 mm and 0.964 mm at interproximal and buccal sites, respectively. The analysis performed on a site level (mesial/distal/vestibular) for the depth of both vertical preparations revealed significant differences (p < 0.0001). After a post hoc analysis (Bonferroni), vestibular sites of the shallow vertical preparations resulted in significantly lower values compared to the other sites prepared deeply. Conclusions: the results showed that the location of the margin is an important factor in making a precise and complete impression when IOS (Intra Oral Scanner) is used. Moreover, deep preparation into the sulcus is not recommended for IOS (Intra Oral Scanner) impressions. Full article

(1) Background: Intraoral optical scanning (IOS) has gained increased importance in prosthodontics. The aim of this in vitro study was to analyze the IOS accuracy for treatment with full crowns, considering possible influencing factors. (2) Methods: Two tooth morphologies, each with four different finish-line designs for tooth preparation and epi- or supragingival locations, were digitally designed, 3D-printed, and post-processed for 16 sample abutment teeth. Specimens were digitized using a laboratory scanner to generate reference STLs (Standard Tessellation Language), and were secondary-scanned with two IOS systems five times each in a complete-arch model scenario (Trios 3 Pod, Primescan AC). For accuracy, a best-fit algorithm (Final Surface) was used to analyze deviations of the abutment teeth based on 160 IOS-STLs compared to the reference STLs (16 preparations × 2 IOS-systems × 5 scans per tooth). (3) Results: Analysis revealed homogenous findings with high accuracy for intra- and inter-group comparisons for both IOS systems, with mean values of 80% quantiles from 20 ± 2 μm to 50 ± 5 μm. Supragingival finishing lines demonstrated significantly higher accuracy than epigingival margins when comparing each preparation (p < 0.05), whereas tangential preparations exhibited similar results independent of the gingival location. Morphology of anterior versus posterior teeth showed slightly better results in favor of molars in combination with shoulder preparations only. (4) Conclusion: The clinical challenge for the treatment with full crowns following digital impressions is the location of the prospective restoration margin related to the distance to the gingiva. However, the overall accuracy for all abutment teeth was very high; thus, the factors tested are unlikely to have a strong clinical impact. Full article

Background: with the emergence of technological innovations in the dental industry, one emerging trend has been the intraoral digitizing of patients by using intraoral scanning systems. Compared to taking conventional impressions, the use of intraoral scanners (IOS) is suitable for capturing direct optical impressions, helping to improve diagnostic efficacy, save time, reduce patient discomfort, and simplify clinical procedures. Intraoral scanning systems appear to have a high potential for providing guidance on proper standards of care. However, one main disadvantage is breathing and saliva secretion, which causes deviations, interfering with the applicability and accuracy of the optical impression. The aim of this study was to compare the validity and accuracy of three commercially available intraoral scanners, performing an analysis exploiting a wet model. Methods: an in vitro experimental study of four permanent teeth (two molars and two premolars) on the accuracy of copings obtained by subgingival preparations was performed, using an oral wet environment model. Two hundred and forty digital impressions were produced from three digital scanners using four samples. Descriptive analysis was performed using mean, standard deviation, and median. ANOVA and F-tests were performed to assess the amount of variability between the groups. For statistical analysis a 95% significance level was chosen. Results: all differences between groups were statistically significant. Conclusions: the present data implicate a huge impact of the oral biological fluids on the accuracy of digital impression to corresponding images, implying a failure of accurate impression under wetness conditions. Full article
