Carbon fiber-reinforced plastics (CFRPs) offer excellent in-plane mechanical performance, but their relatively low interlaminar fracture toughness makes them vulnerable to delamination, particularly around intralaminar discontinuities such as resin-rich regions or fiber gaps. This study investigates the effectiveness of polyamide (PA) mesh inserts in improving interlaminar toughness and suppressing delamination in CFRP laminates with such features. Two PA mesh configurations were evaluated: a fully embedded continuous layer and a 20 mm cut mesh strip placed between continuous and discontinuous plies near critical regions. Fracture toughness tests showed that PA mesh insertion improved interlaminar toughness approximately 2.4-fold compared to neat CFRP, primarily due to a mechanical interlocking mechanism that disrupts crack propagation and enhances energy dissipation. Uniaxial tensile tests with digital image correlation revealed that while initial matrix cracking occurred at similar stress levels, the stress at which complete delamination occurred was approximately 60% higher in specimens with a 20 mm mesh and up to 92% higher in specimens with fully embedded mesh. The fully embedded mesh provided consistent delamination resistance across the laminate, while the 20 mm insert localized strain redistribution and preserved global mechanical performance. These findings demonstrate that PA mesh is an effective interleaving material for enhancing damage tolerance in CFRP laminates with internal discontinuities. Full article

The fuselage serves as the primary component of commercial aircraft. The strength reliability of fuselage panels is therefore crucial for commercial aircraft. In the present study, a finite element (FE)-based modeling approach has been developed to predict the post-buckling behavior of curved fuselage panels under combined axial compression and in-plane shear loads at different shear-to-compression ratios. The intra-laminar damage was replicated using a progressive damage model driven by the Hashin’s failure criteria, while the skin−stiffener debonding was modeled using the cohesive zone model. Failure tests were performed using a bespoke Fuselage Panel Test System (FPTS), enabling comparison between experiments and simulations. The predicted buckling loads and ultimate failure loads are in good agreement with those obtained from experiments, which verify the predictive capability of the FE model. The failure load of the panels was found to be at least 30% higher than the initial buckling loads for all loading cases, indicating significant post-buckling load-carrying capacity. Under these four loading conditions studied, the load transfer mechanisms of curved panels were examined. All specimens experienced local skin buckling and subsequent global buckling, resulting in skin−stiffener debonding followed by fracture of the stiffeners, which was the dominant failure mechanism for the panel studied. Full article

This study explores the mechanical behaviour of intra-laminar hybrid flax/E-glass composites, focusing on the role of micro-scale irregularities in flax fibres. By employing computational micromechanics and Monte Carlo simulations, it analyses the influence of flax fibre geometry and elastic properties on the performance of hybrid and non-hybrid composites. A Non-Circular Fibre Distribution (NCFD) algorithm is introduced to generate microstructures with randomly distributed non-circular flax and circular E-glass fibres, which are then modelled using a 3D representative volume element (RVE) model developed in Python 2.7 and implemented with Abaqus/Standard. The RVE dimensions were specified as ten times the mean characteristic length of flax fibres (580 μm) for the width and length, while the thickness was defined as one-tenth the radius of the E-glass fibre. Results show that Monte Carlo simulations accurately estimate the effect of fibre variabilities on homogenised elastic constants when compared to measured values and Halpin-Tsai predictions, and they effectively evaluate the fibre/matrix interfacial stresses and von Mises matrix stresses. While these variabilities minimally affect the homogenised properties, they increase the presence of highly stressed regions, especially at the interface and matrix of flax/epoxy composites. Additionally, intra-laminar hybridisation further increases local stress in these critical areas. These findings improve our understanding of the relationship between the natural fibre shape and mechanical performance in flax/E-glass composites, providing valuable insights for designing and optimising advanced composite materials to avoid or delay damage, such as matrix cracking and splitting, under higher applied loads. Full article

This paper investigates the low-velocity impact response and damage behavior of glass fiber reinforced polymer (GFRP) hollow ribbed emergency pipes of our design under different impact heights. Drop hammer impact tests with impact velocities of 8.41 m/s, 8.97 m/s, and 9.50 m/s were conducted using an impact platform. A progressive damage model for low-velocity impact was developed using Abaqus/Explicit finite element software. The model used the three-dimensional Hashin damage initiation criteria and a damage evolution model based on the equivalent strain method to simulate the initiation and evolution of intralaminar damage in the pipe ring. A cohesive zone model (CZM) based on a bilinear traction-separation law was used to simulate delamination. The results show that the pipe rings experienced fiber or matrix fractures and delamination damage during the impact process. Additionally, the pipe ring specimens underwent bending vibrations under the impact load, leading to fluctuating contact forces at all three impact heights. Analysis of the simulation results reveals that the primary damage modes in the GFRP hollow ribbed emergency pipe are fiber tension damage, matrix tension damage, and fiber compression damage, with delamination occurring mainly in the impact area and the interface area on both sides of the rib. Full article

Recent research emphasizes the growing use of advanced composite materials in modern transportation, highlighting their superior weight-to-strength ratio. These materials are increasingly replacing steel and aluminium in housings to enhance sustainability, improve efficiency, and reduce emissions. Considering these advancements, this article reviews recent studies on composite materials, focusing on fatigue life assessment models. These models, which include performance degradation, progressive damage, and S–N curve models, are essential for ensuring the reliability of composite materials. It is noted that the fatigue damage process in composite materials is complex, as failure can occur in the matrix, reinforcement, or transitions such as interlaminar and intralaminar delamination. Additionally, the article critically examines the integration of artificial intelligence techniques for predicting the fatigue life of composite materials, offering a comprehensive analysis of methods used to indicate the mechanical properties of battery shell composites. Incorporating neural networks into fatigue life analysis significantly enhances prediction reliability. However, the model’s accuracy depends heavily on the comprehensive data it includes, including material properties, loading conditions, and manufacturing processes, which help to reduce variability and ensure the precision of the predictions. This research underscores the importance of continued advancements and their significant scientific contributions to transportation sustainability, especially in the context of emerging artificial intelligence technologies. Full article

This study investigates the effectiveness of polyether block amide (PEBA) thermoplastic elastomeric nanofibers in reducing low-velocity impact damage across three carbon fiber composite lay-up configurations: a cross-ply [0°/90°]2s (CP) and a quasi-isotropic [0°/45°/90°/−45°]s (QI) lay-up utilizing unidirectional plies, and a stacked woven [(0°,90°)]4s (W) lay-up using twill woven fabric plies. The flexural strength and interlaminar shear strength of the composites remained unaffected by the addition of nanofibers: around 750 MPa and 63 MPa for CP, 550 MPa and 58 MPa for QI, and 650 MPa and 50 MPa for W, respectively. The incorporation of nanofibers in the interlaminar regions resulted in a substantial reduction in projected damage area, ranging from 30% to 50% reduction over an impact energy range of 5–20 J. Microscopic analysis showed that especially the delamination damage decreased in toughened composites, while intralaminar damage remained similar for the cross-ply and quasi-isotropic lay-ups and decreased only in the woven lay-up. This agrees with the broad body of research that shows that interleaved nanofibers result in a higher delamination resistance due to toughening mechanisms related to nanofiber bridging of cracks. Despite their ability to mitigate delamination during impact, nanofibers showed limited positive effects on Compression After Impact (CAI) strength in quasi-isotropic and cross-ply composites. Interestingly, only the woven fabric composites demonstrated improved CAI strength, with a 12% improvement on average over the impact energy range, attributed to a reduction in both interlaminar and intralaminar damage. This study indicates the critical role of fiber integrity over delamination size in determining CAI performance, suggesting that the delaminations are not sufficiently large to induce buckling of sub-layers, thereby minimizing the effect of nanofiber toughening on the CAI strength. Full article

This paper presents a mesoscale damage model for composite materials and its validation at the coupon level by predicting scaling effects in un-notched carbon-fiber reinforced polymer (CFRP) laminates. The proposed material model presents a revised longitudinal damage law that accounts for the effect of complex 3D stress states in the prediction of onset and broadening of longitudinal compressive failure mechanisms. To predict transverse failure mechanisms of unidirectional CFRPs, this model was then combined with a 3D frictional smeared crack model. The complete mesoscale damage model was implemented in ABAQUS^®/Explicit. Intralaminar damage onset and propagation were predicted using solid elements, and in-situ properties were included using different material cards according to the position and effective thickness of the plies. Delamination was captured using cohesive elements. To validate the implemented damage model, the analysis of size effects in quasi-isotropic un-notched coupons under tensile and compressive loading was compared with the test data available in the literature. Two types of scaling were addressed: sublaminate-level scaling, obtained by the repetition of the sublaminate stacking sequence, and ply-level scaling, realized by changing the effective thickness of each ply block. Validation was successfully completed as the obtained results were in agreement with the experimental findings, having an acceptable deviation from the mean experimental values. Full article

This paper studies the behavior of S2-glass woven fabric reinforced polymer composite under low-velocity impact at 18–110 J energy. A macro-homogeneous finite element model for the prediction of their response is implemented, considering the non-linear material behavior and intralaminar and interlaminar failure modes for the prediction of impact damage. The model accurately predicted the permanent indentation caused by impact. By applying the Ramberg-Osgood formulation, different initial stiffness values are examined to assess the post-impact unloading response. This approach reveals the significant role of initial stiffness in inelastic strain accumulation and its consequent effect on permanent indentation depth. A higher initial stiffness correlates with increased inelastic strain, influencing the impactor rebound and resulting in greater permanent indentation. By accurately predicting permanent indentation, and damage accumulation for different impact energies, this study contributes to a better understanding of the impact behavior of composite materials, thereby promoting their wider application. Full article

The failure of composite laminates under cyclic fatigue loads is complex, as multiple failure mechanisms are in play at different scales and interact with each other. Predicting the remaining fatigue life as well as the residual capacities of a composite laminate or component is crucial, particularly for safety-critical applications. A progressive fatigue model is proposed to describe the catastrophic failure of open-hole laminates under tensile cyclic fatigue. To represent both intra-laminar and inter-laminar damage, a combination of a continuum damage mechanics model (CDM) and a discrete cohesive zone model (CZM) is implemented in the finite element (FE) software Abaqus. The CDM combines fibre- and matrix-dominated S-N curves with the Palmgren–Miner accumulation rule and Hashin’s residual strength to form a fatigue failure criterion differentiating between fibre failure (FF) and matrix failure (MF). The CZM implemented in this work is the CF20 model proposed by NASA. Fatigue cycling is simulated using an external cycle-jump scheme, where the stiffness degradation is conducted between the FE simulations outside of the implicit solver [90/0] s. Glass fibre reinforced polymer (GFRP) open-hole specimens were tested in tensile cyclic fatigue at a load ratio of 0.1. The experiments were reproduced numerically and the results compared. After calibration of a set of parameters based on one load level, the model was able to reproduce the experimental S-N curve very well, predicting a slope of −0.10, while the experimental value was −0.11. The failure sequence of the laminate was also successfully reproduced. The growth of the split from the hole, and its interaction with inter-laminar delamination, was successfully captured. The proposed approach was able to describe the fatigue failure of an open-hole laminate with a minimal set of material inputs using a simplified fatigue damage model while avoiding convergence issues. Full article

Carbon fiber reinforced polymer composites are widely used in the rehabilitation, repair, and strengthening of civil, marine, and naval infrastructure and structural systems. In these applications, they are exposed to a range of exposure conditions, including humidity and immersion, which are known to affect the durability of the resin and the fiber–matrix interface over long periods of time. This paper presents results of long-term hygrothermal aging of wet layup carbon/epoxy composites including through acceleration by temperature focusing on the development of a comprehensive understanding of moisture uptake kinetics and its effects on glass transition temperature and interface and inter-/intra-laminar dominated performance characteristics. A two-phase model for uptake that incorporates both diffusion- and relaxation-/deterioration-dominated regimes, as well as a transition regime, is shown to describe uptake well. The inclusion of damage terms to the diffusion and relaxation coefficients is seen to capture changes well, with the effective diffusion and relaxation coefficients increasing with fiber volume fraction and temperature. Effects of uptake, including at elevated temperatures, reflective of accelerated aging, on glass transition temperature and flexural strength are correlated, emphasizing a three-stage progression of overall response in line with the moisture uptake changes. The drop in glass transition temperature per percent increase in moisture uptake was seen to range from a low of 4.38% per % increase in moisture content, for the highest volume fraction at the highest temperature, to a high of 6.95% per % increase in moisture content, for the intermediate volume fraction at the lowest temperature. The composites with heavier fabric showed the greatest drop in both glass transition temperature and flexural strength, indicating a level of correlation between these characteristics as well. It is shown that both glass transition temperature and flexural strength show steep initial decreases, followed by a regime with slower decrease and, then, an asymptotic or near-asymptotic response with time of immersion, suggesting a close correlation with moisture uptake, which forms the basis for future modeling. Full article

The effect of the interface stiffness and interface strength on the low-velocity impact response of woven-fabric semicylindrical composite shells is studied using finite element (FE) models generated with continuum shell elements and cohesive surfaces. The intralaminar damage is accounted for using the constitutive model provided within the ABAQUS software, while the interlaminar is addressed utilising cohesive surfaces. The results show that the interface stiffness has a negligible effect on the force and energy histories for values between 10${}^1$ N/mm${}^3$ and 2.43 × 10${}^6$ N/mm${}^3$. However, it has a significant impact on the delamination predictions. It is observed that only the normal interface strength affects the maximum impact force and the delamination predictions. Increasing its value from 15 MPa to 30 MPa resulted in an 8% growth in the maximum force, and a substantial reduction in the delaminated area. The obtained results serve as guidelines for the accurate and efficient computation of delamination. The successful validation of the FE models establishes a solid foundation for further numerical investigations and offers the potential to significantly reduce the time and expenses associated with experimental testing. Full article

This paper presents an efficient and reliable approach to study the low-velocity impact response of woven composite shells using 3D finite element models that account for the physical intralaminar and interlaminar progressive damage. The authors’ previous work on the experimental assessment of the effect of thickness on the impact response of semicylindrical composite laminated shells served as the basis for this paper. Therefore, the finite element models were put to the test in comparison to the experimental findings. A good agreement was obtained between the numerical predictions and experimental data for the load and energy histories as well as for the maximum impact load, maximum displacement, and contact time. The use of the mass-scaling technique was successfully implemented, reducing considerably the computing cost of the solutions. The maximum load, maximum displacement, and contact time are negligibly affected by the choice of finite element mesh discretization. However, it has an impact on the initiation and progression of interlaminar damage. Therefore, to accurately compute delamination, its correct definition is of upmost importance. The validation of these finite element models opens the possibility for further numerical studies on of woven composite shells and enables shortening the time and expenses associated with the experimental testing. Full article

This work presents a novel strategy for detecting and localizing intra- or inter-laminar damages in composite structures using surface-instrumented strain sensors. It is based on the real-time reconstruction of structural displacements using the inverse Finite Element Method (iFEM). The iFEM reconstructed displacements or strains are post-processed or ‘smoothed’ to establish a real-time healthy structural baseline. As damage diagnosis is based on comparing damaged and healthy data obtained using the iFEM, no prior data or information regarding the healthy state of the structure is required. The approach is applied numerically on two carbon fiber-reinforced epoxy composite structures: for delamination detection in a thin plate, and skin-spar debond detection in a wing box. The influence of measurement noise and sensor locations on damage detection is also investigated. The results demonstrate that the proposed approach is reliable and robust but requires strain sensors proximal to the damage site to ensure accurate predictions. Full article

Currently, FRP composite tubes are drawing increasing attention in many industrial applications, due to their excellent mechanical and lightweight properties, with reduced energy consumption and enhanced sustainability. This study investigates the failure mechanisms and crashworthiness performance of glass and carbon fibre reinforced polymer (GFRP and CFRP) composite tubes under low velocity transverse impact. Finite element methods were developed to establish numerical models to predict the failure responses of FRP composite tubes with a complex ply sequence of both woven and unidirectional layers. In the modelling, continuum damage mechanics and cohesive zone method were used to calculate the intralaminar and interlaminar failure behaviours, respectively, in FRP composite tubes. The numerical models were validated by corresponding experiments, and the effects of the impact energy and material type were investigated. The experimental results show that the initial impact energy does not significantly affect the specific energy absorption (SEA) and peak force (PF) of GFRP composite tubes, and the SEA and PF are generally around 0.5 kJ/kg and 600 N, respectively, when the impact energy varies from 10 J to 50 J. Failure mechanism analyses show that GFRP tubes and CFRP tubes with totally unidirectional plies present global bending deformation with significant matrix damage, and CFRP tubes with “hybrid layer type” exhibit local penetration with severe fibre and matrix damage. The crashworthiness analyses indicate that CFRP tubes perform better in SEA while GFRP tubes possess smaller PF when subjected to low velocity transverse impact. Full article

Impact indentation is believed to be an effective indication of low-velocity impact (LVI) damage for polymer matrix composites. However, it has been discovered that an indentation can partially rebound over time. Impact indentation and its rebound behavior over a period of time are significantly affected by hygrothermal conditions, especially moisture absorption. Therefore, a good understanding of the moisture-dependent impact indentation and its rebound behavior is helpful for impact damage assessment for composites. In this paper, moisture effects are considered for both the intra-laminar transverse property model and the interlaminar interface model in the simulation of impact indentation. Then, in these two models, viscosities are introduced to represent the indentation rebound over time. In order to validate the proposed models, LVI experiments with different impact energies were conducted on dry and hygrothermal conditioned carbon fiber/epoxy matrix composite laminates. For the specimens, the initial depths of impact dents and their rebounds over time were measured. The specimens of hygrothermal conditions were found with deeper dents compared with dry ones under the same impact energy; and their rebounds were also more significant. These phenomena were explained by the fact that moisture softens epoxy in composite and meanwhile elevates its viscosity. This indentation and its rebound phenomenon were simulated in ABAQUS by considering the moisture effects and viscoelasticity with user-defined material subroutines. These experiments were simulated using the proposed models, and the numerical predictions conformed well with the experimental observations. Full article
