Search Results (123)

Search Parameters:
Keywords = interlaminar toughness

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
22 pages, 6962 KiB
Article
Suppression of Delamination in CFRP Laminates with Ply Discontinuity Using Polyamide Mesh
by M. J. Mohammad Fikry, Keisuke Iizuka, Hayato Nakatani, Satoru Yoneyama, Vladimir Vinogradov, Jun Koyanagi and Shinji Ogihara
J. Compos. Sci. 2025, 9(8), 414; https://doi.org/10.3390/jcs9080414 - 4 Aug 2025
Viewed by 109
Abstract
Carbon fiber-reinforced plastics (CFRPs) offer excellent in-plane mechanical performance, but their relatively low interlaminar fracture toughness makes them vulnerable to delamination, particularly around intralaminar discontinuities such as resin-rich regions or fiber gaps. This study investigates the effectiveness of polyamide (PA) mesh inserts in [...] Read more.
Carbon fiber-reinforced plastics (CFRPs) offer excellent in-plane mechanical performance, but their relatively low interlaminar fracture toughness makes them vulnerable to delamination, particularly around intralaminar discontinuities such as resin-rich regions or fiber gaps. This study investigates the effectiveness of polyamide (PA) mesh inserts in improving interlaminar toughness and suppressing delamination in CFRP laminates with such features. Two PA mesh configurations were evaluated: a fully embedded continuous layer and a 20 mm cut mesh strip placed between continuous and discontinuous plies near critical regions. Fracture toughness tests showed that PA mesh insertion improved interlaminar toughness approximately 2.4-fold compared to neat CFRP, primarily due to a mechanical interlocking mechanism that disrupts crack propagation and enhances energy dissipation. Uniaxial tensile tests with digital image correlation revealed that while initial matrix cracking occurred at similar stress levels, the stress at which complete delamination occurred was approximately 60% higher in specimens with a 20 mm mesh and up to 92% higher in specimens with fully embedded mesh. The fully embedded mesh provided consistent delamination resistance across the laminate, while the 20 mm insert localized strain redistribution and preserved global mechanical performance. These findings demonstrate that PA mesh is an effective interleaving material for enhancing damage tolerance in CFRP laminates with internal discontinuities. Full article
Show Figures

Figure 1

19 pages, 4697 KiB
Article
The Delamination Behaviour of Basalt Fibre-Reinforced In Situ-Polymerisable Acrylic and Epoxy Composites: A Sustainable Solution for Marine Applications
by Mohamad Alsaadi, Tomas Flanagan, Daniel P. Fitzpatrick and Declan M. Devine
Sustainability 2025, 17(15), 6967; https://doi.org/10.3390/su17156967 - 31 Jul 2025
Viewed by 224
Abstract
This research paper employed novel sustainable alternative materials to reduce the environmental impact of thermoset/synthetic fibre composites. The effect of seawater hydrothermal ageing at 45 °C for 45 and 90 days on the physical and interlaminar fracture toughness (mode I and mode II) [...] Read more.
This research paper employed novel sustainable alternative materials to reduce the environmental impact of thermoset/synthetic fibre composites. The effect of seawater hydrothermal ageing at 45 °C for 45 and 90 days on the physical and interlaminar fracture toughness (mode I and mode II) of a semi-unidirectional non-crimp basalt fibre (BF)-reinforced acrylic matrix and epoxy matrix composites was investigated. Optical and scanning electron microscopes were used to describe the fracture and interfacial failure mechanisms. The results show that the BF/Elium composite exhibited higher fracture toughness properties compared to the BF/Epoxy composite. The results of the mode I and mode II interlaminar fracture toughness values for the BF/Elium composite were 1280 J/m2 and 2100 J/m2, which are 14% and 56% higher, respectively, than those of the BF/Epoxy composite. The result values for both composites were normalised with respect to the density of each composite laminate. The saturated moisture content and diffusion coefficient values of seawater-aged samples at 45 °C and room temperature for the BF/Elium and BF/Epoxy composites were analysed. Both composites exhibited signs of polymer matrix decomposition and fibre surface degradation under the influence of seawater hydrothermal ageing, resulting in a reduction in the mode II interlaminar fracture toughness values. Enhancement was observed in mode I fracture toughness under hydrothermal ageing, particularly for the BF/Epoxy composite, due to matrix plasticisation and fibre bridging. Full article
(This article belongs to the Section Sustainable Materials)
Show Figures

Figure 1

19 pages, 10561 KiB
Article
Environmental Effects of Moisture and Elevated Temperatures on the Mode I and Mode II Interlaminar Fracture Toughness of a Toughened Epoxy Carbon Fibre Reinforced Polymer
by Anna Williams, Ian Hamerton and Giuliano Allegri
Polymers 2025, 17(11), 1503; https://doi.org/10.3390/polym17111503 - 28 May 2025
Cited by 1 | Viewed by 628
Abstract
The use of composite materials within extreme environments is an exciting frontier in which a wealth of cutting-edge developments have taken place recently. Although there is vast knowledge of composites’ behaviour in standard room temperature and humidity, there is a great need to [...] Read more.
The use of composite materials within extreme environments is an exciting frontier in which a wealth of cutting-edge developments have taken place recently. Although there is vast knowledge of composites’ behaviour in standard room temperature and humidity, there is a great need to understand their performance in ‘hot/wet’ conditions, as these are the conditions of their envisaged applications. One of the key failure mechanisms within composites is interlaminar fracture, commonly referred to as delamination. The environmental effects of moisture and elevated temperatures on interlaminar fracture toughness are therefore essential design considerations for laminated aerospace-grade composite materials. IM7/8552, a toughened epoxy/carbon fibre reinforced polymer, was experimentally characterised in both ‘Dry’ and ‘Wet’ conditions at 23 °C and 90 °C. A moisture uptake study was conducted during the ‘Wet’ conditioning of the material in a 70 °C/85% relative humidity environment. Dynamic mechanical thermal analysis was carried out to determine the effect of moisture on the glass transition temperature of the material. Mode I initiation and propagation fracture properties were determined using double cantilevered beam specimens and Mode II initiation fracture properties were deduced using end-notched flexure specimens. The effects of precracking and the methodology of high-temperature testing are discussed in this report. Mode I interlaminar fracture toughness, GIC, was found to increase with elevated temperatures and moisture content, with GIC=0.205kJ/m2 in ‘Dry 23 °C’ conditions increasing by 26% to GIC=0.259kJ/m2 in ‘Wet 90 °C’ conditions, demonstrating that the material exhibited its toughest behaviour in ‘hot/wet’ conditions. Increased ductility due to matrix softening and fibre bridging caused by temperature and moisture were key contributors to the elevated GIC values. Mode II interlaminar fracture toughness, GIIC, was observed to decrease most significantly when moisture or elevated temperature was applied individually, with the combination of ‘hot/wet’ conditions resulting in an 8% drop in GIIC, with GIIC=0.586kJ/m2 in ‘Dry 23 °C’ conditions and GIIC=0.541kJ/m2 in ‘Wet 90 °C’ conditions. The coupled effect of fibre-matrix interface degradation and increased plasticity due to moisture resulted in a relatively small knockdown on GIIC compared to GIC in ‘hot/wet’ conditions. Fractographic studies of the tested specimens were conducted using scanning electron microscopy. Noteworthy surface topography features were observed on specimens of different fracture modes, moisture saturation levels, and test temperature conditions, including scarps, cusps, broken fibres and river markings. The qualitative features identified during microscopy are critically examined to extrapolate the differences in quantitative results in the various environmental conditions. Full article
Show Figures

Graphical abstract

15 pages, 1952 KiB
Article
Influence of Geometric Non-Linearities on the Mixed-Mode Decomposition in Asymmetric DCB Samples
by Jorge Bonhomme, Victoria Mollón, Jaime Viña and Antonio Argüelles
Fibers 2025, 13(6), 70; https://doi.org/10.3390/fib13060070 - 27 May 2025
Viewed by 683
Abstract
The Asymmetric Double Cantilever Beam (ADCB) is a common test configuration used to produce mixed mode I/II in composite materials. It consists of two sublaminates with different thicknesses or elastic properties, a situation that usually occurs in bimaterial adhesive joints. During this test, [...] Read more.
The Asymmetric Double Cantilever Beam (ADCB) is a common test configuration used to produce mixed mode I/II in composite materials. It consists of two sublaminates with different thicknesses or elastic properties, a situation that usually occurs in bimaterial adhesive joints. During this test, the sample undergoes rotation. In this work, the influence of this rotation on the calculation of the energy release rate (ERR) in modes I and II was studied using the Finite Element Method (FEM). Several models with different degrees of asymmetry (different thickness ratio and/or elastic modulus ratio) and different applied displacements were prepared to obtain different levels of rotation during the test. As is known, the concept of modes I and II refers to the components of the energy release rate calculated in the direction perpendicular and tangential to the delamination plane, respectively. If the model experiences significant rotation during the application of the load, this non-linearity must be considered in the calculation of the mode partition I/II. In this work, appreciable differences were observed in the values of modes I and II, depending on their calculation in a global system or a local system that rotates with the sample. When performing crack growth calculations, the difference between critical loads can be in the order of 4%, while the difference between mode I and mode II results can reach 4% and 14%, respectively, for an applied displacement of only 5 mm. Currently, this correction is not usually implemented in Finite Element calculation codes or in analytical developments. The purpose of this article is to draw attention to this aspect when the rotation of the specimen is not negligible. Full article
Show Figures

Figure 1

17 pages, 3502 KiB
Article
Overcoming Low-Polarity Limitations in Polyphenylene Oxide Electrospinning: Chemical Functionalization and Polymer Hybridization for Interlaminar Toughening of Carbon Fiber Composites
by Yuan Huang, Yi Wei, Canyi Huang, Yiping Qiu, Bohong Gu and Bo Yang
Polymers 2025, 17(11), 1480; https://doi.org/10.3390/polym17111480 - 27 May 2025
Viewed by 518
Abstract
This study investigates the optimization of polyphenylene oxide (PPO) electrospinning for interlaminar toughening in composites, using sulfonation modification and physical blending with polylactic acid (PLA) and polystyrene (PS). Both strategies showed excellent electrospinning performance, significantly reducing fiber diameter (PPO: 12.1 ± 5.8 μm; [...] Read more.
This study investigates the optimization of polyphenylene oxide (PPO) electrospinning for interlaminar toughening in composites, using sulfonation modification and physical blending with polylactic acid (PLA) and polystyrene (PS). Both strategies showed excellent electrospinning performance, significantly reducing fiber diameter (PPO: 12.1 ± 5.8 μm; sulfonated PPO: 524 ± 42 nm; PPO-PLA: 4.73 ± 0.94 μm; PPO-PS: 3.43 ± 0.34 μm). In addition, the PPO-PS fibers were uniform, while PPO-PLA exhibited a mixture of fine and coarse fibers due to phase separation. Interlaminar fracture toughness testing showed that PPO-PS offered the greatest toughening, with GICini and GICpre increasing by 223% and 232%, respectively, compared to the values of the untoughened sample, and by 65% and 61.5% compared to those of the PPO sample. GIIC of the PPO-PS sample was 196% greater than that of the untoughened sample and 30% higher than that of the PPO sample. Scanning electron microscope (SEM) analysis of fracture morphology revealed that the high-toughness system dissipated energy through fiber bridging, plastic deformation, and multi-scale crack deflection, while the low-toughness samples failed due to interface debonding or cohesive failure. This work demonstrates that PPO-PS veils enhance interlaminar toughness through interface reinforcement and multiple toughening mechanisms, providing an effective approach for high-performance composites. Full article
(This article belongs to the Special Issue Advanced Epoxy-Based Materials, 5th Edition)
Show Figures

Figure 1

18 pages, 8651 KiB
Article
Interlaminar Fracture Toughness Analysis for Reliability Improvement of Wind Turbine Blade Spar Elements Based on Pultruded Carbon Fiber-Reinforced Polymer Plate Manufacturing Method
by Hakgeun Kim, Yunjung Jang, Sejin Lee, Chanwoong Choi and Kiweon Kang
Materials 2025, 18(2), 357; https://doi.org/10.3390/ma18020357 - 14 Jan 2025
Viewed by 1000
Abstract
The key structural components of a wind turbine blade, such as the skin, spar cap, and shear web, are fabricated from fiber-reinforced composite materials. The spar, predominantly manufactured via resin infusion—a process of resin injection and curing in carbon fibers—is prone to initial [...] Read more.
The key structural components of a wind turbine blade, such as the skin, spar cap, and shear web, are fabricated from fiber-reinforced composite materials. The spar, predominantly manufactured via resin infusion—a process of resin injection and curing in carbon fibers—is prone to initial defects, such as pores, wrinkles, and delamination. This study suggests employing the pultrusion technique for spar production to consistently obtain a uniform cross-section and augment the reliability of both the manufacturing process and the design. In this context, this study introduces carbon fiber-reinforced polymer (CFRP/CFRP) and glass fiber-reinforced polymer (GFRP/CFRP) test specimens, which mimic the bonding structure of the spar cap, utilizing pultruded CFRP in accordance with ASTM standards to analyze the delamination traits of the spar. Delamination tests—covering Mode I (double cantilever beam), Mode II (end-notched flexure), and mixed mode (mixed-mode bending)—were performed to gauge displacement, load, and crack growth length. Through this crack growth mechanism, the interlaminar fracture toughness derived was examined, and the stiffness and strength changes compared to CFRP based on the existing prepreg manufacturing method were analyzed. In addition, the interlaminar fracture toughness for GFRP, which is a material in contact with the spar structure, was analyzed, and through this, it was confirmed that the crack behavior has less deviation compared to a single CFRP material depending on the stiffness difference between the materials when joining dissimilar materials. This means that the higher the elasticity of the high-stiffness material, the higher the initial crack resistance, but the crack growth behavior shows non-uniform characteristics thereafter. This comparison provides information for predicting interlaminar delamination damage within the interior and bonding area of the spar and skin and provides insight for securing the reliability of the design life. Full article
(This article belongs to the Section Advanced Composites)
Show Figures

Figure 1

16 pages, 17447 KiB
Article
Research on Interlayer Toughening and Damage Detection of Laser-Induced Graphene and Short Kevlar Fibers Aramid Fiber/Epoxy Resin Composites
by Baolai Wang, Weidong Tian, Chao Wang and Qi Wang
Polymers 2024, 16(23), 3380; https://doi.org/10.3390/polym16233380 - 30 Nov 2024
Cited by 1 | Viewed by 1161
Abstract
The poor interlaminar fracture toughness is a critical limiting factor for the structural applications of aramid fiber/epoxy resin composites. This study investigates the effects of laser-induced graphene (LIG) and short Kevlar fibers on the interfacial toughness and damage detection of aramid composite materials. [...] Read more.
The poor interlaminar fracture toughness is a critical limiting factor for the structural applications of aramid fiber/epoxy resin composites. This study investigates the effects of laser-induced graphene (LIG) and short Kevlar fibers on the interfacial toughness and damage detection of aramid composite materials. Mode II tests and tensile tests were conducted to evaluate mechanical properties and damage detection using the piezoresistive characteristics of LIG. The results indicate that LIG combined with short Kevlar fibers significantly enhances the interfacial toughness of the composites, achieving a 381.60% increase in initial Mode II fracture toughness. Although LIG reduced the tensile strength by 14.02%, the addition of short Kevlar fibers mitigated this effect, preserving the overall mechanical performance. Scanning electron microscopy (SEM) analysis revealed enhanced toughening mechanisms, including increased surface roughness, altered crack propagation paths, and fiber bridging. Additionally, LIG enabled real-time damage monitoring, showing a significant increase in resistance upon delamination or crack propagation and a marked increase in resistance upon the tensile fracture. This research indicates that the synergistic effects of LIG and short Kevlar fibers not only enhance the interlaminar toughness of aramid composites but also provide a novel strategy for effective damage detection in fiber-reinforced materials. Full article
(This article belongs to the Special Issue Additive Manufacturing of Fibre Reinforced Polymer Composites)
Show Figures

Figure 1

22 pages, 8368 KiB
Article
Low-Velocity Impact Analysis in Composite Plates Incorporating Experimental Interlaminar Fracture Toughness
by Gyeong-Han Lee, Ji-Yoon Yang, Sang-Woo Kim and Soo-Yong Lee
Materials 2024, 17(23), 5768; https://doi.org/10.3390/ma17235768 - 25 Nov 2024
Cited by 1 | Viewed by 920
Abstract
Reliable performance of composite adhesive joints under low-velocity impact is essential for ensuring the structural durability of composite materials in demanding applications. To address this, the study examines the effects of temperature, surface treatment techniques, and bonding processes on interlaminar fracture toughness, aiming [...] Read more.
Reliable performance of composite adhesive joints under low-velocity impact is essential for ensuring the structural durability of composite materials in demanding applications. To address this, the study examines the effects of temperature, surface treatment techniques, and bonding processes on interlaminar fracture toughness, aiming to identify optimal conditions that enhance impact resistance. A Taguchi experimental design and analysis of variance (ANOVA) were used to analyze these factors, and experimentally derived toughness values were applied to low-velocity impact simulations to assess delamination behavior. Sanding and co-bonding were identified as the most effective methods for improving fracture toughness. Under the identified optimal conditions, the low-velocity impact analysis showed a delamination area of 319.0 mm2. These findings highlight the importance of parameter optimization in enhancing the structural reliability of composite adhesive joints and provide valuable insights for improving the performance and durability of composite materials, particularly in aerospace and automotive applications. Full article
(This article belongs to the Special Issue Impact Behaviour of Materials and Structures)
Show Figures

Figure 1

12 pages, 10087 KiB
Article
Effects of a Novel Three-Dimensional-Printed Wood–Polylactic Acid Interlayer on the Mode II Delamination of Composites
by Mazaher Salamat-Talab, Hossein Kazemi, Alireza Akhavan-Safar, Hossein Malekinejad, Ricardo J. C. Carbas and Lucas F. M. da Silva
J. Compos. Sci. 2024, 8(12), 489; https://doi.org/10.3390/jcs8120489 - 22 Nov 2024
Cited by 1 | Viewed by 1151
Abstract
The interlayering method effectively enhances resistance against delamination in laminated composites. However, synthesis methods for interlayers have been limited and, at times, expensive. Consequently, this study investigates the effect of innovative 3D-printed wood–PLA interlayers on the mode II interlaminar fracture toughness (ILFT) of [...] Read more.
The interlayering method effectively enhances resistance against delamination in laminated composites. However, synthesis methods for interlayers have been limited and, at times, expensive. Consequently, this study investigates the effect of innovative 3D-printed wood–PLA interlayers on the mode II interlaminar fracture toughness (ILFT) of glass/epoxy composites. These interlayers feature a geometric structure comprising rhomboidal cell shapes, enabling the filament to maintain an equal volume percentage to the resin at the delamination interface. To this end, end-notch flexure (ENF) specimens were prepared, and the mode II ILFT was determined using the compliance-based beam method. The experimental results demonstrate a substantial increase in initiation load tolerance (32%) due to the 3D-printed interlayer. The R-curve analysis of the specimens with interlayers reveals significant enhancement in critical delamination parameters, including the length of the fracture process zone (23%), initiation ILFT (80%), and propagation ILFT (44%), compared to the samples without interlayers. The fracture surface analysis of the reinforced specimens with interlayers demonstrated that the interlayer positively impacts the delamination resistance of the ENF specimens. They create a larger resin-rich area and increase surface friction at the delamination interface. Also, this facilitates a crack front pinning mechanism and changes the direction of crack growth. Full article
(This article belongs to the Special Issue Recent Progress in Hybrid Composites)
Show Figures

Graphical abstract

20 pages, 5025 KiB
Article
Toughened Vinyl Ester Resin Reinforced with Natural Flax Fabrics
by Bianca Dal Pont, Laura Aliotta, Elisa Tognarelli, Vito Gigante and Andrea Lazzeri
Appl. Sci. 2024, 14(22), 10459; https://doi.org/10.3390/app142210459 - 13 Nov 2024
Cited by 1 | Viewed by 1890
Abstract
Vinyl ester resins are widely used as thermoset matrix materials for laminated composites, particularly in naval and automotive applications, due to their strength, chemical resistance, and ease of processing. However, their brittleness limits their use, especially in cold conditions. This study investigates the [...] Read more.
Vinyl ester resins are widely used as thermoset matrix materials for laminated composites, particularly in naval and automotive applications, due to their strength, chemical resistance, and ease of processing. However, their brittleness limits their use, especially in cold conditions. This study investigates the toughness of core–shell rubber (CSR)-modified resins in composites with natural fibers. This research compares the properties of the neat resin matrix and the CSR-modified matrix. After optimizing the resin curing process with catalysts, various treatments were tested to analyze their mechanical and thermal properties. Using the vacuum bagging process, flax and glass fibers were used as reinforcements to assess the effects of matrix modifications. Flax fibers were chosen for their sustainability as a potential alternative to glass fibers. Mechanical testing was performed, comparing the performance of flax-based composites to those with glass fibers. Water absorption tests on flax composites followed the ISO 62 standard. Additionally, interlaminar shear strength and SEM micrography studies were conducted to examine the morphology and fiber–matrix adhesion, linking the microscopic structure to mechanical properties. Results indicate that while glass-reinforced composites have superior properties, flax composites offer a sustainable alternative, making them a promising choice for future applications. Full article
Show Figures

Figure 1

15 pages, 5094 KiB
Article
Effect of Star-like Polymer on Mechanical Properties of Novel Basalt Fibre-Reinforced Composite with Bio-Based Matrix
by Rochele Pinto, Tatjana Glaskova-Kuzmina, Kristina Zukiene, Gediminas Monastyreckis, Marie Novakova, Vladimir Spacek, Andrejs Kovalovs, Andrey Aniskevich and Daiva Zeleniakiene
Polymers 2024, 16(20), 2909; https://doi.org/10.3390/polym16202909 - 16 Oct 2024
Cited by 1 | Viewed by 1735
Abstract
This study is aimed at developing a fibre-reinforced polymer composite with a high bio-based content and to investigate its mechanical properties. A novel basalt fibre-reinforced polymer (BFRP) composite with bio-based matrix modified with different contents of star-like n-butyl methacrylate (n-BMA) block [...] Read more.
This study is aimed at developing a fibre-reinforced polymer composite with a high bio-based content and to investigate its mechanical properties. A novel basalt fibre-reinforced polymer (BFRP) composite with bio-based matrix modified with different contents of star-like n-butyl methacrylate (n-BMA) block glycidyl methacrylate (GMA) copolymer has been developed. n-BMA blocks have flexible butyl units, while the epoxide group of GMA makes it miscible with the epoxy resin and is involved in the crosslinking network. The effect of the star-like polymer on the rheological behaviour of the epoxy was studied. The viscosity of the epoxy increased with increase in star-like polymer content. Tensile tests showed no noteworthy influence of star-like polymer on tensile properties. The addition of 0.5 wt.% star-like polymer increased the glass transition temperature by 8.2 °C. Mode-I interlaminar fracture toughness and low-velocity impact tests were performed on star-like polymer-modified BFRP laminates, where interfacial adhesion and impact energy capabilities were observed. Interlaminar fracture toughness improved by 45% and energy absorption capability increased threefold for BFRP laminates modified with 1 wt.% of star-like polymer when compared to unmodified BFRP laminates. This improvement could be attributed to the increase in ductility of the matrix on the addition of the star-like polymer, increasing resistance to impact and damage. Furthermore, scanning electron microscopy confirmed that with increase in star-like polymer content, the interfacial adhesion between the matrix and fibres improves. Full article
(This article belongs to the Special Issue Mechanical Properties of 3D Printed Polymer Composites)
Show Figures

Figure 1

17 pages, 9947 KiB
Article
Assessment of Fatigue Crack Growth Characteristics of Laminated Biaxial/Triaxial Hybrid Composite in Wind Turbine Blades
by Hak-Geun Kim and Ki-Weon Kang
Appl. Sci. 2024, 14(17), 7929; https://doi.org/10.3390/app14177929 - 5 Sep 2024
Cited by 1 | Viewed by 1507
Abstract
The composite blade is integral to megawatt-class wind turbines and frequently incurs interlaminar damages such as adhesive failures, cracks, and fractures, which may originate from manufacturing flaws or sustained external fatigue loads. Notably, adhesive joint failure in the spar–web and trailing edge (TE) [...] Read more.
The composite blade is integral to megawatt-class wind turbines and frequently incurs interlaminar damages such as adhesive failures, cracks, and fractures, which may originate from manufacturing flaws or sustained external fatigue loads. Notably, adhesive joint failure in the spar–web and trailing edge (TE) represents a predominant damage mode. This study systematically explores the failure mechanism in these regions, using mode I fracture toughness tests for an in-depth, quantitative analysis of the adhesive joint’s fatigue crack growth characteristics. Additionally, we conducted extensive material and technical evaluations on specimen units, aiming to validate the reliability of techniques employed for wind blade damage modeling. A damage model, inspired by the NREL 5 MW wind generator’s composite blade structure, meticulously considers the interactions between the TE and spar–web. Utilizing the virtual crack closure technique (VCCT), this model effectively simulates crack growth dynamics in wind blade adhesive joints, while the extended finite element method (XFEM) aids in analyzing crack propagation trajectories under repetitive fatigue loading. By applying this integrated methodology, we successfully determined the lifespan of the spar–web adhesive joint under constant load amplitudes, providing crucial insights into the resilience and longevity of critical wind turbine components. Full article
(This article belongs to the Section Materials Science and Engineering)
Show Figures

Figure 1

59 pages, 4658 KiB
Review
The Effect of Carbon Nanofibers on the Mechanical Performance of Epoxy-Based Composites: A Review
by Paulo Santos, Abílio P. Silva and Paulo N. B. Reis
Polymers 2024, 16(15), 2152; https://doi.org/10.3390/polym16152152 - 29 Jul 2024
Cited by 12 | Viewed by 3448
Abstract
This review is a fundamental tool for researchers and engineers involved in the design and optimization of fiber-reinforced composite materials. The aim is to provide a comprehensive analysis of the mechanical performance of composites with epoxy matrices reinforced with carbon nanofibers (CNFs). The [...] Read more.
This review is a fundamental tool for researchers and engineers involved in the design and optimization of fiber-reinforced composite materials. The aim is to provide a comprehensive analysis of the mechanical performance of composites with epoxy matrices reinforced with carbon nanofibers (CNFs). The review includes studies investigating the static mechanical response through three-point bending (3PB) tests, tensile tests, and viscoelastic behavior tests. In addition, the properties of the composites’ resistance to interlaminar shear strength (ILSS), mode I and mode II interlaminar fracture toughness (ILFT), and low-velocity impact (LVI) are analyzed. The incorporation of small amounts of CNFs, mostly between 0.25 and 1% by weight was shown to have a notable impact on the static and viscoelastic properties of the composites, leading to greater resistance to time-dependent deformation and better resistance to creep. ILSS and ILFT modes I and II of fiber-reinforced composites are critical parameters in assessing structural integrity through interfacial bonding and were positively affected by the introduction of CNFs. The response of composites to LVI demonstrates the potential of CNFs to increase impact strength by reducing the energy absorbed and the size of the damage introduced. Epoxy matrices reinforced with CNFs showed an average increase in stiffness of 15% and 20% for bending and tensile, respectively. The laminates, on the other hand, showed an increase in bending stiffness of 20% and 15% for tensile and modulus, respectively. In the case of ILSS and ILFT modes I and II, the addition of CNFs promoted average increases in the order of 50%, 100%, and 50%, respectively. Full article
(This article belongs to the Section Polymer Composites and Nanocomposites)
Show Figures

Graphical abstract

16 pages, 5495 KiB
Article
Design, Manufacturing, and Evaluation of Race and Automotive Prototypal Components Fabricated with Modified Carbon Fibres and Resin
by Dionisis Semitekolos, Andreia Araújo, Raquel M. Santos, Chiara Pernechele, Francesco Panozzo, Luca Vescovi and Costas Charitidis
Polymers 2024, 16(14), 2062; https://doi.org/10.3390/polym16142062 - 19 Jul 2024
Cited by 2 | Viewed by 1422
Abstract
This study explores the enhancement of Carbon Fibre Reinforced Polymers (CFRPs) for automotive applications through the integration of modified carbon fibres (CF) and epoxy matrices. The research emphasizes the use of block copolymers (BCPs) and electropolymerisation techniques to improve mechanical properties and interfacial [...] Read more.
This study explores the enhancement of Carbon Fibre Reinforced Polymers (CFRPs) for automotive applications through the integration of modified carbon fibres (CF) and epoxy matrices. The research emphasizes the use of block copolymers (BCPs) and electropolymerisation techniques to improve mechanical properties and interfacial adhesion. Incorporating 2.5 wt.% D51N BCPs in the epoxy matrix led to a 64% increase in tensile strength and a 51.4% improvement in interlaminar fracture toughness. The electropolymerisation of CFs further enhanced interlaminar shear strength by 23.2%, reflecting a substantial enhancement in fibre–matrix interaction. A novel out-of-autoclave manufacturing process for an energy absorber prototype was developed, achieving significant reductions in production time and cost while maintaining performance. Compression tests demonstrated that the modified materials attained an energy absorption rate of 93.3 J/mm, comparable to traditional materials. These results suggest that the advanced materials and manufacturing processes presented in this study are promising for the development of lightweight, high-strength automotive components, meeting rigorous performance and safety standards. This research highlights the potential of these innovations to contribute significantly to the advancement of materials used in the automotive industry. Full article
(This article belongs to the Section Polymer Composites and Nanocomposites)
Show Figures

Graphical abstract

13 pages, 3019 KiB
Article
Effect of Post-Cured through Thickness Reinforcement on Disbonding Behavior in Skin–Stringer Configuration
by Jimesh D. Bhagatji, Christopher Morris, Yogaraja Sridhar, Bodhisatwa Bhattacharjee, Krishnanand N. Kaipa and Oleksandr G. Kravchenko
Materials 2024, 17(14), 3389; https://doi.org/10.3390/ma17143389 - 9 Jul 2024
Cited by 3 | Viewed by 1257
Abstract
An experimental investigation of interlaminar toughness for post-cured through-thickness reinforcement (PTTR) skin–stringer sub-element is presented. The improvement in the crack resistance capability of skin–stringer samples was shown through experimental testing and finite element analysis (FEA) modeling. The performance of PTTR was evaluated on [...] Read more.
An experimental investigation of interlaminar toughness for post-cured through-thickness reinforcement (PTTR) skin–stringer sub-element is presented. The improvement in the crack resistance capability of skin–stringer samples was shown through experimental testing and finite element analysis (FEA) modeling. The performance of PTTR was evaluated on a pristine and initial-disbond of the skin–stringer specimen. A macro-scale pin–spring modeling approach was employed in FEA using a non-linear spring to capture the pin failure under the mixed-mode load. The experimental results showed a 15.5% and 20.9% increase in strength for the pristine-PTTR and initial-disbond PTTR specimens, respectively. The modeling approach accurately represents the overall structural response of PTTR laminate, including stiffness, adhesive strength, crack extension scenarios and progressive pin failure modes. This modeling approach can be beneficial for designing damage-tolerant structures by exploring various PTTR arrangements for achieving improved structural responses. Full article
Show Figures

Figure 1
