This study employs the effective heat capacity method within the COMSOL simulation framework to analyze the thermal performance of double-layer phase-change walls under typical summer climatic conditions in Zhengzhou, Henan Province. The model considers a wall structure with a total thickness of 100 mm and a height of 300 mm, where the exterior surface represents the outdoor environment, the interior surface represents the indoor environment, and the top and bottom boundaries are assumed to be adiabatic. A highly refined triangular mesh ensures numerical stability and solution accuracy. Special attention is given to the influence of Micro-PCM content on thermal storage characteristics. Simulation results demonstrate that increasing the Micro-PCM content substantially enhances the thermal regulation capacity of the double-layer phase-change walls. At a Micro-PCM volume fraction of 15%, the peak temperature of the double-layer phase-change wall is reduced by 4.33 °C compared to a conventional wall, while the attenuation factor increases to 16.88. Furthermore, the mean thermal delay extends to 440 min, the temperature amplitude decreases to 1.13 °C, and the peak instantaneous heat flux is reduced to 13.24 W/m². These findings highlight the significant latent heat storage capacity and superior thermal modulation performance of double-layer phase-change walls, offering a valuable technical reference for the design of energy-efficient building envelope systems. Full article

The external walls of a building represent the interface between the interior and exterior environments. Insulating external walls represents the most cost-effective means of ensuring indoor comfort. Despite the prevailing assumption that insulation will increase the cost of the building, this study has demonstrated that this is not the case. Notwithstanding the increase in investment costs, the application of insulation to the external walls has been demonstrated to result in a reduction in fuel consumption and operating costs. In accordance with TS 825, there are five distinct degree-day zones, with the requisite heat loads in these zones exhibiting variability. Accordingly, a cost-based methodology is required to ascertain the optimal insulation thicknesses for the various degree-day zones. In this study, the gains to be obtained in the case of using three different insulation materials for five different wall types to be used in the buildings to be built instead of the buildings destroyed in the earthquake in Turkey in 2023 were analyzed. Samples from three degree-day zones affected by earthquakes were assessed for insulation, wall structures, and fuel types. The study assesses optimum insulation thickness, investment cost, annual fuel savings, annual economic benefits, and investment payback period. Full article

Autoclaved aerated concrete (AAC) has gained widespread acceptance in construction as a lightweight solution for exterior and interior walls. However, traditional steel-reinforced autoclaved aerated concrete (SR-AAC) has limitations, including concerns over its ductility and difficulty in cutting during installation. The steel reinforcement also has high embodied carbon that does not align with the actions in the construction section to reach carbon neutrality shortly. This study investigated the material properties and mechanical performances of factory-produced fiber-reinforced autoclaved aerated concrete (FR-AAC) panels, aiming to examine their potential as an alternative solution. Full-scale FR-AAC panels with thicknesses of 100 mm, 150 mm, and 200 mm were manufactured and tested. Some panels were down-sampled to determine the dry density, water absorption, compressive strength, and flexural strength of the material, while the mechanical performances were evaluated through static and impact loading tests. The results showed that the average dry density and absorption of the FR-AAC material are 533 kg/m³ and 63%, respectively, with compressive strengths up to 3.79 MPa and flexural strengths reaching 0.97 MPa. All six panels tested under static uniformly distributed loading exceeded the self-weight limit by a factor of 1.5, satisfying standard requirements for load-bearing capacity. However, the brittle failure modes observed in some tests raise potential health and safety concerns. In contrast, the impact tests revealed that the panels have acceptable performances with the inclusion of fibers. Full article

During bridge deck construction, the deck finishing machine and the fresh concrete often produce large vertical loads and torsional moments acting on the bridge girder system. In some cases, these loads can cause excessive vertical deflection and transverse rotation in the bridge girders, leading to many maintenance and safety problems, such as changes in deck thickness and local and global instabilities during construction. To minimize the potential problems caused by deck construction, the AASHOTO LRFD Bridge Design Specification requires consideration of these torsional moments during the design procedure, and a detailed three-dimensional finite element analysis may be conducted. However, for bridge girders with open-section thin-walled sections, only the solid or shell element can be used to recognize the warping of the girder since the torsional warping effect is not included in the classical beam element. In this research, a warping degree of freedom was added to a beam element, and a three-dimensional beam element with seven degrees of freedom (7-DOF) at each node was derived as an alternative method for analyzing girder bridges during deck construction. A computer program based on the 7-DOF beam element was also developed in MATLAB. To assess the 7-DOF beam element, one bridge was selected to measure the transverse rotation, vertical deflection, and stress of the exterior girder and the first interior girder during deck construction. Also, three full-scale numerical models using solid elements, classical three-dimensional beam elements, and 7-DOF beam elements were created based on the geometries and loads of the experimental bridge. A comparative study was conducted by comparing the results from the numerical models and experimental monitoring data to evaluate the 7-DOF beam element. The results showed that the 7-DOF beam element had excellent behavior in analyzing the girder bridges under construction load, especially in the torsional analysis of bridge girders. Also, unlike the solid element model, which also provided reasonable results, the 7-DOF beam element model can compute the internal forces of the cross-sections along the bridge, which allows the 7-DOF beam element to be an alternative approach for design and research requiring less modeling effort and computational complexity. Full article

The present investigation carries out a thermal evaluation of two rooms located in the Royal Hospital of Granada (Rector’s Office). This is a heritage building where have been done studies that allow the as-sessment of possible improvements in future interventions that guarantee improvement in en-ergy and regulatory compliance are decisive. This article presents for the first time, through energy simulation, the behavior of two rooms in two temporal periods, thermally extreme (summer and winter) and with opposite orientations. This has allowed the potential benefits to be considered in real climate conditions. The results demonstrate and quantify that considering the location, orientation, arrangement of openings, and inclusion of transition zones between the exterior and the interior, an improvement in thermal comfort is obtained. The southwesterly orientation is favorable in the winter period and the northeasterly orientation in the summer period. It is also confirmed that the arrangement of thick masonry walls responds adequately in climates with high thermal amplitudes, favoring the mitigation of extreme conditions. It is concluded by stating that the orientation and the construction components are the main responsible factors for the thermal capacity in this type of building. In this context, the use of non-destructive study methods offers valuable scientific support through the results obtained. Full article

As the foundation for digitalization, building information modeling (BIM) technology has been widely used in the field of architecture, engineering, construction, and facility management (AEC/FM). Unmanned aerial vehicle (UAV) oblique photogrammetry and laser scanning have become increasingly popular data acquisition techniques for surveying buildings and providing original data for BIM modeling. However, the geometric and topological reconstruction of solid walls, which are among the most important architectural structures in BIM, is still a challenging undertaking. Due to noise and missing data in 3D point clouds, current research mostly focuses on segmenting wall planar surfaces from unstructured 3D point clouds and fitting the plane parameters without considering the thickness or 3D shape of the wall. Point clouds acquired only from the indoor space are insufficient for modeling exterior walls. It is also important to maintain the topological relationships between wall objects to meet the needs of complex BIM modeling. Therefore, in this study, a geometry and topology modeling method is proposed for solid walls in BIM based on photogrammetric meshes and laser point clouds. The method uses a kinetic space-partitioning algorithm to generate the building footprint and indoor floor plan. It classifies interior and exterior wall segments and infers parallel line segments to extract wall centerlines. The topological relationships are reconstructed and maintained to build wall objects with consistency. Experimental results on two datasets, including both photogrammetric meshes and indoor laser point clouds, exhibit more than 90% completeness and correctness, as well as centimeter-level accuracy of the wall surfaces. Full article

Rock art offers traces of our most remote past and was made with mineral and organic substances in shelters, walls, or the ceilings of caves. As it is notably fragile, it is fortunate that some instances remain intact—but a variety of natural and anthropogenic factors can lead to its disappearance. Therefore, as a valuable cultural heritage, rock art requires special conservation and protection measures. Geomatic remote-sensing technologies such as 3D terrestrial laser scanning (3DTLS), drone flight, and ground-penetrating radar (GPR) allow us to generate exhaustive documentation of caves and their environment in 2D, 2.5D, and 3D. However, only its combined use with 3D geographic information systems (GIS) lets us generate new cave maps with details such as overlying layer thickness, sinkholes, fractures, joints, and detachments that also more precisely reveal interior–exterior interconnections and gaseous exchange; i.e., the state of senescence of the karst that houses the cave. Information of this kind is of great value for the research, management, conservation, monitoring, and dissemination of cave art. Full article

The mechanical behavior of buried HDPE double-wall corrugated pipes is mainly affected by the material and the structure of the pipe wall. Here we studied a peculiar material that added fly ash (FA) in high density polyethylene (HDPE) to develop composites. We have conducted research on FA/HDPE composites with different mix proportions. When 5% compatibilizer was added to the 10% FA masterbatch/HDPE composite, the Young’s Modulus of FA/HDPE composite was higher. This paper mainly studies the mechanical behavior of the structure of pipe walls for materials with this proportion of the ingredients. The mechanical behavior of double-wall corrugated pipes with different ratios of interior and exterior wall thicknesses is studied by keeping the sum of the interior and exterior wall thicknesses unchanged. Pipes with six different ratios of interior and exterior wall thicknesses are simulated; the results show that the strain of crest and liner gradually decreased and the valley strain gradually increased with the increase of the exterior wall thickness. By comparing inner and outer wall thickness ratios from 0.67 to 2.33, it is found that the structural performance and economic advantage for the double-wall corrugated pipes is best when the thickness ratio of the interior wall and the exterior wall is controlled to be from 1.3 to 1.8. This paper expounds the deformation mechanism of double-wall corrugated pipes from the perspective of mechanical behavior and structural characteristics, and provides a reference for material selection and structural design of double-wall corrugated pipes. Full article

A prediction model based on artificial neural networks is adapted to forecast the acoustic performance of airborne sound insulation of various lightweight wooden façade walls. A total of 100 insulation curves were used to develop the prediction model. The data are laboratory measurements of façade walls in one-third-octave bands (50 Hz–5 kHz). For each façade wall, geometric and physical information (material type, dimensions, thicknesses, densities, and more) are used as input parameters. The model shows a satisfactory predictive capability for airborne sound reduction. A higher accuracy is obtained at middle frequencies (250 Hz–1 kHz), while lower and higher frequency ranges often show higher deviations. The weighted airborne sound reduction index ($R_w$) of façades can be estimated with a maximum difference of 3 dB. Sometimes, the model shows high variations within fundamental and critical frequencies that influence the predictive precision. A sensitivity analysis is implemented to investigate the significance of parameters in insulation estimations. The material density (i.e., cross-laminated timber panel, gypsum board), thickness of the insulation materials, thickness and spacing between interior studs and the total density of façades are factors of significant weight on predictions. The results also emphasize the importance of façade thickness and the total density of the clustered exterior layers. Full article

Rammed earth (RE) is a low-tech recyclable building material with good heat storage and moisture absorption performance that can better maintain the stability of the indoor thermal environment and improve indoor comfort. With innovations in and the development of new technology, the field of rammed earth construction technology is gradually expanding. However, deficiencies in the thermal insulation of traditional rammed earth structures make it impossible for them to meet China’s building energy codes in cold regions. This study constructs a comprehensive evaluation index of the thermal performance of rammed earth walls that is based on the heat transfer mechanism, optimizing the thickness of the boundary conditions of the building interior’s design temperature, as well as the energy demand and economic efficiency. This research also offers a new design for the thermal insulation of rammed earth construction by combining the building energy savings design code with WUFI Pro software. This study demonstrates that the optimum thickness of rammed earth construction in Beijing is about 360 mm, the thickness of extruded polystyrene board (XPS) is 50 mm (for public buildings) and 70 mm (for residential buildings), and the structural form of external insulation offers the highest performance benefit. In addition, this work also evaluates the risk of condensation inside composite rammed earth construction, finding that there is a risk of condensation on the exterior side of the wall and at the interface between the insulation panels and rammed earth wall, thus requiring an additional moisture-proof layer. In this study, thermal mass and insulation are fully considered and a design strategy for rammed earth construction given quantitatively, providing a theoretical basis for the application of rammed earth materials in cold regions. Full article

Due to global concerns about energy issues, global warming, and urban quality, vertical greening systems (VGS) are receiving more attention in construction and design research. Therefore, VGS has become part of building envelope design as a passive technique for saving energy in building sectors. The current study aimed to investigate shading and energy performances of VGS in buildings in hot climate regions and to optimize VGS design as a building design element. The study was conducted through simulation and field experiments in a student housing building at a university campus (Irbid, Jordan). Field measurements were taken to assess the thermal effect of the green wall and daylight performance as well as the efficiency of the typical green wall design configuration. Furthermore, a methodology for accurately representing green walls was established and used. Both simulation and experimentation demonstrated that the thickness of the air cavity and the percentage of foliage coverage can have a substantial impact on the performance of the green wall system. Results showed that green wall systems are effective natural sunscreens and shading systems. A green wall helped to reduce the exterior wall surface temperatures by a range of 6 to 11 °C compared to the base case of the wall without a VGS on different days. In addition, it decreased the interior surface temperature of the investigated southern façade by an average of 5 °C compared to the base case. Green wall design configurations for hot climate regions, such as Jordan, will help designers to use the VGS as a design element. Our findings indicate that GW could help to improve the thermal and daylight environment and thus the results could be taken as indicative for GW wall design in other areas or buildings. Full article

Sensitivity analysis is crucial in building energy assessments. It is used to determine the major variables influencing building thermal performance, using both observational research and energy simulation models. This study investigates the most influential envelope design parameters on the thermal performance of a typical residential building in Budapest, Hungary. Sensitivity analysis is used in conjunction with the IDA-Indoor and Climate Energy (IDA-ICE 4.8) simulation tool to assess the effects of 33 envelope design parameters for energy consumption and carbon dioxide concentrations. The input parameters include thickness, materials, density, specific heat and thermal conductivity of the basement, exterior floor, interior floor, exterior wall, interior wall, roof, ground slab, glazing type, and infiltration rate. The results show that exterior floor materials have the biggest impact on annual delivered energy for heating and cooling, whereas the density of all structural elements and thickness of the basement, exterior floors, interior floors, and walls have minimal effects on energy consumption. It is also shown that the impact of all investigated parameters is not sensitive to the carbon dioxide concentration in the building. The authors consider that the findings of the paper assist designers to assess the performance of existing buildings and more efficiently generating alternative solutions in the energetic retrofitting of existing and energy design of new residential buildings. Full article

The Wood Innovation Research Lab was designed as a low energy-use building to facilitate the construction and testing of engineered wood products by the faculty and staff of the Master of Engineering in Integrated Wood Design Program at the University of Northern British Columbia in Prince George, BC, Canada. Constructed using a 533 mm thick-wall and 659 mm flat roof assembly, it received certification as Canada’s first industrial facility built to the International Passive House standard. Temperature and humidity sensors were installed in the north and south exterior wall assemblies to measure long-term hygrothermal performance. Data collected between 2018–2020 shows no record of long-term moisture accumulation within the exterior assemblies. Data collected during this time period was used to validate hygrothermal performance models for the building created using the WUFI^® Plus software. Long-term performance models created using future climate data for five cities across Canada under two global warming scenarios shows favorable results, with an increase in average annual temperatures resulting in lower average relative humidity values at the interior face of the exterior sheathing board in the exterior wall assemblies. Full article

In times of unprecedented climate change and energy scarcity, the design and delivery of energy-efficient and sustainable buildings are of utmost importance. This study aimed to design a hotel building for hot and dry climate conditions and perform its energy performance analysis using energy simulation tools. The model of the hotel building was constructed by a graphical tool OpenStudio and EnergyPlus following the ASHRAE Standard 90.1. To reduce the energy demand of the hotel, parametric analysis was conducted and building envelope parameters such as the thickness of insulation layer in the exterior wall and the roof, thermal conductivity of insulation layer, rate of infiltration, U-factor of windows, and thermal resistance of air gap in the interior walls (R-value), window-to-wall ratio, and orientation of the building were tested and the impact on the energy use of the building was analyzed. It was found that most of the design assumptions based on the ASHRAE standard were already optimal for the considered locality, however, were still optimized further to reach the highest efficiency level. Apart from this, three sustainable technologies—thermochromic windows, phase change materials, and solar panels—were incorporated into the building and their energy consumption reduction potential was estimated by energy simulations. Cumulatively, these sustainable technologies were able to reduce the total energy use from 2417 GJ to 1593 GJ (i.e., by 824 GJ or 34%). Calculation of payback period and return on investments showed that thermochromic windows and solar panels have relatively short payback periods and high return on investments, whereas PCM was found to be economically nonviable. The findings of this study are deemed to be useful for designing a sustainable and energy-efficient hotel building in a sub-tropical climate. However, the overall design and energy performance analysis algorithm could be used for various buildings with varying climate conditions. Full article

The building sector is the largest consumer of energy, but there are still major scientific challenges in this field. The façade, being the interface between the exterior and interior space, plays a key role in the energy efficiency of a building. In this context, this paper focuses on a ventilated bioclimatic wall for nearly zero-energy buildings (NZEB). The aim of this study is to investigate an experimental setup based on a hot box for the characterization of the thermal performances of the ventilated wall. A specific ventilated prototype and an original thermal metrology are developed. This paper presents the ventilated prototype, the experimental setup, and the experimental results on the thermal performances of the ventilated wall. The influence of the air space thickness and the air flow rate on the thermal performances of the ventilated wall is studied. Full article
