This study investigates the performance of lattice-structured heat sinks based on BCCz unit cells in comparison to conventional straight-fin and pin-fin designs. Various lattice configurations were explored. Numerical simulations and experimental evaluations were carried out to analyze thermal resistance, pressure drop, and temperature distribution under different operating conditions. Among the designs, the BCCz configuration with a circular cross-section was identified as the most promising candidate for integration into the final heat sink demonstrator, offering reliable and consistent performance. A prototype using the BCCz lattice structure was additively manufactured, alongside a conventional design for comparison. The results highlight the superior heat dissipation capabilities of lattice structures, achieving up to a 100% improvement in thermal performance at high flow rates and up to 300% at low flow rates compared to a conventional straight-fin heat sink. However, the pressure drop generated by the lattice structures remains a challenge that must be addressed. This work underscores the potential of optimized lattice-based heat exchangers to meet the severe thermal management requirements of railway power electronics. Full article

Masked cold spray additive manufacturing (CSAM) is investigated for fabricating nickel-based electrodes with pyramidal pin-fins that enlarge the active area for the hydrogen-evolution reaction (HER). To bypass the high cost of purely CFD-driven optimization, we construct a two-stage machine learning (ML) framework trained on 48 high-fidelity CFD simulations. Stage 1 applies sampling and a K-nearest-neighbor kernel-density-estimation algorithm that predicts the spatial distribution of impacting particles and re-allocates weights in regions of under-estimation. Stage 2 combines sampling, interpolation and symbolic regression to extract key features, then uses a weighted random forest model to forecast particle velocity and temperature upon impact. The ML predictions closely match CFD outputs while reducing computation time by orders of magnitude, demonstrating that ML-CFD integration can accelerate CSAM process design. Although developed for a masked setup, the framework generalizes readily to unmasked cold spray configurations. Full article

This numerical study presents six three-dimensional (3D) cathode flow field designs for a passive air-cooled polymer electrolyte membrane (PEM) fuel cell to enhance heat removal and H₂O retention. The data collected are evaluated in terms of water content, average temperature, and current flux density. The proposed cathode flow field designs are a straight baseline channel (Design 1), converging channel (Design 2), diverging channel (Design 3), straight channel with cylindrical pin fins (Design 4), trapezium cross-section channel (Design 5), and semi-circle cross-section channel (Design 6). The lowest cell temperature value of 56.67 °C was obtained for Design 2, while a noticeable water retention improvement of 6.5% was achieved in a semi-circle cathode flow field (Design 5) compared to the baseline channel. However, the current flux density shows a reduction of 0.1% to 1.2%. Nevertheless, those values are relatively small compared to the improvement in the durability of the fuel cell due to heat reduction. Although the modifications to the cathode flow field resulted in only minor improvements, ongoing advancements in fuel cell technology have the potential to make our energy landscape more sustainable. These advancements can help reduce emissions, increase efficiency, integrate renewable energy sources, enhance energy security, and support the transition to a hydrogen-based economy. Full article

Using the SST k-ω turbulence model, a comprehensive numerical investigation was conducted to analyze the flow and heat transfer characteristics of steam within an isosceles trapezoidal cooling channel with pin-fin arrays modeled from the trailing edge of a F-class gas turbine high-temperature blade. The influence laws of various parameters, including the Reynolds number (Re, from 10,000 to 50,000), dimensionless pin-fin diameter (d/H, from 0.4 to 0.8), and dimensionless pin-fin spacing (S/H, from 1.6 to 2.4), on the flow and heat transfer performance of the isosceles trapezoidal cooling channel with pin-fin arrays were examined. Sensitivity analysis was employed to determine the relative significance of these influence parameters on the cooling performance of the isosceles trapezoidal channel with pin-fin arrays. Finally, the corresponding heat transfer and friction correlations within the investigated parameter range were developed. The research findings reveal that under different Reynolds numbers, as the dimensionless pin-fin diameter increases from 0.4 to 0.8, the friction factor within the isosceles trapezoidal cooling channel with pin-fin arrays increases by a factor of 3.25 to 3.41, while the overall average Nusselt number improves by 31.05% to 37.41%. Conversely, when the dimensionless pin-fin spacing increases from 1.6 to 2.4, the friction factor within the isosceles trapezoidal cooling channel with pin-fin arrays decreases by 67.38% to 69.18%, accompanied by a reduction in the overall average Nusselt number by 24.95% to 31.14%. When both the flow performance and heat transfer performance are taken into account, the importance of the influence parameters ranks as follows: Reynolds number, pin-fin diameter, and pin-fin spacing. It also suggests that smaller pin-fin diameters and larger pin-fin spacing should be selected in the design stage based on the variation laws of integrated thermal-hydraulic performance. The results may provide valuable references and insights for the design of steam cooling structures within high-temperature turbine blade trailing edge channels in advanced gas turbines. Full article

Equipment integrity is an essential aspect of process engineering. Design guidelines facilitate the design and production of safe-to-operate and economic devices. Thin-walled, slit-shaped modules form a subgroup of process engineering devices made via additive manufacturing (AM). Being subject to internal pressure, they have lacked design guidelines until now. We derived a user-centered calculation model for such modules with regular internal structures. It was validated with Finite Element Analysis (FEA) and practical pressure tests for which the modules were manufactured additively. The performance of the calculation could be confirmed, and a design graph was derived. Slit-shaped modules with appropriate internal structures can withstand high pressure at a minimum wall thickness, and they are efficiently fabricated. These structures, being pins, fins, lattice, or heat transfer enhancing fluid-guiding elements (FGEs), occupied approximately 10% of the modules’ internal volume. Full article

For the multi-objective design of heat sinks, several evolutionary algorithms usually require many iterations to converge, which is computationally expensive. Variable-fidelity multi-objective (VFO) methods were suggested to improve the efficiency of evolutionary algorithms. However, multi-objective problems are seldom optimized using VFO. Therefore, a variable-fidelity evolutionary method (VFMEM) was suggested. Similar to other variable-fidelity algorithms, VFMEM solves a high-fidelity model using a low-fidelity model. Compared with other algorithms, the distinctive characteristic of VFMEM is its application in multi-objective optimization. First, the suggested method uses a low-fidelity model to locate the region where the global optimal solution might be found. Sequentially, both high- and low-fidelity models can be integrated to find the real global optimal solution. Circulation distance elimination (CDE) was suggested to uniformly obtain the PF. To evaluate the feasibility of VFMEM, two classical benchmark functions were tested. Compared with the widely used multi-objective particle swarm optimization (MOPSO), the efficiency of VFMEM was significantly improved and the Pareto frontier (PFs) could also be obtained. To evaluate the algorithm’s feasibility, a polygonal pin fin heat sink (PFHS) design was carried out using VFMEM. Compared with the initial design, the results showed that the mass, base temperature, and temperature difference of the designed optimum heat sink were decreased 5.5%, 18.5%, and 62.0%, respectively. More importantly, if the design was completed directly by MOPSO, the computational cost of the entire optimization procedure would be significantly increased. Full article

Aeroengines and heavy-duty gas turbines are the core power equipment in the field of national defense and energy. Their research and development (R&D) level and manufacturing level represent the status of a country’s heavy industry in the world. The common cooling technologies of turbine blades including impingement cooling, film cooling, effusion cooling, layer cooling, pin fin cooling, and rough ribs were introduced in this paper. With the continuous improvement of the efficiency and performance of aeroengines and gas turbines, the turbine inlet temperature increases gradually every year; turbine blades will be exposed to higher gas temperatures in the future as gas temperatures break 2000 K. In order to ensure the safe operation of turbine blades under severe super-high temperature working conditions, cooling technology must be developed emphatically. This paper first reviews the research status of turbine blade cooling technology and points out future research focuses. The development trends of next-generation turbine blade cooling technology for above 2000 K temperature are summarized from several aspects: the innovative excavation of high-efficiency composite cooling configuration, multi-objective cooperative cooling structure and optimization design based on 3D printing, composite cooling structure design and optimization based on an artificial intelligence algorithm, tapping the cooling potential of new cooling media and heat pipes, integrated thermal protection with new thermal insulators, and the application of low-resistance and high-efficiency surface dimple cooling. The summary of this paper can provide a reference for the researchers of turbine blade cooling technology. Full article

Condensers are an integral part of air conditioning systems. The thermal efficiency of condensers solely depends on the rate of heat transfer from the cooling medium. Fin tubes are extensively used for heat transfer applications due to their enhanced heat transfer capabilities. Fins provide appreciable drainage because surface tension produces pressure gradients. Much research, contributed by several scientists, has focused on adjusting parameters, such as fin design, flow rates and retention angles. In this study, a setup with an observing hole was used to inspect the influence on retention angle of adjusting the flow rates of the fluid. The increase in retention angle was examined using several velocities and concentration mixtures. Pin-fin tubes were used to obtain coherent results using a photographic method. The experimental setup was designed to monitor the movement of fluid through the apparatus. The velocity was varied using dampers and visibility was enhanced using dyes. Photographs were taken at 20 m/s velocities after every 20 s. and 0.1% concentration and the flooding point observed. The experimental results were verified by standard observation which showed little variation at lower velocity. For water/water-propanol mixtures, a vapor velocity of 12 m/s and concentration ratio of 0.04% was the optimal combination to achieve useful improvement in retention angle. With increase of propanol from 0% to 0.04%, the increase in retention angle was greater compared to 0.04% to 0.1%. For velocities ranging from 0 to 12 m/s, the increase in retention angle was significant. A sharp change was observed for concentration ratios ranging from 0.01% to 0.05% compared to 0.05% to 0.1%. Full article

The annual waste heat available from industry in the European Union is more than 2700 PJ. Consequently, the utilization of the unexploited thermal energy will decisively contribute to a reduced overall power consumption and lower greenhouse gas emissions. In the present investigation, a cycle layout, based on supercritical carbon dioxide (sCO₂), was applied for a certain waste heat source, a gas compressor station. The boundary conditions determined by the cycle were used by the numerical code ANSYS CFX to design a pre-cooler. Subsequently, this printed circuit heat exchanger was examined for sCO₂ mass fluxes between 100 kg/m²s and 900 kg/m²s. The heat transfer and pressure drop increase as the flow channel diameter is reduced. As the pressure drop of the coolant channel is more sensitive to the diameter, a larger coolant channel diameter is selected to maintain a reasonably low pressure drop. The optimum pre-cooler design consists of a 0.5 mm and 0.8 mm channel diameter for the sCO₂ and coolant channel. Based on these results, internal fins were applied and optimized, to improve the heat transfer performance. An internal fin height of 4 mm was found to achieve the optimum thermal-flow performance for the pre-cooler. Full article
