The ability to perform instantaneous frequency measurement (IFM) of unknown microwave signals holds significant importance across various application domains. This paper presents a power-independent microwave photonic IFM system. The proposed system implements frequency measurement through the construction of an amplitude comparison function (ACF) curve, achieved by introducing a frequency-dependent time delay via an optical tunable delay line (OTDL) for the signal under test (SUT). System simulation demonstrates the measurement capability across a wide bandwidth of 0.1–40 GHz with high precision, exhibiting frequency errors ranging from −0.03 to 0.04 GHz. The scheme also maintains consistent performance under varying input power levels. Key implementation aspects, including single-sideband modulation selection and system extension methods, are analyzed in detail to optimize measurement accuracy. Notably, the proposed architecture features a simple and compact design with excellent integration potential. These characteristics, combined with its wide operational bandwidth and high measurement precision, make this approach particularly suitable for demanding applications in electronic reconnaissance and communication. Full article

Measuring pH is a critical parameter in environmental monitoring, biomedical diagnostics, food safety, and industrial processes. Optical fiber sensors have proven highly effective for pH detection due to their exceptional sensitivity, rapid response, and resistance to electromagnetic interference, making them well suited for real-time monitoring. This review offers a comprehensive analysis of recent advances in optical fiber-based pH sensors, covering key techniques such as fluorescence-based, absorbance-based, evanescent wave, and interferometric methods. Innovations in Fiber Bragg Grating and Surface Plasmon Resonance technologies are also examined. The discussion extends to the impact of pH-sensitive coatings—ranging from nanomaterials and polymeric films to graphene-based compounds—on enhancing sensor performance. Recent advancements have also enabled automation in data analysis and improvements in remote sensing capabilities. The review further compares the economic viability of optical fiber sensors with traditional electrochemical methods, while acknowledging persistent issues such as temperature cross-sensitivity, long-term stability, and fabrication costs. Overall, recent developments have broadened the functionality and application scope of these sensors by improving efficiency, accuracy, and scalability. Future research directions are outlined, including advanced optical interrogation techniques, such as Addressed Fiber Bragg Structures (AFBSs), microwave photonic integration, and optimized material selection. These approaches aim to enhance performance, reduce costs, and enable the broader adoption of optical fiber pH sensors. Full article

Terahertz spectroscopy (0.1~10 THz), as a new type of non-destructive testing method with both microwave and infrared characteristics, has shown remarkable potential in the field of food quality testing in recent years. Its unique penetration, high sensitivity, and low photon energy characteristics, combined with chemometrics and machine learning methods, provide an efficient solution for the qualitative and quantitative analysis of complex food ingredients. In this paper, we systematically review the principles of terahertz spectroscopy and its key applications in food testing, focusing on its research progress in pesticide residues, additives, biotoxins, and mold, adulteration identification, variety identification, and nutrient content detection. By integrating spectral data preprocessing, reconstruction algorithms, and machine learning model optimization strategies, this paper further analyzes the advantages and challenges of this technology in enhancing detection accuracy and efficiency. In addition, combined with the urgent demand for fast and nondestructive technology in the field of food detection, the future development direction of the deep integration of terahertz spectroscopy technology and artificial intelligence is envisioned, with a view to providing theoretical support and technical reference for food safety assurance and nutritional health research. Full article

Silicon-based optical waveguides exhibit high Brillouin gain, enabling the realization of Brillouin lasers directly on silicon substrates. These lasers hold significant promise for applications such as tunable-frequency laser emission, ultrafast pulse generation via mode-locking techniques, and other advanced photonic functionalities. However, a key challenge in silicon-based Brillouin lasers is the requirement for long waveguide lengths to achieve sufficient optical feedback and reach the lasing threshold. This study proposes a novel floating waveguide architecture designed to significantly enhance the Brillouin gain in silicon-based systems. Furthermore, we introduce a breakthrough method for achieving wide-range phonon frequency tunability, enabling precise control over stimulated Brillouin scattering (SBS) dynamics. By strategically engineering the waveguide geometry (shape and dimensions), we demonstrate a tunable SBS phonon laser, offering a versatile platform for on-chip applications. Additionally, the proposed waveguide system features adjustable operating frequencies, unlocking new opportunities for compact Brillouin devices and integrated microwave photonic signal sources. Full article

Modern radar systems frequently encounter constraints on bandwidth, transmission speed, and resolution, particularly within complex electromagnetic settings. Microwave photonics (MWP) provides solutions through the integration of photonic elements to improve radar’s functionalities. This review paper examines the question of how to improve radar performance by using MWP-based radar components for signal transmission, local oscillator signal generation, radar waveforming, optical beamforming networks, mixing, filtering, co-site interference suppression, real-time Fourier transformation, and analog-to-digital conversion. MWP radar systems achieve wider bandwidths, greater resistance to electromagnetic interference, and reduced phase noise, size, weight, and power consumption. Consequently, the integration of MWP into radar systems has the potential to increase the accuracy of these systems. Full article

Micro-racetrack resonators have become one of the key components for realizing signal processing, generation, and integration in microwave photonics, owing to their high Q factor, compact footprint, and tunability. However, most of the reported micro-racetrack resonators are confined to the single-mode regime. In this paper, we designed an ultra-compact multimode micro-racetrack resonator (MMRR) based on shape-optimized multimode waveguide bends (MWBs). Cubic spline curves were used to represent the MWB boundary and adjoint methods were utilized for inverse optimization, achieving an effective radius of 8 μm. Asymmetric directional couplers (ADCs) were designed to independently couple three modes into a multimode micro-racetrack, according to phase-matching conditions and transmission analysis. The MMRR was successfully fabricated on a commercial platform using a 193 nm dry lithography process. The device exhibited high loaded Q factors of 2.3 × 10⁵, 4.1 × 10⁴, and 2.9 × 10⁴, and large free spectral ranges (FSRs) of 5.4, 4.7, and 4.2 nm for ${\mathrm{TE}}_0$, ${\mathrm{TE}}_1$, and ${\mathrm{TE}}_2$ modes, with about a 19 × 55 μm² footprint. Full article

This letter presents a scheme for obtaining a microwave photonic frequency multiplier with low phase noise, in which an optoelectronic oscillator (OEO) is integrated with a directly modulated laser (DML)-based injection-locking technique. The system achieves frequency multiplication factors of 10 and 20, producing 10.01009 and 19.99095 GHz microwave signals with high side-mode suppression ratios of 62.0 and 50.2 dB. The measured single-sideband phase noise values are −121.87 and −111.95 dBc/Hz@10 kHz, which are 34.9 and 31.0 dB lower than those of traditional electronic frequency multiplication methods for 1 GHz signals. By utilizing the nonlinear characteristics of the DML, combined with injection locking and the OEO system, this cost-effective scheme reduces the system complexity while enhancing the stability and phase noise performance, offering a highly efficient solution for microwave frequency multiplication. Full article

In this study, we designed and experimentally demonstrated a compact polarization-insensitive 2 × 2 3 dB quasi-adiabatic coupler based on B-spline curves and shape optimization. By using the supermode to enable the segmented shape optimization of the coupler, we significantly reduced the computational cost of the optimization process. The numerical simulation results exhibited a power imbalance below ±0.46 dB and an insert loss (IL) of less than 0.09 dB over a broad bandwidth of 140 nm, ranging from 1490 nm to 1630 nm for both the TE and TM polarizations, with a compact coupling length of 12 µm. The experimental results showed a power splitting ratio within 3 ± 0.46 dB over the range of 1525 nm–1600 nm for the TM mode and 1576 nm–1610 nm for the TE mode. This broadband and low-loss 3 dB coupler is suitable for microwave photonic (MPW) applications, enabling efficient polarization-independent signal processing in integrated photonic systems. Full article

Optoelectronic oscillators (OEOs) have emerged as indispensable tools for generating low-phase-noise microwave and millimeter-wave signals, which are critical for a variety of high-performance applications. These include radar systems, satellite links, electronic warfare, and advanced instrumentation. The ability of OEOs to produce signals with exceptionally low phase noise makes them ideal for scenarios demanding high signal purity and stability. In radar systems, low-phase-noise signals enhance target detection accuracy and resolution, while, in communication networks, such signals enable higher data throughput and improved signal integrity over extended distances. Furthermore, OEOs play a pivotal role in precision instrumentation, where even minor noise can compromise the performance of sensitive equipment. This review examines the progress in OEO technology, transitioning from classical designs relying on long optical fiber delay lines to modern integrated systems that leverage photonic integration for compact, efficient, and tunable solutions. Key advancements, including classical setups, hybrid designs, and integrated configurations, are discussed, with a focus on their performance improvements in phase noise, side-mode suppression ratio (SMSR), and frequency tunability. A 20-GHz oscillation with an SMSR as high as 70 dB has been achieved using a classical dual-loop configuration. A 9.867-GHz frequency with a phase noise of −142.5 dBc/Hz @ 10 kHz offset has also been generated in a parity–time-symmetric OEO. Additionally, integrated OEOs based on silicon photonic microring resonators have achieved an ultra-wideband tunable frequency from 3 GHz to 42.5 GHz, with phase noise as low as −93 dBc/Hz at a 10 kHz offset. The challenges in achieving fully integrated OEOs, particularly concerning the stability and phase noise at higher frequencies, are also explored. This paper provides a comprehensive overview of the state of the art in OEO technology, highlighting future directions and potential applications. Full article

The ability to freely manipulate the wavefronts of surface plasmon polaritons (SPPs) or surface waves (SWs), particularly with multifunctional integration, is of great importance in near-field photonics. However, conventional SPP control devices typically suffer from low efficiency and single-function limitations. Although recent works have proposed metasurfaces that achieve bifunctional SPP manipulation, their implementation relies on the excitations of circularly polarized (CP) light with different helicities. Here, we propose a generic approach to designing bifunctional SPP meta-devices under single-helicity circularly polarized incidence. Constructed using carefully selected and arranged meta-atoms that possess both structural resonance and a geometric phase, this kind of meta-device can exhibit two distinct SPP manipulation functionalities in both co- and cross-polarized output channels under one CP incidence. As proof of this concept, we designed a bifunctional meta-device in the microwave regime and numerically demonstrated that it can convert a normally incident left circularly polarized (LCP) beam into SWs, exhibiting both a focused wavefront in the co-polarized output channel and a deflected wavefront in the cross-polarized output channel. Our findings substantially enrich the capabilities of metasurfaces to manipulate near-field electromagnetic waves, which can find many applications in practice. Full article

With the ever-growing demand for high-speed optical communications, microwave photonics, and quantum key distribution systems, compact electro-optic (EO) modulators with high extinction ratios, large bandwidth, and high tuning efficiency are urgently pursued. However, most integrated lithium–niobate (LN) modulators cannot achieve these high performances simultaneously. In this paper, we propose an improved theoretical model of a chip-scale electro-optic (EO) microring modulator (EO-MRM) based on X-cut lithium–niobate-on-insulator (LNOI) with a hybrid architecture consisting of a 180-degree Euler bend in the coupling region, double-layer metal electrode structure, and ground–signal–signal–ground (G-S-S-G) electrode configuration, which can realize highly comprehensive performance and a compact footprint. After parameter optimization, the designed EO-MRM exhibited an extinction ratio of 38 dB. Compared to the structure without Euler bends, the increase was 35 dB. It also had a modulation bandwidth of 29 GHz and a tunability of 8.24 pm/V when the straight waveguide length was 100 μm. At the same time, the proposed device footprint was 1.92 × 10⁴ μm². The proposed MRM model provides an efficient solution to high-speed optical communication systems and microwave photonics, which is helpful for the fabrication of high-performance and multifunctional photonic integrated devices. Full article

This paper presents an integrated tunable hybrid multi-laser module designed to simultaneously generate multiple radiofrequency (RF) local oscillator (LO) signals through optical heterodyning. The device consists of five hybrid InP/Si₃N₄ integrated lasers, each incorporating an intracavity wavelength-selective optical filter formed by two micro-ring resonators. Through beating the wavelengths generated from three of these lasers, we demonstrate the simultaneous generation of two LO signals within bands crucial for satellite communications (SatCom): one in the Ka-band and the other in the V-band. The device provides an extensive wavelength tuning range across the entire C-band and exhibits exceptionally narrow optical linewidths, below 40 kHz in free-running mode. This results in ultra-wideband tunable RF signals with narrow electrical linewidths below 100 kHz. The system is compact and highly scalable, with the potential to generate up to 10 simultaneous LO signals, being a promising solution for advanced RF signal generation in high throughput satellite payloads. Full article

Developing switchable and multifunctional metasurfaces is essential for high-integration photonics. However, most previous studies encountered challenges such as limited degrees of freedom, simple tuning of predefined functionality, and complicated control systems. Here, we develop a general strategy to construct switchable and multifunctional metasurfaces. Two spin-modulated wave-controls are enabled by the proposed high-efficiency metasurface, which is designed using both resonant and geometric phases. Furthermore, the switchable wavefront tailoring can also be achieved by flexibly altering the lattice constant and reforming the phase retardation of the metasurfaces based on the “rotating square” (RS) kirigami technique. As a proof of concept, a kirigami metasurface is designed that successfully demonstrates dynamic controls of three-channel beam steering. In addition, another kirigami metasurface is built for realizing tri-channel complex wavefront engineering, including straight beam focusing, tilted beam focusing, and anomalous reflection. By altering the polarization of input waves as well as transformation states, the functionality of the metadevice can be switched flexibly among three different channels. Microwave experiments show good agreement with full-wave simulations, clearly demonstrating the performance of the metadevices. This strategy exhibits advantages such as flexible control, low cost, and multiple and switchable functionalities, providing a new pathway for achieving switchable wavefront engineering. Full article

Radio photonic technologies have emerged as a promising solution for addressing microwave frequency synthesis challenges in current and future communication and sensing systems. One particularly effective approach is the optoelectronic oscillator (OEO), a simple and cost-effective electro-optical system. The OEO can generate microwave signals with low phase noise and high oscillation frequencies, often outperforming traditional electrical methods. However, a notable disadvantage of the OEO compared to conventional signal generation methods is its significant frequency tuning step. This paper presents a novel approach for continuously controlling the output frequency of an optoelectronic oscillator (OEO) based on integrated photonics. This is achieved by tuning an integrated optical delay line within a feedback loop. The analytical model developed in this study calculates the OEO’s output frequency while accounting for nonlinear errors, enabling the consideration of various control schemes. Specifically, this study examines delay lines based on the Mach–Zehnder interferometer and microring resonators, which can be controlled by either the thermo-optic or electro-optic effect. To evaluate the model, we conducted numerical simulations using Ansys Lumerical software. The OEO that utilized an MRR-based electro-optical delay line demonstrated a tuning sensitivity of 174.5 MHz/V. The calculated frequency tuning sensitivity was as low as 6.98 kHz when utilizing the precision digital-to-analog converter with a minimum output voltage step of 40 μV. The proposed approach to controlling the frequency of the OEO can be implemented using discrete optical components; however, this approach restricts the minimum frequency tuning sensitivity. It provides an additional degree of freedom for frequency tuning within the OEO’s operating range, which is ultimately limited by the amplitude-frequency characteristic of the notch filter. Thus, the proposed approach opens up new opportunities for increasing the accuracy and flexibility in generating microwave signals, which can be significant for various communications and radio engineering applications. Full article

Microwave photonics (MWP) applications often require a high optical input power (>100 mW) to achieve an optimal signal-to-noise ratio (SNR). However, conventional silicon spot-size converters (SSCs) are susceptible to high optical power due to the two-photon absorption (TPA) effect. To overcome this, we introduce a silicon nitride (SiN) SSC fabricated on a silicon-on-insulator (SOI) substrate. When coupled to a tapered fiber with a 4.5 μm mode field diameter (MFD), the device exhibits low coupling losses of <0.9 dB for TE modes and <1.4 dB for TM modes at relatively low optical input power. Even at a 1W input power, the additional loss is minimal, at approximately 0.1 dB. The versatility of the SSC is further demonstrated by its ability to efficiently couple to fibers with MFDs of 2.5 μm and 6.5 μm, maintaining coupling losses below 1.5 dB for both polarizations over the entire C-band. This adaptability to different mode diameters makes the SiN SSC a promising candidate for future electro-optic chiplets that integrate heterogeneous materials such as III-V for gain and lithium niobate for modulation with the SiN-on-SOI for all other functions using advanced packaging techniques. Full article
