Millimeter-wave signals experience substantial path loss when penetrating common building materials, hindering seamless indoor coverage from outdoor networks. To address this limitation, we present the 28-GHz “Meta-Window”, a mass-producible, visible transparent device designed to enhance millimeter-wave signal focusing. Fabricated via metal sputtering and etching on a standard soda-lime glass substrate, the meta-window incorporates subwavelength metallic structures arranged in a rotating pattern based on the Pancharatnam–Berry phase principle, enabling 0–360$°$ phase control within the 25–32 GHz frequency band. A 210 mm × 210 mm prototype operating at 28 GHz was constructed using a 69 × 69 array of metasurface unit cells, leveraging planar electromagnetic lens principles. Experimental results demonstrate that the meta-window achieves greater than 20 dB signal focusing gain between 26 and 30 GHz, consistent with full-wave electromagnetic simulations, while maintaining up to 74.93% visible transmittance. This dual transparency—for both visible light and millimeter-wave frequencies—was further validated by a communication prototype system exhibiting a greater than 20 dB signal-to-noise ratio improvement and successful demodulation of a 64-QAM single-carrier signal (1 GHz bandwidth, 28 GHz) with an error vector magnitude of 4.11%. Moreover, cascading the meta-window with a reconfigurable reflecting metasurface antenna array facilitates large-angle beam steering; stable demodulation (error vector magnitude within 6.32%) was achieved within a ±40$°$ range using the same signal parameters. Compared to conventional transmissive metasurfaces, this approach leverages established glass manufacturing techniques and offers potential for direct building integration, providing a promising solution for improving millimeter-wave indoor penetration and coverage. Full article

The 2 μm wavelength is ideal for light detection and ranging and gas sensing due to its eye-safe operation, strong molecular absorption targeting, and low atmospheric scattering—critical for environmental monitoring and free-space communications. The existing 2 μm systems rely on mechanical beam steering, which limits speed and reliability. Integrated photonic solutions have not yet been demonstrated in this wavelength. We propose a focal plane array design to address these challenges. Compared to optical phased arrays requiring complex phase control for each antenna, FPAs have a simple switch-based control and high suppression of background noise. Although FPAs need an external lens for beam collimation, they significantly reduce system complexity. This study introduces a compact, low-loss 1 × 8 focal plane array operating in the 2 μm range, employing a cascaded Mach–Zehnder interferometer switch array on a silicon nitride platform. The device demonstrates a field of view of 16.8°, background suppression better than 17 dB, and excess loss of −1.4 dB. This integrated photonic beam steering solution offers a highly promising, cost-effective approach for rapid beam switching. This integrated photonic beam steering solution offers a highly promising, cost-effective approach for rapid beam switching. Full article

A novel approach to underwater optical wireless coherent communications using liquid crystal spatial light modulators (LC-SLMs) and an aperture averaging lens, in combination with optical phased-array (OPA) antennas, is presented. A comprehensive channel model that includes a wide range of underwater properties, including absorption, scattering, and turbulence effects, is employed to simulate the underwater optical wireless communication (UOWC) system in a realistic manner. The proposed system concept utilizes aperture averaging and adaptive optics techniques to mitigate the degrading effects of turbulence. Additionally, OPA antennas are integrated into the system to provide electronic beam steering capabilities, facilitating precise pointing, acquisition, and tracking (PAT) between mobile underwater vehicles. This integration enables high-speed and reliable communication links by maintaining optimal alignment. The numerical results show that under strong turbulence, our combined turbulence-compensation approach (LC-SLM plus aperture averaging) can extend the communication range by approximately threefold compared to a baseline system without compensation. For instance, at a soft-decision FEC threshold of $1.25\times {10}^{-2}$, the maximum achievable link distance increases from around $10\mathrm{m}$ to over $30\mathrm{m}$. Moreover, the scintillation index is reduced by more than $90\%$, and the bit error rate (BER) improves. Full article

This work proposes an all-quartz integrated lens antenna for the first time. The antenna feed and lens materials are both made of quartz. The antenna is designed to work at 26 GHz and has the advantages of small size and reduced surface wave loss. Two antennas, a hemispheric lens and an extended hemispheric lens, are demonstrated. The hemispheric lens has an area of 30 × 30 mm² and a height of 16 mm, while the extended hemispheric lens, with the same area, has a height of 26 mm. The measured peak gain of the extended hemispheric integrated lens antenna is 15.49 dBi, and the simulated peak gain is 17.68 dBi. The electric-field distribution was analyzed, and two hemispheric lens and extended hemispheric lens antennas of the same size were designed on PCB substrate for comparative analysis. The measured results validate the impact of the surface wave effect on the gain of the lens antenna proposed in this study. Full article

Alkali-activated concrete (AAC), produced from industrial by-products like fly ash and slag, offers a promising alternative to traditional Portland cement concrete by significantly reducing carbon emissions. Yet, the inherent variability in AAC formulations presents a challenge for accurately predicting its compressive strength using conventional approaches. To address this, we leverage machine learning (ML) techniques, which enable more precise strength predictions based on a combination of material properties and cement mix design parameters. In this study, we curated an extensive dataset comprising 1756 unique AAC mixtures to support robust ML-based modeling. Four distinct input variable schemes were devised to identify the optimal predictor set, and a comparative analysis was performed to evaluate their effectiveness. After this, we investigated the performance of several popular ML algorithms, including random forest (RF), adaptive boosting (AdaBoost), gradient boosting regression trees (GBRTs), and extreme gradient boosting (XGBoost). Among these, the XGBoost model consistently outperformed its counterparts. To further enhance the predictive accuracy of the XGBoost model, we applied four state-of-the-art optimization techniques: the Gray Wolf Optimizer (GWO), Whale Optimization Algorithm (WOA), beetle antennae search (BAS), and Bayesian optimization (BO). The optimized XGBoost model delivered superior performance, achieving a remarkable coefficient of determination (R²) of 0.99 on the training set and 0.94 across the entire dataset. Finally, we employed SHapely Additive exPlanations (SHAP) to imbue the optimized model with interpretability, enabling deeper insights into the complex relationships governing AAC formulations. Through the lens of ML, we highlight the benefits of the multi-faceted synergistic approach for AAC strength prediction, which combines careful input parameter selection, optimal hyperparameter tuning, and enhanced model interpretability. This integrated strategy improves both the robustness and scalability of the model, offering a clear and reliable prediction of AAC performance. Full article

This study introduces a groundbreaking antenna system, the directive Metasurface Half-Maxwell Fish-Eye (MHMF) lens antenna, tailored specifically for Internet-of-Things (IoT) networks. Designed to operate at 60 GHz, this antenna ingeniously integrates a dipole antenna within a parallel-plate waveguide to illuminate a Half-Maxwell Fish-Eye (HMFE) lens. The HMFE lens serves as a focal point, enabling a crucial high gain for IoT operations. The integration of metasurface structures facilitates the attainment of the gradient refractive index essential for the lens surface. By employing commercial Ansys HFSS software, extensive numerical simulations were conducted to meticulously refine the design, focusing particularly on optimizing the dimensions of unit cells, notably the modified H-shaped cells within the parallel waveguides housing the beam launchers. A functional prototype of the antenna was constructed using a standard PCB manufacturing process. Rigorous testing in an anechoic chamber confirmed the functionality of these manufactured devices, with the experimental results closely aligning with the simulated findings. Far-field measurements have further confirmed the effectiveness of the antenna, establishing it as a high-gain antenna solution suitable for IoT applications. Specifically, it operates effectively within the 60 GHz range of the electromagnetic spectrum, which is crucial for ensuring reliable communication in IoT devices. The directive HMFE lens antenna represents a significant advancement in enhancing IoT connectivity and capabilities. Leveraging innovative design concepts and metasurface technology, it heralds a new era of adaptable and efficient IoT systems. Full article

In this paper, a 3D conformal meta-lens designed for manipulating electromagnetic beams via height-to-phase control is proposed. The structure consists of a 40 × 20 array of tunable unit cells fabricated using 3D printing, enabling full 360° phase compensation. A novel automatic synthesizing method (ASM) with an integrated optimization process based on genetic algorithm (GA) is adopted here to create the meta-lens. Simulation using CST Microwave Studio and MATLAB reveals the antenna’s beam deflection capability by adjusting phase compensations for each unit cell. Various beam scanning techniques are demonstrated, including single-beam, dual-beam generation, and orbital angular momentum (OAM) beam deflection at different angles of 0°, 10°, 15°, 25°, 30°, and 45°. A 3D-printed prototype of the dual-beam feature has been fabricated and measured for validation purposes, with good agreement between both simulation and measurement results, with small discrepancies due to 3D printing’s low resolution and fabrication errors. This meta-lens shows promise for low-cost, high-gain beam deflection in mm-wave wireless communication systems, especially for sensing applications, with potential for wider 2D beam scanning and independent beam deflection enhancements. Full article

Transient terahertz time-domain spectroscopy (THz-TDS) imaging has emerged as a novel non-ionizing and noninvasive biomedical imaging modality, designed for the detection and characterization of a variety of tissue malignancies due to their high signal-to-noise ratio and submillimeter resolution. We report our design of a pair of aspheric focusing lenses using a commercially available lens-design software that resulted in about 200 × 200-μm² focal spot size corresponding to the 1-THz frequency. The lenses are made of high-density polyethylene (HDPE) obtained using a lathe fabrication and are integrated into a THz-TDS system that includes low-temperature GaAs photoconductive antennae as both a THz emitter and detector. The system is used to generate high-resolution, two-dimensional (2D) images of formalin-fixed, paraffin-embedded murine pancreas tissue blocks. The performance of these focusing lenses is compared to the older system based on a pair of short-focal-length, hemispherical polytetrafluoroethylene (Teflon^TM) lenses and is characterized using THz-domain measurements, resulting in 2D maps of the tissue refractive index and absorption coefficient as imaging markers. For a quantitative evaluation of the lens effect on the image resolution, we formulated a lateral resolution parameter, R₂₀₈₀, defined as the distance required for a 20–80% transition of the imaging marker from the bare paraffin region to the tissue region in the same image frame. The R₂₀₈₀ parameter clearly demonstrates the advantage of the HDPE lenses over Teflon^TM lenses. The lens-design approach presented here can be successfully implemented in other THz-TDS setups with known THz emitter and detector specifications. Full article

An integrated automatic optical inspection (iAOI) system with a procedure was proposed for a printed circuit board (PCB) production line, in which pattern distortions and performance deviations appear with process variations. The iAOI system was demonstrated in a module comprising a camera and lens, showing improved supportiveness for commercially available hardware. The iAOI procedure was realized in a serial workflow of image registration, threshold setting, image gradient, marker alignment, and geometric transformation; furthermore, five operations with numerous functions were prepared for image processing. In addition to the system and procedure, a graphical user interface (GUI) that displays sequential image operation results with analyzed characteristics was established for simplicity. To demonstrate its effectiveness, self-complementary Archimedean spiral antenna (SCASA) samples fabricated via standard PCB fabrication and intentional pattern distortions were demonstrated. The results indicated that, compared with other existing methods, the proposed iAOI system and procedure provide unified and standard operations with efficiency, which result in scientific and unambiguous judgments on pattern quality. Furthermore, we showed that when an appropriate artificial intelligence model is ready, the electromagnetic characteristic projection for SCASAs can be simply obtained through the GUI. Full article

This paper proposes a circularly polarized ultra-wideband (UWB) antenna for a Uni-Traveling-Carrier Photodiode (UTC-PD) to meet the growing demand for bandwidth and polarization diversity in terahertz (THz) communication. In the design of the UTC-PD integrated antenna, the planar electrodes of the chip are directly integrated with the antenna to simplify the integration process. However, this integration introduces new problems, such as asymmetry inside the spiral antenna, which leads to a deterioration in the corresponding high-frequency performance. To address this issue, the antenna’s structure is optimized, and a lens is integrated to enhance directivity and eliminate surface waves. As a result, the proposed antenna achieves a 100–1500 GHz (175%) impedance bandwidth and a 150–720 GHz (131%) axial ratio bandwidth for the UTC-PD. The maximum gain of the antenna is 21.05 dBi at 1 THz. Full article

A design strategy to alter the radiation characteristics of modular radar printed circuit boards without the need for expensive retooling and remanufacturing is presented in this paper. To this end, a compact radar module including microstrip array antennas integrated with a dielectric rod lens is considered for a demonstration of an X-band radar antenna gain improvement leading to radar detection range enhancement. Using travelling wave theory, the proposed lens is designed to target the excitation of HE11 mode to achieve gain improvement without disturbing reflection coefficients. Using a low-cost rapid-manufacturing 3D-printing technology, two pairs of the 3D-printed dielectric rods integrated with a dielectric housing are designed and fabricated uniformly for a commercially available off-the-shelf radar module. The radar integration with the dielectric rod lens leads to a low-cost and easy-to-fabricate long-range radar system. Compared with the radar without the rods, the design system achieved a measured 6.6 dB gain improvement of the transmitter and receiver antennas which causes doubling the detection range for both elevation and azimuth directions at 10.525 GHz. Full article

In this paper, a dual-polarized antenna based on a substrate-integrated waveguide (SIW) horn antenna and Vivaldi antenna is proposed. The horizontal polarization (HP) is achieved by using the H-plane SIW horn antenna, while the vertical polarization (VP) is realized by a typical Vivaldi antenna etched on the surface of the SIW horn antenna. In front of the horn aperture, a dielectric lens is designed to optimize impedance matching and enhance directivity. Different feeding structures of the two polarizations are used to enhance the isolation between the two ports. The measured results demonstrate a 20.04–25.5 GHz (23.97%) overlapped dual-polarized impedance bandwidth, and the measured maximum gains of the HP and VP are 5.2 dBi and 8.2 dBi, respectively. A good isolation of 35 dB within the operating band is realized. The proposed dual-polarized antenna meets the demand to transmit and receive signals in two polarization directions simultaneously for wireless communication well. Full article

This paper reports on the design and experimental validation of a fully-metallic double-ridged waveguide 10 × 10 Rotman lens additively manufactured as a single part. The wide band operation of this quasi-optical beamformer enables us to cover the uplink and downlink frequencies allocated to satellite communications in the K/K${}_{\mathrm{a}}$-band, from 17.3 GHz to 30 GHz. The feeding port design was adjusted to enable vertical printing, thus minimizing the use of supporting structures. A prototype was manufactured and tested. The reported results indicate losses in the range of 0.5 dB in the lower-frequency band and 0.8 dB in the upper-frequency band, including the waveguide transitions added for test purposes. The measured reflection and coupling coefficients remain below −11.5 dB over the operating band. The standard deviation of the residual phase error across the array ports is below $5°$ in simulation and below $10°$ in measurements. Array factors synthesized using the scattering parameters confirm the good stability of the beamforming functionality over the wide frequency band analyzed. This monolithic design is a promising step toward more integrated antenna systems, such as a compact dual-stack configuration for planar array design. Full article

This paper describes the integration of a plate Luneburg lens with a microstrip patch antenna (MPA) with a complementary split ring resonator (CSRR) at 17 GHz frequency. The main advantage of the method is the compact size of the optimized MPA with CSRR such that the radiation pattern of the antennas successfully overlaps at −3 dB. The overlapping is achieved by positioning multiple MPA with CSRR structures around the plate Luneburg lens with 0.408λ distance between the elements. To test the performance of the lens, CST simulations are carried out using a classical WR62 open-ended waveguide to feed the structure, then adding more waveguides rotated at focal points of the lens. After that, the waveguide is substituted with the MPA with CSRR structure. The superiority of the proposed method over the conventional waveguide or regular patch antenna is confirmed by an overlap in radiation pattern at −3 dB with a narrow beamwidth of 10.9°. Full article

In this article, a high-gain millimeter-wave transmitarray antenna (TAA) maintaining scanning ability is developed, integrating an array feed as the primary emitter. The work is achieved within a limited aperture area, avoiding the replacement or extension of the array. The addition of a set of defocused phases along the scanning direction to the phase distribution of the monofocal lens allows the converging energy to be dispersed into the scanning scope. The beam forming algorithm proposed in this article can determine the excitation coefficients of the array feed source, and is beneficial to improve the scanning capability in array-fed transmitarray antennas. A transmitarray based on the square waveguide element illuminated by an array feed is designed with a focal-to-diameter ratio (F/D) of 0.6. A 1-D scan with a scope of −5° to 5° is realized through calculation. The measured results show that the transmitarray can achieve a high gain, 37.95 dBi at 160 GHz, although a maximum 2.2 dB error appears compared with the calculation in the operating band of 150–170 GHz. The proposed transmitarray has been proven to generate scannable high-gain beams in the millimeter-wave band and is expected to demonstrate its potential in other applications. Full article
