In high-voltage transmission lines, insulators subjected to prolonged electromechanical stress are prone to zero-value defects, leading to insulation failure and posing significant risks to power grid reliability. The conventional detection method of spark gap is vulnerable to environmental interference, while the emerging electric field distribution-based techniques require complex instrumentation, limiting its applications in scenes of complex structures and atop tower climbing. To address these challenges, this study proposes an electroluminescent sensing strategy for zero-value insulator identification based on the electroluminescence of ZnS:Cu. Based on the stimulation of electrical stress, real-time monitoring of the health status of insulators was achieved by applying the composite of epoxy and ZnS:Cu onto the connection area between the insulator steel cap and the shed. Experimental results demonstrate that healthy insulators exhibit characteristic luminescence, whereas zero-value insulators show no luminescence due to a reduced drop in electrical potential. Compared with conventional detection methods requiring access of electric signals, such non-contact optical detection method offers high fault-recognition accuracy and real-time response capability within milliseconds. This work establishes a novel intelligent sensing paradigm for visualized condition monitoring of electrical equipment, demonstrating significant potential for fault diagnosis in advanced power systems. Full article

Fault diagnosis based on the partial discharge (PD) recognition has been widely applied on a gas-insulated line breaker (GILB) and gas-insulated switchgear (GIS) as a reliable online condition monitoring method. This paper dealt with insulation defect diagnosis based on a Random Forest (RF) algorithm with an optimized feature selection method. Four different types of insulation defect models, such as the free-moving particle (FMP) defect, the protrusion-on-conductor (POC) defect, the protrusion-on-enclosure (POE) defect, and the delamination defect, were prepared to simulate representative PD single pulses and PRPD patterns generated from the GILB. The PD signals generated from defect models were detected using the PRPD sensor which can detect phase-synchronized PD signals with the applied high-voltage (HV) signals without the need for additional equipment. Various statistical PD features were extracted from PD single pulses and PRPD patterns according to four kinds of PD defect models, and optimized features were selected with respect to variance importance analysis. Two kinds of PD datasets were established using all statistical features and top-ranked features. From the experimental results, the RF algorithm achieved accuracy rates exceeding 92%, and the PD datasets using only half of the statistical PD features could reduce the computational times while maintaining the accuracy rates. Full article

The alumina doped epoxy resin composites have been widely used to prepare the basin-type insulators in gas-insulated switchgear (GIS). In recent years, the air cavity defects in the basin-type insulators became one of the most common factors to induce GIS faults. Therefore, the development of novel detection techniques for air cavities in epoxy resin composites is of great importance. In this study, multiple epoxy resin samples containing various submillimeter air cavities were prepared. Long pulse thermography (LPT) was employed to detect defects in the epoxy resin composite, and multiple data processing methods were applied to extract the characteristics of the air cavity defects. Quantitative analysis was also used to characterize the detection effectiveness in different thermograms. Experimental results show that derivative thermograms are capable of detecting air cavity defects with a diameter of 0.2 mm at a depth of 1.2 mm. The derivative thermograms can reduce noise and sharpen the defect recognition, exhibiting a high signal-to-noise ratio (SNR). This study also analyzes the impact of the aspect ratio on the detection result, which indicates that the defect with a small aspect ratio is difficult to detect. Based on the infrared thermography technology, this work provides a promising route for defects detection in basin-type insulators. Full article

As a relatively weak part of cable insulation, T-type cable terminals will have insulation defects due to process, installation, and other problems, resulting in partial discharge. Therefore, this paper uses Deep Convolution Neural Network (DCNN) and Empirical Mode Decomposition (EMD) to identify the partial discharge type of a 10 kV T-type cable terminal. This method uses the partial discharge experimental platform of the T-type cable terminal to collect the partial discharge signal. After the original signal that is difficult to identify is decomposed by EMD, a series of intrinsic mode components (IMFs) that are easy to locate are obtained. The deep learning network model is used to identify the defect type of the IMF signal. The results show that the overall defect recognition rate of this method reaches 95.3%. Compared with the traditional random forest algorithm (RF), the 10 kV T-type terminal partial discharge type recognition method based on EMD–DCNN is considered in this paper. The recognition accuracy of the main insulation scratch, bushing fouling, and joint loosening defects is higher than that of the traditional mechanical learning algorithm, RF, indicating that the method adopted in this paper can more effectively and accurately identify the defect type. Full article

Accurately detecting defect-induced photon emissions enables early defect detection and characterization. To address this, a defect evolution state recognition model based on phase-resolved photon counting and dimensionality reduction calculations is proposed under alternating current (AC) excitation. Initially, photon information from protruding metal defects simulated using needle–plane electrodes during partial discharge (PD) evolution is analyzed in SF₆. Subsequently, phase-resolved photon counting (PRPC) techniques and statistical analysis are employed to extract feature parameters for quantitative characterization of defect-induced photon responses. Finally, a t-distributed stochastic neighbor embedding (t-SNE) dimensionality reduction analysis is utilized to establish criteria for categorizing defect evolution states. The findings reveal that metal-particle-triggered optical PRPC maintains the obvious polarity effect, and the entire evolution of the discharge can be divided into three processes. These research findings are expected to advance the accurate assessment of operational risks in gas-insulated systems. Full article

Gas Insulated Switchgear (GIS) is a type of critical substation equipment in the power system, and its safe and stable operation is of great significance for ensuring the reliability of power system operation. To accurately identify partial discharge in GIS, this paper proposes an acoustic identification method based on improved mel frequency cepstral coefficients (MFCC) and dung beetle algorithm optimized random forest (DBO-RF) based on the ultrasonic detection method. Firstly, three types of typical GIS partial discharge defects, namely free metal particles, suspended potential, and surface discharge, were designed and constructed. Secondly, wavelet denoising was used to weaken the influence of noise on ultrasonic signals, and conventional, first-order, and second-order differential MFCC feature parameters were extracted, followed by principal component analysis for dimensionality reduction optimization. Finally, the feature parameters after dimensionality reduction optimization were input into the DBO-RF model for fault identification. The results show that this method can accurately identify partial discharge of typical GIS defects, with a recognition accuracy reaching 92.2%. The research results can provide a basis for GIS insulation fault detection and diagnosis. Full article

Distribution line insulators play a key role in electrical insulation and supporting lines in distribution lines. Insulator defects due to overvoltage, thermal stress, and environmental pollution may trigger power transmission instability and line collapse, thus threatening the safe operation of distribution networks. However, distribution line insulators often present detection challenges due to their compact dimensions, diverse flaw types, and frequent installation in populated areas with visually cluttered environments. The combination of these factors, including small defect sizes, varying failure patterns, and complex background interference, in both urban and rural settings, creates significant difficulties for precise defect identification in these critical components. In response to these challenges, this paper proposes a defect recognition algorithm for distribution line insulators based on the improved YOLO11 model. Firstly, the algorithm combines the detection head of the original model with the Adaptively Spatial Feature Fusion (ASFF) module to effectively fuse defect features at different resolution levels and improve the model’s ability to recognize multi-scale defect features. Secondly, a Bidirectional Feature Pyramid Network (BiFPN) replaces the FPN + PAN structure of the original model to achieve a more effective transfer of contextual information in order to facilitate the model’s efficiency in performing defect feature fusion, and the Convolutional Block Attention Module (CBAM) Attention mechanism is embedded in the BiFPN output so that the model is able to give priority attention to defective features on insulators in complex recognition environments. Finally, the ShuffleNetV2 module is used to reduce the parameters of the improved model by replacing the large-parameter C3k2 module at the end of the backbone network for easy deployment on lightweight and small devices. The experimental results show that the improved model performs well in the distribution line insulator defect detection task, with an accuracy precision (AP) and mean accuracy precision (mAP) of 97.0% and 98.1%, respectively, which are 1.4% and 0.7% higher than the original YOLO11 model. Full article

As critical infrastructure in modern distribution systems, power cables face progressive insulation degradation from partial discharge (PD), while conventional recognition methods struggle with feature extraction and model generalizability. This study develops an integrated experimental platform for PD pattern recognition in power cable systems, comprising a control console, high-voltage transformer, high-frequency current transformer, and ultra-high-frequency (UHF) signal acquisition equipment. Four distinct types of discharge-defective models are constructed and tested through this dedicated high-voltage platform, generating a dataset of phase-resolved partial discharge (PRPD) spectra. Based on this experimental foundation, an improved Swin Transformer-based framework with adaptive learning rate optimization is developed to address the limitations of conventional methods. The proposed architecture demonstrates superior performance, achieving 94.68% classification accuracy with 20 training epochs while reaching 97.52% at the final 200th epoch. Comparisons with the original tiny version of the Swin Transformer model show that the proposed Swin Transformer with an adaptive learning rate attains a maximum improvement of 6.89% over the baseline model in recognition accuracy for different types of PD defect detection. Comparisons with other deeper Convolutional Neural Networks illustrate that the proposed lightweight Swin Transformer can achieve comparable accuracy with significantly lower computational demands, making it more promising for application in real-time PD defect diagnostics. Full article

Insulation pull rods used in gas-insulated switchgear (GIS) inevitably contain the micro defects generated during production. The intelligent identification method, which requires large datasets with a balanced distribution of defect types, is regarded as the prevailing way to avoid insulation faults. However, the number of defective pull rods is limited, and the occurrence of different types of defects is highly imbalanced in actual production, leading to poor recognition performance. Thus, this work proposes a data preprocessing method for the insulation pull rod defect feature dataset. In this work, the YOLOv5s algorithm is used to detect defects in insulation pull rod images, creating a dataset with five defect categories. Two preprocessing methods for impurities and bubbles are introduced, including copy–paste within images and bounding box corrections for hair-like impurities. The results show that these two methods can specifically enhance small-sized defect targets while maintaining the detection performance for other types of targets. In contrast, the proposed method integrates copy–paste within images with Mosaic data augmentation and corrects bounding boxes for hair-like impurities significantly improving the model’s performance. Full article

This paper presents a cable defect assessment method based on a mixed-domain multi-feature set derived from overall harmonic signals. Four typical defect types—thermal ageing, cable moisture, excessive bending, and insulation damage—were simulated under laboratory conditions. Grounding current tests and Variational Mode Decomposition (VMD) time series analysis were performed on the test samples to extract the overall harmonic sequences in the grounding current. Mixed-domain multi-feature set is then formed through feature extraction and validity analysis. To optimize the assessment performance, a Support Vector Machine (SVM) classifier optimized by the Sparrow Search Algorithm (SSA) was constructed. The results show that different defects lead to significantly differentiated harmonic distortions in the grounding currents, which has proved to be a reliable data basis for cable defect assessment. The proposed method refines the data information and achieves the most accurate recognition of cable defects, which may contribute to the reliable operation of power networks. Full article

In modern power systems, drones are increasingly being utilized to monitor the condition of critical power equipment. However, limited computing capacity is a key factor limiting the application of drones. To optimize the computational load on drones, this paper proposes a cloud–edge collaborative intelligence strategy to be applied to insulator identification and defect detection scenarios. Firstly, a low-computation method deployed at the edge is proposed for determing whether insulator strings are present in the captured images. Secondly, an efficient insulator recognition and defect detection method, I-YOLO (Insulator-YOLO), is proposed for cloud deployment. In the neck network, we integrate an I-ECA (Insulator-Enhanced Channel Attention) mechanism based on insulator characteristics to more comprehensively fuse features. In addition, we incorporated the insulator feature cross fusion network (I-FCFN) to enhance the detection of small-sized insulator defects. Experimental results demonstrate that the cloud–edge collaborative intelligence strategy performs exceptionally well in insulator-related tasks. The edge algorithm achieved an accuracy of 97.9% with only 0.7 G FLOPs, meeting the inspection requirements of drones. Meanwhile, the cloud model achieved a $mA{P}_{50}$ of 96.2%, accurately detecting insulators and their defects. Full article

As the scale of the power grid rapidly expands, its operation becomes increasingly complex, with higher demands on personnel proficiency, grid stability, equipment safety, and operational efficiency. In this study, a novel power insulator defect detection method based on convolutional neural networks (CNNs) is proposed. This method innovatively combines the feature extraction advantages of deep learning to build an efficient binary classification model capable of accurately detecting defects in power insulators in complex backgrounds. To avoid the impact of a small dataset on model performance, transfer learning was employed during model training to enhance the model’s generalization ability. A combination of Grid Search and Random Search was used for hyperparameter tuning, and the Early Stopping strategy was introduced to effectively prevent the model from overfitting to the training set, ensuring generalization performance on the validation set. Experimental results show that the proposed method achieves an average accuracy of 98.6%, a recall of 96.8%, and an F1 score of 97.7% on the test set. Compared to traditional Faster RCNN and PCA-SVM methods, the proposed CNN model significantly improves detection accuracy and computational efficiency in complex backgrounds, exhibiting superior recognition precision and model generalization ability for efficiently and accurately identifying defective insulators. Full article

Partial discharge is a fault that occurs at the site of insulation defects within a transformer. Dual instances of partial discharge origination discharging simultaneously embody a more intricate form of discharge, where the interaction between the discharge sources leads to more intricate and unpredictable insulation damage. Conventional piezoelectric transducers are magnetically affixed to the exterior metal tank of transformers. The ultrasonic signals emanating from partial discharge undergo deflection and reverberation upon traversing the windings, insulation paperboards, and the outer shell, resulting in signal attenuation and thus making it difficult to detect such faults. Furthermore, it is challenging to distinguish between simultaneous discharges from dual partial discharge sources and continuous discharges from a single source, often leading to missed detection and repairs of fault points, which increase the maintenance difficulty and cost of power equipment. With the advancement of MEMS (Micro-Electro-Mechanical System) technology, fiber-optic ultrasonic sensors have surfaced as an innovative technique for optically detecting partial discharges. These sensors are distinguished by their minute dimensions, heightened sensitivity, and robust immunity to electromagnetic disturbances. and excellent insulation properties, allowing for internal installation within power equipment for partial discharge monitoring. In this study, we developed an EFPI (Extrinsic Fabry Perot Interferometer) optical fiber ultrasonic sensor that can be installed inside transformers. Based on this sensor array, we also created a partial discharge ultrasonic detection system that estimates the directional information of single and dual partial discharge sources using the received signals from the sensor array. By utilizing the DOA (Direction of Arrival) as a feature recognition parameter, our system can effectively detect both simultaneous discharges from dual partial discharge sources and continuous discharges from a single source within transformer oil tanks, meeting practical application requirements. The detection methodology presented in this paper introduces an original strategy and resolution for pinpointing the types of partial discharges occurring under intricate conditions within power apparatus, effectively distinguishing between discharges from single and dual partial discharge sources. Full article

In general, a high voltage (HV) substation can be made up of multiple insulation subsystems: an air insulation subsystem (AIS), gas insulation subsystem (GIS), liquid insulation subsystem (power transformers), and solid insulation subsystem (power cables), all of them with their grounding structures interconnected and linked to the substation earth. Partial discharge (PD) pulses, which are generated in a HV apparatus belonging to a subsystem, travel through the grounding structures of the others. PD analyzers using high-frequency current transformer (HFCT) sensors, which are installed at the connections between the grounding structures, are sensitive to these traveling pulses. In a substation made up of an AIS, several non-critical PD sources can be detected, such as possible corona, air surface, or floating discharges. To perform the correct diagnosis, non-critical PD sources must be separated from critical PD sources related to insulation defects, such as a cavity in a solid dielectric material, mobile particles in SF6, or surface discharges in oil. Powerful diagnostic tools using PD clustering and phase-resolved PD (PRPD) pattern recognition have been developed to check the insulation condition of HV substations. However, a common issue is how to determine the subsystem in which a critical PD source is located when there are several PD sources, and a critical one is near the boundary between two HV subsystems, e.g., a cavity defect located between a cable end and a GIS. The traveling direction of the detected PD is valuable information to determine the subsystem in which the insulation defect is located. However, incorrect diagnostics are usually due to the constraints of PD measuring systems and inadequate PD diagnostic procedures. This paper presents a diagnostic procedure using an appropriate PD analyzer with multiple HFCT sensors to carry out efficient insulation condition diagnoses. This PD procedure has been developed on the basis of laboratory tests, transient signal modeling, and validation tests. The validation tests were carried out in a special test bench developed for the characterization of PD analyzers. To demonstrate the effectiveness of the procedure, a real case is also presented, where satisfactory results are shown. Full article

This paper proposes a new method for recognizing, extracting, and processing Phase-Resolved Partial Discharge (PRPD) patterns from two-dimensional plots to identify specific defect types affecting electrical equipment without human intervention while retaining the principals that make PRPD analysis an effective diagnostic technique. The proposed method does not rely on training complex deep learning algorithms which demand substantial computational resources and extensive datasets that can pose significant hurdles for the application of on-line partial discharge monitoring. Instead, the developed Cosine Cluster Net (CCNet) model, which is an image processing pipeline, can extract and process patterns from any two-dimensional PRPD plot before employing the cosine similarity function to measure the likeness of the patterns to predefined templates of known defect types. The PRPD pattern recognition capabilities of the model were tested using several manually classified PRPD images available in the existing literature. The model consistently produced similarity scores that identified the same defect type as the one from the manual classification. The successful defect type reporting from the initial trials of the CCNet model together with the speed of the identification, which typically does not exceed four seconds, indicates potential for real-time applications. Full article
