This study presents a compact and high-efficiency microstrip antenna integrated with a square electromagnetic band-gap (EBG) structure for radio frequency energy harvesting to power battery-less Internet of Things (IoT) sensors and medical devices in the 5.8 GHz Industrial, Scientific, and Medical (ISM) band. The proposed antenna features a compact design with reduced physical dimensions of 36 × 40 mm² (0.69λ_o × 0.76λ_o) while providing high-performance parameters such as a reflection coefficient of −27.9 dB, a voltage standing wave ratio (VSWR) of 1.08, a gain of 7.91 dBi, directivity of 8.1 dBi, a bandwidth of 188 MHz, and radiation efficiency of 95.5%. Incorporating EBG cells suppresses surface waves, enhances gain, and optimizes impedance matching through 50 Ω inset feeding. The simulated and measured results of the designed antenna show a high correlation. This study demonstrates a robust and promising solution for high-performance wireless systems requiring a compact size and energy-efficient operation. Full article

This paper presents a novel, four-port, rectangular microstrip, inset-feed multiple-input and multiple-output (MIMO) antenna array, enhanced with metamaterials for improved gain and isolation, specifically designed for multi-operator 5G open radio access network (ORAN)-based indoor software-defined radio (SDR) applications. ORAN is an open-source interoperable framework for radio access networks (RANs), while SDR refers to a radio communication system where functions are implemented via software on a programmable platform. A 3 × 3 metamaterial (MTM) superstrate is placed above the MIMO antenna array to improve gain and reduce the mutual coupling of MIMO. The proposed MIMO antenna operates over a 300 MHz bandwidth (3.5–3.8 GHz), enabling shared infrastructure for multiple operators. The antenna’s dimensions are 75 × 75 × 18.2 mm³. The antenna possesses a reduced mutual coupling less than −30 dB and a 3.5 dB enhancement in gain with the help of a novel 3 × 3 MTM superstrate 15 mm above the radiating MIMO elements. A performance evaluation based on simulated results and lab measurements demonstrates the promising value of key MIMO metrics such as a low envelope correlation coefficient (ECC) < 0.002, diversity gain (DG) ~10 dB, total active reflection coefficient (TARC) < −10 dB, and channel capacity loss (CCL) < 0.2 bits/sec/Hz. Real-world testing of the proposed antenna for ORAN-based sub-6 GHz indoor wireless systems demonstrates a downlink throughput of approximately 200 Mbps, uplink throughput of 80 Mbps, and transmission delays below 80 ms. Additionally, a walk test in an indoor environment with a corresponding floor plan and reference signal received power (RSRP) measurements indicates that most of the coverage area achieves RSRP values exceeding −75 dBm, confirming its suitability for indoor applications. Full article

This paper presents a compact design for a four-element multiple-input multiple-output (MIMO) antenna for millimeter-wave (mmWave) communications covering the bands of n257/n258/n261. The MIMO design covers the frequency range of 24.25–29.5 GHz, with a wide bandwidth of 5.25 GHz. The element of the MIMO antenna structure uses a single circular patch with an inset feed, and, in order to improve the reflection coefficient (S₁₁), a half-disk parasitic patch is positioned on top of the circular patch. Moreover, to fine-tune the antenna’s characteristics, two vertical stubs on the extreme ends of the ground plane are introduced. For this design, a Rogers RT/Duroid 5880 substrate with ultra-thin thickness is used. After the optimization of the design, the four-port MIMO antenna attained a tiny size, with the dimensions 16.2 mm × 16.2 mm × 0.254 mm. In terms of the MIMO parameters, the ECC (Envelop Correlation coefficient) is less than 0.002 and the DG (Diversity Gain) is greater than 9.99 dB in the mentioned band, which are within the tolerance limits. Also, in spite of the very small size and the four-port configuration, the achieved isolation between the neighboring MIMO elements is less than −23.5 dB. Full article

This paper presents a single-fed, single-layer, dual-band antenna with a large frequency ratio of 4.74:1 for vehicle-to-vehicle communication. The antenna consists of a 28 GHz inset-fed rectangular patch embedded into a 5.9 GHz patch antenna for dual-band operation. The designed dual-band antenna operates from 5.81 to 5.99 GHz (Dedicated Short Range Communications, DSRC) and 27.9 to 30.1 GHz (5G millimeter-wave (mm-wave) band). Furthermore, the upper band patch was modified by inserting slots near the inset feed line to achieve an instantaneous bandwidth of 4.5 GHz. The antenna was fabricated and measured. The manufactured prototype operates simultaneously from 5.8 to 6.05 GHz and from 26.8 to 31.3 GHz. Notably, the designed dual-band antenna offers a high peak gain of 7.7 dBi in the DSRC band and 6.38 dBi in the 5G mm-wave band. Full article

In this paper, Pyralux—a modern, ultra-thin, and acrylic-based laminate—was tested as a substrate of a microstrip antenna to examine the antenna characteristics when it is built on such a thin, flexible, and robust dielectric material, with the idea of eventually serving in wearable antennas in the context of smart-clothing applications. We particularly discuss the sensitivity of the design and fabrication of an inset-fed rectangular microstrip antenna (IRMA) in terms of its inset gap width when it is designed in the S-frequency band. The simulated and measured results showed a very small feasible range for the inset gap dimension with respect to the feed line width. Ultimately, an IRMA was successfully designed, fabricated, and tested with both SMA and U.FL connectors. The impedance bandwidth, in either case, was about 2%, the average value of directivity was 5.8 dB, and the realized efficiency was 2.67%, while the 3-dB beamwidths in the E-plane and the H-plane were 90${}^{°}$ or wider. Full article

This article comparatively shows the evolution of parameters of three types of arrays for MIMO microstrip antennas, to which the number of ports is gradually incremented until reaching 32. The three arrays have a 1 × 2 configuration in each port and present different geometry or type of coupling in the next way: square patch with quarter-wave coupling (Antenna I), square patch with inset feed (Antenna II) and circular patch with quarter-wave coupling (Antenna III). The arrays were designed and simulated to operate on the millimetric wave band, specifically in the 60 GHz frequency to be used in wireless technologies such as IEEE 802.11 ad. A method of rapid prototyping was formulated to increase the number of elements in the array obtaining dimensions and coordinates of location in the layout in short periods of time. The simulation was conducted through ADS software, and the results of gain, directivity, return loss, bandwidth, beamwidth, and efficiency were evaluated. In terms of array results of 32 ports, Antenna III obtained the lowest return loss with −42.988 dB, being more than 19 dB lower than the others. The highest gain is also obtained by Antenna III with 24.541 dBi and an efficiency of 66%. Antenna II obtained better efficiency, reaching 71.03%, but with a gain of more than 2dB below the Antenna III. Antenna I obtained the best bandwidth. Full article

A modified monopole patch antenna for microwave-based hemorrhagic or ischemic stroke recognition is presented in this article. The designed antenna is fabricated on a cost-effective FR-4 lossy material with a 0.02 loss tangent and 4.4 dielectric constant. Its overall dimensions are 0.32 λ × 0.28 λ × 0.007 λ, where λ is the lower bandwidth 1.3 GHz frequency wavelength. An inset feeding approach is utilized to feed the antenna to reduce the input impedance (z = voltage/current). A total bandwidth (below −10 dB) of 2.4 GHz (1.3–3.7 GHz) is achieved with an effective peak gain of over 6 dBi and an efficiency of over 90%. A time-domain analysis confirms that the antenna produces minimal signal distortion. Simulated and experimental findings share a lot of similarities. Brain tissue is penetrated by the antenna to a satisfactory degree, while still exhibiting a safe specific absorption rate (SAR). The maximum SAR value measured for the head model is constrained to be equal to or below 0.1409 W/kg over the entire usable frequency band. Evaluation of theoretical and experimental evidence indicates the intended antenna is appropriate for Microwave Imaging (MWI) applications. Full article

In this work, the issue of limited bandwidth typical of microstrip antennas realized on a single thin substrate is addressed. A simple yet effective design approach is proposed based on the combination of traditional single-resonance patch geometries. Two novel shaped microstrip patch antenna elements with an inset feed are presented. Despite being printed on a single-layer substrate with reduced thickness, both radiators are characterized by a broadband behavior. The antennas are prototyped with a low-cost and fast manufacturing process, and measured results validate the simulations. State-of-the-art performance is obtained when compared to the existing literature, with measured fractional bandwidths of 3.71% and 6.12% around 10 GHz on a 0.508-mm-thick Teflon-based substrate. The small feeding line width could be an appealing feature whenever such radiating elements are to be used in array configurations. Full article

This study proposes an on-chip terahertz (THz) detector designed with on-chip inset-feed rectangular patch antenna and catadioptric lens. The detector incorporates a dual antenna and dual NMOSFET structure. Radiation efficiency of the antenna reached 89.4% with 6.89 dB gain by optimizing the antenna inset-feed and micro-strip line sizes. Simulated impedance was 85.55 − j19.81 Ω, and the impedance of the antenna with the ZEONEX horn-like catadioptric lens was 117.03 − j20.28 Ω. Maximum analyzed gain of two on-chip antennas with catadioptric lens was 17.14 dB resonating at 267 GHz. Maximum experimental gain of two on-chip patch antennas was 4.5 dB at 260 GHz, increasing to 10.67 dB at 250 GHz with the catadioptric lens. The proposed on-chip rectangular inset-feed patch antenna has a simple structure, compatible with CMOS processing and easily implemented. The horn-like catadioptric lens was integrated into the front end of the detector chip and hence is easily molded and manufactured, and it effectively reduced terahertz power absorption by the chip substrate. This greatly improved the detector responsivity and provided very high gain. Corresponding detector voltage responsivity with and without the lens was 95.67 kV/W with NEP = 12.8 pW/Hz^0.5 at 250 GHz, and 19.2 kV/W with NEP = 67.2 pW/Hz^0.5 at 260 GHz, respectively. Full article

In this paper, a compact microstrip feed inset patch sensor is proposed for measuring the salinities in seawater. The working principle of the proposed sensor depends on the fact that different salinities in liquid have different relative permittivities and cause different resonance frequencies. The proposed sensor can obtain better sensitivity to salinity changes than common sensors using conductivity change, since the relative permittivity change to salinity is 2.5 times more sensitive than the conductivity change. The patch and ground plane of the proposed sensor are fabricated by conductive copper spray coating on the masks made by 3D printer. The fabricated patch and the ground plane are bonded to a commercial silicon substrate and then attached to 5 mm-high chamber made by 3D printer so that it contains only 1 mL seawater. For easy fabrication and testing, the maximum resonance frequency was selected under 3 GHz and to cover salinities in real seawater, it was assumed that the salinity changes from 20 to 35 ppt. The sensor was designed by the finite element method-based ANSYS high-frequency structure simulator (HFSS), and it can detect the salinity with 0.01 ppt resolution. The designed sensor has a resonance frequency separation of 37.9 kHz and reflection coefficients under −20 dB at the resonant frequencies. The fabricated sensor showed better performance with average frequency separation of 48 kHz and maximum reflection coefficient of −35 dB. By comparing with the existing sensors, the proposed compact and low-cost sensor showed a better detection capability. Therefore, the proposed patch sensor can be utilized in radio frequency (RF) tunable sensors for salinity determination. Full article

A periodic leaky-wave antenna (LWA) design based on low loss substrate-integrated waveguide (SIW) technology with inset half-wave microstrip antennas is presented. The developed LWA operates in the V-band between 50 and 70 GHz and has been fabricated using standard printed circuit board (PCB) technology. The presented LWA is highly functional and very compact supporting 1D beam steering and multibeam operation with only a single radio frequency (RF) feeding port. Within the operational 50–70 GHz bandwidth, the LWA scans through broadside, providing over 40° H-plane beam steering. When operated within the 57–66 GHz band, the maximum steering angle is 18.2°. The maximum gain of the fabricated LWAs is 15.4 dBi with only a small gain variation of +/−1.5 dB across the operational bandwidth. The beam steering and multibeam capability of the fabricated LWA is further utilized to support mobile users in a 60 GHz hot-spot. For a single user, a maximum wireless on-off keying (OOK) data rate of 2.5 Gbit/s is demonstrated. Multibeam operation is achieved using the LWA in combination with multiple dense wavelength division multiplexing (WDM) channels and remote optical heterodyning. Experimentally, multibeam operation supporting three users within a 57–66 GHz hot-spot with a total wireless cell capacity of 3 Gbit/s is achieved. Full article
