Sabots are vital to the successful launch of hypervelocity projectiles (HVPs), supporting and protecting the projectile’s flight body within the barrel. After the projectile exits the muzzle, aerodynamic forces induce relative motion between the sabot and the flight body, termed ‘sabot discard’. During this process, there are complex aerodynamic interactions between the sabot and flight body. These interactions impact the flight body’s flight stability and accuracy. This research focuses on an HVP with a two-segment sabot at Mach 7.2, employing the unstructured overset grid method and three-degree-of-freedom model to investigate the impact of the angle of attack (AOA) on the discard. At the AOA = 0 Deg, the sabot segments’ movement is symmetric, causing fluctuations in the flight body’s drag. However, at AOAs $\ne$ 0 Deg, the sabot segments’ movement becomes asymmetric. The upper sabot segment accelerates while the lower one decelerates, causing significant fluctuations in drag and lift, and prolonged disturbance. As the AOA increases, both asymmetry and disturbances intensify. Notably, at the AOA = 8 Deg, the absolute value of the discard angle difference between the upper and lower sabot segments reaches 45 Deg. Considering the AOA’s impact, it is advisable to maintain the AOA for HVP sabot discard in the range of [−2, 2] Deg. Full article

A numerical method has been presented to simulate hypervelocity impacts on metal targets. The target is a rectangular prism and is positioned at various inclined angles relative to the impact direction, while four different projectiles such as square prism, triangular prism, truncated cone, and ogival shape are chosen. This numerical model employs an open-source code, MPM3D-F90, which is based on the Material Point Method. In order to enhance flexibility of the code for defining projectiles and target bodies in the material domain, a preprocessor is developed to create a variety of geometrical shapes for a given volume. In addition to supplementing and defining various geometrical bodies, this tool also simplifies the preprocessing process to create the user’s specific preferences for the problem. To demonstrate the utility of the preprocessor tool and investigate the influence of geometry on hypervelocity impacts, simulations are conducted using various projectile and target configurations. The analysis results reveal that the structure of the debris cloud formations, scattering behavior of the ejected particle from both front and rear faces, and penetration depth measures are significantly influenced by the projectile shape and impact angles. Full article

Oblique detonation waves (ODWs) are hypersonic combustion phenomena induced by oblique shock waves. When applied to air-breathing engines, ODWs offer high thermal cycle efficiency, adaptability to a wide range of flight Mach numbers, and the advantage of a short combustion chamber, making them highly promising for hypersonic propulsion applications. Despite numerous numerical studies on the heat release and multi-wave flow mechanisms of ODWs, practical applications of oblique detonation engines (ODEs) remain limited due to several technical challenges. These challenges include generating the required high-velocity test environments, achieving effective fuel and oxidant mixing, and measuring the flow field structure in hyper-velocity and high-temperature flows. These limitations hinder the development of ODEs, underscoring the importance of experimental research, particularly for understanding the initiation and propagation mechanisms of ODWs. One of the primary experimental techniques involves inducing oblique detonation using high-velocity models. This method is extensively used to study the initiation process, shock structure, initiation criteria, and ODW propagation. It is advantageous because the state of the experimental mixture is controllable, and the model state can be precisely measured. This paper reviews studies on oblique detonation induced by hyper-velocity projectiles, presenting advances in experimental methods, detonation wave structures, unsteady processes, and initiation characteristics. Additionally, we discuss the deficiencies in existing studies, noting that the current measurement methods fall short of the requirements for observing the ODW initiation process, propagation process, and fine structure. The application of advanced combustion diagnostic techniques and the exploration of the relationship between initiation processes and criteria are crucial for advancing our understanding of ODW initiation and stabilization mechanisms. Finally, we summarize the current state of experimental facilities and measurement techniques, providing suggestions for future research on the measurement of shock waves and chemical reaction zones. Full article

Collisions of space debris and micrometeorites with spacecraft represent an existential hazard for human activities in near-Earth orbits. Currently, guidelines, policies, and best practices are encouraged to help mitigate further propagation of this space debris field from redundant spacecraft and satellites. However, the existing space debris field is an environment that still poses a great threat and requires the design of contingency and fail-safe systems for new spacecraft. In this context, both the monitoring and tracking of space debris impact paths, along with knowledge of spacecraft design features that can withstand such impacts, are essential. Regarding the latter, terrestrial test facilities allow for replicating of space debris collisions in a safe and controlled laboratory environment. In particular, light-gas guns allow launching impactors at speeds in the high-velocity and hypervelocity ranges. The data acquired from these tests can be employed to validate in-orbit observations and structural simulations and to verify spacecraft components’ survivability. Typically, projectiles are launched and protected using a sabot system. This assembly, known as a launch package, is fired towards a sabot-stopping system. The sabot separates from the rest of the launch package, to avoid target contamination, and allows the projectile to travel towards the target through an opening in the assembly. The response and survivability of the sabot-stopping system, along with the transmission of the forces to the light-gas gun structure and prevention of target contamination, is an important design feature of these test apparatuses. In the framework of the development of Malta’s first high-velocity impact facility, particular attention was dedicated to this topic: in this paper, the description of a novel sabot-stopping system is provided. The system described in this research is mechanically decoupled from the interaction with the impact chamber and the light-gas gun pump tube; this solution avoids damage in case of failures and allows easier operations during the pre- and post-test phases. Full article

In this work, the mechanical behavior and energy absorption characteristics of flexible fabric under hypervelocity impact (HVI) were investigated. Basalt fabric, ultra-high molecular weight polyethylene (UHMWPE) fabric, and aluminum alloy (Al) plate were chosen to be the sample materials for their excellent mechanical properties and applicative prospect in spacecraft shielding. HVI experiments had been conducted with the help of a two-stage light-gas gun facility, wherein Al projectile with 3.97 mm diameter was launched at velocities in the range 4.1~4.3 km/s. Impact conditions and areal density were kept constant for all targets. The microstructural damage morphology of fiber post-impact was characterized using a scanning electron microscope (SEM). Analysis results show that a brittle fracture occurred for Basalt fiber during HVI. On the contrary, the ductile fractures with large-scale plastic deformation and apparent thermal softening/melting of the material had happened on the UHMWPE fiber when subjected to a projectile impact. According to the HVI shielding performance and microstructural damage analysis results, it can be inferred that ductile fractures and thermal softening/melting of the material were the prevailing energy absorption behaviors of UHMWPE fabric, which leads to absorbing more impact energy than Basalt fabric and eventually, contributes the superior shielding performance. Full article

The hypervelocity impact of space debris causes damage or destruction to spacecraft. The continuous damage caused by space debris creates greater requirements for protective materials. Wave-impedance gradient-protection material is a new type of space-debris-protection material with high kinetic-energy dissipation. However, the relationship between the distribution characteristics of the impedance layer and the protective performance is still unclear. This study provides guidance for the design of high-performance wave-impedance gradient materials by establishing the quantitative relationship between impedance-layer distribution characteristics and protective performance. Based on the one-dimensional shock-wave theory, this paper analyzes the propagation process of shock waves in wave-impedance gradient materials, establishes a transmission model of shock waves with changes in impedance layers, and quantitatively studies the influence of the change in wave impedance on the impact pressure, internal-energy conversion, and projectile- breaking characteristics by means of a numerical simulation. The results show that, when the surface and back of the wave-impedance gradient material are titanium alloy and nylon, respectively, the total transmission coefficient increases from 0.206 to a maximum of 0.339 with the continuous change in the gradient. The reduction amplitude of the shock wave with time under the three working conditions is Ti-Al-Mg-Ny > Ti-Al-Ny > Ti-Ny. The relationship of the transformed internal energy is Ti Al-Mg-Ny > Ti-Al-Ny > Ti-Ny, and the projectile breaking area is Ti-Al-Mg-Ny > Ti-Al-Ny > Ti-Ny. The analysis shows that the continuous change in wave impedance is beneficial to reduce the attenuation of the amplitude of the shock wave in the hypervelocity projectile, to keep the stress amplitude of the shock wave at a higher level, and to improve the internal-energy conversion and impact-breaking degree of the projectile, thereby enhancing the protection performance of the wave-impedance gradient material. Full article

The passive shielding of space craft structures is critical due to the increase in demand for lightweight protection, which is required to counter the damaging effects of micro-meteoroid orbital debris (MMOD) on unmanned spacecraft, which have steeply increased in recent years. Research on hypervelocity impact (HVI) led to the development of shield configurations such as the conventional Whipple shield, which consists of two plates separated by a stand-off distance to allow for the fragmentation and dispersion of the debris from the impact. Variations in the Whipple shield have been proposed, where additional layers are included for increased energy dissipation efficiency. In this work, the authors develop, validate and test a numerical model of an orthogonally loaded hybrid Whipple shield, incorporating an aluminium honeycomb core, orientated with hexagonal tubes perpendicular to the direction of proposed debris travel, to mitigate the well-known channelling effect. The debris threat is an A2024-T3 projectile, impacting the structure at a velocity of 6.5 km/s. The proposed model is validated with experimental observations of the debris spread at half-angle and the efficiency of the proposed topology is assessed against a conventional two-plate A2024-T3 shield. The honeycomb core cell density, its position relative to the point of impact, the thickness of the honeycomb shell, and the material of the honeycomb are thoroughly analysed. A hybrid honeycomb structure concept is proposed, which provides a highly efficient alternative to a standard Whipple shield design, without significantly compromising the weight of the structure. The obtained results clearly show that the hybrid Whipple shield exhibits significantly increased the kinetic energy dissipation of the debris from the impactor and shield front plate, with an increase in the dissipated kinetic energy that can reach $86.8\%$ relative to the conventional shield. Full article

Hyper-velocity impact (HVI) caused by a collision between orbital debris and spacecraft exists widely in outer space, and it poses a threat to spacecraft. This paper proposes a probabilistic hyperbola method based on Lamb waves analysis to detect and locate the impact in stiffened aluminum (Al) plates. A hybrid model using finite element analysis (FEA) and smoothed particle hydrodynamics (SPH) was developed to gain an insight into characteristics of HVI-induced acoustic emission (AE) and shock wave propagation. In addition, an experimental validation was carried out with a two-stage light gas gun, giving an aluminum projectile a velocity of several kilometers per second. Then a quantitative agreement is obtained between numerical and experimental results, demonstrating the correctness of the hybrid model and facilitating the explanation of received AE signals in experiments. Signal analysis shows that the shock wave quickly converts to a Lamb wave as it propagates from the HVI spot, and the zeroth-order symmetric wave mode (S0) dominates wave signal energy. The S0 wave is dispersive and shows a wide frequency range, with dominant magnitudes below 500 kHz. Finally, the HVI experiment results obtained with a light gas gun showed that the average location error could be less than 1 cm with only four sensors for a 1-square-meter stiffened metal plate. Full article

Impact delivery of prebiotic compounds to the early Earth from an impacting comet is considered to be one of the possible ways by which prebiotic molecules arrived on the Earth. Given the ubiquity of impact features observed on all planetary bodies, bolide impacts may be a common source of organics on other planetary bodies both in our own and other solar systems. Biomolecules such as amino acids have been detected on comets and are known to be synthesized due to impact-induced shock processing. Here we report the results of a set of hypervelocity impact experiments where we shocked icy mixtures of amino acids mimicking the icy surface of planetary bodies with high-speed projectiles using a two-stage light gas gun and analyzed the ejecta material after impact. Electron microscopic observations of the ejecta have shown the presence of macroscale structures with long polypeptide chains revealed from LCMS analysis. These results suggest a pathway in which impact on cometary ices containing building blocks of life can lead to the synthesis of material architectures that could have played a role in the emergence of life on the Earth and which may be applied to other planetary bodies as well. Full article

This paper aims to study the difference of results in breakup state judgment, debris cloud and fragment characteristic parameter during hypervelocity impact (HVI) on large-scale complex spacecraft structures by various numerical simulation methods. We compared the results of the test of aluminum projectile impact on an aluminum plate with the simulation results of the smooth particle hydrodynamics (SPH), finite element method (FEM)-smoothed particle Galerkin (SPG) fixed coupling method, node separation method, and finite element method-smooth particle hydrodynamics adaptive coupling method under varying mesh/particle sizes. Then based on the test of the complex simulated satellite under hypervelocity impact of space debris, the most applicable algorithm was selected and used to verify the accuracy of the calculation results. It was found that the finite element method-smooth particle hydrodynamics adaptive coupling method has lower mesh sensitivity in displaying the contour of the debris cloud and calculating its characteristic parameters, making it more suitable for the full-scale numerical simulation of hypervelocity impact. Moreover, this algorithm can simulate the macro breakup state of the full-scale model with complex structure and output debris fragments with clear boundaries and accurate shapes. This study provides numerical simulation method options for the follow-up research on breakup conditions, damage effects, debris clouds, and fragment characteristics of large-scale complex spacecraft. Full article

Impact cratering experiments were performed on semi-infinite concrete targets with 7 mm-diameter 40CrNiMo steel long-rod projectiles at impact velocities ranging from 2117 m/s to 3086 m/s by using a two-stage combustion light-gas gun. After the impact experiments, the crater diameter and depth as well as the crater volume were carefully measured. The concrete fragments were collected from the target chamber and the fragment mass was measured. The size of the crater (including the volume, diameter, and depth) and the fragment mass increased with increasing impact velocities, while the fragment distributions at different impact velocities were almost the same. Scaling laws for the crater volume impacted by the rod-shaped projectile were discussed and an empirical formula of crater volume was determined by the experimental data from the literature. Through the verification of the present experimental results, the predictive ability of the empirical formula proved to be reliable. Scaling laws for the size distribution of concrete fragments were also discussed. The normalized fragment mass distribution was proportional to the impact velocity raised to the power 1.5. Full article

An improved shielding structure of a bumper that constructed from Ti/Al/Mg density-graded materials was presented. Two types of Ti/Al/Mg density-graded materials with the same areal density were prepared by diffusion bonding and powder metallurgy, respectively. The characteristics of hypervelocity impact including penetration holes in the bumper, damage patterns on the rear wall and micrographs of the crater were investigated. The results show that damage mechanism of Ti/Al/Mg density-graded materials is closely related to the interface bonding strength and matrix strength. The penetration holes of Ti/Al/Mg density-graded material obtained by diffusion bonding exhibit typical ductile characteristics. The Ti/Al/Mg density-graded material prepared by powder metallurgy shows significant mechanical synergistic response under high strain compression and appears fragile characteristic. The shielding performance of Ti/Al/Mg bumper is increased by 20.4% compared with aluminum bumper. A theoretical analysis suggests that a Ti-Al-Mg bumper can fully break the projectile and greatly increase the entropy during the impact process. Larger projectile kinetic energy is converted into the internal energy during the impact process, thereby causing an obvious increase in shielding performance. Full article

To understand and analyze crater damage of rocks under hypervelocity impact, the hypervelocity impact cratering of 15 shots of hemispherical-nosed cylindrical projectiles into granite targets was studied within the impact velocity range of 1.91–3.99 km/s. The mass of each projectile was 40 g, and the length–diameter ratio was 2. Three types of metal material were adopted for the projectiles, including titanium alloy with a density of 4.44 g/cm³, steel alloy with a density of 7.81 g/cm³, and tungsten alloy with a density of 17.78 g/cm³. The projectile–target density ratio (ρ_p/ρ_t) ranged from 1.71 to 6.86. The depth–diameter ratios (H/D) of the craters yielded from the experiments were between 0.14 and 0.24. The effects of ρ_p/ρ_t and the impact velocity on the morphologies of the crater were evaluated. According to the experimental results, H/D of craters is negatively correlated with the impact velocity, whereas the correlation between H/D and ρ_p/ρ_t is weak positive. The crater parameters were expressed as power law relations of impact parameters by using scaling law analysis. The multiple regression analysis was utilized to obtain the coefficients and the exponents of the relation equations. The predicted values of the regression equations were close to the experimental results. Full article

Hypervelocity impact (HVI), ubiquitous in low Earth orbit with an impacting velocity in excess of 1 km/s, poses an immense threat to the safety of orbiting spacecraft. Upon penetration of the outer shielding layer of a typical two-layer shielding system, the shattered projectile, together with the jetted materials of the outer shielding material, subsequently impinge the inner shielding layer, to which pitting damage is introduced. The pitting damage includes numerous craters and cracks disorderedly scattered over a wide region. Targeting the quantitative evaluation of this sort of damage (multitudinous damage within a singular inspection region), a characterization strategy, associating linear with nonlinear features of guided ultrasonic waves, is developed. Linear-wise, changes in the signal features in the time domain (e.g., time-of-flight and energy dissipation) are extracted, for detecting gross damage whose characteristic dimensions are comparable to the wavelength of the probing wave; nonlinear-wise, changes in the signal features in the frequency domain (e.g., second harmonic generation), which are proven to be more sensitive than their linear counterparts to small-scale damage, are explored to characterize HVI-induced pitting damage scattered in the inner layer. A numerical simulation, supplemented with experimental validation, quantitatively reveals the accumulation of nonlinearity of the guided waves when the waves traverse the pitting damage, based on which linear and nonlinear damage indices are proposed. A path-based rapid imaging algorithm, in conjunction with the use of the developed linear and nonlinear indices, is developed, whereby the HVI-induced pitting damage is characterized in images in terms of the probability of occurrence. Full article
