Search Results (48)

The use of vacuum-hybrid DC circuit breaking methods allows the short-circuit current to be switched off in a shorter time, resulting in a reduction in the arc burning time. This requires the use of a drive, such as the Thomson Coil Actuator TCA, capable of providing a short response time for opening the vacuum interrupter VI, regardless of its rated current. The IDD is powered by a pre-charged capacitor, which, together with the drive coil, forms an LC oscillating circuit that, when switched on by a thyristor, generates a current pulse of several kA with a frequency above 1 kHz. The paper investigates the effect of modifying the basic IDD power supply circuit by adding semiconductor diodes to shape the current pulse and improve its performance. The authors also focused on exploring the impact of the connection quality and their length and the associated loss in drive force while proving that a circuit with a reverse diode on the IDD coil is most beneficial and that the effect of the circuit on the front of the current pulse can significantly slow down the drive. Full article

In order to solve the problem of the slow initial speed caused by the large mass of the bistable permanent magnetic actuator (PMA) in the traditional bistable permanent magnetic–electromagnetic repulsion mechanism (PM-ERM), a novel fast contact operating mechanism is proposed by using the flexible spring system (SS) between the PMA and the ERM. The novel structure can separate the mass of the PMA and the ERM at the initial phase of the interrupting process, improve the initial speed of the contact and increase the initial opening distance of the contact. Firstly, the paper conducts an extensive investigation and analysis of the principle of the existing fast operating mechanism and points out the advantages and disadvantages of the existing mechanism. In order to meet the requirement of fast interrupting and improve the service life of the mechanism, a novel mechanism is proposed. And then, the working principle of the novel mechanism is introduced. The cooperative relationship between the ERM and the PMA and the working principle and performance parameter requirements of the ERM, SS and PMA are analyzed and designed. Finally, the feasibility of the novel mechanism is verified by the experiment. The results show that the opening distance of the novel operating mechanism can reach 2.25 mm in 1 ms. Compared with 1.24 mm of the traditional operating mechanism, it improves the initial opening distance of the contact by 81.5% and is conducive to the rapid interruption of the Hybrid DC current-limiting circuit breaker (HDCCLCB). Full article

Hybrid DC circuit breakers combine mechanical switches with a redirecting current path, typically controlled by power electronic devices, to prevent arcing during switch contact separation. The authors’ past work includes a bipolar hybrid DC circuit breaker that effectively redirects the fault current and returns it to the source. This reduces arcing between the mechanical breaker’s contacts and prevents large voltage overshoots across them. However, the breaker’s performance declines as the upstream line inductance increases, causing overvoltage. This work introduces a modification to the originally proposed hybrid DC breaker to make it suitable to use anywhere along DC grid lines. By using a switch-controlled surge arrester in parallel with the DC breaker, part of the arc energy is dissipated in the surge arrester, preventing an overvoltage across the mechanical switches. Based on the experimental results, the proposed method can effectively interrupt the fault current with minimal arcing and reduce the voltage stress across the mechanical switches. To address practical fault currents, tests at high fault currents (900 A) and voltage levels (500 V) are conducted and compared with simulation models and analytical studies. Furthermore, the application of the breaker for the protection of DC distribution grids is illustrated through simulations, and the procedure for designing the breaker components is explained. Full article

DC circuit breakers (DCCBs) are the key equipment to rapidly interrupt the fault current in high-voltage DC power grids and ensure the safe operation of the system. However, most DCCBs do not take current-limiting measures and rely solely on current-limiting reactors in the system to limit the rate of current rise during the interruption process. The extensive use of fully controlled power electronic devices in circuit breakers (CBs) results in high costs. To address the issues above, this paper proposes a DCCB topology with a current-limiting function based on thyristors and diodes, which can reduce the cost of CB while ensuring reliable interruption. The impact of various parameters on CB performance is analyzed using numerical calculations to optimize the parameters. Then, a simulation model of a 500 kV/16 kA DCCB is built in PSCAD/EMTDC, and the performance of the proposed CB topology is compared with the other CB topologies. By comparison, the proposed DCCB topology can reliably isolate fault currents and reduce the amplitude of fault currents and the cost of CBs. Significantly, the energy absorbed by the metal oxide varistor (MOV) during the interruption process decreases by 64.2%, reducing the cost and volume of the MOV. Finally, the feasibility of the CB is further verified in the ±500 kV 4-terminal high-voltage DC power grid simulation model. The results show that the proposed DCCB topology can limit the fault current rise rate, interrupt and isolate the fault reliably, and reduce the cost. Full article

The interline power flow controller (IPFC) based on a modular multilevel converter with a half-bridge configuration can control the active and reactive power flows of multiple alternating current (AC) lines. However, it forms a multiterminal system on the direct current (DC) side, which leads to DC faults. To reduce the protection and clearance requirements on the DC side of IPFCs, this paper proposes a hybrid current limiter topology suitable for generating a DC-side fault ride-through scheme. The current limiter employs a low-loss branch in steady-state conditions; when the fault occurs, a commutation capacitor and controllable power electronic devices are used to transfer the fault current to the current-limiting branch. To clarify the operating principles of the current limiter, the working states of each stage and electrical stress of each device are analyzed. Different components with varying limiter parameters are also discussed, and optimal parameters to achieve the best limitation effect are discussed. PSCAD simulations show that the proposed limiter can limit the overcurrent effectively, and DC-side fault clearance can be achieved easily with this fault ride-through strategy. Full article

Hybrid circuit breakers are the most promising circuit breakers among DC circuit breakers. Conventional hybrid circuit breakers complete fault current isolation by converting current to IGBT when fault current occurs. However, in this case, the fault current continues to increase, so the IGBT must be large enough to withstand this current. In addition, in the case of a method of detecting and operating a fault, a delay time of up to hundreds of microseconds occurs, and in a hybrid circuit breaker, this delay time is a very large value. To solve this problem, this paper proposes a hybrid Z-source circuit breaker that operates without delay for low-impedance faults. The proposed breaker is designed to reduce stress on IGBTs and mechanical switches by generating a current zero crossing, as well as to enable the breaker to trip quickly in high-risk cases such as low-impedance fault circuits. Due to the limited environment of the laboratory, we performed 600 V fault isolation experiments. As a result of the experiment, it was confirmed that the proposed circuit breaker successfully isolated the fault within 1.6 ms. The current limiting feature of the Z-source appears to reduce stress on the IGBTs and MOVs used, and it allows for faster fault isolation. Full article

In instances where vessels encounter impacts or other factors leading to communication impairments, the status of electrical equipment becomes inaccessible through standard communication lines for the controllers. Consequently, the shipboard power system enters the partial observable state. Failure to timely ascertain and respond to the current state of the shipboard power system with appropriate restorative controls can result in irreversible damages to the electrical infrastructure and potentially precipitate a complete systemic failure. In this paper, an innovative fault-tolerant control and state estimation approach is proposed to address the partial observability problem of shipboard power systems, based on distributed control architecture and hybrid automata modeling, where controllers are unable to fully acquire equipment status due to device failures like sensor malfunctions. This approach infers the overall state of subsystems using data from intact equipment and discrete events from circuit breakers. Through fault-tolerant control techniques, it ensures that the subsystem state avoids invalid regions, effectively preventing the system from entering unhealthy operational states and significantly reducing the risk of performance degradation or systemic collapse due to faults. Simulation results confirm that this approach can quickly and accurately estimate the system’s current state under partial observation, enabling subsequent fault recovery strategies to accurately pinpoint fault locations and identify optimal recovery solutions. Full article

Aimed at the optimization design of the parameters of the commutation circuit of a hybrid DC-current-limiting circuit breaker (HDCCLCB), a parameter selection model considering the short-time withstand of the thyristor and the volume of the commutation circuit is proposed by simplifying the object, and the commutation circuit parameters were preliminarily obtained. In order to verify the correctness of the method of selecting the commutation circuit parameters, the circuit simulation model of the HDCCLCB was built. The experimental platform was built, and the breaking experiment was completed under the fault condition with the current rising rate of 20 A/μs. The correctness of the simulation model and parameter design method was verified by comparing the circuit model simulation results with the experimental results. In order to further optimize the parameters of the commutation circuit, a mathematical model for optimization design was established. Taking the maximum critical breakdown voltage under unit capacitance energy as the objective function, the arcing time before commutating and the current-limiting inductance and capacitance are enumerated to obtain the optimized commutation circuit parameters. By comparing this result with the result of the preliminary design, the objective function is improved by 20.7%, laying a solid foundation for further research and the development of current-limiting circuit breakers for medium-voltage DC systems. Full article

The state of the energy-absorption branch MOV in the hybrid DC circuit breaker (DCCB) has a very important impact on the short fault breaking operation of the circuit breaker. Therefore, it is necessary to evaluate the state of the MOV, which is also called the “sleep component”. Due to DCCB being placed indoors, the aging is mainly caused by short-circuit impulse current. Therefore, this paper mainly focuses on the study of the short-circuit impulse aging characteristics of the energy-absorption branch MOV. The dynamic simulation system of a hybrid DCCB was built to investigate the impulse of short-circuit current on the MOV of the energy-absorption branch during the circuit breaking process. Then, an accelerated impulse aging test platform was built and the accelerated impulse aging tests of the MOV were conducted. The aging characteristics of the MOV were analyzed in detail and detailed analysis was conducted of the macroscopic parameters and microstructure changes. The results indicate that the nonlinear coefficient α could be emphasized as a basis for judging the “sleeping” component states and aging degree of the hybrid DC circuit breaker, and can be expected to be applicable to MOV condition monitoring of BCCB in the future. Full article

While traditional AC mechanical circuit breakers can protect AC circuits, many other DC power distribution technologies, such as DC microgrids (MGs), yield superior disruption performance, e.g., faster and more reliable switching speeds. However, novel DC circuit breaker (DCCB) designs are challenging due to the need to quickly break high currents within milliseconds, caused by the high fault current rise in DC grids compared to AC grids. In DC grids, the circuit breaker must not provide any current crossing and must absorb surges, since the arc is not naturally extinguished by the system. Additionally, the DC breaker must mitigate the magnetic energy stored in the system inductance and withstand residual overvoltages after current interruption. These challenges require a fundamentally different topology for DCCBs, which are typically made using solid-state semiconductor technology, metal oxide varistors (MOVs), and ultra-fast switches. This study aims to provide a comprehensive review of the development, design, and performance of DCCBs and an analysis of internal topology, the energy absorption path, and subcircuits in solid-state (SS)-based DCCBs. The research explores various novel designs that introduce different structures for an energy dissipation solution. The classification of these designs is based on the fundamental principles of surge mitigation and a detailed analysis of the techniques employed in DCCBs. In addition, our framework offers an advantageous reference point for the future evolution of SS circuit breakers in numerous developing power delivery systems. Full article

IGBT power modules are usually used as circuit-breaking components in power systems, and are widely used in solid-state DC circuit breakers, hybrid DC circuit breakers, all-electric aircraft, high-speed railways, new energy vehicles, and power transmission systems. In these systems, IGBT power modules are usually faced with extremely harsh working conditions and there is a failure risk. Insulation degradation should be a cause for concern as a potential path of power module failure. In this paper, the discharge phenomena of the IGBT power module were observed based on Intensified Charge Coupled Devices (ICCD), and the triple junctions composed of copper–ceramic–silicone gel inside IGBT were found as the discharge points. Furthermore, the directed bonded copper (DBC) ceramic filled with silicone gel was used as a test sample to study the discharge failure process, including the partial discharge (PD), surface charges, and electric trees. The mechanism of discharge failure is discussed and analyzed. The insulation degradation process is accompanied by phenomena such as severe partial discharge and rapid electric tree growth. This research provides support for the analysis idea and guidance of the research method for the cause of power module failure. Full article

To solve the problem of the high rising rate and large peak value of the expected current of the short-circuit current in marine DC power system faults, a hybrid DC current limiting circuit breaker scheme based on a high-speed electromagnetic repulsion mechanism is proposed. A parameter selection model is constructed by comprehensively considering the short-time withstand of the thyristor, the volume of the commutation circuit, and capacitor energy, and the optimal value of the commutation circuit parameters at a certain voltage level is obtained. The finite element mathematical model of the high-speed electromagnetic repulsion mechanism is established by coupling the electromagnetic force field, which enables the deformation process of the mechanism under the condition of high acceleration to be considered. The von Mises yield criterion is adopted as the mechanical boundary condition in the design of a high-speed electromagnetic repulsion mechanism, which solves the problem of the long inherent time of opening. The experiment platform is built, and the experiment under the fault condition with a current rising rate of 20 A/μs is completed. The arcing time, commutation time, zero-voltage recovery time, and contact movement characteristics are obtained, which meet the design requirements, verify the effectiveness of the analysis, and lay a solid foundation for further research and development of the current limiting circuit breakers for medium voltage DC systems. Full article

As the utilization of DC systems increases worldwide, the importance of DC cutoff technology is increasing. We proposed a hybrid DC cutoff technology combining an SFCL (superconducting fault-current-limiter) and a mechanical DC circuit breaker. This model can perform a fault-current-limiting operation through the quenching of the SFCL and a breaking operation through an artificial cutoff zero point of a mechanical DC circuit breaker. In particular, the SFCL is responsible for the growth of the initial fault current according to the DC characteristics. As the DC system’s supply and demand increase, the DC system’s capacity also increases. Therefore, the fault-current-limiting capability of the SFCL should be increased according to the increasing DC system breaking capacity. The fault-current-limiting capability can be increased by increasing the superconducting wires used in the SFCL. Current commercially available SFCLs use bifilar-helical-type and bifilar-spiral-type winding methods. These have the disadvantage of increased volume with increased capacity. To compensate for these disadvantages, we proposed a bifilar-meander-type winding method. In this paper, a new bifilar-meander-type winding method was introduced. In addition, the structural and electromagnetic parts of the existing winding method and the bifilar-meander-type winding method were compared and analyzed for differences. The program used for this analysis is the electromagnetic analysis Maxwell program. As a result, it was confirmed that the bifilar-meander-type winding method is superior to the conventional bifilar-helical and bifilar-spiral types. Full article

Energy routers act as an interface between the distribution network and electrical facilities, which meet the requirements of clean energy substitution and achieve the energy sharing and information transmission in the energy network. However, the protection of the dc load side of residential energy routers including interruption and isolation of short-circuit fault currents is vital for discussion. Since the traditional mechanical and hybrid circuit breakers for dc fault protection have the drawback of slow operation, a solid-state circuit breaker (SSCB) is an optimal solution for fast dc fault interruption. In this paper, a dc SSCB is proposed that uses an RCD + MOV snubber circuit, which is considered the best and most complete circuit used in common SSCBs. There are two main contributions in this paper: First, a dc SSCB is designed, which isolates both positive and negative terminals of a circuit and its working principle and operating modes along with the formulas for calculation of crucial time intervals, voltages, and currents along with the design procedure are provided. Second, a soft turn-on auxiliary is designed to prevent a high current surge caused by the capacitance difference between the source and the load. The experimental results demonstrate the proper performance of the topology and the validity of the findings. Full article

This article is a study of the research development of electrodynamic phenomena occurring in ultra-fast electrodynamic drives. These types of linear drives are among the fastest, not only because of the huge accelerations achieved, but, above all, because of the extremely short reaction time. For this reason, electrodynamic drives are used in hybrid short-circuit breakers. The phenomena occurring in this type of drive are actually magneto-thermo-elastic in nature, but the coupling of these phenomena should be considered weak if the criteria for repeatable operation in a hybrid circuit breaker system are met. The authors have been researching this type of drive for many years through not only experimental studies, but also primarily simulation studies developing models of such drives. The authors present the history of the development starting from the first works of Thomson, and Kesserling and ending with the most current models, including mainly their own. This article presents mainly works studying electrodynamic phenomena. Thermal and mechanical phenomena were comprehensively presented by the authors in previous papers. Full article
